2003 NISSAN X-TRAIL display

DTC P1146 HO2S2
EC-297
[QR (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
DTC Confirmation ProcedureEBS00BBZ
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
l"COMPLETED" will appear on CONSULT-II screen when all tests "COND1", "COND2" and
"COND3" are completed.
lIf "DTC confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and
wait at least 10 seconds before conducting the next test.
TESTING CONDITION:
Never stop engine during this procedure. If the engine is stopped, retry procedure from step 2 in "Pro-
cedure for COND1"
WITH CONSULT-II
Procedure for COND1
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch "OFF" and wait at least 10 seconds.
3. Turn ignition switch "ON" and select "HO2S2 (B1) P1146" of "HO2S2" in "DTC WORK SUPPORT" mode
with CONSULT-II.
4. Touch "START".
5. Start engine and let it idle for at least 30 seconds.
6. Rev engine up to 2,000 rpm 2 or 3 times quickly under no load.
If "COMPLETED" appears on CONSULT-II screen, go to step 2 in "Procedure for COND3".
If "COMPLETED" does not appear on CONSULT-II screen, go to the following step.
7. Drive vehicle at a speed of more than 70 km/h (43 MPH) for 2 consecutive minutes.
8. When the following conditions are met, "TESTING" will be displayed at "COND1" on the CONSULT-II
screen. Maintain the conditions continuously until "TESTING" changes to "COMPLETED". (It will take
approximately 60 seconds.)
NOTE:
lIf "TESTING" is not displayed after 5 minutes, retry from step 2 in " Procedure for COND1".
lIf "COMPLETED" already appears at "COND2" on CONSULT-II screen before "Procedure for
COND2" is conducted, it is unnecessary to conduct step 1 in " Procedure for COND2".
ENG SPEED More than 1,000 rpm
B/FUEL SCHDL More than 1.0 msec
COOLANT TEMP/S 70 - 105°C
Selector lever Suitable position
PBIB0555E

EC-298
[QR (WITH EURO-OBD)]
DTC P1146 HO2S2
Procedure for COND2
1. While driving, release accelerator pedal completed with "OD"
OFF (A/T models only) from the above condition [step 8] until
"INCOMPLETE" at "COND2" on CONSULT-II screen has turned
to "COMPLETED" (It will take approximately 4 seconds.)
NOTE:
If "COMPLETE" already appears at "COND3" on CONSULT-
II screen before "Procedure for COND3" is conducted, it is
unnecessary to conduct step 1 in "Procedure for COND3".
Procedure for COND3
1. Stop vehicle and let it idle until "INCOMPLETE" of "COND3" on
CONSULT-II screen has turned to "COMPLETED". (It will take a
maximum of approximately 6 minutes.)
2. Make sure that "OK" is displayed after touching "SELF-DIAG
RESULTS".
If "NG" is displayed, refer toEC-300, "
Diagnostic Procedure".
Overall Function CheckEBS00BC0
Use this procedure to check the overall function of the heated oxygen sensor 2 circuit. During this check, a 1st
trip DTC might not be confirmed.
WITH GST
1. Start engine and drive vehicle at a speed of more than 70 km/h (43 MPH) for 2 consecutive minutes.
2. Stop vehicle with engine running.
3. Set voltmeter probes between ECM terminal 95 [HO2S2 (B1) signal] and engine ground.
4. Check the voltage when revving up to 4,000 rpm under no load
at least 10 times.
(Depress and release accelerator pedal as soon as possible.)
The voltage should be below 0.50V at least once during this
procedure.
If the voltage can be confirmed in step 4, step 5 is not nec-
essary.
5. Keep vehicle at idling for 10 minutes, then check the voltage. Or
check the voltage when coasting from 80 km/h (50 MPH) in “D”
position with “OD” OFF (A/T), 3rd gear position (M/T).
The voltage should be below 0.50V at least once during this
procedure.
6. If NG, go toEC-300, "
Diagnostic Procedure".
PBIB0556E
SEC775C
PBIB0550E

