2003 NISSAN ALMERA N16 DIAGRAM

MODELS WITH YD ENGINE (WITHOUT COMMON RAIL)NJHA0128S06
YHA468
GI
MA
EM
LC
EC
FE
CL
MT
AT
AX
SU
BR
ST
RS
BT
SC
EL
IDX
TROUBLE DIAGNOSESMANUAL
Wiring Diagram — A/C, M — (Cont’d)
HA-31

YHA469
TROUBLE DIAGNOSESMANUAL
Wiring Diagram — A/C, M — (Cont’d)
HA-32

YHA470
GI
MA
EM
LC
EC
FE
CL
MT
AT
AX
SU
BR
ST
RS
BT
SC
EL
IDX
TROUBLE DIAGNOSESMANUAL
Wiring Diagram — A/C, M — (Cont’d)
HA-33

RHA623H
COMPONENT DESCRIPTIONNJHA0209Intake Door MotorNJHA0209S01The intake door motor is attached to the intake unit. It rotates so
that air is drawn from inlets set by the heater control panel. Motor
rotation is conveyed to a lever which activates the intake door.
DIAGNOSTIC PROCEDURE FOR INTAKE DOOR
MOTOR CIRCUIT
NJHA0210
1 CHECK POWER SUPPLY FOR HEATER CONTROL PANEL
Do approx. 12 volts exist between heater control panel harness terminal No. 1 and body ground?
RHA251I
YesorNo
Ye s G O T O 2 .
No Check 10A (No. 15) fuse at fuse block. Refer to EL-14, “Wiring Diagram — POWER —”.
2 CHECK RECIRCULATION (REC) SWITCH
Refer to HA-40.
OK or NG
OK GO TO 3.
NG Replace recirculation (REC) switch.
TROUBLE DIAGNOSESMANUAL
Intake Door (Cont’d)
HA-38

BLOWER MOTOR CIRCUIT=NJHA0147SYMPTOM:
Blower motor does not rotate.
Symptom
table No.INCIDENT
1 Fan fails to rotate.
2 Fan does not rotate at 1-speed.
3 Fan does not rotate at 2-speed.
4 Fan does not rotate at 3-speed.
5 Fan does not rotate at 4-speed.
1 DIAGNOSTIC PROCEDURE
Check if blower motor rotates properly at each fan speed.
Conduct checks as per symptom table at above.
1GO TO 2.
2, 3, 4GO TO 8.
5GO TO 10.
2 CHECK POWER SUPPLY FOR BLOWER MOTOR
1. Disconnect blower motor harness connector.
2. Do approx. 12 volts exist between blower motor harness terminal No. 1 andbody ground?
RHA343FD
YesorNo
Ye s G O T O 3 .
No Check 15A (Nos. 14 and 16) fuses at fuse block. Refer to EL-14, “Wiring Diagram —
POWER —”.
TROUBLE DIAGNOSESMANUAL
Blower Motor (Cont’d)
HA-46

3 CHECK CIRCUIT CONTINUITY BETWEEN A/C RELAY AND COMPRESSOR HARNESS
Check circuit continuity between A/C relay harness terminal No. 3 and compressor harness terminal No. 1.
RHA634H
Continuity should exist.
If OK, check harness for short.
OK or NG
OK GO TO 4.
NG Repair harness or connector.
4 CHECK POWER SUPPLY FOR A/C RELAY
Disconnect A/C relay.
Do approx. 12 volts exist between A/C relay harness terminal Nos. 1, 5 and body ground?
RHA635H
YesorNo
Ye s G O T O 5 .
No Check power supply circuit and 10A (No. 15) fuse at fuse block. Refer to EL-14, “Wiring
Diagram — POWER —”.
5 CHECK A/C RELAY AFTER DISCONNECTING IT
Refer to HA-65.
OK or NG
OK Reconnect A/C relay. GO TO 6.
NG Replace A/C relay.
TROUBLE DIAGNOSESMANUAL
Magnet Clutch (Cont’d)
HA-54

3 CHECK CIRCUIT CONTINUITY BETWEEN A/C RELAY AND COMPRESSOR HARNESS
Check circuit continuity between A/C relay harness terminal No. 3 and compressor harness terminal No. 1.
RHA634H
Continuity should exist.
If OK, check harness for short.
OK or NG
OK GO TO 4.
NG Repair harness or connector.
4 CHECK POWER SUPPLY FOR A/C RELAY
Disconnect A/C relay.
Do approx. 12 volts exist between A/C relay harness terminal Nos. 1, 5 and body ground?
RHA635H
YesorNo
Ye s G O T O 5 .
No Check power supply circuit and 10A (No. 15) fuse at fuse block. Refer to EL-14, “Wiring
Diagram — POWER —”.
5 CHECK A/C RELAY AFTER DISCONNECTING IT
Refer to HA-65.
OK or NG
OK Reconnect A/C relay. GO TO 6.
NG Replace A/C relay.
GI
MA
EM
LC
EC
FE
CL
MT
AT
AX
SU
BR
ST
RS
BT
SC
EL
IDX
TROUBLE DIAGNOSESMANUAL
Magnet Clutch (Cont’d)
HA-61
