2003 SUBARU IMPREZA Owners Manual

22
Tire changing tools
1) Jack (page 9-24)
2) Jack handle (page 9-24)
3) Spare tire (page 9-24)

1
1-1
– CONTINUED –
Front seats 1-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fore and aft adjustment 1-3 . . . . . . . . . . . . . . . . . . . . . . . . . .
Reclining the seatback 1-4 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat cushion height adjustment
(driver’ s seat) 1-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Head restraint adjustment 1-5 . . . . . . . . . . . . . . . . . . . . . . .
Seat heater (if equipped) 1-6 . . . . . . . . . . . . . . . . . . . . . . . . .
Rear seats 1-8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Armrest (if equipped) 1-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headrest adjustment – Wagon 1-10 . . . . . . . . . . . . . . . . . .
Folding down the rear seat – Wagon 1-11 . . . . . . . . . . .
Seatbelts 1-12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seatbelt safety tips 1-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency Locking Retractor (ELR) 1-14 . . . . . . . . . .
Automatic/Emergency Locking Retractor (A/ELR) 1-14
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seatbelt warning light and chime 1-15 . . . . . . . . . . . . . . .
Fastening the seatbelt 1-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seatbelt maintenance 1-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front seatbelt pretensioners 1-27 . . . . . . . . . . . . . . . . . . . .
System monitors 1-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
System servicing 1-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Precautions against vehicle modification 1-30 . . . . .
Child restraint systems 1-31 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing child restraint systems with seatbelt 1-34
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation of child restraint systems by use of lower and tether anchorages 1-36 . . . . . . . . . Top tether anchorages 1-39
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
SRS airbag
(Supplemental Restraint System airbag) 1-42 .
Vehicle with driver ’s and front passenger ’s
SRS airbags and lap/shoulder restraints 1-42 . . . .
SRS frontal airbag 1-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SRS side airbag (if equipped) 1-55 . . . . . . . . . . . . . . . . . . .
SRS airbag system monitors 1-63 . . . . . . . . . . . . . . . . . . . .
SRS airbag system servicing 1-64 . . . . . . . . . . . . . . . . . . . .
Precautions against vehicle modification 1-66 . . . . .
Seat, seatbelt and SRS airbags

Seat, seatbelt and SRS airbags
1-2
Front seats
WARNING
Never adjust the seat while driving to avoid
the possibility of loss of vehicle control and of
personal injury. Before adjusting the seat, make sure the
hands and feet of rear seat passengers areclear of the adjusting mechanism. Seatbelts provide maximum restraint when
the occupant sits well back and upright in the
seat. To reduce the risk of sliding under the
seatbelt in a collision, the front seatbacksshould be always used in the upright position
while the vehicle is running. If the front seat-
backs are not used in the upright position in a
collision, the risk of sliding under the lap belt
and of the lap belt sliding up over the abdo-men will increase, and both can result in seri-ous internal injury or death.
WARNING
Put children aged 12 and under in the rear seat
properly restrained at all times. The SRS airbag
deploys with considerable speed and force and
can injure or even kill children, especially if
they are 12 years of age and under and are not
restrained or improperly restrained. Because
children are lighter and weaker than adults,
their risk of being injured from deployment is
greater. For that reason, we strongly recom-
mend that ALL children (including those in
child seats and those that have outgrown child

Seat, seatbelt and SRS airbags
1-3
– CONTINUED –
restraint devices) sit in the REAR seat properly
restrained at all times in a child restraint device
or in a seatbelt, whichever is appropriate for
the child’s age, height and weight. Secure ALL
types of child restraint devices (including for-
ward facing child seat) in the REAR seats at all times.
NEVER INSTALL A REARWARD FACING CHILD
SEAT IN THE FRONT SEAT. DOING SO RISKS
SERIOUS INJURY OR DEATH TO THE CHILD
BY PLACING THE CHILD ’S HEAD TOO CLOSE
TO THE SRS AIRBAG.
According to accident statistics, children are
safer when properly restrained in the rear seat-
ing positions than in the front seating posi-
tions. For instructions and precautions con-
cerning child restraint systems, see the “Child
restraint systems ” section in this chapter.
Fore and aft adjustment
Pull the lever upward and slide the seat to the de-
sired position. Then release the lever and move the
seat back and forth to make sure that it is securelylocked into place.

Seat, seatbelt and SRS airbags
1-4
Reclining the seatback
Pull the reclining lever up and adjust the seatback to
the desired position. Then release the lever and
make sure the seatback is securely locked intoplace.
The seatback placed in a reclined position can
spring back upward with force when released.
When operating the reclining lever to return the seat- back, hold it lightly so that it may be raised back
gradually.WARNING
To prevent the passenger from sliding under the seatbelt in the event of a collision, alwaysput the seatback in the upright position whilethe vehicle is in motion. Also, do not place
objects such as cushions between the pas- senger and the seatback. If you do so, the risk of sliding under the lap belt and of the lap belt
sliding up over the abdomen will increase,and both can result in serious internal injuryor death.

Seat, seatbelt and SRS airbags
1-5
– CONTINUED –
Seat cushion height adjustment
(driver’ s seat)
1) When the lever is pushed down, the seat is lowered.
2) When the lever is pulled up, the seat rises.
The height of the seat can be adjusted by moving the seat cushion adjustment lever up and down.
Head restraint adjustment
To raise the head restraint, pull it up.
To lower it, push the head restraint down while
pressing the release button on the top of the seat-back.
The head restraint should be adjusted so that the
center of the head restraint is closest to the top of the occupant ’s ears.

Seat, seatbelt and SRS airbags
1-6
WARNING
Never drive the vehicle with the head re-
straints removed because they are designedto reduce the risk of serious neck injury in the
event that the vehicle is struck from the rear.Seat heater (if equipped)
The seat heater operates when the ignition switch is
either in the
“ACC” or “ON” position.
To turn on the seat heater, push the “LO” or “HI”
position on the switch, as desired, depending on the
temperature. Selecting the “HI” position will cause
the seat to heat up quicker.

Seat, seatbelt and SRS airbags
1-7
– CONTINUED –
1)HI – Rapid heating
2) LO – Normal heating
The indicator located on the switch comes on when the seat heater is in operation. When the vehicle ’s in-
terior is warmed enough or before you leave the ve-
hicle, be sure to turn the switch off.
CAUTION
There is a possibility that people with deli-
cate skin may suffer slight burns even at low
temperatures if he/she uses the seat heater for a long period of time. When using the
heater, always be sure to warn the persons concerned.
Do not put anything on the seat which insu-
lates against heat, such as a blanket, cushion,or similar items. This may cause the seat heat-er to overheat.
NOTE Use of the seat heater for a long period of time
while the engine is not running can cause battery discharge. When cleaning the seat, do not use benzine,
paint thinner, or any similar materials.
