2003 SUBARU LEGACY Owners Manual

2
Keys and doors2-7
–
CONTINUED –
HB1000BE
Locking the doors
Briefly press the “LOCK/ARM” button (for less than two seconds) to
lock all doors (and rear gate on the station wagon). An electronic
chirp will sound one time and the turn signal lights will flash one time.
If any of the doors (or the rear gate) is not fully closed, an electronic
chirp will sound five times and the turn signal lights will flash five
times to alert you that the doors (or the rear gate) are not properly
closed. When you close the door, it will automatically lock.
NOTE If the “LOCK/ALARM” button is pressed for two seconds or long-
er, the panic alarm will sound. When locking the doors in normal
circumstances, press the “LOCK/ALARM” button for less than
two seconds. For details on the panic alarm, refer to “Sounding
the panic alarm ”.
Unlocking the doors
Briefly press the “UNLOCK/DISARM” button (for less than two
seconds) to unlock the driver ’s door. An electronic chirp will sound
two times and the turn signal lights will flash two times. To unlock all
doors (and rear gate on the station wagon), briefly press the
“UNLOCK/DISARM” button a second time within 5 seconds.
NOTE If the interval between the first and second presses of the “UN-

2-8LOCK/DISARM”
button (for unlocking of all of the doors and the
rear gate) is extremely short, the system may not respond. Illuminated entry
The interior (dome) light will illuminate when the “UNLOCK/DISARM”
button is pressed. These lights stay illuminated for approximately 30
seconds if any of the doors (or the rear gate on the station wagon) isnot opened.If the “LOCK/ARM” button is pressed before 30 seconds have
elapsed, these lights will go out. Also, these lights will go out if the key
is inserted in the ignition switch. The interior light must be set to the
middle position in order for this function to operate.
Vehicle finder function
Use this functon to find your vehicle parked among many vehicles in a
large parking lot. Provided you are within 30 feet (10 meters) of the ve-
hicle, pressing the “LOCK/ARM” button three times in a five-second peri-
od will cause your vehicle ’s horn to sound one time and its turn signal
lights to flash three times.
Sounding a panic alarm
To activate the alarm, keep the “LOCK/ARM” button pressed for more
than two seconds .
The horn will sound and the turn signal lights will flash.
To deactivate it, press the “LOCK/ARM” button or “UNLOCK/DISARM”
button. Unless a button on the remote is pressed, the alarm will be
deactivated after approximately 30 seconds. Selecting audible signal operation
Using an electronic chirp, the system will give you an audible signal
when the doors lock and unlock. If desired, you may turn the audible
signal off.
To turn the audible signal off, unlock the doors by pushing “UNLOCK/
DISARM” button and then simultaneously depress “LOCK/ARM” and
“UNLOCK/DISARM” buttons for more than two seconds. An electronic
chirp will sound two times and the turn signal lights will flash two
times to inform you that the audible signal has been turned off.

2
Keys and doors2-9
–
CONTINUED –
To turn the audible signal on, unlock the doors by pushing
“UNLOCK/
DISARM” button and then simultaneously depress “LOCK/ARM” and
“UNLOCK/DISARM” buttons for more than two seconds. An electronic
chirp will sound one time and the turn signal lights will flash two times
to inform you that the audible signal has been turned on. Replacing the battery CAUTION
Do not let dust, oil or water get on or in the transmitter when
replacing the battery.
When the transmitter battery begins to get weak, transmitter range will
begin to decrease and the LED will not illuminate. Replace the batteryas soon as possible.
HB1002BB
HB1001BA
Positive (+) side facing up
To replace the battery:
1. Remove the two screws on the back of the transmitter case by
using a phillips screwdriver.
2. Separate the case.
3. Remove the old battery from the holder.
4. Replace with a new battery (Type CR2032 or equivalent) making
sure to install the new battery with the positive (+) side facing up.
5. Install the back half of the transmitter case.
6. Reinstall the two screws on the back of the transmitter case.
After the battery is replaced, the transmitter must be synchro-

2-10nized with the keyless entry system
’s control unit. Press either
the “LOCK/ARM” or “UNLOCK/DISARM” button six times to syn-
chronize the unit. Replacing lost transmitters
If you lose a transmitter or want to purchase additional transmitters
(up to four can be programmed), you should re-program all of your
transmitters for security reasons. It is recommended that you have
your dealer program all of your transmitters into your system. n Programming the transmitters
The keyless entry system is equipped with a special code learning
feature that allows you to program new transmitter codes into the sys-
tem or to delete old ones. The system can learn up to four uniquetransmitter codes. The four transmitter codes may be the same or dif-
ferent.
To enter the programming mode:
HB1005BC
HB1000CB
1 Press to dis-
arm the security system (if so equipped).
2
3
1. Disarm the security system. (if your vehicle is equipped with the
optional security system.)
2. Open the driver ’s door and sit in the driver ’s seat.
3. Close the driver ’s door.

