2. Tilt the retainer downward and through the wheel
opening. Make sure the retainer is fully seated
across the underside of the wheel.3. Attach the wheel wrench and extensions together.
5-87

4. Insert the hoist end through the hole in the rear
bumper and into the funnel-shaped guide.
5. Turn the wheel wrench clockwise to raise the tire
part way up. Make sure the retainer is seated in
the wheel opening and the valve stem is
pointed down.
6. Raise the tire fully against the underside of the
vehicle by turning the wheel wrench clockwise
until you feel it skip twice. You cannot overtighten
the cable.A. Push and Pull on Tire
B. Turn Tire
7. Make sure the tire is stored securely. Push, pull, and
then try to turn the tire. If the tire moves, check to
make sure the tire valve stem is pointing down, then
use the wheel wrench to loosen and then tighten
the cable.
5-88

Return the wheel wrench and jack extensions and the
storage bag to the location under the front passenger’s
seat. Reinstall the jack and wheel blocks, be sure to
install the wheel blocks rst. Secure the items in the
vehicle as shown.
A. Bottle Jack
B. Wheel Blocks
C. Wing NutA. Bottle Jack
B. Wheel Blocks
C. Wing Nut
Crew Cab
Regular and
Extended Cab
5-89

Secondary Latch System
Your vehicle has an underbody mounted tire hoist
assembly equipped with a secondary latch system. It is
designed to stop the spare tire from suddenly falling
off your vehicle. For the secondary latch to work,
the spare must be installed with the valve stem pointing
down. See “Storing a Flat or Spare Tire, Jack and
Tools” earlier in this section.
{CAUTION:
Before beginning this procedure read all the
instructions. Failure to read and follow the
instructions could damage the hoist assembly
and you and others could get hurt. Read and
follow the instructions listed below.To release the spare tire from the secondary latch do
the following:
1. Check under the vehicle to see if the cable end
tting is visible.
2. If the cable end tting is not visible proceed
to Step 6.
If it is visible, rst try to tighten the cable by turning
the wheel wrench clockwise until you hear two
clicks or feel it skip twice. You cannot overtighten
the cable.
3. Loosen the cable by turning the wheel wrench
counterclockwise three or four turns.
5-90

4. Repeat this procedure at least two times. If the
spare tire lowers to the ground, continue with
Step 5 of “Removing the Spare Tire and Tools”
earlier in this section.
5. Turn the wrench counterclockwise until
approximately six inches (15 cm) of cable
is exposed.
6. Stand the wheel blocks
on their shortest ends,
with the backs
facing each other.
7. Place the bottom edge of the jack on the wheel
blocks, separating them so that the jack is
balanced securely.8. Attach the jack handle, extension, and wheel
wrench to the jack and place it (with the wheel
blocks) under the vehicle towards the front of the
rear bumper. Position the center lift point of the jack
under the wheel.
9. Turn the wrench clockwise to raise the jack until it
lifts the tire.
10. Continue raising the jack until the tire stops moving
upward and is held rmly in place. The secondary
latch has released and the tire is balancing on
the jack.
5-91

11. Remove the jack handle and insert the hoist end of
the extension through the hole in the rear bumper.
Turn the wheel counterclockwise one turn or
until the wheel retainer assembly falls out.
12. Reinsert the jack handle into the jack. Lower the
jack by turning the wheel wrench counterclockwise.
Keep lowering the jack until the spare tire slides
off the jack or is hanging by the cable.
{CAUTION:
Someone standing too close during the
procedure could be injured by the jack. If the
spare tire does not slide off the jack
completely, make sure no one is behind you or
on either side of you as you pull the jack out
from the spare.
13. Disconnect the jack handle from the jack and
carefully remove the jack. Use one hand to push
against the spare while rmly pulling the jack out
from under the spare tire with the other hand.
If the spare tire is hanging from the cable, insert the
hoist handle, extension and wheel wrench into
the hoist shaft hole in the bumper and turn
the wheel wrench counterclockwise to lower the
spare the rest of the way.
5-92

14. Tilt the tire retainer at the end of the cable and pull
it through the wheel opening. Pull the tire out from
under the vehicle.
15. If the cable is hanging under the vehicle, turn the
wheel wrench clockwise to raise the cable back up.
Have the hoist assembly inspected as soon as you can.
You will not be able to store a spare or at tire using
the hoist assembly until it has been replaced.
To continue changing the at tire, see “Removing the
Flat Tire and Installing the Spare Tire” earlier in
this section.
Spare Tire
Compact Spare Tire
Your vehicle may be equipped with a compact spare
tire. Although the compact spare tire was fully inated
when your vehicle was new, it can lose air after a time.
Check the ination pressure regularly. It should be
60 psi (420 kPa).
After installing the compact spare on your vehicle, you
should stop as soon as possible and make sure
your spare tire is correctly inated. The compact spare
is made to perform well at speeds up to 65 mph
(105 km/h) for distances up to 3,000 miles (5 000 km),
so you can nish your trip and have your full-size
tire repaired or replaced where you want. For heavy
payloads or towing, and for low traction or
four-wheel-drive conditions, repair or replace the
full-size tire, and reinstall for best performance. Of
course, it’s best to replace your spare with a full-size tire
as soon as you can. Your spare will last longer and
be in good shape in case you need it again.
Notice:When the compact spare is installed, don’t
take your vehicle through an automatic car wash
with guide rails. The compact spare can get caught
on the rails. That can damage the tire and wheel,
and maybe other parts of your vehicle.
Don’t use your compact spare on other vehicles.
5-93

And don’t mix your compact spare tire or wheel with
other wheels or tires. They won’t t. Keep your spare tire
and its wheel together.
Notice:Tire chains won’t t your compact spare.
Using them can damage your vehicle and can
damage the chains too. Don’t use tire chains on
your compact spare.
Full-Size Spare Tire
Your vehicle may be equipped with a full-size spare tire,
which, when new, was fully inated. A spare tire,
whether compact–size or full–size, may lose air over
time, so check its ination pressure regularly. See
Ination - Tire Pressure on page 5-64andLoading Your
Vehicle on page 4-50for information regarding proper
tire ination and loading your vehicle. For instruction on
how to remove, install or store a spare tire, see
Changing a Flat Tire on page 5-74.
After installing the spare tire on your vehicle, you should
stop as soon as possible and make sure the spare is
correctly inated. Have the damaged or at road
tire repaired or replaced as soon as you can and
installed back onto your vehicle. This way, a spare tire
will be available in case you need it again.
Don’t mix tires and wheels of different sizes, because
they won’t t. Keep your spare tire and its
wheel together.
