170 Controls in detailClimate controlDeactivating the climate control sys-tem
Deactivating
Press button M(
page 164).
Reactivating

Press button Magain(
page 164).
or

Press any button on the climate control
panel (
page 164).
Air conditioner
The air conditioner is operational while the
engine is running and cools the interior air
to the temperature set by the operator.
Deactivating
It is possible to deactivate the air condi-
tioning (cooling) function of the climate
control system. The air in the vehicle will
then no longer be cooled or dehumidified.
Press buttonAC
OFF
(page 164).
The indicator lamp on the
buttonAC
OFF
comes on.Activating
Moist air can fog up the windows. You can
dehumidify the air with the air conditioner.

PressAC
OFF
again (
page 164).
The indicator lamp on the
buttonAC
OFF
goes out.
The air conditioner uses the refrigerant
R134a. This refrigerant is free of CFCs
which are harmful to the ozone layer.
iCondensation may drip out from under-
neath the vehicle. This is normal and
not an indication of a malfunction.
!If the air conditioner cannot be turned
on again, this indicates that the air con-
ditioner is losing refrigerant. The com-
pressor has turned itself off.
Have the air conditioner checked at the
nearest authorized Mercedes-Benz
Center.
ProCarManuals.com

171 Controls in detail
Climate control
Residual heat and ventilation*
With the engine switched off, it is possible
to continue to heat or ventilate the interior
for up to 30 minutes. This feature makes
use of the residual heat produced by the
engine.
Activating
Turn the key in the starter switch to
position1 or remove it from the starter
switch.

Press buttonT (
page 164).
The indicator lamp on buttonT
comes on.Deactivating

Press buttonT (
page 164).
The indicator lamp on buttonT
goes out.
The residual heat is automatically turned
off:


when the ignition is switched on


after about 30 minutes


if the battery voltage drops
iHow long the system will provide heat-
ing depends on the coolant tempera-
ture and the temperature set by the
operator. The blower will run at speed
setting1 regardless of the air distribu-
tion control setting.
ProCarManuals.com

175 Controls in detail
Automatic climate control*
The automatic climate control is a 4-zone
intelligent climate control system. Your ve-
hicle interior is divided into 4 zones.With the help of a sun sensor, the automat-
ic climate control determines the relation
of the sun to the vehicle and automatically
adjusts the inside temperature for every in-
dividual zone.
You can set the temperature for each of
the 4 zones separately. These settings can
be assigned to a key and stored in memory
(
page 144).
The automatic climate control is operation-
al whenever the engine is running. It cools
the vehicle’s interior according to the an-
gle and intensity of the sun’s rays, the out-
side temperature and the selected
temperature.The activated charcoal filter, when
switched on, markedly reduces odors and
removes pollutants from the air entering
the passenger compartment.
The automatic climate control is operation-
al whenever the engine is running. You can
operate the climate control system in ei-
ther the automatic or manual mode. The
system cools or heats the interior depend-
ing on the selected interior temperature
and the current outside temperature.iCondensation may drip from under-
neath the vehicle. This is normal and
not an indication of a malfunction.
!If the interior has been heated, air the
vehicle out before driving.
Keep the air intake between the hood
and the windshield free of snow.
Do not cover the ventilation slot be-
tween the rear shelf and the rear win-
dow.
ProCarManuals.com

181 Controls in detail
Automatic climate control*
Air conditioner
The air conditioner is operational while the
engine is running and cools the interior air
to the temperature set by the operator.
Deactivating
It is possible to deactivate the air condi-
tioning (cooling) function of the automatic
climate control system. The air in the vehi-
cle will then no longer be cooled or dehu-
midified.
Press buttonAC
OFF
.
The indicator lamp on the
buttonAC
OFF
lights up.Activating
Moist air can fog up the windows. You can
dehumidify the air with the air conditioner.

PressAC
OFF
again.
The indicator lamp on
theAC
OFF
button goes out.
The air conditioner uses the refrigerant
R134a. This refrigerant is free of CFCs
which are harmful to the ozone layer.
Warning!
G
Any accumulation of snow and ice should be
removed from the rear window before driv-
ing. Visibility could otherwise be impaired,
endangering you and others.!If the rear window defroster switches
off too soon and the indicator lamp
starts blinking, this means that too
many electrical consumers are operat-
ing simultaneously and there is insuffi-
cient voltage in the battery. The system
responds automatically by deactivating
the rear window defroster.
As soon as the battery has sufficient
voltage, the rear window defroster au-
tomatically turns itself back on.
iCondensation may drip out from under-
neath the vehicle. This is normal and
not an indication of a malfunction.
!If the air conditioner cannot be turned
on again, this indicates that the air con-
ditioner is losing refrigerant. The com-
pressor has turned itself off.
Have the air conditioner checked at the
nearest authorized Mercedes-Benz
Center.
ProCarManuals.com

182 Controls in detailAutomatic climate control*Residual heat and ventilation
With the engine switched off, it is possible
to continue to heat or ventilate the interior
for up to 30 minutes. This feature makes
use of the residual heat produced by the
engine.
Activating
Turn the key in the starter switch to
position1 o r r e m o ve i t f r o m t h e s t a r t e r
switch.

