2003 SUBARU LEGACY Owners Manual

12
Specifications12-9
–
CONTINUED –
Fuse panel Circuit
Fuse rating
420ACigarette lighter
Remote controlled rear view mirrors
510ATail light
Parking light
615ASRS airbag
715AFront fog light
830AABS (VDC) solenoid
915ARadio
Clock
1015ATrailer
1115AEngine ignition system
SRS airbag
1210AIllumination brightness control
1315AFuel pump
1410ARear window wiper and washer
1530AWindshield wiper and washer
1620ABrake light
1715AAir conditioner
1815ABackup light
Cruise control
ABS (VDC) control
1920AMirror heater
Wiper deicer

12-10Fuse panel Circuit
Fuse rating
2020AMcIntosh audio amp (if equipped)
2120AAccessory power socket
Seat heater
Fuse panel located in the engine compartment 2.5 liter models
HBC003BC
FWD socket
(without SPORTSHIFT mode)
Fuse panel
Fuse ratingCircuit
120A Radiator cooling fan (Main)
220ARadiator cooling fan (Sub)
350AABS motor
420ARear window defogger
515AHazard warning flasher
Horn
615AMeter
SRS airbag system warning light

12
Specifications12-11
–
CONTINUED –
Fuse panel Circuit
Fuse rating
710AAutomatic transmission control unit
ABS UNIT
810AAlternator
915AHeadlight (right side)
1015AHeadlight (left side)
1120ALighting switch
1215AClock
Interior light

12-12
3.0 liter models
HBC004BC
Fuse panelFuse ratingCircuit
130ARadiator cooling fan (Main)
230ARadiator cooling fan (Sub)
350AABS (VDC) motor
430AMcIntosh audio amp (if equipped)
520ARear window defogger
615AHazard warning flasher
Horn
715AMeter
SRS airbag system warning light
810AAutomatic transmission control unit
ABS UNIT
910AAlternator
1015AHeadlight (right side)

12
Specifications12-13
–
CONTINUED –
Fuse panel Circuit
Fuse rating
1115AHeadlight (left side)
1220ALighting switch
1315AClock
Interior light

12-14
Bulb chart
Wattage Bulb No.
Headlight GT and OUTBACK
Low beam 12V –55W H1
High beam 12V –60W 9005 (HB3)
Except GT and OUTBACK 12V –60/55W 9007 (HB5)
Front turn signal 12V –27W 1156NA (Amber)
Spot light 12V –8W —
Dome light 12V –8W —
Door step light 12V –3.4W —
Parking and front side marker light 12V –27/8W 1157NA (Amber)
Front fog light Except OUTBACK 12V –55W H3
OUTBACK 12V– 51W 9006 (HB4)
Backup light
Sedan 12V–27W 3156K
Station wagon 12V –27W 1156
Luggage area light 12V –13W —
High mount stop light
Sedan 12V–16W 921
Station wagon 12V –13W 912
Rear turn signal light Sedan 12V–21W —
Station wagon 12V –21W R2172 7440
Brake/tail light
Sedan 12V–27/8W 3157K
Station wagon 12V –27/8W 1157
Licence plate light Sedan 12V–5W 168
Station wagon 12V –3.8W or 5W 194 or 168
Trunk room light 12V –5W W5W

12
Specifications12-15
–
CONTINUED –
Vehicle identification
HBD002BB
1 Emission control label
2 Vehicle identification number
3 Radio noise label (Canada model)
4 Vacuum hose connectionslabel 5
Tire inflation pressure label
6 Certification and bar cordlabel
7 Vehicle identification numberplate
8 Model number plate

12-16