EC-300
[QR (WITH EURO-OBD)]
DTC P1146 HO2S2
Diagnostic Procedure
EBS00BC2
1.RETIGHTEN GROUND SCREWS
1. Turn ignition switch “OFF”.
2. Loosen and retighten engine ground screws.
>> GO TO 2.
2.CLEAR THE SELF-LEARNING DATA
With CONSULT-II
1. Start engine and warm it up to normal operating temperature.
2. Select “SELF-LEARNING CONT” in “WORK SUPPORT” mode
with CONSULT-II.
3. Clear the self-learning control coefficient by touching “CLEAR”.
4. Run engine for at least 10 minutes at idle speed.
Is the 1st trip DTC P0172 detected?
Is it difficult to start engine?
Without CONSULT-II
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch “OFF”.
3. Disconnect mass air flow sensor harness connector, and restart
and run engine for at least 5 seconds at idle speed.
4. Stop engine and reconnect mass air flow sensor harness con-
nector.
5. Make sure 1st trip DTC P0102 is displayed.
6. Erase the 1st trip DTC memory. Refer toEC-46, "
HOW TO
ERASE EMISSION-RELATED DIAGNOSTIC INFORMATION".
7. Make sure DTC P0000 is displayed.
8. Run engine for at least 10 minutes at idle speed.
Is the 1st trip DTC P0172 detected?
Is it difficult to start engine?
Ye s o r N o
Yes >> Perform trouble diagnosis for DTC P0172. Refer toEC-200.
No >> GO TO 3.
PBIB0494E
SEF215Z
PBIB0495E

EC-304
[QR (WITH EURO-OBD)]
DTC P1147 HO2S2
DTC Confirmation Procedure
EBS00BC9
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
l"COMPLETED" will appear on CONSULT-II screen when all tests "COND1", "COND2" and
"COND3" are completed.
lIf "DTC confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and
wait at least 10 seconds before conducting the next test.
TESTING CONDITION:
Never stop engine during this procedure. If the engine is stopped, retry procedure from step 2 in "Pro-
cedure for COND1"
WITH CONSULT-II
Procedure for COND1
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch "OFF" and wait at least 10 seconds.
3. Turn ignition switch "ON" and select "HO2S2 (B1) P1147" of "HO2S2" in "DTC WORK SUPPORT" mode
with CONSULT-II.
4. Touch "START".
5. Start engine and let it idle for at least 30 seconds.
6. Rev engine up to 2,000 rpm 2 or 3 times quickly under no load.
If "COMPLETED" appears on CONSULT-II screen, go to step 2 in "Procedure for COND3".
If "COMPLETED" does not appear on CONSULT-II screen, go to the following step.
7. Drive vehicle at a speed of more than 70 km/h (43 MPH) for 2 consecutive minutes.
8. When the following conditions are met, "TESTING" will be displayed at "COND1" on the CONSULT-II
screen. Maintain the conditions continuously until "TESTING" changes to "COMPLETED". (It will take
approximately 60 seconds.)
NOTE:
lIf "TESTING" is not displayed after 5 minutes, retry from step 2 in "Procedure for COND1".
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1147
11 4 7Heated oxygen sensor
2 maximum voltage
monitoringThe maximum voltage from the sensor is not
reached to the specified voltage.
lHarness or connectors
(The sensor circuit is open or shorted)
lHeated oxygen sensor 2
lFuel pressure
lInjectors
lIntake air leaks
ENG SPEED More than 1,000 rpm
B/FUEL SCHDL More than 1.0 msec
COOLANT TEMP/S 70 - 105°C
Selector lever Suitable position
PBIB0557E

