AISIN AUTOMATIC TRANSAXLE 5A2 – 59
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0722
OUPUT SHAFT SPEED (OSS) SENSOR CIRCUIT NO
SIGNAL
Conditions for Setting the DTC
S This DTC detects no signal of Output Shaft Speed
(OSS) sensor circuit for a long period of time. (
Revolution : 0 rpm
10000 rpm).
S TCM detects no pulse of Output Shaft Speed
(OSS) sensor while TCM detects 178 pulses of In-
put Shaft Speed sensor. This detection 500 times
continuously.
S D,2,L range selected
S Input speed is 5 km/h (3 mph) or greater.
S DTCs P0751, P0753, P0756, P0758, P0717 and
P0705 are not set.
S 25 seconds later after Neutral to Drive shift.
Action Taken When the DTC Sets
S TCM will request the illumination of MIL and store
DTC when TCM detects a failure on the first ignition
cycle.
S No lockup control
S No engine torque reduction control
S No engagement pressure controlS No 4th gear
S No self–learning control
S No prevent reverse gear control
Conditions for Clearing the DTC
S The TCM turns off the MIL when no further failures
detected for three consecutive ignition cycles.
S The scan tool can clear the DTC from the TCM his-
tory.
S The TCM clears the DTC from the TCM history
memory after forty consecutive warm up cycles
without fault.
S TCM detects 250 pulses of Output Shaft Speed
(OSS) sensor while failure detection is not
achieved.
Cause of Failure
S Wiring harness or connector between Output Shaft
Speed (OSS) sensor and TCM
S OSS sensor
S TCM

5A2 – 60IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DTC P0722 Output Shaft Speed (OSS) sensor Circuit No Signal
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3. With the engine OFF, turn the ignition switch to
the ON position.
4. Select Store Freeze Frame/Failure Records
from the Diagnostic Trouble Codes Information
menu.
5. Store Freeze Frame/Failure Records.
6. Select Clear DTC Information from the Diag-
nostic Trouble Codes Information menu.
7. Clear DTC Information.
8. Perform one vehicle drive cycle.
Is the Malfunction Indicator Lamp (MIL) ON?–Go to Step 2Repair the tem-
porary connec-
tion failure of
connector (Re-
fer to ”Wiring
Harness and
Connector In-
spection” in this
section.)
21. Select Request DTC by Status from the Diag-
nostic Trouble Codes Information menu.
2. Request DTC by Status.
Is DTC P0722 displayed?–Go to Step 3Repair the tem-
porary connec-
tion failure of
connector (Re-
fer to ”Wiring
Harness and
Connector In-
spection” in this
section.)
31. Turn the ignition OFF.
2. Inspect the voltage between vehicle harness
and the Output Shaft Speed (OSS) sensor.
3. Disconnect the connector (X–1) of the vehicle
harness.
4. Connect the voltmeter to monitor the voltage
between terminal B25 and ground.
5. Turn ignition ON and lift up the vehicle.
6. Check the voltage change from approximately
0 v to 12 v when the wheel is turned slowly.
Does the measurement change within the specified
value?0–12 vGo to Step 4Go to Step 5
41. Estimate the failure of between the vehicle wir-
ing harness connector and TCM.
2. Inspect the connector. Refer to ”Wiring Har-
ness and Connector Inspection” in this section.
3. Inspect the connection condition between the
connectors (C–1).
Is the connection condition OK?–Go to Step 6Repair the wir-
ing harness
connectors.
51. Estimate the failure of T/M wire or between the
connectors of OSS sensor.
2. Inspect the OSS sensor. Refer to ”Unit Inspec-
tion” in this section
Is the condition of OSS sensor OK?–Go to Step 7Replace the
OSS sensor

