2004 DODGE GRAND CARAVAN wiper

N Turn Signals .........................102
N Headlight Low/High Beam Selector Switch . . . 103
N Passing Light ........................103
N Windshield Wipers And Washers ..........103
m Tilt Steering Column Ð If Equipped .........104
m Traction Control Switch Ð If Equipped .......105
m Adjustable Pedals Ð If Equipped ...........106
m Electronic Speed Control Ð If Equipped ......107
N To Activate ..........................108
N To Set At A Desired Speed ...............108
N To Deactivate ........................108
N To Resume Speed .....................108
N To Vary The Speed Setting ...............109 N To Accelerate For Passing ...............109
m Overhead Console Ð If Equipped ...........110
N Courtesy/Reading Lights ................110
N Sunglass Storage ......................111
N Compass/Temperature Display ...........111
N Mini-Trip Computer ...................114
N Electronic Vehicle Information Center
(EVIC) Ð If Equipped ..................115
N Customer Programmable Features Ð If
Equipped ...........................116
m Garage Door Opener Ð If Equipped .........119
N Programming Homelink ................120
N Canadian Programming/Gate Programming . . 123
N Using Homelink ......................123UNDERSTANDING THE FEATURES OF YOUR VEHICLE 75
3

Turn Signal Warning
If the vehicle electronics sense that the vehicle has traveled
at over 18 mph (29 km/h) for about one mile with the turn
signals on, a chime will sound to alert the driver.
Headlight Low/High Beam Selector Switch
Pull the multifunction lever toward the steering wheel to
switch the headlights between HIGH and LOW beam.
Passing Light
You can signal another vehicle with your headlights by
lightly pulling the multifunction lever toward the steer-
ing wheel. This will cause the headlights to turn on at
high beam and remain on until the lever is released.
Windshield Wipers and Washers
The wipers and washers are operated by a switch in the
multifunction lever. Rotate the end of the lever to select
the desired wiper speed. NOTE: Always remove any build-up of snow that
prevents the windshield wiper blades from returning to
the OFF position. If the windshield wiper switch is
turned OFF and the blades cannot return to the OFF
position, damage to the wiper motor may occur.
To use the washer, press the end of the multifunction
lever in when spray is desired, the washers will spray for UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103
3

a maximum of 20 seconds or until the lever is released. If
another washer cycle is desired the end of the lever must
be pressed again to get another 20 second washer cycle. If
the lever is depressed while in the delay range, the
wipers will operate for several seconds after the lever is
released, and then resume the intermittent interval pre-
viously selected.
If the end of the lever is depressed while in the OFF
position, the wipers will operate for approximately two
wipe cycles, then turn OFF.
WARNING!Sudden loss of visibility through the windshield
could lead to an accident. You might not see other
vehicles or other obstacles. To avoid sudden icing of
the windshield during freezing weather, warm the
windshield with defroster before and during wind-
shield washer use. Intermittent Wiper System
Use the intermittent wipers when weather conditions
make a single wiping cycle, with a variable pause be-
tween cycles, desirable.
Rotate the end of the lever to the first detent position,
then turn the end of the lever to select the desired delay
interval. The delay can be regulated from a maximum of
about 20 seconds between cycles, to a cycle every 2
seconds. The time delay will be doubled if the vehicle
speed is less than 10 mph (16 km/h).
TILT STEERING COLUMN Ð IF EQUIPPED
To tilt the column, pull the small lever, located behind the
turn signal control, toward you and move the wheel up
or down, as desired. Release the lever to lock the wheel
firmly in place.104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

30, 60, or 90 seconds, or not remain on. Pressing the
ªSTEPº button when in this display will select 30, 60, 90,
or ªOFF.º
Headlamp On With Wipers (Available with Auto
Headlights Only)
When this feature is selected and the headlight switch
has been moved to the ªAUTOº position, the engine is
running and, the front wipers are turned on for 10
seconds, the headlights will turn ON. The display will
remain on Parade Mode (Daytime Brightness) for ease of
viewing. Pressing the ªSTEPº button when in this display
will select ªYesº or ªNo.º
Power Accessory Delay
When this feature is selected, accessory power will be
supplied for up to 45 seconds for the power windows, radio, power vent windows, power outlets, and remov-
able center console, when the ignition switch is turned off
or until the key is removed and either front door is
opened.
GARAGE DOOR OPENER Ð IF EQUIPPED
The HomeLink t Universal Transceiver replaces up to
three remote controls (hand held transmitters) that oper-
ate devices such as garage door openers, motorized
gates, or home lighting. It triggers these devices at the
push of a button. The Universal Transceiver operates off
your vehicle's battery and charging system; no batteries
are needed.
For additional information on HomeLink t , call 1±800±
355±3515, or on the internet at www.homelink.com. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119
3

