TROUBLE DIAGNOSIS
EC-689
[YD]
C
D
E
F
G
H
I
J
K
L
MA
EC
D1 L/OR Tachometer[Engine is running]
lWarm-up condition
lIdle speed0-12.5V
[Engine is running]
lWarm-up condition
lEngine speed is 2,000 rpm0-12.5V
D2 OR Glow lamp[Ignition switch “ON”]
lGlow lamp is "ON"Approximately 1.0V
[Ignition switch “ON”]
lGlow lamp is "OFF"BATTERY VOLTAGE
(11 - 14V)
D9 OR/L Malfunction indicator[Ignition switch “ON”]Approximately 1.0V
[Engine is running]
lIdle speedBATTERY VOLTAGE
(11 - 14V)
D11 L Air conditioner relay[Engine is running]
lAir conditioner switch is "OFF"BATTERY VOLTAGE
(11 - 14V)
[Engine is running]
lBoth air conditioner switch and blower fan
switch are "ON" (Compressor is operating)Approximately 0.1V
D14 G/YAccelerator pedal
released position switch[Ignition switch “ON”]
lAccelerator pedal slightly depressedBATTERY VOLTAGE
(11 - 14V)
[Ignition switch “ON”]
lAccelerator pedal fully releasedApproximately 0V
D18
D19W/R
W/RIgnition switch[Ignition switch “ON”]BATTERY VOLTAGE
(11 - 14V)
D23 PU/W Air conditioner switch[Engine is running]
lAir conditioner switch is "OFF"BATTERY VOLTAGE
(11 - 14V)
[Engine is running]
lBoth air conditioner switch and blower fan
switch are "ON" (compressor is operating)Approximately 0.1V
D24
D26G
GECM relay (self-shutoff)[Ignition switch “ON”]
[Ignition switch “OFF”]
lFor a few seconds after turning ignition
switch "OFF"Approximately 0V
[Ignition switch “OFF”]
lA few seconds passed after turning ignition
switch "OFF"BATTERY VOLTAGE
(11 - 14V) TERMI-
NAL
NO.WIRE
COLORITEM CONDITIONDATA
(DC Voltage and Pulse Signal)
PBIB0397E
PBIB0398E

TROUBLE DIAGNOSIS
EC-691
[YD]
C
D
E
F
G
H
I
J
K
L
MA
EC
: Average voltage for pulse signal (Actual pulse signal can be confirmed by oscilloscope.)
CONSULT-II FunctionEBS0037H
CONSULT-II INSPECTION PROCEDURE
1. Turn ignition switch OFF.
2. Connect CONSULT-II to data link connector, which is located
under the driver side dash panel.
E12 P/BPower steering oil pres-
sure switch[Engine is running]lSteering wheel is being turnedApproximately 0V
[Engine is running]
lSteering wheel is not being turnedBATTERY VOLTAGE
(11 - 14V)
E13 G/ORPark/Neutral position
switch[Ignition switch “ON”]
lGear position is "Neutral"Approximately 0V
[Ignition switch “ON”]
lExcept the above gear positionBATTERY VOLTAGE
(11 - 14V)
E16 G/W Suction control valve 2[Engine is running]
lWarm-up condition
lIdle speed0-12.5V
[Engine is running]
lWarm-up condition
lEngine speed is 2,000 rpm0-12.5V
E21 L/B Vehicle speed sensor[Engine is running]
lLift up the vehicle
lIn 2nd gear position
lVehicle speed is 30 km/h (19 MPH)0-5V TERMI-
NAL
NO.WIRE
COLORITEM CONDITIONDATA
(DC Voltage and Pulse Signal)
PBIB0401E
PBIB0402E
PBIB0386E
PBIB0376E

EC-694
[YD]
TROUBLE DIAGNOSIS
NOTE:
Any monitored item that does not match the vehicle being diagnosed is deleted from the display automatically.
ACTIVE TEST MODE
COOLING FAN
[LOW/HI/OFF]´
lIndicates the control condition of the
cooling fans (determined by ECM
according to the input signal).
LOW ... Operates at low speed.
HI ... Operates at high speed.
OFF ... Stopped
EGR VOL CON/V [step]´
lIndicates the EGR volume control
value computed by the ECM accord-
ing to the input signals.
lThe opening becomes larger as the
value increases.
INT/AVOLUME[mg/]
lThe intake air volume computed from
the mass air flow sensor signal is dis-
played.
BARO SEN [kPa]´´
lThe barometric pressure (deter-
mined by the signal voltage from the
absolute pressure sensor built into
the ECM) is displayed.
CYL COUNT [0/1/2/3]
lThe cylinder being injected is dis-
played.
0 ... Cylinder No.1 is injected.
1 ... Cylinder No.3 is injected.
2 ... Cylinder No.4 is injected.
3 ... Cylinder No.2 is injected.
Vo ltag e [V ]
Voltage, frequency, duty cycle or pulse
width measured by the probe.Only "#" is displayed if item is unable to
be measured.
Figures with "#"s are temporary ones.
They are the same figures as an actual
piece of data which was just previously
measured. [Hz] or [%] Frequency [msec], [Hz] or
[%]
DUTY-HI
DUTY-LOW
PLS WIDTH-HI
PLS WIDTH-LOWMONITOR ITEMECM
input
signalMain
signalsCONDITION SPECIFICATION
TEST ITEM CONDITION JUDGEMENT CHECK ITEM (REMEDY)
POWER BAL-
ANCE
lEngine: After warming up, idle the
engine.
lA/C switch “OFF”
lShift lever “N”
lCut off each injector signal one at
a time using CONSULT-IIEngine runs rough or dies.
lHarness and connectors
lCompression
lFuel injectors
COOLING FAN
lIgnition switch: ON
lOperate the cooling fan at “LOW”,
“HI” speed and turn “OFF” using
CONSULT-II.Cooling fan moves at “LOW”, “HI”
speed and stops.
lHarness and connector
lCooling fan motor
lCooling fan relay
OFF ACCEL PO
SIG
lThis mode is used for ECM to learn accelerator pedal released positions.