5A2 – 62IAISIN AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0727
ENGINE SPEED INPUT CIRCUIT NO SIGNAL
Conditions for Setting the DTC
S TCM detects that malfunction of engine speed sig-
nal for 2 seconds.
S No DTCs U2105
Action Taken When the DTC Sets
S TCM will request the illumination of MIL and store
DTC when TCM detects a failure on the first ignition
cycle.
S No engine torque reduction control
S No lock–up
S No engagement pressure control
S No 4th gear
S No self–learning control
S No timing solenoid control for N–DS TCM judges the engine revolution is 0 rpm.
Conditions for Clearing the DTC
S The TCM turns off the MIL when no further failures
detected for three consecutive ignition cycles.
S The scan tool can clear the DTC from the TCM his-
tory.
S The TCM clears the DTC from the TCM history
memory after forty consecutive warm up cycles
without fault.
Cause of Failure
S Wiring harness or connector between ECM and
TCM
S ECM
S TCM

AISIN AUTOMATIC TRANSAXLE 5A2 – 63
DAEWOO V–121 BL4
DTC P0727 Engine Speed Input Circuit No Signal
StepActionValue(s)YesNo
11. Turn the ignition OFF.
2. Install the Scan tool.
3. With the engine OFF, turn the ignition switch to
the ON position.
4. Select Store Freeze Frame/Failure Records
from the Diagnostic Trouble Codes Information
menu.
5. Store Freeze Frame/Failure Records.
6. Select Clear DTC Information from the Diag-
nostic Trouble Codes Information menu.
7. Clear DTC Information.
8. Perform one vehicle drive cycle.
Is the Malfunction Indicator Lamp (MIL) ON?–Go to Step 2Repair the tem-
porary connec-
tion failure of
connector.
21. Select Request DTC by Status from the Diag-
nostic Trouble Codes Information menu.
2. Request DTC by Status.
Is DTC P0727 displayed?–Go to Step 3Repair the tem-
porary connec-
tion failure of
connector.
31. Turn the ignition OFF.
2. Disconnect the TCM wiring connector and
ECM wiring connector.
3. Measure the resistance between terminal A17
of the TCM wiring connector and terminal 88 of
the ECM wiring connector.
4. Measure the resistance between terminal A7 of
the TCM wiring connector and terminal 57 of
the ECM wiring connector.
Is the resistance within the values shown?0 WGo to Step 5Go to Step 4
4Repair the malfunctioning terminals as necessary.
Is the action complete?–System OK–
51. Turn the ignition ON.
2. Measure the voltage of terminal A17.
3. Measure the voltage of terminal A7.
Is the voltage within the values shown?11–14 vGo to Step 6Go to Step 7
6Repair the malfunctioning terminals as necessary.
Is the action complete?–System OK–
71. Inspect the ”Engine Speed”. Refer to Section
1F, Diagnosis.
Was a problem found?–Refer to Sec-
tion 1F, Diagno-
sis.Go to Step 8
81. Replace the TCM.
2. Turn the ignition OFF.
3. Turn the ignition ON.
4. Check if P0727 DTC is set.
Is the DTC set?–Go to Step 9Go to Step 10

AISIN AUTOMATIC TRANSAXLE 5A2 – 65
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0741
TORQUE CONVERTER CLUTCH (TCC) CIRCUIT STUCK
OFF
Conditions for Setting the DTC
S Lockup solenoid is stuck OFF.
S D range selected
S Engine water normal temperature
S 20 seconds have passed since the transaxle was
placed in D.
S Engine revolution is 600 rpm or greater.
S No failure of input speed sensor / engine revolution
/ water temperature signal / solenoid electrical /
ranger sensor / throttle signal
Action Taken When the DTC Sets
S TCM will request the illumination of MIL and store
DTC when TCM detects failures on two consecu-
tive ignition cycles.Conditions for Clearing the DTC
S The TCM turns off the MIL when no further failures
detected for three consecutive ignition cycles.
S The scan tool can clear the DTC from the TCM his-
tory.
S The TCM clears the DTC from the TCM history
memory after forty consecutive warm up cycles
without fault.
Cause of Failure
S Lockup solenoid
S Inside A/T
S Inside valve body
S TCM

