2003 MERCEDES-BENZ E-CLASS engine

53 Getting started
Parking and locking
Turning off with KEYLESS-GO*
Place the gear selector lever in P.

Press the KEYLESS-GO start/stop but-
ton until the engine shuts off.
With the driver's door closed, the start-
er switch is now in position1. With the
driver’s door opened, the starter switch
is set to position0, same as key re-
moved from starter switch
(page 31).

Press the seat belt release button
(page 41).1Lock button on the door handle

After exiting the vehicle, press lock
button1 on the door handle or on the
trunk lid.
The locking knobs on the doors move
down. The turn signal indicators light
up briefly
!If you hear a warning signal you have ei-
ther

forgotten to turn off the lights, or


not put the gear selector lever inP
before opening the driver’s door.
Turn off the lights or place the gear se-
lector lever inP.
Warning!
G
To prevent possible personal injury, always
keep hands and fingers away from the door
openings when closing the doors. Be espe-
cially careful when small children are
around.
Before closing doors, ensure that there is no
possibility of someone getting caught in a
door during closing.
ProCarManuals.com

61 Safety and Security
Occupant safety


independently of the side impact air-
bags
The airbags will not deploy in impacts
which do not exceed the system’s deploy-
ment thresholds. You will then be protect-
ed by the fastened seat belts.
The front passenger airbag will only be de-
ployed if:


the front passenger seat is occupied


the PASSENGER AIRBAG OFF indicator
lamp in the center console is not lit
(page 67)Side impact airbags, window curtain
airbags
1Side impact airbags
2Window curtain airbag
The side impact airbags and window cur-
tain airbags are deployed:


on the impacted side of the vehicle


in impacts exceeding a preset deploy-
ment threshold


independently of the front airbags
The front passenger side airbag will only
deploy if the system senses that the front
passenger seat is occupied.The side impact airbags are not deployed
in impacts which do not exceed the sys-
tem’s deployment threshold.
Seat belts
The seat belt nonusage warning lamp <
in the instrument cluster lights up and a
warning sounds for a short time when you
turn the key in the starter switch to
position2 or press the KEYLESS-GO* (if so
equipped) start/stop button twice and the
drivers seat belt is not fastened.
After starting the engine the seat belt non-
usage warning lamp blinks for a brief peri-
od to remind the driver and passengers to
fasten the seat belts.
The use of seat belts and infant and child
restraint systems is required by law in
most states and all Canadian provinces.
Even where this is not the case, all vehicle
occupants should have their seat belts fas-
tened whenever the vehicle is in motion.
!Do not place objects heavier than 20
lbs (9 kg) on the front passenger seat.
This could cause the front or side im-
pact airbag on the front passenger side
to deploy in a crash which exceeds the
system's deployment threshold.
ProCarManuals.com

74 Safety and SecurityDriving safety systemsContinuos steady brake pedal pressure
yields the advantagesprovided by the ABS,
namely braking power and ability to steer
the vehicle.
The - warning lamp in the instrument
cluster lights up when you turn the key in
the starter switch to position2 or press
the KEYLESS-GO* (if so equipped)
start/stop button twice. It goes out when
the engine is running.
More information can be found in the
"Practical hints" section (
page 289).
BAS
The Brake Assist System (BAS) operates in
emergency situations. If you apply the
brakes very quickly, the BAS automatically
provides full brake boost, thereby poten-
tially reducing the braking distance. Apply
continuous full braking pressure until the
emergency braking situation is over. The
ABS will prevent the wheels from locking.
When you release the brake pedal, the
brakes function again as normal. The BAS
is then deactivated.
iTo alert following vehicles to slippery
road conditions you discover, operate
your hazard warning flashers as appro-
priate.
Warning!
G
The ABS cannot prevent the natural laws of
physics from acting on the vehicle, nor can
it increase braking or steering efficiency be-
yond that afforded by the condition of the
vehicle brakes and tires or the traction. The
ABS cannot prevent accidents, including
those resulting from excessive speed in
turns, following another vehicle too closely,
or aquaplaning. Only a safe, attentive, and
skillful driver can prevent accidents. The ca-
pabilities of an ABS equipped vehicle must
never be exploited in a reckless or danger-
ous manner which could jeopardize the us-
er’s safety or the safety of others.
ProCarManuals.com

