2003 SUBARU IMPREZA Owners Manual

Seat, seatbelt and SRS airbags
1-64
Frontal airbag module (Passenger ’s side)
Side airbag sensor (Driver ’s side — if equipped)
Side airbag sensor (Passenger ’s side — if
equipped) Side airbag module (Driver ’s side — if equipped)
Side airbag module (Passenger ’s side — if
equipped) Seatbelt pretensioner (Driver ’s side)
Seatbelt pretensioner (Passenger ’s side)
All related wiring
In the event of a malfunction indicated by any of fol-
lowing, the vehicle should be taken promptly to your
nearest SUBARU dealer to have the system
checked. Unless checked and repaired, the SRS
airbags will not function reliably: Flashing or flickering of the indicator light.
No illumination of the warning light when the igni-
tion switch is first turned to the “ON” position.
Continuous illumination of the warning light.
Illumination of the warning light while driving.
SRS airbag system servicing
WARNING
When discarding an airbag module or scrap-
ping the entire car damaged by a collision,
consult your SUBARU dealer. The SRS airbag has no user-serviceable
parts. Do not use electrical test equipment on any circuit related to the SRS airbag system.For required servicing of the SRS airbag, see
your nearest SUBARU dealer. Tampering withor disconnecting the system ’s wiring could re-
sult in accidental inflation of the SRS airbag
or could make the system inoperative, which
may result in serious injury. The wiring har-
nesses of the SRS airbag system are coveredwith yellow insulation and system connectorsare yellow for easy identification.

Seat, seatbelt and SRS airbags
1-65
– CONTINUED –
CAUTION
If you need service or repair in areas listed be-
low, we recommend that you have an autho-
rized SUBARU dealer perform the work. The
SRS airbag control module, impact sensors
and airbag modules are stored in these areas.Under the center console
Inside each front fender
Steering wheel and column and nearby
areas Top of the dashboard on front passenger ’s
side and nearby areas Each front seat and nearby area (only for ve-
hicles with SRS side airbags) Inside each center pillar
In the event that the SRS airbag is deployed, re-
placement of the system should be performed
only by an authorized SUBARU dealer. When the
components of the SRS airbag system are re-
placed, use only genuine SUBARU parts.
To ensure their long-term reliability, the SRS airbags must be inspected by a SUBARU dealer ten years
after the date of manufacture, which is shown on the
certification plate attached to the driver ’s door jamb. NOTE In the following cases, contact your SUBARU dealer as soon as possible.
The front part of the vehicle was involved in an
accident in which the SRS frontal airbags did not
deploy. The pad section of the steering wheel or front
passenger’ s frontal airbag cover is scratched,
cracked, or otherwise damaged. In addition, if your vehicle is equipped with SRS side airbags, contact your SUBARU dealer assoon as possible in the following cases. Either center pillar or a nearby area of the ve-
hicle was involved in an accident in which the
SRS side airbag did not deploy. The fabric or leather of either front seatback is
cut, frayed, or otherwise damaged.

Seat, seatbelt and SRS airbags
1-66
Precautions against vehicle modifica- tion
WARNING
To avoid accidental activation of the system
or rendering the system inoperative, which
may result in serious injury, no modifications should be made to any components or wiring of the SRS airbag system.This includes following modifications: Installation of custom steering wheels
Attachment of additional trim materials to
the dashboard Installation of custom seats (for vehicles
with SRS side airbags only) Replacement of seat fabric or leather (for
vehicles with SRS side airbags only) Installation of additional fabric or leather
on the front seat (for vehicles with SRS side airbags only)
Installation of additional electrical/electronic
equipment such as a mobile two-way radio on or near the SRS airbag system componentsand/or wiring is not advisable. This could in-
terfere with proper operation of the SRS air- bag system.
CAUTION
Do not perform any of the following modifica- tions. Such modifications can interfere with proper operation of the SRS airbag system. Attachment of any equipment (brush bar,
winches, snow plow, skid plate, etc.) otherthan SUBARU genuine accessory parts to thefront end. Modification of the suspension system or
front end structure. Installation of a tire of different size and
construction from the tires specified on thetire placard attached to the driver ’s door jamb.
Attachment of any equipment (side steps or
side sill protectors, etc.) other than SUBARU genuine accessory parts to the side body (for
vehicles with side airbags only).
Always consult your SUBARU dealer if you want to
install any accessory parts to your vehicle.

