Page 137 of 397
2. Place the rear corners of the cargo organizer into the
supports located on the rear trim panel. Press down on
the back of the cargo organizer to lock it into place. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137
3
Page 138 of 397
WARNING!Do not load objects over 20 lbs (9 kg) in the upper
position. Failure to follow this warning could cause
the cargo organizer to collapse resulting in personal
injury.
CAUTION!Do not load objects over 100 lbs (45 kg) in the lower
position. Failure to follow this could cause damage
to the cargo organizer. To Open Storage Compartments
1. Pull up on the center opening of the cargo organizer.
2. Lift up on the storage compartment dividers and lock
into place.138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 139 of 397
Cargo Organizer removal
Unscrew the two plastic fasteners located on the floor of
the rear of the cargo area and remove the cargo organizer
from the vehicle.
NOTE: The cargo organizer must be removed to take
out the third row seat. ROOF LUGGAGE RACK Ð IF EQUIPPED
The crossbars and siderails are designed to carry the
weight on vehicles equipped with a luggage rack. The
load must not exceed 150 lbs (68 kg), and should be
uniformly distributed over the luggage rack crossbars.
Distribute cargo weight evenly on the roof rack crossbars.
The roof rack does not increase the total load carrying UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139
3
Page 140 of 397

capacity of the vehicle. Be sure the total load of cargo
inside the vehicle plus that on the external rack does not
exceed the maximum vehicle load capacity.
To move the cross bars, press the upper edge of each
cross bar button pass the detent, then move the cross bar
to the desired position. Once the cross bar is in place,
press the lower edge of the cross bar button to lock it into
position.
Attempt to move the crossbar again to ensure that it has
properly locked into position. NOTE: To help control wind noise when installing the
cross bars make sure that the arrows marked on the front
side of the cross bars are facing the front of the vehicle.
Also, when the cross bars are not in use the notch on the
cross bars should be aligned with the arrows on the side
rails. This will help reduce the amount of wind noise
when the crossbars are not in use.
The tie down holes on the cross bar ends should always
be used to tie down the load. Check the straps frequently
to be sure that the load remains securely attached.140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 141 of 397

CAUTION!² To avoid damage to the roof rack and vehicle, do
not exceed the maximum roof rack load capacity
of 150 lbs (68 kg). Always distribute heavy loads
as evenly as possible and secure the load appro-
priately.
² Long loads which extend over the windshield,
such as wood panels or surfboards, or loads with
large frontal area should be secured to both the
front and rear of the vehicle.
² Travel at reduced speeds and turn corners care-
fully when carrying large or heavy loads on the
roof rack. Wind forces, due to natural causes or
nearby truck traffic, can add sudden upward
loads. This is especially true on large flat loads
and may result in damage to the cargo or your
vehicle. WARNING!Cargo must be securely tied before driving your
vehicle. Improperly secured loads can fly off the
vehicle, particularly at high speeds, resulting in
personal injury or property damage. Follow the Roof
Rack Cautions when carrying cargo on your roof
rack.
LOAD LEVELING SYSTEM
The automatic load leveling system will provide a level
riding vehicle under most passenger and cargo loading
conditions.
A hydraulic pump contained within the shock absorbers
raises the rear of the vehicle to the correct height. It takes
approximately 1 mile (1.6 km) of driving for the leveling
to complete depending on road surface conditions. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141
3
Page 142 of 397
If the leveled vehicle is not moved for approximately 15
hours, the leveling system will bleed itself down. The
vehicle must be driven to reset the system.
WARNING!Do not install the load leveling system on vehicles
that are not equipped with Anti-Lock Brakes. Ve-
hicles without Anti-Lock Brakes (ABS) have a
height-sensing proportioning valve. Installing a lev-
eling system will render this system ineffective,
inappropriately reducing rear brake pressure, result-
ing in increased stopping distances. You could have
an accident. 142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 143 of 397
UNDERSTANDING YOUR INSTRUMENT PANELCONTENTS m Instruments And Controls .................148
m Base Instrument Cluster ..................149
m Instrument Cluster With Tach ..............150
m Instrument Cluster Descriptions ............151
m Information Center Ð If Equipped ..........159
N Turn Signal Indicators ..................159
N High Beam Light .....................159
m Electronic Digital Clock ..................159
N Clock Setting Procedur e.................160 m Radio General Information ................160
N Radio Broadcast Signals .................160
N Two Types Of Signals ..................160
N Electrical Disturbances ..................160
N AM Reception .......................161
N FM Reception ........................161
m Sales Code RAZÐAM/ FM Stereo Radio With
Cassette Tape Player, CD Player And CD
Changer Controls Ð If Equipped ...........161
N Operating Instructions Ð Radio ...........1614
Page 144 of 397

N Power Switch, Volume Control ............162
N Seek Button (Radio Mode) ...............162
N Tuning .............................162
N PTY (Program Type) Button ..............162
N Balance ............................164
N Fade ..............................164
N Tone Control ........................164
N AM/FM Selection .....................164
N Scan Button .........................164
N To Set The Radio Push-Button Memory ......165
N To Change From Clock To Radio Mode ......165
N Operating Instructions Ð Tape Player .......165
N Seek Button .........................165 N Fast Forward (FF) .....................166
N Rewind (RW) ........................166
N Tape Eject ...........................166
N Scan Button .........................166
N Changing Tape Direction ................166
N Metal Tape Selection ...................166
N Pinch Roller Release ...................167
N Noise Reduction ......................167
N Operating Instructions Ð CD Player ........167
N Inserting The Compact Disc ..............167
N Seek Button .........................168
N EJT CD (Eject) Button ..................168
N FF/Tune/RW ........................169144 UNDERSTANDING YOUR INSTRUMENT PANEL
