[QR]PRECAUTIONSPFP:00001
Precautions for Liquid GasketBBS0059K
LIQUID GASKET APPLICATION PROCEDURE
1. Remove old liquid gasket adhering to the liquid gasket application surface and the mating surface.

Remove liquid gasket completely from the liquid gasket application surface, mounting bolts, and bolt
holes.
2. Wipe the liquid gasket application surface and the mating surface with white gasoline (lighting and heating
use) to remove adhering moisture, grease and foreign materials.
3. Attach liquid gasket tube to the tube presser (SST).
Use Genuine Liquid Gasket or equivalent.

Within 5 minutes of liquid gasket application, install the mating
component.

If liquid gasket protrudes, wipe it off immediately.

Do not retighten mounting bolts or nuts after the installation.

Wait 30 minutes or more after installation before refilling
engine oil and engine coolant.
PBIC2160E

ENGINE OIL
LU-7
[QR]
C
D
E
F
G
H
I
J
K
L
MA
LU

ENGINE OILPFP:KLA92
InspectionBBS0059P
ENGINE OIL LEVEL
NOTE:
Before starting engine, put vehicle horizontally and check the engine oil level. If engine is already started, stop
it and allow 10 minutes before checking.
1. Pull out oil level gauge and wipe it clean.
2. Insert oil level gauge and make sure the engine oil level is within
the range shown in the figure.
3. If it is out of range, adjust it.
ENGINE OIL APPEARANCE

Check engine oil for white turbidity or heavy contamination.

If engine oil becomes turbid and white, it is highly probable that it is contaminated with engine coolant.
Repair or replace damaged parts.
ENGINE OIL LEAKAGE
Check for engine oil leakage around the following area.

Oil pan

Oil pan drain plug

Oil pressure switch

Oil filter

Intake valve timing control cover and intake valve timing control solenoid valve

Front cover

Mating surface between cylinder block and lower cylinder block

Mating surface between cylinder block and cylinder head

Mating surface between cylinder head and rocker cover

Crankshaft oil seals (front and rear)
OIL PRESSURE CHECK
WARNING:

Be careful not to burn yourself, as engine oil may be hot.

Engine oil pressure check should be in “ Parking position”.
1. Check engine oil level. Refer to LU-7, "
ENGINE OIL LEVEL" .
2. Remove splash guard (RH).
3. Disconnect harness connector at oil pressure switch, and
remove oil pressure switch using deep socket (commercial ser-
vice tool).
PBIC0249E
PBIC2428E

PRECAUTIONS
LU-15
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
LU

[VQ]PRECAUTIONSPFP:00001
Precautions for Liquid GasketBBS004WF
LIQUID GASKET APPLICATION PROCEDURE
1. Remove old liquid gasket adhering to the liquid gasket application surface and the mating surface.

Remove liquid gasket completely from the liquid gasket application surface, mounting bolts, and bolt
holes.
2. Wipe the liquid gasket application surface and the mating surface with white gasoline (lighting and heating
use) to remove adhering moisture, grease and foreign materials.
3. Attach liquid gasket tube to tube presser (SST).
Use Genuine Liquid Gasket or equivalent.

Within 5 minutes of liquid gasket application, install the mating
component.

If liquid gasket protrudes, wipe it off immediately.

Do not retighten mounting bolts or nuts after the installation.

After 30 minutes or more have passed from the installation, fill
engine oil and engine coolant.
PBIC2160E

ENGINE OIL
LU-19
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
LU

ENGINE OILPFP:KLA92
InspectionBBS004WK
ENGINE OIL LEVEL
NOTE:
Before starting engine, put vehicle horizontally and check the engine oil level. If engine is already started, stop
it and allow 10 minutes before checking.
1. Pull out oil level gauge and wipe it clean.
2. Insert oil level gauge and make sure the engine oil level is within
the range shown in the figure.
3. If it is out of range, adjust it.
ENGINE OIL APPEARANCE

Check engine oil for white turbidity or heavy contamination.

If engine oil becomes turbid and white, it is highly probable that it is contaminated with engine coolant.
Repair or replace damaged parts.
ENGINE OIL LEAKAGE
Check for engine oil leakage around the following areas:

Oil pan

Oil pan drain plug

Oil pressure switch

Oil filter

Oil cooler (VQ35DE)

Water pump cover

Chain tensioner cover

Intake valve timing control cover and intake valve timing control solenoid valve

Mating surface between cylinder block and cylinder head

Mating surface between cylinder head and rocker cover

Mating surface between front timing chain case and rear timing chain case

Mating surface between rear timing chain case and cylinder block

Crankshaft oil seals (front and rear)
PBIC0249E

OIL COOLER (VQ35DE)
LU-23
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
LU

OIL COOLER (VQ35DE)PFP:21305
Removal and InstallationBBS004WN

Refer to GI-10, "Components" for symbol marks in the figure.
WARNING:
Be careful not to get burn yourself, as engine oil and engine coolant may be hot.
REMOVAL
NOTE:
When removing oil cooler only, step 2 is unnecessary.
1. Remove splash guard (RH).
2. Drain engine coolant from radiator and cylinder block. Refer to CO-34, "
Changing Engine Coolant" and
EM-229, "
DISASSEMBLY" .
NOTE:
Perform this step when removing water pipes.
3. Remove oil filter. Refer to LU-22, "
OIL FILTER" .
CAUTION:
Do not spill engine oil on drive belts.
4. Disconnect water hoses from oil cooler.

When removing oil cooler only, pinching water hoses near oil cooler to prevent engine coolant spilling.
1. Connector bolt 2. Copper gasket 3. Water drain plug
4. Water pipe 5. Bracket 6. Water hose
7. Relief valve 8. O-ring 9. Oil cooler
10. Connector bolt 11. Oil filter 12. Water hose
13. Water pipe 14. Clamp 15. Water hose
16. Clamp
A. Refer to LU-22
:Engine front
PBIC4731E

LU-24
[VQ]
OIL COOLER (VQ35DE)

CAUTION:

Perform this step when engine is cold.

Do not spill engine coolant on drive belts.
5. Remove connector bolt, and remove oil cooler.
CAUTION:
Do not spill engine oil to rubber parts such as drive belts and engine mounting insulator.
6. Remove water pipes, as necessary.
INSPECTION AFTER REMOVAL
Oil Cooler
Check oil cooler for cracks. Check oil cooler for clogging by blowing through engine coolant inlet. If necessary,
replace oil cooler.
Relief Valve
Check relief valve for movement, cracks and breaks by pushing the ball. If replacement is necessary, remove
relief valve by prying it out with suitable tool. Install a new relief valve in place by tapping it.
INSTALLATION
Note the following, and install in the reverse order of removal.

Make sure that no foreign objects are adhering to the installation surfaces of oil cooler and oil pan (upper).

Align cutout on oil cooler with protrusion on oil pan (upper) side,
and tighten connector bolt.
INSPECTION AFTER INSTALLATION
1. Check the engine oil level and the engine coolant level, and add engine oil and engine coolant. Refer to
LU-19, "
ENGINE OIL" and CO-34, "ENGINE COOLANT" .
2. Start engine, and make sure that there is no leaks of engine oil or engine coolant.
3. Stop engine and wait for 10 minutes.
4. Check the engine oil level and the engine coolant level again. Refer to LU-19, "
ENGINE OIL" and CO-34,
"ENGINE COOLANT" .
PBIC2508E