2
2-1
– CONTINUED –
Keys 2-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key number 2-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door locks 2-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Locking and unlocking from the outside 2-3 . . . . . .
Locking and unlocking from the inside 2-4 . . . . . . .
Power door locking switches
(if equipped) 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Remote keyless entry system (if equipped) 2-6 Locking the doors 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Unlocking the doors 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illuminated entry 2-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sounding a panic alarm 2-8 . . . . . . . . . . . . . . . . . . . . . . . . . .
Selecting audible signal operation 2-8 . . . . . . . . . . . . .
Replacing the battery 2-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing lost transmitters 2-10 . . . . . . . . . . . . . . . . . . . . . .
Security system (if equipped) 2-14 . . . . . . . . . . . . . . . . . .
System operation 2-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Arming the system 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disarming the system 2-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sounding a panic alarm 2-17 . . . . . . . . . . . . . . . . . . . . . . . . . .
Valet mode 2-17
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Passive arming 2-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Child safety locks 2-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windows 2-22
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power windows 2-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trunk lid (Sedan) 2-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
To open and close the trunk lid from outside 2-26
To open the trunk lid from inside 2-26 . . . . . . . . . . . . . . . To cancel the trunk lid release 2-27
. . . . . . . . . . . . . . . . . .
Internal trunk lid release handle 2-27 . . . . . . . . . . . . . . . .
Rear gate (Wagon) 2-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keys and doors

Keys and doors
2-2
Keys
1) Master key
2) Submaster key3) Valet key
4) Key number plate
Three types of keys are provided for your vehicle:
Master key, submaster key and valet key. The master key and submaster key fit all locks on your vehicle. Ignition switch
Doors
Trunk (sedan) or Rear gate (wagon)
Glove box The valet key fits only the ignition switch and driver
’s
door lock. You can keep the trunk and glove boxlocked when you leave your vehicle and valet key at
a parking facility.
Key number
The key number is stamped on the metal plate
attached to the key set. Write down the key number and keep it in another safe place, not in the vehicle.
This number is needed to make a replacement key ifyou lose your key or lock it inside the vehicle.

Keys and doors
2-3
– CONTINUED –
Door locks Locking and unlocking from the out- side
1) Lock 2) Unlock
To lock the door from the outside with the key, turn
the key toward the rear. To unlock the door, turn the
key toward the front. Pull the outside door handle to open an unlocked
door.
1) Rotate the lock lever rearward.
2) Close the door.
To lock the door from the outside without the key,
rotate the lock lever rearward and then close the
door.
To lock the door from the outside using the power
door locking switch, push the front side of the switch
(“LOCK” side) and then close the door. In this case,
all closed doors and the rear gate (for wagon) arelocked at the same time.
Always make sure that all doors and the rear gate
(wagon) are locked before leaving your vehicle.

Keys and doors
2-4
NOTE
Make sure that you do not leave the key inside the vehicle when locking the doors from the out-
side without the key. Locking and unlocking from the inside
1) Lock 2) Unlock
To lock the door from the inside, rotate the lock lever
rearward. To unlock the door from the inside, rotate
the lock lever forward.
The red mark on the lock lever appears when the door is unlocked. Pull the inside door handle to open an unlocked
door.
Always make sure that all doors and the rear gate
(wagon) are closed before starting to drive.
WARNING
Keep all doors locked when you drive, espe-
cially when small children are in your vehicle. Along with the proper use of seat belts and child restraints, locking the doors reduces the
chance of being thrown out of the vehicle inan accident.It also helps prevent passengers from fallingout if a door is accidentally opened, and in-
truders from unexpectedly opening doors and entering your vehicle.

Keys and doors
2-5
– CONTINUED –
Power door locking switches (if equipped)
1) Lock 2) Unlock
All doors and the rear gate (wagon) can be locked and unlocked by the power door locking switches
located at the driver ’s side and the front passenger ’s
side doors.
To lock the doors, push the front side of the switch.
To unlock the doors, push the rear side of theswitch.
When you close the doors after you set the door locks, the doors remain locked. NOTE
Make sure that you do not leave the key inside the vehicle before locking the doors from theoutside using power door locking switches.
