2003 SUBARU IMPREZA Owners Manual

Driving tips
8-36
safety’s sake, you should employ extra cau-
tion when towing a trailer and you should
never speed. You should also keep the follow-ing tips in mind:
Before starting out on a trip
Check that the vehicle and vehicle-to-hitch mount-
ing are in good condition. If any problems are
apparent, do not tow the trailer. Check that the vehicle sits horizontally with the
trailer attached. If the vehicle is tipped sharply up at
the front and down at the rear, check the total trailer
weight, GVW, GAWs and tongue load again, then
confirm that the load and its distribution are accept-able. Check that the tire pressures are correct.
Check that the vehicle and trailer are connected
properly. Confirm that
–the trailer tongue is connected properly to the
hitch ball.– the trailer lights connector is connected prop-
erly and trailer ’s brake lights illuminate when the
vehicle’ s brake pedal is pressed, and that the trail-
er’ s turn signal lights flash when the vehicle ’s turn
signal lever is operated.– the safety chains are connected properly. –
all cargo in the trailer is secured safety in posi-
tion.– the side mirrors provide a good rearward field of
view without a significant blind spot.
Sufficient time should be taken to learn the “feel”
of the vehicle/trailer combination before starting out
on a trip. In an area free of traffic, practice turning, stopping and backing up.
Driving with a trailer
You should allow for considerably more stopping
distance when towing a trailer. Avoid sudden brak-
ing because it may result in skidding or jackknifing
and loss of control. Avoid abrupt starts and sudden accelerations. If
your vehicle has a manual transmission, always start
out in first gear and release the clutch at moderate
engine revolution. Avoid uneven steering, sharp turns and rapid lane
changes. Slow down before turning. Make a longer than
normal turning radius because the trailer wheels will
be closer than the vehicle wheels to the inside of the
turn. In a tight turn, the trailer could hit your vehicle. Crosswinds will adversely affect the handling of
your vehicle and trailer, causing sway. Crosswindscan be due to weather conditions or the passing of

Driving tips
8-37
– CONTINUED –
large trucks or buses. If swaying occurs, firmly grip the steering wheel and slow down immediately but
gradually.When passing other vehicles, considerable dis-
tance is required because of the added weight and
length caused by attaching the trailer to your vehicle.
1) Left turn 2) Right turn
Backing up with a trailer is difficult and takes
practice. When backing up with a trailer, never
accelerate or steer rapidly. When turning back, gripthe bottom of the steering wheel with one hand and
turn it to the left for a left turn, and turn it to the right for a right turn.
If the ABS warning light illuminates while the
vehicle is in motion, stop towing the trailer and have
repairs performed immediately by the nearest
SUBARU dealer.
Driving on grades
Before going down a steep hill, slow down and
shift into lower gear (if necessary, use 1st gear) in
order to utilize the engine braking effect and prevent
overheating of your vehicle ’s brakes. Do not make
sudden downshifts. When driving uphill in hot weather, the air condi-
tioner may turn off automatically to protect the
engine from overheating. When driving uphill in hot weather, pay attention to
the water temperature gauge pointer (for all
vehicles) and AT OIL TEMP warning light (for AT
vehicles) since the engine and transmission are rel-
atively prone to overheating under these conditions.
If the water temperature gauge pointer approaches
the OVERHEAT zone or the AT OIL TEMP warning
light illuminates, immediately switch off the air condi-
tioner and stop the vehicle at the nearest safe place.Refer to the “Engine overheat ” section in chapter 9,
and “Warning and indicator lights ” section in chap-
ter 3.

Driving tips
8-38
If your vehicle has an automatic transmission,
avoid using the accelerator pedal to stay stationary on an uphill slope instead of using the parking brakeor foot brake. That may cause the transmission fluid
to overheat. Also, if your vehicle is equipped with an
automatic transmission, avoid driving with the gear selector lever in “D” when towing a heavy trailer to
prevent fluid overheating. A lower gear should be used.
Parking on a grade
Always block the wheels under both vehicle and
trailer when parking. Apply the parking brake firmly.
You should not park on a hill or slope. But if parking on a hill or slope cannot be avoided, you shouldtake the following steps:
1. Apply the brakes and hold the pedal down.
2. Have someone place wheel blocks under boththe vehicle and trailer wheels.
3. When the wheel blocks are in place, release the
regular brakes slowly until the blocks absorb theload.
4. Apply the regular brakes and then apply the
parking brake; slowly release the regular brakes.
5. Shift into 1st or reverse gear (manual transmis- sion) or “P” (automatic transmission) and shut off the
engine.

