2003 NISSAN TEANA low beam

LT-60
HEADLAMP - HALOGEN TYPE -

Aiming AdjustmentBKS001O1
PREPARATION BEFORE ADJUSTING
For Details, Refer To the Regulations In Your Own Country.
Before performing aiming adjustment, check the following.
1. Keep all tires inflated to correct pressures.
2. Place vehicle on level ground.
3. Set that there is no-load in vehicle other then the driver (or equivalent weight placed in driver’s position).
Coolant, engine oil filled up to correct level and full fuel tank.
LOW BEAM AND HIGH BEAM
1. Turn headlamp low beam ON.
CAUTION:
Be sure aiming switch is set to “0” when performing aiming adjustment.
2. Use adjustment screws to perform aiming adjustment.
PKIC9406E

LT-62
HEADLAMP - HALOGEN TYPE -

Bulb ReplacementBKS001O2
HEADLAMP (UPPER) HIGH BEAM
1. Turn lighting switch OFF.
2. Remove washer tank inlet when replacing bulb RH. Refer to WW-38, "
Removal and Installation of Washer
Ta n k" .
Remove air cleaner case when replacing bulb LH. Refer to EM-17, "
Removal and Installation" (models
with QR engine), or EM-131, "
Removal and Installation" (models with VQ engine).
3. Turn plastic cap counterclockwise and unlock it.
4. Remove the socket connected to the bulb.
5. Unlock retaining spring and remove bulb from headlamp.
HEADLAMP (LOWER) LOW BEAM
1. Turn lighting switch OFF.
2. Remove washer tank inlet when replacing bulb RH. Refer to WW-38, "
Removal and Installation of Washer
Ta n k" .
Remove air cleaner case when replacing bulb LH. Refer to EM-17, "
Removal and Installation" (models
with QR engine), or EM-131, "
Removal and Installation" (models with VQ engine).
3. Turn plastic cap counterclockwise and unlock it.
4. Remove the socket connected to the bulb.
5. Unlock retaining spring and remove bulb from headlamp.
PARKING LAMP
1. Turn lighting switch OFF.
2. Remove fender protector (front). Refer to EI-23, "
Removal and Installation" .
3. Turn bulb socket counterclockwise and unlock it.
4. Remove bulb from its socket.
FRONT TURN SIGNAL LAMP
1. Turn lighting switch OFF.
2. Remove fender protector (front). Refer to EI-23, "
Removal and Installation" .
3. Turn bulb socket counterclockwise and unlock it.
4. Remove bulb from its socket.
CAUTION:
After installing bulb, be sure to install plastic cap and bulb socket securely to ensure watertight-
ness.
Removal and InstallationBKS001O3
Refer to LT- 3 6 , "Removal and Installation" .
NOTE:
After installation, perform aiming adjustment. Refer to LT- 6 0 , "
Aiming Adjustment" . Headlamp (upper) high beam : 12V - 55W (H7)
Headlamp (lower) low beam : 12V - 55W (H11)
Parking lamp : 12V - 5W
Front turn signal lamp : 12V - 21W (amber)

AUTO LIGHT SYSTEM
LT-65
C
D
E
F
G
H
I
J
L
MA
B
LT


to BCM terminal 14.
AUTO LIGHT OPERATION
Applicable lamps

Low beam headlamp

Parking, license plate and tail lamps

High beam headlamp (with the lighting switch in HIGH BEAM position)

Front fog lamp (with the lighting switch in front fog lamp ON position)
When the lighting switch is in AUTO position with the ignition switch in ON position, BCM detects the AUTO
LIGHT (ON) by BCM combination switch reading function. BCM turns automatically ON/OFF the applicable
lamps according to ambient brightness depending on the following condition.

It turns ON applicable lamps in 3 seconds when ambient brightness is less than 1250 lux.

This lighted lamps is turned OFF in 5 seconds when ambient brightness becomes 2500 lux or higher.
Releasing Function:

Turn ignition switch to the OFF position, or

Change lighting switch to the OFF, 1ST, 2ND position.
NOTE:
Timing for when lamps turn ON/OFF can be changed by the function setting of CONSULT-II. Refer to LT- 1 9 ,
"WORK SUPPORT" .
COMBINATION SWITCH READING FUNCTION
Refer to BCS-3, "COMBINATION SWITCH READING FUNCTION" .
HEADLAMP LOW AND HIGH OPERATION (XENON TYPE)
Refer to LT- 6 , "System Description" .
HEADLAMP LOW AND HIGH OPERATION (HALOGEN TYPE)
Refer to LT- 3 8 , "System Description" .
FRONT FOG LAMP OPERATION
Refer to LT- 1 2 6 , "System Description" .
PARKING, LICENSE PLATE AND TAIL LAMPS OPERATION
Refer to LT- 1 9 6 , "System Description" .
CAN Communication System DescriptionBKS001O7
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN Communication UnitBKS001O8
Refer to LAN-49, "CAN System Specification Chart" .
Major Components and FunctionsBKS001O9
Components Functions
BCM