75 Safety and Security
Driving safety systems
ESP
The Electronic Stability Program (ESP)
monitors the vehicle's traction (force of
adhesive friction between the tires and the
road surface) and handling.
The ESP recognizes when a wheel is spin-
ning or if the vehicle starts to skid. By ap-
plying brakes to the appropriate wheel and
by limiting engine output, the ESP works to
stabilize the vehicle. The ESP is especially
useful during take-off and on wet or slip-
pery road surfaces.
The ESP warning lamp v in the instru-
ment cluster flashes when the ESP is en-
gaged.
The ESP warning lamp v in the instru-
ment cluster lights up when you turn the
key in the starter switch to position2 or
press the KEYLESS-GO* (if so equipped)
start/stop button twice. It goes out when
the engine is running.
Warning!
G
The BAS cannot prevent the natural laws of
physics from acting on the vehicle, nor can
it increase braking efficiency beyond that af-
forded by the condition of the vehicle brakes
and tires or the traction. The BAS cannot
prevent accidents, including those resulting
from excessive speed in turns, following an-
other vehicle too closely, or aquaplaning.
Only a safe, attentive, and skillful driver can
prevent accidents. The capabilities of a BAS
equipped vehicle must never be exploited in
a reckless or dangerous manner which
could jeopardize the user’s safety or the
safety of others.
Warning!
G
Never switch off the ESP when you see the
ESP warning lamp
v
flashing in the in-
strument cluster. In this case proceed as fol-
lows:


While driving off, apply as little throttle
as possible


While driving ease up on the accelerator


Adapt your speed and driving style to
the prevailing road conditions
Failure to observe these guidelines could
cause the vehicle to skid.
The ESP cannot prevent accidents resulting
from excessive speed.
ProCarManuals.com

76 Safety and SecurityDriving safety systems
More information can be found in the
"Practical hints" section (
page 288).Switching off the ESP
To improve the vehicle's traction, turn off
the ESP in driving situations where it would
be advantageous to have wheels cut into
surfaces for better grip such as:


s t a r t i n g o u t o n s l i p p e r y s u r f a c e s a n d i n
deep snow in conjunction with snow
chains


in sand or gravel
Warning!
G
The ESP cannot prevent the natural laws of
physics from acting on the vehicle, nor can
it increase the traction afforded. The ESP
cannot prevent accidents, including those
resulting from excessive speed in turns, or
aquaplaning. Only a safe, attentive, and
skillful driver can prevent accidents. The ca-
pabilities of an ESP equipped vehicle must
never be exploited in a reckless or danger-
ous manner which could jeopardize the us-
er’s safety or the safety of others.
!Because of the ESP’s automatic opera-
tion, the engine must be shut off (key in
starter switch position0 or1) when:

the parking brake is being tested on
a brake test dynamometer


the vehicle is being towed with the
front axle raised
Active braking action through the ESP
may otherwise seriously damage the
rear axle brake system.
The ESP will only function properly if
you use wheels of the recommended
tire size.
Warning!
G
The ESP should not be switched off during
normal driving other than in the circum-
stances described below. Disabling of the
system will reduce vehicle stability in stan-
dard driving maneuvers.
ProCarManuals.com

81 Safety and Security
Anti-theft systems
Anti-theft systems
Immobilizer
The immobilizer prevents unauthorized
persons from starting your vehicle.
Activating

With the key: Removing the key from
the starter switch activates the immo-
bilizer.


With KEYLESS-GO*: Turning off the en-
gine by means of the KEYLESS-GO
start/stop button on the gear selector
lever activates the immobilizer.Deactivating


With the key: Inserting the key in the
starter switch deactivates the immobi-
lizer.