9
9-1
– CONTINUED –
If you park your vehicle in case of
an emergency 9-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temporary spare tire (if equipped) 9-3 . . . . . . . . . . . .
Flat tires 9-5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a flat tire 9-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump starting 9-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to jump start 9-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine overheating 9-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If steam is coming from the engine compartment 9-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If no steam is coming from the engine compartment 9-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Towing 9-18
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Towing and tie-down hooks 9-19 . . . . . . . . . . . . . . . . . . . . .
Using a flat-bed truck 9-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Towing with all wheels on the ground 9-22 . . . . . . . . .
Maintenance tools 9-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jack and jack handle 9-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In case of emergency

In case of emergency
9-2
If you park your vehicle in case of an emergency
The hazard warning flasher should be used in day
or night to warn other drivers when you have to parkyour vehicle under emergency conditions.
Avoid stopping on the road. It is best to safely pull
off the road if a problem occurs.
The hazard warning flasher can be activated
regardless of the ignition switch position.
Turn on the hazard warning by pushing the hazard
warning flasher switch. Turn it off by pushing theswitch again.NOTE When the hazard warning flasher is on, the turn
signals do not work.

In case of emergency
9-3
– CONTINUED –
Temporary spare tire (if equipped)
The temporary spare tire is smaller and lighter than
a conventional tire and is designed for emergency
use only. Remove the temporary spare tire and re-
install the conventional tire as soon as possible be-
cause the spare tire is designed only for temporary use.
Check the inflation pressure of the temporary spare
tire periodically to keep the tire ready for use. The
correct pressure is 60 psi (4.2 kg/cm2
, 420 kPa) .
When using the temporary spare tire, note the fol-lowing: Do not exceed 50 mph (80 km/h).
Do not put a tire chain on the temporary spare tire.
Because of the smaller tire size, a tire chain will not
fit properly. Do not use two or more temporary spare tires at
the same time. Do not drive over obstacles. This tire has a smaller
diameter, so road clearance is reduced.
1) Tread wear indicator bar
2) Indicator location mark
When the wear indicator appears on the tread, re-
place the tire.

In case of emergency
9-4
1) Spare fuse
2) FWD connector
NOTE
(If your vehicle is AWD with automatic transmis-
sion, except Turbo models) Before driving your
vehicle with the temporary spare tire, put a spare fuse inside the FWD connector in the main fuse box located in the engine compartment and con-firm that the Front-wheel drive warning light
“FWD” in the combination meter comes on. The
all wheel drive capability of the vehicle has now
deactivated. After re-installing the conventional tire, remove the spare fuse from the FWD con- nector in order to reactivate all wheel drive.
WARNING
Never tow a trailer when the temporary spare tire is used. The temporary spare tire is not
designed to sustain the towing load. Use ofthe temporary spare tire when towing can result in failure of the spare tire and/or less
stability of the vehicle and may lead to anaccident.
CAUTION
Never use any temporary spare tire other than the original. Using other sizes may result in
severe mechanical damage to the drive trainof your vehicle.

In case of emergency
9-5
– CONTINUED –
Flat tires
If you have a flat tire while driving, never brake sud- denly; keep driving straight ahead while gradually
reducing speed. Then slowly pull off the road to asafe place. Changing a flat tire
WARNING
Do not jack up the vehicle on an incline or a
loose road surface. The jack can come out of
the jacking point or sink into the ground and this can result in a severe accident. Use only the jack provided with your ve-
hicle. The jack supplied with the vehicle is de-signed only for changing a tire. Never get un-der the vehicle while supporting the vehicle with this jack. Always turn the engine off before raising the
flat tire off the ground using the jack. Neverswing or push the vehicle supported with the
jack. The jack can come out of the jackingpoint due to a jolt and this can result in a
severe accident. 1. Park on a hard, level surface, whenever possible,
then stop the engine.
2. Set the parking brake securely and shift a manual
transmission vehicle in reverse or an automatictransmission vehicle in the
“P” (Park) position.
3. Turn on the hazard warning flasher and have ev-
eryone get out of the vehicle.
4. Put wheel blocks at the front and rear of the tire
diagonally opposite the flat tire.