Turns ON/OFF circuits of parking lamp, license plate lamp, tail lamp and headlamp according to signals from
optical sensor, lighting switch (AUTO), and ignition switch (ON, OFF).
Optical sensor

Converts outside brightness (lux) to voltage, and sends it to BCM. (Detects brightness of 800 to 2500 lux)

AUTO LIGHT SYSTEM
LT-69
C
D
E
F
G
H
I
J
L
MA
B
LT

Terminals and Reference Values for IPDM E/RBKS001OD
How to Perform Trouble DiagnosisBKS001OE
1. Confirm the symptom or customer complaint.
2. Understand operation description and function description. Refer to LT- 6 4 , "
System Description" .
3. Preform the Preliminary Check. Refer to LT- 7 0 , "
Preliminary Check" .
4. Check symptom and repair or replace the cause of malfunction.
5. Does the auto light system operate normally? If YES, GO TO 6. If NO, GO TO 4.
6. INSPECTION END.
Te r m i n a l
No.Wire
colorSignal nameMeasuring condition
Reference value
Ignition
switchOperation or condition
20 R/Y Headlamp low (RH) ON Lighting switch 2ND positionOFF Approx. 0 V
ON Battery voltage
22 R/LParking, license plate and
tail lampsON Lighting switch 1ST positionOFF Approx. 0 V
ON Battery voltage
27 L/W Headlamp high (RH) ONLighting switch HIGH BEAM
position or PASS positionOFF Approx. 0 V
ON Battery voltage
28 G Headlamp high (LH) ONLighting switch HIGH BEAM
position or PASS positionOFF Approx. 0 V
ON Battery voltage
30 L Headlamp low (LH) ON Lighting switch 2ND positionOFF Approx. 0 V
ON Battery voltage
38 B Ground ON — Approx. 0 V
48 L CAN− H— — —
49 P CAN− L— — —
60 B Ground ON — Approx. 0 V

LT-76
ACTIVE AFS

OUTLINE
Power is supplied at all times

to ignition relay [located in IPDM E/R (Intelligent Power Distribution Module Engine Room)], from battery
direct,

through 15A fuse (No. 71, located in IPDM E/R)

to CPU (central processing unit) in IPDM E/R,

through 15A fuse (No. 78, located in IPDM E/R)

to CPU in IPDM E/R,

through 10A fuse (No. 38, located in fuse and fusible link block)

to AFS control unit terminal 6.
With the ignition switch in the ON or START position, power is supplied

to ignition relay (located in IPDM E/R),

through 10A fuse [No. 12, located in fuse block (J/B)]

to steering angle sensor terminal 3 and

to AFS control unit terminal 1.
Ground is supplied

to IPDM E/R terminals 38 and 60

through grounds E1 and E31,

to steering angle sensor terminal 2 and

to AFS control unit terminal 4

through grounds M71 and M72.
BENDING LAMP OPERATION
Bending lamp right/left turn ON depending on the steering wheel angle and the vehicle speed under the oper-
ating condition. Bending lamp right/left turn OFF when the steering wheel is returned to the straight.

Operation condition

CAN communication control
AFS control unit is connected to CAN communication line, and receives the signal necessary for active
AFS control with CAN communication.
Steering wheel Lighting switch A/T or CVT shift positionBending lamp RH Bending lamp LH
Lamp ON Lamp ON
Turn to rightOFF, 1ST —
2ND
(LOW, HIGH)P range
Except P range×
Turn to leftOFF, 1ST —
2ND
(LOW, HIGH)P range
Except P range×
Ignition switch Headlamp status A/T or CVT shift position Steering wheel angle Vehicle speed
ONIlluminated
(LOW or HIGH)Except P rangeBending lamp turn ON/
OFF according to the
steering wheel angle.Steering wheel angle, which decides if
bending lamp turn ON, depends on the
vehicle speed.
Transmit unit Meter & A/C amp. Steering angle sensor TCM IPDM E/R
Signal name Vehicle speed signal Steering angle sensor signal TCM shift position signal

Headlamp LO beam signal

Headlamp HI beam signal

ACTIVE AFS
LT-87
C
D
E
F
G
H
I
J
L
MA
B
LT

ACTIVE TEST
Operation Procedure
1. Touch ADAPTIVE LIGHT” on “SELECT SYSTEM” screen.
2. Touch “ACTIVE TEST” on “SELECT DIAG MODE” screen.
3. Touch item to be tested on “SELECT TEST ITEM” and check
operation of the selected item.
4. During operation check, touching “OFF” deactivates operation.
Test Item List

LOW BEAM TEST RIGHT
Bending lamp (RH) can be operated by ON-OFF operations.

