2004 DODGE GRAND CARAVAN Owners Manual

N Program Button 4 (Random Play) ..........169
N Mode ..............................169
N Tape CD Button ......................169
N Time Button .........................170
N Scan Button .........................170
N CD Changer Control Capability Ð If
Equipped ...........................170
m Sales Code RBQÐAM/FM Stereo Radio With
6 - Disc CD Changer ....................171
N Radio Operation ......................171
N CD Player Operation ...................174
m Sales Code RBKÐAM/ FM Stereo Radio With
CD Player And CD Changer Controls ........178
N Radio Operation ......................178 N CD Player Operation ...................180
N CD Changer Control Capability Ð If
Equipped ...........................182
N Radio Display Messages ................184
m 6 Disc CD Changer Ð If Equipped ..........184
N Loading The CD Changer ...............185
N Playing Discs ........................185
N Seek Button .........................185
N FF/Tune/RW ........................185
N Mode Button ........................186
N Program Button 1 .....................186
N Program Button 4 (Random Play) ..........186
N Program Button 5 .....................186 UNDERSTANDING YOUR INSTRUMENT PANEL 145
4

N Time Button .........................186
N Changing Modes ......................186
N Removing Discs From The CD Changer .....187
N CD Changer Operation With The Changer
Off ...............................187
m 6 Disc CD/Digital Video Disc (DVD)
Changer Ð If Equipped ..................187
N Operating Instructions Ð CD/DVD Changer . . 188
N Eject (EJT) Button .....................189
N Operating Instructions Ð Remote Control ....189
N Operating Instructions Ð Video Screen ......191
N Operating Instructions Ð Headphones ......192
N Operating Instructions Ð MP3 Player .......194 N Operating Instructions Ð Video
Games/Camcorders ...................195
m Remote Sound System Controls Ð If Equipped . . 195
N Radio Operation ......................196
N Tape Player .........................196
N CD Player ..........................197
m Cassette Tape And Player Maintenance .......197
m CD/DVD Disc Maintenance ...............198
m Radio Operation And Cellular Phones ........198
m Climate Controls .......................199
N Manual Air Conditioning And Heating
System .............................199
N Front Mode Control ...................200146 UNDERSTANDING YOUR INSTRUMENT PANEL

N Manual Air Conditioning Operation ........203
N Manual Rear Zone Climate Control Ð If
Equipped ...........................206
N Infrared Three-Zone Automatic Temperature
Control Ð If Equipped .................208
m Rear Window Features ...................219
N Intermittent Rear Wiper Operation Ð Manual
Temperature Control Only ...............219
N Rear Washer Operation Ð Manual Temperature
Control Only ........................219 N Rear Wiper Operation Ð Automatic
Temperature Control Only ...............220
N Intermittent Rear Wiper Operation Ð
Automatic Temperature Control Only .......220
N Rear Washer Operation Ð Automatic
Temperature Control Only ...............221
N Electric Rear Window Defroster Ð If
Equipped ...........................222 UNDERSTANDING YOUR INSTRUMENT PANEL 147
4

INSTRUMENTS AND CONTROLS 148 UNDERSTANDING YOUR INSTRUMENT PANEL

BASE INSTRUMENT CLUSTER UNDERSTANDING YOUR INSTRUMENT PANEL 149
4

INSTRUMENT CLUSTER WITH TACH 150 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER DESCRIPTIONS
1. Fuel Gauge
The pointer shows the level of fuel in the fuel tank when
the ignition switch is in the ON position.
2. Low Fuel Light
When the fuel level reaches approximately 3.0
gallons (11.0 liters) this light will turn on and
remain on until fuel is added.
3. Liftgate Ajar
This light turns on if the liftgate is not com-
pletely closed.
4. Door Ajar Light
This light turns on if a door is not completely
closed. 5. Speedometer
Indicates vehicle speed.
6. Brake System Warning Light
This light monitors various brake functions,
including brake fluid level and parking brake
application. If the brake light turns on, it may
indicate that the parking brake is applied, there
is a low brake fluid level or there is a problem with the
anit-lock brake system.
The dual brake system provides a reserve braking capac-
ity in the event of a failure to a portion of the hydraulic
system. Failure of either half of the dual brake system is
indicated by the Brake Warning Light which will turn on
when the brake fluid level in the master cylinder has
dropped below a specified level.
The light will remain on until the cause is corrected. UNDERSTANDING YOUR INSTRUMENT PANEL 151
4

NOTE: The light may flash momentarily during sharp
cornering maneuvers which change fluid level condi-
tions. The vehicle should have service performed.
If brake failure is indicated, immediate repair is neces-
sary.
WARNING!Driving a vehicle with the brake light on is danger-
ous. Part of the brake system may have failed. It will
take longer to stop the vehicle. You could have an
accident. Have the vehicle checked immediately.
Vehicles equipped with Anti-Lock brakes (ABS), are also
equipped with Electronic Brake Force Distribution (EBD).
In the event of an EBD failure, the Brake Warning Light
will turn on along with the ABS Light. Immediate repair
to the ABS system is required. The operation of the Brake Warning Light can be checked
by turning the ignition switch from the OFF position to
the ON position. The light should illuminate for approxi-
mately four seconds. The light should then turn off
unless the parking brake is applied or a brake fault is
detected. If the light does not illuminate, have the light
inspected by an authorized dealer.
The light also will turn on when the parking brake is
applied with the ignition switch in the ON position.
NOTE: This light shows only that the parking brake is
applied. It does not show the degree of brake application.
7. Airbag Light
This light turns on and remains on for 6 to 8
seconds as a bulb check when the ignition
switch is first turned ON. If the light is not on
during starting, stays on, or turns on while
driving, have the system inspected by an authorized
dealer as soon as possible.152 UNDERSTANDING YOUR INSTRUMENT PANEL