DTC P1147 HO2S2
EC-305
[QR (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
lIf "COMPLETED" already appears at "COND2" on CONSULT-II screen before "Procedure for
COND2" is conducted, it is unnecessary to conduct step 1 in "Procedure for COND2".
Procedure for COND2
1. While driving, release accelerator pedal completed with "OD"
OFF (A/T models only) from the above condition [step 8] until
"INCOMPLETE" at "COND2" on CONSULT-II screen has turned
to "COMPLETED" (It will take approximately 4 seconds.)
NOTE:
If "COMPLETE" already appears at "COND3" on CONSULT-
II screen before "Procedure for COND3" is conducted, it is
unnecessary to conduct step 1 in "Procedure for COND3".
Procedure for COND3
1. Stop vehicle and let it idle until "INCOMPLETE" of "COND3" on
CONSULT-II screen has turned to "COMPLETED". (It will take a
maximum of approximately 6 minutes.)
2. Make sure that "OK" is displayed after touching "SELF-DIAG
RESULTS".
If "NG" is displayed, refer toEC-307, "
Diagnostic Procedure".
Overall Function CheckEBS00BCA
Use this procedure to check the overall function of the heated oxygen sensor 2 circuit. During this check, a 1st
trip DTC might not be confirmed.
WITH GST
1. Start engine and drive vehicle at a speed of more than 70 km/h (43 MPH) for 2 consecutive minutes.
2. Stop vehicle with engine running.
3. Set voltmeter probes between ECM terminal 95 [HO2S2 (B1) signal] and engine ground.
4. Check the voltage when revving up to 4,000 rpm under no load
at least 10 times.
(Depress and release accelerator pedal as soon as possible.)
The voltage should be above 0.68V at least once during this
procedure.
If the voltage can be confirmed in step 4, step 5 is not nec-
essary.
5. Keep vehicle idling for 10 minutes, then check the voltage. Or
check the voltage when coasting from 80 km/h (50 MPH) in “D”
position with “OD” OFF (A/T), 3rd gear position (M/T).
The voltage should be above 0.68V at least once during this
procedure.
6. If NG, go toEC-307, "
Diagnostic Procedure".
PBIB0558E
SEC778C
PBIB0550E

DTC P1147 HO2S2
EC-307
[QR (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
Diagnostic ProcedureEBS00BCC
1.RETIGHTEN GROUND SCREWS
1. Turn ignition switch “OFF”.
2. Loosen and retighten engine ground screws.
>> GO TO 2.
2.CLEAR THE SELF-LEARNING DATA
With CONSULT-II
1. Start engine and warm it up to normal operating temperature.
2. Select “SELF-LEARNING CONT” in “WORK SUPPORT” mode
with CONSULT-II.
3. Clear the self-learning control coefficient by touching “CLEAR”.
4. Run engine for at least 10 minutes at idle speed.
Is the 1st trip DTC P0171 detected?
Is it difficult to start engine?
Wi t h ou t C O N S U LT-I I
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch “OFF”.
3. Disconnect mass air flow sensor harness connector, and restart
and run engine for at least 5 seconds at idle speed.
4. Stop engine and reconnect mass air flow sensor harness con-
nector.
5. Make sure 1st trip DTC P0102 is displayed.
6. Erase the 1st trip DTC memory. Refer toEC-46, "
HOW TO
ERASE EMISSION-RELATED DIAGNOSTIC INFORMATION".
7. Make sure DTC P0000 is displayed.
8. Run engine for at least 10 minutes at idle speed.
Is the 1st trip DTC P0171 detected?
Is it difficult to start engine?
Ye s o r N o
Yes >> Perform trouble diagnosis for DTC P0171. Refer toEC-194.
No >> GO TO 3.
PBIB0494E
SEF215Z
PBIB0495E