With KEYLESS-GO*: Starting the en-
gine by means of the KEYLESS-GO
start/stop button on the gear selector
lever deactivates the immobilizer.
iIn case the engine cannot be started
(yet the vehicle’s battery is charged),
the system is not operational. Contact
an authorized Mercedes-Benz Center
or call 1-800-FOR-MERCedes (in the
USA), or 1-800-387-0100 (in Canada).
ProCarManuals.com

90 Controls in detailLocking and unlocking
Important notes on using KEYLESS-GO

You can also use the SmartKey with
KEYLESS-GO like a normal key
(page 86).


You can combine KEYLESS-GO func-
tions with normal key functions (e.g.
unlocking with KEYLESS-GO and lock-
ing with the remote control).


Always carry the SmartKey with
KEYLESS-GO with you.


Never store the SmartKey with
KEYLESS-GO together with:

Electronic items such as a cellular
phone or another SmartKey with
KEYLESS-GO


Metallic objects such as coins or
metal foil
Doing so could impair the function of
the KEYLESS-GO system.


To lock or unlock the vehicle, the key
must be located outside the vehicle
within approximately 3 ft. (1 m) of a
door or the trunk.


In order to start the engine with the
SmartKey with KEYLESS-GO:

The SmartKey with KEYLESS-GO
must be located in the vehicle.


All the doors must be closed.


If you have started the engine with the
KEYLESS-GO start/stop button, you
can only turn it off again with this but-
ton, even if you have put the key in the
starter switch in the meantime.


This does not apply if, after starting, the
selector lever is still in positionP. The
SmartKey will then have priority over
the KEYLESS-GO function and the vehi-
cle’s electrical system will operate ac-
cording to the position of the key in the
starter switch, even stopping the en-
gine.


If the SmartKey with KEYLESS-GO is
positioned farther away from the vehi-
cle (e.g. inside clothing or briefcase)
and can no longer be recognized by the
Warning!
G
When leaving the vehicle always remove the
key from the starter switch, take the Smart-
Key with KEYLESS-GO (if so equipped) with
you and lock the vehicle. Do not leave chil-
dren unattended in the vehicle, or with ac-
cess to an unlocked vehicle. Unsupervised
use of vehicle equipment may cause serious
personal injury.!To prevent possible malfunction, avoid
exposing the SmartKey with
KEYLESS-GO to high levels of electro-
magnetic radiation.
ProCarManuals.com

91 Controls in detail
Locking and unlocking
system, the vehicle cannot be locked
or the engine started via the KEY-
LESS-GO system.


If the SmartKey with KEYLESS-GO is re-
moved from the vehicle while the igni-
tion is switched on (e.g. if passenger
exits the vehicle with the key), the mes-
sage
Key not recognized!
will appear
in the multifunction display.
Find the key or change its present loca-
tion immediately (e.g. place it on the
front passenger seat or insert it in shirt
pocket).


Remember that the engine can be
started by anyone with a SmartKey
with KEYLESS-GO that is left inside the
vehicle. If you leave the card behind
when exiting and locking the vehicle,
the message
Key recognized in vehi-
cle!
will appear in the multifunction
display.Factory setting
Global unlocking

Grasp the door handle.
The vehicle will lock again automatically
within approximately 40 seconds if neither
door nor trunk is opened.Global locking

Press lock button at door handle
(page 53) or trunk lid (
page 92).
iThe vehicle could be inadvertently un-
locked if the SmartKey with KEY-
LESS-GO is within 3 ft. (1 m) of the
vehicle and

the door handle is splashed with
water, or


you attempt to clean the door
handle.
!If you cannot lock or unlock the vehicle
with the SmartKey with KEYLESS-GO,
then either the batteries of the key are
discharged or the key is malfunction-
ing.

Check the batteries of the Smart-
Key with KEYLESS-GO (
page 88)
and replace them if necessary
(
page 328).


Use the mechanical key to unlock
the driver’s door (
page 327) and
trunk lid (
page 328) as required.
Lock the vehicle using the mechan-
ical key (
page 328).
If your SmartKey with KEYLESS-GO is
malfunctioning, contact your autho-
rized Mercedes-Benz Center.
ProCarManuals.com