EC-696
[YD]
TROUBLE DIAGNOSIS
–If the malfunction is displayed as soon as “DATA MONITOR” is selected, reset CONSULT-II to “MANU
TRIG”. By selecting “MANU TRIG” you can monitor and store the data. The data can be utilized for further
diagnosis, such as a comparison with the value for the normal operating condition.
FUNCTION TEST
This mode is used to inform customers of their vehicle condition of periodic maintenance.
CONSULT-II Reference Value in Data Monitor ModeEBS0037I
Remarks:
lSpecification data are reference values.
lSpecification data are output/input values which are detected or supplied by the ECM at the connector.
* Specification data may not be directly related to their components signals/values/operations.
SEF720X
MONITOR ITEM CONDITION SPECIFICATION
CKPS-RPM (TDC)
lTachometer: Connect
lRun engine and compare tachometer indication with the CONSULT-
II valueAlmostthesamespeedasthe
CONSULT-II value
COOLAN TEMP/S
lEngine: After warming up More than 70°C (158°F)
VHCL SPEED SE
lTurn drive wheels and compare speedometer indication with the
CONSULT-II valueAlmostthesamespeedasthe
CONSUT-II value
FUEL TEMP SEN
lEngine: After warming up More than 40°C (104°F)
ACCEL POS SEN
lIgnition switch: ON
(Engine stopped)Accelerator pedal: fully released 0.8 - 1.3V
Accelerator pedal: fully depressed More than 3.5V
ACCEL SEN 2
lIgnition switch: ON
(Engine stopped)Accelerator pedal: fully released 0.3 - 1.8V
Accelerator pedal: fully depressed More than 3.0V
OFF ACCEL SW
lIgnition switch: ON
(Engine stopped)Accelerator pedal: fully released ON
Accelerator pedal: slightly
depressedOFF

TROUBLE DIAGNOSIS
EC-697
[YD]
C
D
E
F
G
H
I
J
K
L
MA
EC
MAS AIR/FL SE
lEngine: After warming up
lAir conditioner switch: OFF
lShift lever: Neutral position
lNo-loadIdle 1.0 - 2.5V
2,000 rpm 2.1 - 2.7V
BATTERY VOLT
lIgnition switch: ON (Engine stopped) 11 - 14V
P/N POSI SW
lIgnition switch: ONShift lever: Neutral position ON
Except above OFF
START SIGNAL
lIgnition switch: ON®START®ON OFF®ON®OFF
PW/ST SIGNAL
lEngine: After warming up, idle
the engineSteering wheel is in neutral posi-
tion. (Forward direction)OFF
Steering wheel is turned. ON
BRAKE SW
lIgnition switch: ONBrake pedal: Fully released OFF
Brake pedal: Slightly depressed ON
IGN SW
lIgnition switch: ON®OFF ON®OFF
ACT CR PRESS
lEngine: After warming up
lAir conditioner switch: OFF
lShift lever: Neutral position
lNo-loadIdle 30 - 40 MPa
2,000 rpm 40 - 50 MPa
SUCTION CV
lEngine: After warming up
lAir conditioner switch: OFF
lShift lever: Neutral position
lNo-loadIdle 70.0 - 71.5°CA
2,000 rpm 73.5 - 75.0°CA
MAIN INJ WID
lEngine: After warming up
lShift lever: Neutral position
lIdle speedNo-load 0.68 - 0.78 msec
Air conditioner switch: ON
Rear window defogger switch: ON0.78 - 0.88 msec
GLOW RLY Refer toEC-796, "
GLOW CONTROL SYSTEM".
COOLING FAN
lWhen cooling fan is stopped. OFF
lWhen cooling fans operate at low speed. LOW
lWhen cooling fans operate at high speed. HIGH
EGR VOL CON/V
lEngine: After warming up
lAir conditioner switch: OFF
lShift lever: Neutral position
lNo-loadAfter one minute at idle More than 10 steps
Revvingenginefromidleto3,600
rpm0step
INT/A VOLUME
lEngine: After warming up, idle the engine 150 - 450 mg/st
BARO SEN
lIgnition switch: ONAltitude
Approx. 0m: Approx. 100.62 kPa
(1.0062 bar, 1.026 kg/cm
2,14.59
psi)
Approx. 1,000 m: Approx. 88.95
kPa (0.8895 bar, 0.907 kg/cm
2,
12.90 psi)
Approx. 1,500 m: Approx. 83.16
kPa (0.8316 bar, 0.848 kg/cm
2,
12.06 psi)
Approx. 2,000 m: Approx. 78.36
kPa (0.7836 bar, 0.799 kg/cm
2,
11 . 3 6 p s i )
CYL COUNT
lEngine is running 0®1®2®3 MONITOR ITEM CONDITION SPECIFICATION

