TRANSFER CASE (TOD) 5D2-51
25. Install the pin on the tang end of the helical cam into thehole in the front case. Position the torsion spring tangs so that they are pointing toward the top side of the transfer case and just touching the high-low shift fork. CAUTIONDo not bend the helical cam during installation to the front case because of possible damage to the pin at the tangend of the motor shaft.
26. Install the shift rail through the high-low shift fork and make sure that the reverse gear shift rail is seated in the frontcase bore.
27. Install upper and lower speed sensors into the cover. Feed the coil wire through the upper speed sensor wire shield.
2 8. Install upper tone wheel, speedometer gear and rear output seal. Use Output Shaft Seal Replacer and Driver orequivalent to install seal.
29. Coat the mating surface of the front case with a bead of Black Non-Acid Cure Silicone Rubber or equivalent.
30. The following procedure must be followed prior to installing the rear case onto the front case half:
a. Align the output shaft with the rear case output shaft bore.
b. Align the helical cam with the rear case motor bore. If difficulty is encountered with seating the rear case, tap
the rear output shaft with a sharp blow using a rubber
mallet in a direction away from the triangular shaft whilepushing down on the rear case.
Tightening Torque 25 - 37 Nm
31. Install the bolts retaining the case halves and tighten.

5D2-52 TRANSFER CASE (TOD)
32. Install shift shaft oil seal if it is not installed.
33. Using pliers equipped with soft jaws, rotate the triangularshaft so it is aligned with the triangular slot in the transfer
case shift motor. If triangular shaft will not rotate, rotate the rear output shaft.
34. Slightly loosen the two nuts that attach the slotted support bracket to the end of the motor house.
35. Apply Black Non-Acid Cure Silicone Rubber or equivalent to motor housing base and install on transfer case.
36. Install the transfer case shift motor and three bolts along with speed sensor wire harness bracket and tighten. NoticeThe wire harness must be routed as shown to provide clearance and to prevent the wire harness from grounding
the damper.
37. Holding the slotted support bracket tight against the motor housing end, secure the bracket to the transfer case,
tightening the bolt with lockwasher to 8-11 Nm (72-96 lb-in).
38. Retighten the two nuts that attach the slotted support bracket to the end of the motor.
39. Install the clutch coil wire terminal and sensor wires.

FATC-HAVC 7D-3
SERVICE SPECIFICATIONSResistance (25 °C)
Voltage Rating Current RatingResistance (25 °C)
Voltage Rating Current Rating Resistance (25 °C)
Voltage RatingCurrent Rating
Application
Incar Sensor Ambient Sensor
Coolant Temperature Sensor
Description
Input Section
2.186k
±0.07k
5V
3mA
1.0k ±0.03k
5V
3mA
0.55k ±0.02k
5V
3mA
Current Rating (at 12V) LOCK CurrentCurrent Rating (at 12V)LOCK CurrentCurrent Rating (at 12V) LOCK Current IcPc
Application
Intake Actuator Mode Actuator Mix Actuator Power TRBlower Motor Power Consumption
Description
Output Section
70±30mA
Less than 500mA 100±40mA
Less than 500mA 100±40mA
Less than 500mA 30A
200W 220W

FATC-HAVC 7D-5
FATC BLOCK DIAGRAM
INCAR SENSOR
AMBIENT SENSOR
WATER TEMPERATURE SENSOR
SUN LOAD SENSOR
TEMPERATURE SWITCH
BLOWER SWITCH
MODE SWITCH
DEFROSTER SWITCH
INTAKE SWITCH
AUTO SWITCH
A/CON SWITCH
OFF SWITCH
TEMP DOOR POSITION FEEDBACKVOLTAGE
POWER TRANSISTOR COLLECTORVOLTAGE
VFD
MAX HI RELAY
POWER T/R
BLOWERMOTOR
ECUCOMPRESSOR
MIX ACTUATORMIX DOOR
INTAKE ACTUATORINTAKE DOOR
MODE ACTUATORMODE DOOR
Airconditioner output
C ON
T
RO L
UN I
T

