2003 SUBARU LEGACY Owners Manual

6
Interior equipment6-9
–
CONTINUED –

Rear passenger ’s cup holder (if equipped)
HB6024BAHB7009CA
The rear passenger ’s cup holder is located on the lower side of the
back of the center console. To use the cup holder, open the lid by
pulling its upper edge.
Cigarette lighter socket (if equipped)
CAUTION
The electrical power socket located on the lower part of the
instrument panel is originally designed to use a SUBARU genuine
cigarette lighter plug. Do not use non-genuine cigarette lighterplugs in the socket. Doing so may cause a short-circuit and over-heating, resulting in a fire. If the socket is ever used for a plug-in accessory such as a
mobile phone, they may damage the portion of the socket ’s inter-
nal mechanism that causes a cigarette lighter plug to “pop out ”
after its lighter element is heated. Therefore, do not place a ciga-rette lighter plug in a socket that has been used, even once, to
power a plug-in accessory. Doing so may cause the plug to stickand overheat, creating a potential fire hazard. Do not place any foreign objects, especially metal ones such
as coins or aluminum foil, into the socket. That could cause ashort circuit.

6-10
HB6011BA
The electrical power socket located on the lower part of the instrument
panel can be used as cigarette lighter socket. A cigarette lighter plug is
an optional accessory. It is available from your SUBARU dealer.
The cigarette lighter socket may also be used as a power source for anin-car use electrical appliance.Use with a cigarette lighter
WARNING
To avoid being burned, never grasp the lighter by the end withthe heating element. Doing so could result in injury and couldalso damage the heating element.
CAUTION
Do not hold the lighter pushed in, because it will overheat.

6
Interior equipment6-11
–
CONTINUED –
HB6011DA
The cigarette lighter operates only when the ignition switch is in the
“ON” and “ACC” positions.
To use the cigarette lighter, push in the knob and wait a few moments.
It will automatically spring up when ready for use. Using as an accessory power outlet
Electrical power (12V DC) from the battery is on tap at the socket when the ignition switch is either in the “ACC” or “ON” position.
If you use the socket as an accessory power outlet, take the following
precautions.
When the socket is not in use, always put the cap on the socket to
prevent any foreign object from entering it.
CAUTION
Use only in-car use electrical appliances which are designed
for 12V DC and which consume less than 120W. Overloading the
socket can cause a short circuit. Do not use double adapters ormore than one electrical appliance. If the plug on your electric appliance is either too loose or too
tight for the socket, this can result in a poor contact or cause the
plug to get stuck. Only use plugs that fit properly. Use of an electric appliance in the socket for a long period of
time while the engine is not running can cause battery discharge. Before driving your vehicle, make sure that the plug and the
cord on your electrical appliance will not interfere with your shift-

6-12ing gears and operating the accelerator and brake pedals. If they do, do not use the electrical appliance while driving.
If the socket has been used for electrical appliances, damage may
have been done to the internal mechanism that cause a cigarette
lighter to “pop-out” after its element has been heated. For that reason,
a cigarette lighter, even if it is a genuine part, should not be used in
the socket. If you want to use the socket for a cigarette lighter again,
or to protect your purchaser before you sell your car, have your
SUBARU dealer replace the socket with a new one.
Ashtray
CAUTION
Do not use ashtrays as waste receptacles or leave a lighted ciga-
rette in an ashtray. This could cause a fire.
Fully close the ashtray after using it to help reduce residual smoke.
HB7009BA
HB6011CA
Front ashtray
To open the ashtray, pull the lid out. Rear ashtray (if equipped)
The rear ashtray is located on the upper side of the back of the center
console. To open the ashtray, pull the upper edge of the lid.

6
Interior equipment6-13
–
CONTINUED –
To remove the ashtray for cleaning, open it and pull it out while pushing the inner plate down. OnStar
 system (if equipped)
OnStar is a vehicle communications system that offers a variety of ser-
vices. OnStar provides a one-touch hands-free communication link be-
tween you and the OnStar Center, and allows you to make and receive
personal calls as well. To receive OnStar services, a service subscription
agreement is required and an additional fee may be required. Services
are available 24 hours a day, 7 days a week. For more information, call
1-888-ONSTAR7 (888-667-8277).
HB6027BB
OnStar services button
Press this button, and you will be connected to an OnStar Advisor.
You will hear a chime, followed by the words “Connecting to OnStar ”.
The connection process will normally take about 15 seconds. Your
system is equipped with backup connection retry capabilities. If you
do not immediately connect to OnStar, DO NOT DISCONNECT. A se-
ries of retry attempts will be made automatically. If you wish to cancel
your call to the OnStar center, simply press the OnStar Communica-
tion button. OnStar emergency button
In an emergency, press this button to connect with an OnStar Advisor. 1
Emergency button
2 OnStar service button
3 Communication button
4 System status light