N Manual Air Conditioning Operation ........203
N Manual Rear Zone Climate Control Ð If
Equipped ...........................206
N Infrared Three-Zone Automatic Temperature
Control Ð If Equipped .................208
m Rear Window Features ...................219
N Intermittent Rear Wiper Operation Ð Manual
Temperature Control Only ...............219
N Rear Washer Operation Ð Manual Temperature
Control Only ........................219 N Rear Wiper Operation Ð Automatic
Temperature Control Only ...............220
N Intermittent Rear Wiper Operation Ð
Automatic Temperature Control Only .......220
N Rear Washer Operation Ð Automatic
Temperature Control Only ...............221
N Electric Rear Window Defroster Ð If
Equipped ...........................222 UNDERSTANDING YOUR INSTRUMENT PANEL 147
4

A/C Air Filter Ð If Equipped
The climate control system filters out dust, pollen and
some odors from the air. Strong odors can not be totally
filtered out. Refer to section 7 ªAir Conditioningº for
filter replacement instructions.
REAR WINDOW FEATURES
Intermittent Rear Wiper Operation Ð Manual
Temperature Control Only
The controls are located on the Manual Tempera-
ture Control head above the front blower control.
When the button is pressed and released and the
Ignition Switch in ON, the rear wiper will operate at a
fixed interval of about 8 seconds. As vehicle speed
increases, the time delay will shorten. The LED indicator
will light when the wiper is ON. Pressing and releasing
the button again with turn the wiper off. Rear Washer Operation Ð Manual Temperature
Control Only
The controls are located on the Manual Tempera-
ture Control head above the front blower control.
Press and hold the button for as long as spray is
desired. If the button is depressed and held while the
Intermittent wiper is on, the wiper will operated for a few
seconds after the button is released, then resume inter-
mittent operation. If the button was pressed and held
when the intermittent wiper is off, the wiper will operate
for two cycles, then turn off. The LED will not illuminate
when Washer is selected and Intermittent is OFF.
NOTE: The washer will stop spraying if the switch is
pressed longer than 10 seconds. UNDERSTANDING YOUR INSTRUMENT PANEL 219
4

Vehicles equipped with Automatic Temperature Control,
the controls for these features are located in the middle of
the instrument panel above the radio. Rear Wiper Operation Ð Automatic Temperature
Control Only
Press this button to have the rear wiper have a
continuous wipe. When the ignition switch is in the
ON/RUN position, the rear wiper switch position as well
as an indicator light will show that the wiper is ON.
Intermittent Rear Wiper Operation Ð Automatic
Temperature Control Only
When this button is pressed and the ignition
switch is in the ON position, the rear wiper will
operate at a fixed interval of about 8 seconds. As
vehicle speed increases, the time delay will shorten. The
switch position as well as an indicator light will show
when the wiper is ON.220 UNDERSTANDING YOUR INSTRUMENT PANEL

Rear Washer Operation Ð Automatic
Temperature Control Only
Press and hold the button as long as spray is
desired. If the switch is depressed while the wipers
are on, the wipers will operate for a few seconds
after the switch is released then resume the previously set
mode of intermittent wiper or continuous wipe. If the
switch is depressed when the wipers are off, the wipers
will operate for two cycles, then turn off.
NOTE: The washers will stop spraying if the switch is
pressed longer than 10 seconds.
Adding Washer Fluid
The fluid reservoir for the windshield washers and the
rear window washer is shared. It is located in the front of
the engine compartment on the passenger side and
should be checked for fluid level at regular intervals. Fill the reservoir with windshield washer solvent (not radia-
tor antifreeze) and operate the system for a few seconds
to flush out the residual water.
The washer fluid reservoir will hold a full gallon of fluid
when the Low Washer Fluid Light illuminates. UNDERSTANDING YOUR INSTRUMENT PANEL 221
4
