2003 SUBARU LEGACY Owners Manual

5
Audio5-33
–
CONTINUED –

While the player is in the loading mode, if you press FM/AM selec-
tion button, the player will enter standby mode. Press the “DISC” but-
ton to start playback. n Loading all the magazine (Full disc loading mode)
1. If you continue to press the “LOAD” button
E for more than 1.5 se-
conds, the player will produce beep sound and will enter the full disc
loading mode.
2. A “DISC” indicator will blink, and the “CD-IN” will be on display for
a period of 15 seconds. If a disc is successfully loaded during thisperiod, the “DISC” indicator will stop blinking and will steadily light.
3. When the loading of a disc is complete, the next “DISC” indicator
will blink. Then repeat Step 2.
4. When the magazine is filled with discs by repeating Steps 2 and 3,
the player will start playback of the discs, beginning with the one in-
serted first.
If you fail to insert any disc during each 15-second interval, the full
disc loading mode will be canceled, and the player will start playback
of the disc inserted first. How to play back a CD or make a pause
n When there is no CD inserted:
Insert a CD by referring to “How to Insert a CD(s) ”.
When a CD is loaded, the player will start playback of the CD, begin-
ning with the first number. n When there are CDs loaded:
Press a desired one of the “DISC SELECT ” buttons
U the “DISC” indi-
cator of which steadily lights up. The player will then start playback of
the selected CD, beginning with the first number.

5-34
Selecting a desired track (TRACK)
HB5065BA
nSkipping forward
Turn the FF ·FB dial T clockwise and release it immediately to skip to
the beginning of the next track. Each time the knob is turned and re-
leased, the indicated track number will increase. n Skipping backward
Turn the FF ·FB dial
T counterclockwise and release it immediately to
skip to the beginning of the current track. If you continue to turn and
release the knob, the indicated truck number will decrease. n Fast forwarding
Turn the FF ·FB dial T clockwise and hold it continuously for more than
0.5 second to fast forward the disc.
Release the knob to stop fast forwarding. n Fast reversing
Turn the FF ·FB dial T counterclockwise and hold it continuously for
more than 0.5 second to fast reverse the disc.
Release the knob to stop fast reverse. Repeat playback
Press the “RPT” button R while a song is playing to play the song
repeatedly. The “RPT” indicator will come on and the song will be
played continuously. To cancel the repeat mode, press the button
again. Then the “RPT” indicator goes out, and normal playback mode
is restored.
❚: Skipping forward
❚ : Skipping backward
: Fast forwarding
: Fast reversing

5
Audio5-35
–
CONTINUED –

How to unload CDs from the player
n Ejecting a CD from the player
Of the discs loaded, you can select and remove only one disc.
1. Press the “DISC SELECT ” button U of the disc whose “DISC” indi-
cator is ON.
2. Press the “EJECT” button
W. Then the “DISC” indicator associated
with the disc you have selected will blink, and the disc will be ejected.
To remove more discs in succession, repeat Steps 1 and 2. n Ejecting all discs from the player (All disc ejection mode)
1. If you continue to press the “EJECT” button W, the player will pro-
duce beep sound and will enter the all disc ejection mode.
2. Remove the disc that has been ejected. The other discs loaded
will then be ejected one after another. If you do not remove the discthat has been ejected, the “All disc ejection mode ” will be canceled.
NOTE
Avoid driving the vehicle with a CD sticking out, because vibra- tion might make it fall out.
OnStar  system operation (models with OnStar  sys-
tem) When the OnStar system operates and a call is initiated, the message
”PHONE” will be shown on the display, and the speakers will automati-
cally switch over to the incoming voice signal. NOTE A call will not be suspended even if the ignition key is turned to the
Off position. In such a case, however, the audio system will turn offwhen the call is ended.