EC-700
[YD]
POWER SUPPLY CIRCUIT FOR ECM
POWER SUPPLY CIRCUIT FOR ECM
PFP:24110
ECM Terminals and Reference ValueEBS00369
Remarks: Specification data are reference values and are measured between each terminal and ground.
CAUTION:
Do not use ECM ground terminals when measuring input/output voltage. Doing so may result in dam-
age to the ECM's transistor. Use a ground other than ECM terminals, such as the ground.
TERMI-
NAL
NO.WIRE
COLORITEM CONDITIONDATA
(DC Voltage and Pulse Signal)
A5
A6
A7B
B
BECM ground[Engine is running]
lIdle speedApproximately 0V
A8
A9R
RPower supply for ECM[Ignition switch "ON"]BATTERY VOLTAGE
(11 - 14V)
A31 W/L Power supply for ECM[Ignition switch “ON”]BATTERY VOLTAGE
(11 - 14V)
D18
D19W/R
W/RIgnition switch[Ignition switch “ON”]BATTERY VOLTAGE
(11 - 14V)
D24
D26G
GECM relay (self-shutoff)[Ignition switch “ON”]
[Ignition switch “OFF”]
lFor a few seconds after turning ignition
switch "OFF"Approximately 0V
[Ignition switch “OFF”]
lA few seconds passed after turning ignition
switch "OFF"BATTERY VOLTAGE
(11 - 14V)

EC-704
[YD]
POWER SUPPLY CIRCUIT FOR ECM
8.CHECK OUTPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Disconnect ECM harness connector.
2. Check harness continuity between ECM terminals D24, D26 and ECM relay terminal 2. Refer to Wiring
Diagram.
3. Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 9.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
9.CHECK ECM POWER SUPPLY CIRCUIT-IV
1. Check harness continuity between ECM terminals A8, A9 and ECM relay terminal 7. Refer to Wiring Dia-
gram.
2. Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 10.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
10.CHECK ECM RELAY
Refer toEC-705, "
Component Inspection".
OK or NG
OK >> GO TO 11.
NG >> Replace ECM relay.
11 .CHECK ECM POWER SUPPLY CIRCUIT-V
1. Turn ignition switch “OFF”.
2. Check voltage between ECM terminal A31 and ground.
OK or NG
OK >> GO TO 13.
NG >> GO TO 12.
12.DETECT MALFUNCTIONING PART
Check the following.
lHarness connectors E65, F6
l20A fuse
lHarness for open or short between ECM and fuse
>> Repair open circuit or short to ground or short to power in harness or connectors. Continuity should exist.
Continuity should exist.
Voltage: Battery voltage
PBIB0478E

DTCP0100MASSAIRFLOWSENSOR(MAFS)
EC-707
[YD]
C
D
E
F
G
H
I
J
K
L
MA
EC
: Average voltage for pulse signal (Actual pulse signal can be confirmed by oscilloscope.)
On Board Diagnosis LogicEBS004Q3
DTC Confirmation ProcedureEBS004Q4
WITH CONSULT-II
1. Turn ignition switch “ON”, and wait at least 6 seconds.
2. Select “DATA MONITOR” mode with CONSULT-II.
3. Start engine and wait at least 3 seconds.
4. If DTC is detected, go toEC-709, "
Diagnostic Procedure".
D24
D26G
GECM relay (self-shutoff)[Ignition switch “ON”]
[Ignition switch “OFF”]lFor a few seconds after turning ignition
switch "OFF"Approximately 0V
[Ignition switch “OFF”]
lA few seconds passed after turning ignition
switch "OFF"BATTERY VOLTAGE
(11 - 14V) TERMI-
NAL
NO.WIRE
COLORITEM CONDITIONDATA
(DC Voltage and Pulse Signal)
DTC Malfunction is detected when ... Check Items (Possible Cause)
P0100
lAn excessively high or low voltage from the sensor
is sent to ECM.lHarness or connectors
(The sensor circuit is open or shorted.)
lMass air flow sensor
SEF817Y