2
Keys and doors2-11
–
CONTINUED –
HB2032BB
4. Place the ignition key into the ignition switch and cycle the switch
from LOCK to ON ten times within 15 seconds. Be sure to stop at the
LOCK position. The horn will sound once to indicate that you are in
the transmitter programming mode.
NOTE
You must finish the next step (opening the driver ’s door) within
45 seconds of starting this procedures.
To program the transmitters:
HB1000DB
1
2
HB1005BB3 Press any button.
1. Open the driver ’s door.
2. Close the driver ’s door.
3. Press and release any button on the transmitter that you wish to
program into the system. The horn will sound two times to indicate

2-12that the transmitter has been programmed.
Any additional transmitters can also be programmed at this time.
Repeat steps 1 through 3 for an additional transmitter.
To exit the programming mode:
1. After all of your transmitters are programmed, remove the key fromthe ignition switch.
The horn will sound three times to indicate that the system has exited
the programming mode.
2. Make sure that the keyless entry system properly operates by
operating each transmitter. n
Deleting old transmitter codes
The control unit of the keyless entry system has four memory loca-
tions to store transmitter codes, giving it the ability to operate with up
to four transmitters. When you lose a transmitter, the lost transmitter ’s
code remains in the memory. For security reasons, lost transmitter
codes should be deleted from the memory.
To delete old transmitter codes, program four transmitter codes into
the system. If you have only one current transmitter, program it four
times. If you have two current transmitters, program each one twice. If
you have three current transmitters, program two of them once and
the third one twice. This process will leave only current transmittercodes in the system ’s memory.
NOTE
Make sure no one else is operating their keyless entry system within range of your vehicle when programming transmitters. If
someone else were to operate their remote transmitter while youare programming your transmitters, it is possible that their trans-mitter code will be programmed into your system, allowing themunauthorized access to your vehicle.

2
Keys and doors2-13
–
CONTINUED –
Security system (if equipped)
The security system helps to protect your vehicle and valuables from
theft. The horn sounds and the turn signal lights flash if someone
attempts to break into your vehicle. The starter motor is also interrupted
to prevent starting the vehicle without a key.
The system can be armed and disarmed with the remote transmitter.
The system does not operate when the key is inserted into the ignitionswitch.
System operation
The security system will give the following alarm indications when trig-
gered: The turn signal lights will flash and the horn will sound intermit-
tently. In addition, the starter motor will not operate. The alarm automatically resets after 30 seconds; however, the
alarm will reactivate if the vehicle is tampered with again. The alarmwill continue for six times if any sensor continues to be activated.
The alarm is triggered by: Opening a door, the rear gate or trunk lid.
Application of physical shock to the vehicle (e.g. breaking glass or
forced entry). Note that there are two alarm levels for shock: warning
and alarm. In warning mode, the alarm detects lower level vibrations
and triggers 2 warning chirps on the horn and two flashes on the
lights as a deterrent to would be vandals. In alarm mode, higher lev-
els of shock are detected and the system will go into full alarm. Ignition switch being turned on while in armed state.
NOTE
With the valet mode selected, the security system does not oper-
ate and the parking lights do not flash when the remote transmit-ter is used for locking and unlocking.The security system indicator light in the combination meter
flashes twice per second to show that the valet mode is selected.For details, refer to “Valet mode ” in this section.

2-14
Arming the system
n To arm the system using remote transmitter
HB2033BB
Press to Arm the system. Press to Disarm the system.
HB1000EB
1. Close all windows and moonroofs (if so equipped).
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood (and the trunk lid) are locked.
5. Close all doors (and the rear gate on the station wagon).
6. Briefly press the “LOCK/ARM” button (for less than two seconds).
All doors (and the rear gate on the station wagon) will lock, an elec-
tronic chirp will sound one time, the turn signal lights will flash one
time and the indicator light starts flashing slowly (approximately once
every two seconds).
If any of the doors, (rear gate or trunk lid) is not fully closed, an elec-
tronic chirp sounds five times, the turn signal lights flash five times to
alert you that the doors (or the rear gate) are not properly closed.
When you close the door, the system will automatically arm and doorswill automatically lock.