5-36In-dash 6 CD auto changer (if equipped)
HB5040BB
1 Disc slot
2 Disc indicators (disc No.1 to 6) 3
Disc select buttons (disc No.1 to 6)
4 Eject button
CAUTION
Do not attempt to insert two or more discs into the slot at a
time. Doing so can cause mechanical damage to the CD changer. Use only music CDs identified by a
mark.
Do not use CDs listed below which could cause damage to the
CD player.
3-inch (8 cm) compact disc.
Any disc with a peel-off or seal on it.
Any disc with scratches and/or dust.
Bent disc.
Cleaning disc.
CD accessory. (E.g., 3-inch (8 cm) disc adapter)
Do not insert or remove any disc when the automatic transmis-
sion selector lever is in the park position; the selector lever in that position can interfere with disc insertion or removal, causing
scratches on the disc surface (for AT vehicles).

5
Audio5-37
–
CONTINUED –

To insert a disc
1. Press one of the “Disc select ” buttons 3 (numbered from 1 to 6)
for which the disc indicator light 2 is “OFF”.
The Disc indicator lights are located directly above the corresponding “ Disc select ” buttons.
2. The indicator will begin blinking. The blinking will last for 15 se-conds.
During this period, insert a desired disc, and the disc will begin to
play. (If any disc is not inserted during this period, the “Disc slot ”
1
door will close. Repeat step 1.)
Be sure to hold a disc with the label side (the side where titles areprinted) up.
3. To insert another disc, repeat step 1 and 2 choosing a differentdisc select button. To insert six discs at a time
1. Press and hold the “Disc select ” button number 1 until all disc indi-
cators begin blinking (about 1.5 seconds).
2. The indicators will blink for 15 seconds. During this period, insert
desired six discs.
3. When all discs are loaded, the first disc will begin to play. (If no
disc is inserted within this 15 seconds, the entire disc load sequencewill be canceled.) To remove a disc
1. Press the desired one of the “Disc select ” buttons
3 (numbered
from 1 to 6) for which the disc indicator light is on.
2. Press the “Eject button ”
4 . The selected disc will be ejected and
the indicator light will begin blinking.
3. To remove another disc, repeat step 1 and 2 choosing a different“ Disc select ” button.
(To remove discs when the ignition switch is in the “Lock” position,
press the “Eject” button, and the first disc will be ejected. Press the
“Eject” button again, and the next disc will be ejected and so on. At
this time, the “Disc select ” buttons are disabled.)

5-38
To remove all discs at one time
1. Press and hold the “Eject” button 4 until all “Disc” indicators begin
blinking (about 1.5 seconds), and the first disc will be ejected.
2. When the disc is removed, the next one will be ejected, and so on. To replace a playing disc with another
Simply press the desired one of “Disc select ” buttons
3 (numbered
from 1 to 6) or press the “DISC UP ” or “DISC DOWN ” button on the
radio unit to select the desired disc, and the disc will begin to play. Disc indicators
Lit: when the corresponding storage tray is occupied by a disc. Blinking: Disc player is either in loading, eject or changing mode.OFF: No disc is loaded or the ignition switch is in the “LOCK” position.
Function control
Refer to CD player control operating instructions described in the“ Type A and B audio sets ” or “Type C audio set ” section.

55
Audio5-39
–
CONTINUED –
Precautions to observe when handling a compact disc (CD)
Use only compact discs (CDs) that have the mark shown below. CD-
RWs cannot be used. Also, some CD-Rs cannot be played.
HB5062AA

In cold and/or rainy weather, dew can form inside the CD player, pre-
venting normal operation. If this happens, eject the CD and wait for the
player to dry out. Skipping may occur when the CD player is subjected to severe vibra-
tion (for example, when the vehicle is driven on a rough surface). To remove a disc from the case, press the center of the case and hold
both edges of the disc. If the disc surface is touched directly, contamina-
tion could cause poor tone quality. Do not touch the disc surface. Use a clean disc whenever possible. If there are deposits, wipe the
disc surface from the center outward with a dry, soft cloth. Be sure not to
use a hard cloth, thinner, benzene, alcohol, etc. Do not use any disc that is scratched, deformed, or cracked. Also, do
not use any disc that has a non-standard shape (for example, a heart
shape). Malfunctions or problems might result. A disc is vulnerable to heat. Never keep it either in places exposed to
direct sunlight, near heaters or in vehicles parked in the sun or hot days.

5-40HB5061BA