EC-310
[QR (WITH EURO-OBD)]
DTC P1212 ESP/TCS/ABS COMMUNICATION LINE
DTC P1212 ESP/TCS/ABS COMMUNICATION LINE
PFP:47850
DescriptionEBS00D0F
NOTE:
If DTC P1212 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
EC-114
.
This CAN communication line is used to control the smooth engine operation during ESP/TCS/ABS operation.
Pulse signals are exchanged between ECM and ESP/ABS/TCS control unit.
Be sure to erase the malfunction information such as DTC not only in ESP/TCS/ABS control unit but
also ECM after the ESP/TCS/ABS related repair.
On Board Diagnosis LogicEBS00D0G
Freeze frame data is not stored in the ECM for this self-diagnosis. The MI will not light up for this self-
diagnosis.
DTC Confirmation ProcedureEBS00D0H
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 10.5V at idle.
WITH CONSULT-II
1. Turn ignition switch “ON”.
2. Select “DATA MONITOR” mode with CONSULT-II.
3. Start engine and let it idle for at least 10 seconds.
4. If a 1st trip DTC is detected, go toEC-310, "
Diagnostic Proce-
dure".
WITH GST
Follow the procedure "WITH CONSULT-II" above.
Diagnostic ProcedureEBS00D2D
1.CHECK ESP/TCS/ABS CONTROL UNIT FUNCTION
Refer toBRC-60, "
TROUBLE DIAGNOSIS".
>>INSPECTION END
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1212
1212ESP/TCS/ABS commu-
nication lineECM can not receive the information from
ESP/TCS/ABS control unit continuously.
lHarness or connectors
(The CAN communication line between
ECM and ESP/TCS/ABS control unit is
open or shorted.)
lESP/TCS/ABS control unit
lDead (Weak) battery
SEF058Y

INDEX FOR DTC
EC-379
[QR (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
[QR (WITHOUT EURO-OBD)]INDEX FOR DTCPFP:00024
Alphabetical IndexEBS00BEJ
Check if the vehicle is a model with Euro-OBD (E-OBD) system or not by the "Type approval number" on the
identification plate. Refer toGI-45, "
IDENTIFICATION PLATE".
NOTE:
If DTC U1000 is displayed with other DTC, first perform the trouble diagnosis for DTC U1000. Refer to
EC-460
.
*1: 1st trip DTC No. is the same as DTC No.
*2: In Diagnostic Test Mode II (Self-diagnostic results).
*3: When engine is running.
*4: When the fail-safe operation occurs, the MI illuminates.
*5: The trouble shooting for this DTC needs CONSULT-II.
*6: Except for M/T models without ESP/TCS/ABS system.
*7: For M/T models with ESP/TCS/ABS system.Items
(CONSULT-II screen terms)DTC*1
Reference page
CONSULT-II ECM*2
APP SEN/CIRCUIT P0121 0121EC-484
BRAKE SW/CIRCUIT P1805 1805EC-562
CAN COMM CIRCUIT*6 U1000 1000*5EC-460
CKP SEN/CIRCUIT P0335 0335EC-501
CMP SEN/CIRCUIT P0340 0340EC-507
ECM P0605 0605EC-523
ECM BACK UP/CIRC P1065 1065EC-530
ECT SEN/CIRCUIT*4 P0117 0117EC-470
ECT SEN/CIRCUIT*4 P0118 0118EC-470
ENG OVER TEMP P1217 1217EC-548
E T C A C T R P 11 2 1 11 2 1EC-534
ETC FUNCTION/CIRC P1122 1122EC-536
ETC MOT RLY/CIRC P1123 1123EC-542
HO2S1 (B1) P0134 0134EC-490
KNOCK SEN/CIRC-B1 P0327 0327EC-496
KNOCK SEN/CIRC-B1 P0328 0328EC-496
MAF SEN/CIRCUIT*4 P0102 0102EC-463
MAF SEN/CIRCUIT*4 P0103 0103EC-463
MIL/CIRC P0650 0650EC-526
NATS MALFUNCTION P1610 - P1615 1610 - 1615EC-403
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.No DTC Flashing*3EC-404
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.P0000 0000 —
PW ST P SEN/CIRC P0550 0550EC-518
TCS/CIRC*7 P1212 1212EC-547
THRTL POS SEN/CIRC*4 P0120 0120EC-475
VEH SPEED SEN/CIRC P0500 0500EC-513