LOW BEAM TEST LEFT
Bending lamp (LH) can be operated by ON-OFF operations.
PKIB8783E
CONSULT-II screen display Test item
LOW BEAM TEST RIGHT Bending lamp (RH) output
LOW BEAM TEST LEFT Bending lamp (LH) output
CONSULT-II screen display Operation Operation status
LOW BEAM TEST RIGHTON ON
OFF OFF
PKIB8784E
CONSULT-II screen display Operation Operation status
LOW BEAM TEST LEFTON ON
OFF OFF
PKIB8785E

ACTIVE AFS
LT-89
C
D
E
F
G
H
I
J
L
MA
B
LT

4. CHECK BENDING LAMP SIGNAL
1. Turn lighting switch to 2ND position and select lever to the other than P range.
2. The “BEND LAMP LH” and “BEND LAMP RH” with “DATA MON-
ITOR” screen, change OFF to ON when steering wheel is turned
to the left or right. And change ON to OFF when steering wheel
is returned to the straight.
Lighting operation
Lights out operation
OK or NG
OK >> GO TO 5.
NG >> Replace AFS control unit. Refer to LT- 9 4 , "
Removal and Installation of AFS Control Unit" .
5. CHECK BENDING LAMP
1. Select “ADAPTIVE LIGHT” on CONSULT-II. Select “ACTIVE
TEST” on “SELECT DIAG MODE” screen.
2. Select “LOW BEAM TEST RIGHT” or “LOW BEAM TEST LEFT”
on “SELECT TEST ITEM” screen.
3. Touch “ON” and “OFF” screen.
4. Make sure of bending lamp operation.
OK or NG
OK >> INSPECTION END. If bending lamp is not turned ON/OFF under the operating condition, replace
AFS control unit.
NG >> Refer to LT- 9 0 , "
Bending Lamps Do Not Illuminate (Both Side)" , LT- 9 1 , "Bending Lamp Does Not
Illuminate (One Side)" or LT- 9 2 , "Bending Lamp Does Not turn OFF" .
PKIB8782E
TEST ITEM Turn to the right Turn to the left
STR ANGLE SIG Less than –90°More than 90°
BEND LAMP LH ON OFF
BEND LAMP RH OFF ON
TEST ITEM Return to the straight Return to the straight
STR ANGLE SIG More than -15°Less than 15°
BEND LAMP LH OFF OFF
BEND LAMP RH OFF OFF
CONSULT-II display Operation Operation status

LOW BEAM TEST RIGHT

LOW BEAM TEST LEFTON ON
OFF OFFPKIB8784E

LT-90
ACTIVE AFS

Bending Lamps Do Not Illuminate (Both Side)BKS002FB
1. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connector.
3. Check voltage between AFS control unit harness connector and
ground.
OK or NG?
OK >> GO TO 2.
NG >> Repair harness or connector.
2. CHECK BENDING LAMP SIGNAL
1. Select “ADAPTIVE LIGHT” on CONSULT-II. Select “ACTIVE TEST” on “SELECT DIAG MODE” screen.
2. Select “LOW BEAM TEST RIGHT” or “LOW BEAM TEST LEFT” on “SELECT TEST ITEM” screen.
3. Touch “ON” screen.
4. Check voltage between AFS control unit harness connector and
ground.
OK or NG
OK >> GO TO 3.
NG >> Replace AFS control unit. Refer to LT- 9 4 , "
Removal and Installation of AFS Control Unit" .
3. CHECK CIRCUIT BETWEEN AFS CONTROL UNIT AND BENDING LAMP
1. Turn ignition switch OFF.
2. Disconnect AFS control unit connector and bending lamp (RH and LH) connector.
3. Check harness continuity between AFS control unit harness
connector (A) and bending lamp (RH and LH) harness connec-
tor (B).
OK or NG
OK >> GO TO 4.
NG >> Repair harness or connector.
Terminals Ignition switch position
(+)
(−)OFF ON
AFS control unit
connectorTe r m i n a l
M931
GroundApprox. 0 V Battery voltage
6 Battery voltage Battery voltage
PKIC9894E
Terminals
Vo l ta g e (+)
(-)
AFS control unit connector Terminal
RH
M938
Ground Battery voltage
LH 3
PKIC9895E
CircuitAB
Continuity
Connector Terminal Connector Terminal
RH
M938E509
Ye s
LH 3 E51 9
PKIC9897E