AISIN AUTOMATIC TRANSAXLE 5A2 – 67
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0742
TORQUE CONVERTER CLUTCH (TCC) CIRCUIT STUCK
ON
Conditions for Setting the DTC
S Lockup solenoid is stuck ON.
S D range selected
S Engine water normal temperature
S 20 seconds have passed since the transaxle was
placed in D.
S Engine revolution is 600 rpm or greater.
S No failure of input speed sensor / engine revolution
/ water temperature signal / solenoid electrical /
ranger sensor / throttle signal
Action Taken When the DTC Sets
S TCM will request the illumination of MIL and store
DTC when TCM detects failures on two consecu-
tive ignition cycles.Conditions for Clearing the DTC
S The TCM turns off the MIL when no further failures
detected for three consecutive ignition cycles.
S The scan tool can clear the DTC from the TCM his-
tory.
S The TCM clears the DTC from the TCM history
memory after forty consecutive warm up cycles
without fault.
Cause of Failure
S Lockup solenoid
S Inside A/T
S Inside valve body
S TCM

AISIN AUTOMATIC TRANSAXLE 5A2 – 69
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0743
TORQUE CONVERTER CLUTCH (TCC) ELECTRICAL
Conditions for Setting the DTC
S TCM detects that the ON signal of the lockup sole-
noid monitor during 0.5 seconds when lockup sole-
noid driver outputs the OFF signal.(When the TCC
circuit is open or short to battery).
S The above detection 2 times at shifting continuous-
ly.(When the Tcc circuit is open or short to battery).
S TCM detects that the OFF signal of the lockup sole-
noid monitor during 0.3 seconds when lockup sole-
noid driver outputs the ON signal.(When the TCC
circuit is short to ground).
S The above detection 1 time at shifting continuous-
ly.(When the TCC circuit is short to ground).
Action Taken When the DTC Sets
S TCM will request the illumination of MIL and store
DTC when TCM detects failures on two consecu-
tive ignition cycles.
S No TCC lockup solenoid
S 1st gear fixed under the 10km/hConditions for Clearing the DTC
S The TCM turns off the MIL when no further failures
detected for three consecutive ignition cycles.
S The scan tool can clear the DTC from the TCM his-
tory.
S The TCM clears the DTC from the TCM history
memory after forty consecutive warm up cycles
without fault.
S TCM detects the ON signal of the lockup solenoid
monitor during 160 ms when lockup solenoid driver
outputs the ON signal and TCM detects the OFF
signal of the lockup solenoid monitor during 160 ms
when lockup solenoid driver outputs the OFF sig-
nal.
Cause of Failure
S Wiring harness or connector between lockup sole-
noid and TCM
S Lockup solenoid
S TCM

AISIN AUTOMATIC TRANSAXLE 5A2 – 75
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE (DTC) P0751
SHIFT SOLENOID 1 (SS1) STUCK OFF
Conditions for Setting the DTC
S Shift Solenoid 1 (SS1) is stuck ON/OFF.
S D range selected
S Engine water normal temperature
S 20 seconds have passed since the transaxle was
placed in D.
S Engine revolution is 600 rpm or greater.
S No failure of output speed sensor / input speed
sensor / engine revolution / water temperature sig-
nal / solenoid electrical / ranger sensor / throttle
signal
Action Taken When the DTC SetsS TCM will request the illumination of MIL and store
DTC when TCM detects failures on two consecu-
tive ignition cycles.
Conditions for Clearing the DTC
S The TCM turns off the MIL when no further failures
detected for three consecutive ignition cycles.
S The scan tool can clear the DTC from the TCM his-
tory.
S The TCM clears the DTC from the TCM history
memory after forty consecutive warm up cycles
without fault.
Cause of Failure
S Shift Solenoid 1 (SS1)
S Inside Valve Body
S TCM