6-14Your call will be given the highest priority, and you will hear a chime
followed by the words
“Connecting to OnStar Emergency. ” The Advi-
sor will attempt to locate your vehicle, find out what kind of assistance
you require, and contact a nearby emergency services provider who
can dispatch ambulance, fire, police or other emergency services.
Please use this button only for true emergencies. If you press this but-
ton by mistake, please stay on the line and tell the advisor that there
is no emergency. OnStar communication button (White DOT)
Press this button at the end of a call. You ’ll hear the words “OnStar
Request Ended. ” Also, press this button to answer a call from the
OnStar Center, or cancel a call if one of the other buttons is acciden-
tally pressed. This button is also used to access OnStar Personal
Calling and Virtual Advisor services, if those services have been acti-vated. System status light
Solid green – Indicates the OnStar system in the vehicle is pow-
ered ON and ready to make or receive calls. Blinking green – The light blinks green to indicate a call is being
connected or in progress. If you notice this light blinking while you are
not on a call, press the OnStar Communication (white dot) button. Red – This signals that your OnStar system may not be functioning
properly. Press the OnStar button to attempt to contact an OnStar ad-
visor. If the connection is made, the advisor will assist you in making
sure your OnStar system is operating properly. If you cannot contact
the OnStar Center, please take your vehicle to the nearest Subarudealership for diagnosis and service. Volume control
You can control the volume of the OnStar System using the volume
control knob on the radio.
OnStar subscription plans* The OnStar safe & sound plan
Choose this plan for excellent protection, 24/7, 365 days a year. It in-

6
Interior equipment6-15
–
CONTINUED –
cludes valuable services such as Automatic Notification of Air Bag Deployment, Remote Door Unlock** and Online Concierge services,to name just a few!
The OnStar directions & connections plan
This plan features all of the Safe & Sound services, plus Route Sup-
port, RideAssist and Information and Convenience services. The OnStar luxury & leisure plan
This plan features all of the Directions & Connections features, plus
fee-free OnStar MED-NET and the luxury of Personal Concierge ser-vices.
* One of these plans is normally included for a specific duration with each ve-
hicle at time of purchase. Check with your dealership or with your OnStar advi-
sor to determine which plan is included with your vehicle. Services within plans
are subject to change. Please check our website at www.onstar.com
for ser-
vices included in each plan.
** Remote door unlock capabilities vary by vehicle
OnStar services
The following services are available within OnStar service plans. Your ve-
hicle comes with a specific one-year service plan that allows use ofsome or all of the following services.
Automatic notification of air bag deployment
Should your air bag deploy, a priority signal will be sent to the OnStarCenter with your vehicle ’s location (as long as cellular service and the
vehicle’ s electrical system are operable). An advisor will attempt to
contact you to assess the nature of your emergency, and then notify
the necessary emergency services provider. Emergency services
Should you require emergency assistance, press the OnStar Emer-
gency button and we will contact a nearby emergency services pro-
vider with your exact location and your request for help. Roadside assistance***
There’ s nothing worse than being stranded on the road with car
trouble. No matter what the problem is (flat tire, out of gas, or engine

6-16trouble), just call OnStar. We will contact your vehicle manufacturer
’s
roadside service provider for the help you need to get you quickly
back on the road.
*** There will be no charge for Roadside Assistance as long as the basic lim-
ited warranty on your vehicle has not expired. Stolen vehicle location
OnStar doesn ’t just protect you, it protects your vehicle, too. If your
vehicle is ever stolen, just contact OnStar. We will put you in touch with the authorities and aid them in locating your vehicle. Ask your in-
surance carrier about possible premium discounts. AccidentAssist
AccidentAssist provides step-by-step guidance about what to do in
case of an accident. Working with leading insurance companies wehave developed a “best practices ” list to assist you through most ac-
cident situations. OnStar AccidentAssist can make the process of
completing a police report and/or insurance claim less stressful. Remote door unlock/vehicle alert
If you ’ve locked your keys in your vehicle, just call OnStar at
1-888-466-7827 (888-4ONSTAR) and an Advisor will send a signal to
attempt to unlock your door. If you ’re having trouble locating your ve-
hicle, OnStar can flash your lights and sound your horn for you. This
feature is disabled 48 hours after the vehicle is parked in order to
maintain battery charge. OnStar MED-NET****
OnStar MED-NET securely stores your personal medical information (e.g., physician ’s name, emergency contacts, medications, chronic
conditions) and in an emergency, can quickly send it to a medical fa-
cility. This important information can help assist with diagnosis and
treatment.
**** Requires activation and additional fee for Safe & Sound and Directions &
Connections subscribers. To enroll or for more OnStar Med-Net information,
call 1-800-320-3991.
