2003 VOLVO XC70 ECO mode

2003 VOLVO XC70
Volume of traffic information/news/PTY-HU-803 only
If you change the volume when the TP, PTY or NEWS function is active, th\
e new volume setting will be
stored automatically.

pg. 159 AUM (Advanced User Mode) - certain models
AUM (Advanced User Mode)
l With the radio switched off, press and hold the volume wheel down for at\
least 5 seconds to start the
AUM function.
l Turn the 1-20/DISC knob to choose an AUM function (see function list below).
l When the function has been chosen, the function's current setting flashe\
s. Press the 1-20/DISC knob
to choose an alternative (e.g. ON/OFF, LOW/MID/HIGH, etc., depending on\
the function).
l Continue to choose function/alternative.
To reset all AUM functions to factory settings, turn the 1-20/DISC knob until "SET TO DEFAULT"
is shown in the display, and then press the same knob. All AUM settings \
are reset to default position and
the radio reverts to normal status (music, news, etc.).
To save any changes and revert to normal position, turn the 1-20/DISC knob until "BACK and SAVE"
are shown in the display, and press the same knob.
To revert to normal position without saving the changes, turn the 1-20/DISC knob until "BACK
without SAVE" is shown in the display, and press the same knob.
AUM functions (starting position "default" is underscored)
The following functions are available on all audio systems:
l SET TO DEFAULT (See above).
l ASC (Active Sound Control) ON/OFF - The ASC function automatically mat\
ches the sound volume
to the speed of the car.
l ASC TABLE - Choose level of the ASC function (LOW/MID/HIGH).
l SRC ON/OFF - Use this function to activate/deactivate the function which\
reduces the noise in poor
reception conditions. The function is normally used when the radio is in\
AM mode.
l SRC TABLE - Choose level of SRC function (LOW/MID/HIGH).
l TAPE DOLBY ON/OFF - Activates/deactivates Dolby noise reduction when you\
listen to a cassette
tape (HU 405/605).
l BACK and SAVE (See above).
file:///K|/ownersdocs/2003/2003_XC70/03xc70_10b.htm (3 of 13)12/30/200\
6 4:18:07 PM

2003 VOLVO XC70
Set the power output of the rear channels by pressing the button to exte\
nd the control, pulling it out as
far as possible and turning it left or right. A "detent" indicates "norm\
al" power output.
Press the button back after setting (Dolby Surround Pro Logic only).
* The "Effect" button will work only during CD playback or FM in Surroun\
d Pro Logic mode.

pg. 165 Audio systems - specifications
HU-613/HU-803
Output: 4 x 25 W
(HU-803 optional center speaker) 1 x 25 W plus 4 x 50 W through the su\
pplementary amplifier
Impedance: 4 Ohm.
Voltage required: 12 V, negative ground
Radio
Frequency range:
AM 530 - 1710 kHz
FM 87.7 - 107.9 Mhz
Alarm (HU-803 only)
"Alarm!" is displayed when an alarm message is sent. The function is use\
d to warn the driver of a
serious accident or disaster situation.
Dolby noise reduction is manufactured under license from Dolby Laborator\
ies Licensing Corporation.
"Dolby", "Pro Logic" and the double-D symbol are trademarks of Dolby Lab\
oratories Licensing
Corporation. The Dolby Pro Logic Surround System is manufactured under l\
icence from Dolby
Laboratories Licensing Corporation.
CAUTION:
The optional supplementary amplifier (HU-803) may be mounted under the\
front passenger's seat. If the
floor of the car has become soaked for any reason, do not turn on the ra\
dio. This would cause damage to
the amplifier. Contact a Volvo retailer.

file:///K|/ownersdocs/2003/2003_XC70/03xc70_10b.htm (11 of 13)12/30/20\
06 4:18:07 PM

2003 VOLVO XC70
2. Begin by erasing all 3 factory default channels. Hold down the two ou\
tside buttons (buttons 1 and 3 in
the illustration) on the HomeLink® Universal Transceiver for about 2\
0 seconds, until HomeLink®'s
indicator light begins to flash. Then release the buttons.
3. Hold your hand-held transmitter (garage door opener, for example) 2\
to 5 in. (5 to 12 cm) away from
the HomeLink® surface, keeping the indicator light in view. For place\
ment questions, contact
HomeLink® toll-free 1-800-355-3515 (Internet:
www.HomeLink.com).
4. Using two hands, push and hold both your hand-held transmitter's butt\
on and the transceiver button
you wish to program. The indicator light will flash first slowly, then r\
apidly. Rapid flashing tells you the
HomeLink® button has been successfully programmed. Release both butto\
ns.
5. If you are programming a rolling code-equipped device (e.g., garage \
door opener or entry door lock),
refer to "Programming rolling codes" on the next page to complete the pr\
ogramming process.
Repeat steps 3 and 4 to program the other two transceiver buttons.
If, after several attempts, you are unable to successfully train the Hom\
eLink® Universal Transceiver to
learn your hand-held transmitter's signal, contact HomeLink® toll-fre\
e 1-800-355-3515 (Internet:
www.
HomeLink.com).
WARNING!
l If you use HomeLink® to open a garage door or gate, be sure no one is\
near the gate or door while
it is in motion.
l Do not use the HomeLink® Universal Transceiver with any garage door o\
pener that lacks safety
"stop" and "reverse" features as required by federal safety standards. (\
This includes any garage door
opener model manufactured before April 1, 1982) A garage door opener th\
at cannot "detect" an
object, signalling the door to "stop" and "reverse" does not meet curren\
t federal safety standards.
Using a garage door opener without these features increases the risk of \
serious injury or death. For
more information on this matter, call toll-free 1-800-355-3515 (Interne\
t:
www.HomeLink.com).


pg. 168 HomeLink® Universal Transceiver (option)
NOTE - Canadian residents:
During programming, your hand-held transmitter may automatically stop tr\
ansmitting. To successfully
train HomeLink®, continue to hold the HomeLink® button. At the sam\
e time, repeatedly press and hold
file:///K|/ownersdocs/2003/2003_XC70/03xc70_11.htm (2 of 5)12/30/2006 \
4:18:07 PM

2003 VOLVO XC70
Cruise control 33
Cup holder
59
Cup holder in the center console
60
D
Detachable trailer hitch - installing
102
Dimensions
143
Direction indicators
36
Distributor ignition system
147
Door step courtesy lights - replacing
123
Doors and locks
76
Drive belt
131
Driver's seat and remote keyless entry system
57
Driving economy
95
Driving mode indicator
27
Driving mode W
91, 93, 104
Driving with trunk open
96
E
Economical driving
95
Electric socket in cargo compartment
67
Electrical system
148
Electrical system - general information
96
Electrically operated front seats
56
Electrically operated sideview mirrors
41
Electrically operated sun roof
42
Electrically operated windows
40
Electronic Brake Force Distribution
19
Electronic Climate Control (ECC)
48 - 51
Emergency Locking Retractor (ELR)
14
Emergency towing
99, 100
Emergency warning flashers
38
Emissions systems
130
Engine - specifications
144, 145
file:///K|/ownersdocs/2003/2003_XC70/03xc70_12.htm (4 of 12)12/30/2006\
4:18:08 PM