Press buttonT.
The indicator lamp on buttonT
comes on.
Deactivating

Press buttonT.
The indicator lamp on buttonT
goes out.The residual heat is automatically turned
off


when the ignition is switched on


after about 30 minutes


if the battery voltage drops
Rear air conditioning
1Swiveling left rear center air outlet
2Swiveling right rear center air outlet
3Thumbwheel, left rear center air outlet
4Temperature rocker switch, left
5Display
6Temperature rocker switch, right
7Thumbwheel, right rear center air out-
let
iHow long the system will provide heat-
ing depends on the coolant tempera-
ture and the temperature set by the
operator. The blower will run at speed
setting1 regardless of the air distribu-
tion control setting.
ProCarManuals.com

193 Controls in detail
Panorama sliding/pop-up roof*
Closing (Convenience feature)
Press and hold button‹ after lock-
ing the vehicle.
The windows and panorama slid-
ing/pop-up roof begin to close after
approximately one second.

Press and hold buttonΠagain.
The roller blinds close.

Release transmit button to interrupt
procedure.
Ensure that all side windows and the pan-
orama sliding/pop-up roof are properly
closed before leaving the vehicle.Synchronizing the panorama slid-
ing/pop-up roof
It is necessary to resynchronize the pan-
orama sliding/pop-up roof after:


voltage supply interruption due to a
disconnected or discharged battery


the roof has been closed manually


the roof has been opened with an
abrupt movement


a malfunction

Remove the fuse from the main fuse
box.

Replace the fuse in the main fuse box.

Turn the ignition on.

Press the switch in direction 3.

Wait until the panorama sliding/pop-up
roof is raised and then keep the switch
pressed for approximately 1 second.
Solar panel*
Combined with the panorama slid-
ing/pop-up roof a solar panel is available.
The solar cells convert natural light into
electrical energy. When the engine is
switched off, the energy generated auto-
matically switches on the ventilation fan.
The constant air flow creates a cooler tem-
perature for cars parked in the sunlight.
The air flow depends on the intensity of the
solar radiation. The ventilation starts 2
minutes after switching off the engine.
ProCarManuals.com

195 Controls in detail
Driving systems
1Set current or higher speed
2Set current or lower speed
3Cancel cruise control
4Resume at previously set speed
Saving current speed
Accelerate or decelerate to the desired
speed.

Briefly lift1 or depress2 the cruise
control lever.
The current speed is set.

Remove your foot from the accelerator
pedal.
Cruise control is activated.Canceling cruise control
There are several ways to cancel cruise
control:

Step on the brake pedal.
or

Briefly push the cruise control lever to
position3.
Cruise control will be canceled. The
last speed set will be stored for later
use.iOn uphill or downhill grades, cruise
control may not be able to maintain the
set speed. Once the grade eases, the
set speed will be resumed.
!Vehicles with automatic transmission:
Moving gear selector lever to
positionN while driving also cancels
cruise control. However, the gear se-
lector lever should not be moved to
positionN while driving except to coast
when the vehicle is in danger of skid-
ding (e.g. on icy roads).iVehicles with manual transmission:
The set cruise controlled speed is
switched off when declutching exceeds
four seconds during downshifting a
gear.iThe last stored speed is canceled when
you turn off the engine.
ProCarManuals.com

196 Controls in detailDriving systemsSetting stored speed ("Resume"
function)
Briefly push the cruise control lever to
position4.
The cruise control will resume the last
previously set speed.

Remove your foot from the accelerator
pedal.Setting a higher speed

Lift the cruise control lever to
position1 and hold it up until the de-
sired speed is reached.

Release the cruise control lever.
The new speed is set.
Setting a lower speed

Depress the cruise control lever to
position2 and hold it down until the
desired speed is reached.

Release the cruise control lever.
The new speed is set.Fine adjustment in 0.6 mph (1 km/h)
increments
Faster

Briefly tip the cruise control lever in the
direction of arrow1.
Slower

Briefly tip the cruise control lever in the
direction of arrow2.
Warning!
G
The speed stored in memory should only be
set again if prevailing road conditions per-
mit. Possible acceleration or deceleration
differences arising from returning to preset
speed could endanger yourself and others.
iDepressing the accelerator pedal does
not deactivate cruise control. After
brief acceleration (e.g. for passing),
cruise control will resume the last
speed set.
iVehicles with automatic transmission:
When you use the cruise control lever
to decelerate, the transmission will au-
tomatically downshift if the engine’s
braking power does not brake the vehi-
cle sufficiently.
