Power Button
Pressing the power button will turn the headphones
ON/OFF.
NOTE:
² The headphones will turn off automatically and the
red LED will illuminate for approximately 2 minutes
when the radio or rear audio/video system is turned
off.
² The rear audio/video system must be turned ON
before sound can be heard from the headphones.
Volume Control
Rotate the volume control upward to increase the vol-
ume. Scan Button
Pressing the scan button will automatically find the
audio signal that is transmitted from the CD/DVD
changer when the rear audio/video system and the
headphones are on. This button is used only if the
headphones are locked on to a source other than the
vehicle's radio.
NOTE: When the ªGREEN LEDº is showing the head-
phones are receiving the audio signal. When the ªRED
LEDº is showing the headphones are searching for the
audio signal UNDERSTANDING YOUR INSTRUMENT PANEL 193
4

² The trailer tongue load must be considered as part of
the combined weight of occupants and cargo, and
should never exceed the weight referenced on the Tire
and Loading Information placard. Refer to the Tire±
Safety Information Section in this manual.
² The ªDº range can be selected when towing. However,
if frequent shifting occurs while in this range, the ª3º
range must be selected.
NOTE: Using the ª3º range while operating the vehicle
under heavy operating conditions will improve perfor-
mance and extend transaxle life by reducing excessive
shifting and heat build up.
WARNING!Connecting trailer brakes to your vehicle's hydraulic
brake lines can overload your brake system and
cause it to fail. You might not have brakes when you
need them and could have an accident. ² Do not attempt to tow a trailer while using a compact
spare tire.
² Whenever you pull a trailer, regardless of the trailer
size, stop lights and turn signals on the trailer are
recommended for motoring safety.
² The automatic transaxle fluid and filter should be
changed if you REGULARLY tow a trailer for more
than 45 minutes of continuous operation. See Schedule
ªBº in section 8 of this manual for transaxle fluid
change intervals.
NOTE: Check the automatic transaxle fluid level before
towing. Fluid discoloration, or a burnt odor, shows the
need for a transmission fluid and filter change.276 STARTING AND OPERATING

HAZARD WARNING FLASHER
The hazard flasher switch is located in the center of the
instrument panel above the radio.
To engage the Hazard Warning Flashers, depress the
switch on the instrument panel. When the Hazard Warn-
ing Switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emer-
gency. Push the switch a second time to turn off the
flashers.
This is an emergency warning system and should not be
used when the vehicle is in motion. Use it when your
vehicle is disabled and is creating a safety hazard for
other motorists.
When you must leave the vehicle to seek assistance, the
Hazard Warning Flashers will continue to operate even
though the ignition switch is OFF.
NOTE: With extended use, the Hazard Warning Flash-
ers may wear down your battery.280 WHAT TO DO IN EMERGENCIES

N Front Park/Turn Signal And Sidemarker
Lights .............................340
N Front Fog Light ......................341
N Rear Tail, Stop, Turn Signal, Side Marker
And Back-Up Lights ...................342
N Center High Mounted Stop Light (CHMSL) . . . 343
N License Light ........................343 m Fluid Capacities ........................343
m Recommended Fluids, Lubricants And Genuine
Parts ................................344
N Engine .............................344
N Chassis ............................345 MAINTAINING YOUR VEHICLE 297
7

REPLACEMENT LIGHT BULBS
LIGHT BULBS Ð Interior Bulb Number
Center & Rear Dome Light .................. 578
Center & Rear Reading Lights ............... 578
Front Door Courtesy Light .................. 578
Front Header Reading Lights (If Equipped) ...... 578
Instrument Cluster Lights ................. PC74
Liftgate Light(s) .......................... 578
Overhead Console Reading Lights .......... PC579
Removable Console Light (If Equipped) ......... 194
Visor Vanity Lights .................... 6501966
NOTE: For lighted switches, see your dealer for replace-
ment instructions.
All of the interior bulbs are glass wedge base or glass
cartridge types. Aluminum base bulbs are not approved
and should not be used for replacement. LIGHT BULBS Ð Exterior Bulb Number
Back-up, Tail, Stop, Turn Signal, & Sidemarker . . . 3057
Center High-Mounted Stop Light ............. 921
Fog Light ............................. 9040
Front Side marker, Park/Turn Signal ......... 3157A
Headlight ............................. 9007
License ................................ 168338 MAINTAINING YOUR VEHICLE

CAUTION!Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol. Front Park/Turn Signal and Sidemarker Lights
1. Remove the three screws securing the headlight mod-
ule.
2. Twist the turn signal socket to remove from the
headlight module and pull bulb from socket.340 MAINTAINING YOUR VEHICLE

Rear Tail, Stop, Turn Signal, Side Marker and
Back-up Lights
1. Raise the liftgate.
2. Remove the two light assembly push-in type fasteners.
3. Squeeze the socket assembly tabs to remove it from the
housing. 4. Pull the bulb to remove it from the socket.
5. Replace the bulb, reinstall the socket, and reattach the
light assembly.342 MAINTAINING YOUR VEHICLE

Air Cleaner Filter ...................... 308
Block Heater ......................... 230
Break-In Recommendations ................ 70
Checking Oil Level ..................... 303
Compartment ...................... 298,299
Coolant ............................. 344
Cooling ............................. 318
Exhaust Gas Caution .................. 36,269
Fails to Start ....................... 227,229
Fuel Requirements ..................... 266
Oil .............................. 303,344
Oil Change Interval .................... 305
Oil Selection .......................... 305
Oil Synthetic ......................... 307
Overheating .......................... 281
Temperature Gauge ..................... 154
Exhaust Gas Caution .............. 36,71,269,317
Exhaust System ......................... 317
Exterior Folding Mirrors ................... 78 Filters
Air Cleaner .......................... 308
Air Conditioning .................... 219,313
Automatic Transaxle .................... 328
Engine Fuel .......................... 309
Engine Oil ........................ 307,344
Engine Oil Disposal .................... 307
Flashers
Hazard Warning ....................... 280
Turn Signal .................. 158,159,340,342
Fluid Capacities ......................... 343
Fluid Leaks ............................. 72
Fluid Level Checks
Automatic Transaxle .................... 327
Brake ............................... 345
Power Steering ..................... 314,345
Fog Light Service ........................ 341
Fog Lights .......................... 102,341
Freeing A Stuck Vehicle ................... 291386 INDEX