7D-8 FATC-HAVC Self-diagnosis Method
Ignition switch “ON ”
Press the intake switch more than 4 times within
2 seconds while pressing the AUTO switch
Self-diagnosis will start after turning off all displays on VFD for 2.5 seconds
Self-diagnosis items check (continuous action)
Airconditioner control
Self-diagnosis items check
(step action)
Press AUTO Press AUTO Press OFF
Press OFF
DIAGNOSIS TEST
FATC airconditioner system has self-diagnosis function.
Turn the ignition switch ON and press intake switch more than 4 times within 2 seconds while the AUTO switch is
1 AUTO Switch
2 Intake Switch
3 OFF Switch 4 Airconditioner Switch
5 Set temperature Display
pressed, then it will diagnose incar sensor, ambient
sensor, water temperature sensor and temperature actuator for open/short and will display numerical fault code on the set temperature display of VFD.
DIAGNOSIS

FATC-HAVC 7D-9
Diagnosis Item and Fault Code Self-diagnosis Display
1. Data will be displayed at the set temperature display as 2-digit number during self-diagnosis function and other settemperature displays will be OFF.
2. Display of self-diagnosis fault code will be blinking fault code number in the intervals of 0.5 sec.
3. Following fault code number will be displayed at the set temperature display during self-diagnosis function.
4. If no defective, normal display number (00) will blink. Display during continuous action
A. Normal or 1 fault (00 or 11) 15: coolant Sensor Open
16: coolant Sensor Short
17: temperature Actuator Open/Short
18: temperature Actuator Drive Fault
00: normal
11: incar Sensor Open
12: incar Sensor Short
13: ambient Sensor Open
14: ambient Sensor Short
B. Multiple faults (11,13,15.........) Display during step action
A. Normal or 1 fault : the same as continuous action
B. Multiple faults

0.1 sec. 0.1 sec.
0.5 sec.
ON
0.5 sec.OFF
ON
OFF
Display
Buzzer
0.5 sec.Fault 13
0.5 sec.OFF
Fault 15
OFF
Display
Buzzer
Fault 13 Fault 17
Display Buzzer AUTO switch pressedFault
17 Fault 17
Airconditioner switchpressedFault11 Fault 11


0.1 sec. 0.1 sec.

7D-10 FATC-HAVC Fault Safety Function
FATC airconditioner system not only performs self-diagnosis but also has safety function against faults if there is open or
short in the incar sensor, ambient sensor, water temperature
sensor and temperature door potentiometer.
NO.ItemDefects
Fault safety function
1Incar sensor Open or short Control When substituted 25 °C
2
Ambient sensor Control When substituted 20°C
3
Water temperature sensor Perform heating maneuver control function under
refrigeration maneuver control entering conditions
and release after 10 minutes.
4 Temperature door potentiometer Set temperature 17 - 24.5
°C:max. COLD position
Set temperature 25 - 32 °C:max. HOT position
Open or short Open or short Open or short

7D-12 FATC-HAVC Pin Number and Connection Circuit
Pin No.1 Connection circuit
2 3456789
10 11
1213141516
Rheostat Tail lamp
Battery (+)
Power TR (B) Power TR (C)
Temperature actuator (CCW) IG2
Ground
Airconditioner switch ground HI speed relay
Photo sensor (+)
Photo sensor (-)
Temperature actuator F/B
Temperature actuator (CW) IG2
Ground
Connector A
Pin No.
1 Connection circuit
2 345 6 789
101112131415
Incar sensor (+)
Ambient sensor (+) Coolant sensor (+)
Sensor voltage 5V Sensor ground
Intake (ambient) Intake (incar)
- --
VENT
B/L
FLR MIX
DEF
--- - -
Connector B
17 18
19
20
16
