2004 BMW MOTORRAD K 1200 S Rider's Manual (in English)

8135
Technical data
Electrical system Battery
Type 12 V 14 Ah, maintenance-free
Low temperature test current 190 A
Spark plugs
Approved spark plugs BOSCH YR 5DDE
Electrode gap 0.7 mm
Wear limit 1.0 mm
Fuses
All circuits are electronically protected, so
plug-in fuses are no longer necessary. If an
electronic fuse trips and de-energises a circuit,
the circuit is active as soon as the ignition is
switched on after the fault has been rectified.

Technical data8136
Electrical systemBulbs
Design of headlight Clear glass with three reflectors
High-beam headlight 2 H7 halogen bulbs, 12 V 55 W
Low-beam headlight H7 halogen bulb 12 V 55 W
Parking light 12 V 5 W
Brake/rear lights 12 V 21/5 W
Front turn indicators 12 V 16 W
Rear flashing turn indicators 12 V 10 W
Power socket
Ratings 12 V 5 A

8137
Technical data
Dimensions and weightsDimensions
Maximum length 2,214 mm
Maximum width 858 mm
Maximum height (without rider) 1,220 mm
Seat height 820 mm
Wheelbase in normal-load position 1,572 mm
Ground clearance in normal-load position 120 mm
Weights
DIN unladen weight 248 kg
Permissible gross weight 450 kg
Maximum payload 202 kg
Permissible wheel loads
Front 160 kg
Rear 290 kg

Technical data8138
Riding specifications Speeds
Top speed over 200 km/h
Acceleration 0-100 km/h 2.8 s
Noises
Riding noise to EU specification 80 dB (A)
Stationary noise to EU specification 94 dB (A) at 5,100 rpm

9139
Service
BMW Motorrad service ............... 140
Confirmation of maintenance
work .............................................. 143
Confirmation of service .............. 147

Service9140
BMW Motorrad serviceBMW Motorrad service
qualityBMW Motorrad stands not only
for good handling and a high
degree of reliability, but also for
an excellent quality of service.
To ensure that your BMW is
always in optimum condition,
we recommend that you have
the regular maintenance work
required for your motorcycle
carried out and that you have
this done preferably at your
authorised BMW motorcycle
dealer. For goodwill services
after the expiry of the warranty,
proof of regular maintenance is
an indispensable precondition.
Certain signs of wear, moreo-
ver, may otherwise not be
noticed until it is too late to
rectify them at moderate cost.
Your authorised BMW motorcycle dealer knows your
motorcycle intimately and can
step in before small problems
become extremely serious
issues. By having the neces-
sary repairs done properly and
in good time, you save time
and money in the long run.
BMW Motorrad Service
Card – On-the-spot
breakdown assistanceWith all new BMW motorcy-
cles, the BMW Motorrad Serv-
ice Card protects you in the
event of a breakdown with an
extensive range of services
such as breakdown assist-
ance, motorcycle transporta-
tion etc. (differing regulations
are possible in individual coun-
tries).
In the event of a breakdown,
contact BMW Motorrad’s
Mobile Service. Here you willfind our specialists ready to
help in both word and deed.
Important country-specific
contact addresses and the rel-
evant after-sales service
organisation phone numbers
as well as information on
Mobile Service and the dealer-
ship network can be found in
the "Service Kontakt / Service
Contact" brochures.
BMW Motorrad service
networkOur extensive after-sales serv-
ice organisation network is able
to look after you and your
motorcycle in more than
100 countries. In Germany
alone, you have the best possi-
ble access to approximately
200 authorised BMW motor-
cycle dealers.

9141
Service
All information concerning the
international dealership net-
work can be found in the
brochure "Service Contact
Europe" or "Service Contact
Africa, America, Asia,
Australia, Oceania".
You will be given the relevant
brochure for your country
together with your motorcycle;
you can obtain both brochures
from your authorised BMW
motorcycle dealer. Maintenance workMaintenance work is per-
formed on the basis of time
and distance travelled.BMW running-in checkThe BMW running-in check has
to be performed when the
motorcycle has covered
between 500 km and 1,200 km
BMW Annual InspectionSome maintenance work has
to be carried out at least once
a year. Other tasks depend on
the distance the motorcycle
has covered.BMW ServiceAfter the first 10,000 km and
every further 20,000 km
(30,000 km, 50,000 km,
70,000 km, etc.) if this
distance is covered within a
year.BMW InspectionAfter the first 20,000 km and
every further 20,000 km
(40,000 km, 60,000 km,
80,000 km, etc.) if this
distance is covered within a
year.
Maintenance schedulesIf you like, you can view the
current maintenance schedule
for your motorcycle
on the Internet and download
the file from www.bmw-motor-
rad.com/maintenance.
Every authorised BMW
motorcycle dealer has a
fixed scale of charges based
on labour times and carefully
calculated hourly rates. Lubri-
cants and operating materials,
filters, gaskets etc. are
charged separately.c

Service9142
BMW Running-In
CheckCarried out in accordance with
manufacturer’s instructions
Odometer
readingBrake fluid changed:
Without BMW Integral ABS
With BMW Integral ABS
Wheel circuit
Control circuit
Date, stamp, signature
BMW
Pre-delivery CheckCarried out in accordance with
manufacturer’s instructions
Date, stamp, signature
