PICTORIAL INDEX
ix
INSTRUMENT CLUSTER

For detailed information, refer to the description given in each section\
.
PICTORIAL INDEX
xPage
1Automatic transmission second start
indicator light 309
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2Unengaged “Park” warning light 49
. . . . . . . . . . . . . . .
3Automatic transmission fluid temperature
warning light 49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4Low washer fluid warning light 51
. . . . . . . . . . . . . . . . .
5Automatic transmission indicator lights 303 . . . . . .
6Driver’s seat belt reminder light 45
. . . . . . . . . . . . . . . .
7Turn signal indicator light 25
. . . . . . . . . . . . . . . . . . . . .
8Brake system warning light 44
. . . . . . . . . . . . . . . . . . . .
9Headlight high beam indicator light 25
. . . . . . . . . . . .
10“ABS” warning light 48
. . . . . . . . . . . . . . . . . . . . . . . . . .
11Open door warning light 49
. . . . . . . . . . . . . . . . . . . . . . .
12Tachometer 42
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13Headlight indicator light 24
. . . . . . . . . . . . . . . . . . . . . . .
14Cruise control indicator light 312
. . . . . . . . . . . . . . . .
15Engine oil replacement reminder light 51
. . . . . . . . . .
16Engine coolant temperature gauge 41
. . . . . . . . . . . . . Page
17Discharge warning light
50
. . . . . . . . . . . . . . . . . . . . . . .
18Low engine oil pressure warning light 50
. . . . . . . . . .
19Malfunction indicator lamp 47
. . . . . . . . . . . . . . . . . . . .
20Slip indicator light 322, 324, 327, 329
. . . . . . . . . . . . .
21Vehicle skid control system off
indicator light 324 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22Center differential lock indicator light 309
. . . . . . . .
23“VSC TRAC” warning light 50
. . . . . . . . . . . . . . . . . . . . .
24Downhill assist control system
indicator light 326 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
25Rear height control indicator lights 319
. . . . . . . . . . .
26Security indicator light 12, 175
. . . . . . . . . . . . . . . . . . .
27SRS warning light 46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28Trip meter reset knob 42
. . . . . . . . . . . . . . . . . . . . . . . . .
29Odometer and trip meter 42
. . . . . . . . . . . . . . . . . . . . . .
30Low fuel level warning light 51
. . . . . . . . . . . . . . . . . . . .
31Fuel gauge 40
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

PICTORIAL INDEX
xi
SEAT AND STEERING WHEEL
Page
1Tilt and telescopic steering
control switch 114. . . . . . . . . . . . . . . . . .
2Seat position, seat cushion
angle and height control
switch 98, 99. . . . . . . . . . . . . . . . . . . . . .
3Seatback angle control switch 98 . . . .
4Lumbar support
control switch 99. . . . . . . . . . . . . . . . . . .
For detailed information, refer to the
description given in each section.

PPY003
PICTORIAL INDEX
xii
EXTERIOR VIEW
Page
1Rear window defogger31
. . . . . . . . . . .
2Back door 21
. . . . . . . . . . . . . . . . . . . . . .
3Fuel filler door 84
. . . . . . . . . . . . . . . . . .
4Moon roof 86
. . . . . . . . . . . . . . . . . . . . . .
5Wiper and washer 27, 454
. . . . . . . . . .
6Outside rear view mirror 115 . . . . . . . .
7Side door 18
. . . . . . . . . . . . . . . . . . . . . . .
8Tire and wheel 432
. . . . . . . . . . . . . . . . .
9Headlights 24, 455
. . . . . . . . . . . . . . . . .
10Hood 83
. . . . . . . . . . . . . . . . . . . . . . . . . . .
For detailed information, refer to the
description given in each section.

PICTORIAL INDEX
xiii

BASIC OPERATION
1
QUICK REFERENCE
Driver’s seat2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Steering wheel 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
Automatic transmission 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Headlight and turn signal switch 4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper switch 5
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .

Seat position
Head restraint angle
Head restraint height Lumbar supportSeatback angle
Seat cushion height
Seat cushion angle

TILT STEERING WHEEL
 TELESCOPIC STEERING WHEEL
To tilt the steering wheel up or down to the desired angle, push
the control switch in the required direction and release the
button when the steering wheel reaches the desired angle.
To move the steering wheel to the desired position, push the
control switch away from you or pull it toward you until the
steering wheel reaches the desired position.
BPY015
(7.2/5.5)
BPY016
(7.2/59.5)
QUICK REFERENCE
2
1. DRIVER’S SEAT 2. STEERING WHEEL

BPY011
BPY019
Shift while pressing the brake pedal.
(Ignition switch must be in the “ON” position.)
OPERATION OF SELECTOR LEVER
SELECTOR LEVER POSITION
P: Parking, engine starting and key removal
position
R: Reverse position
N: Neutral position
D: Normal driving position (shifting into overdrive
possible)
4: Position for engine braking (shifting into over-
drive not possible)
3, 2: Position for more powerful engine braking
L: Position for maximum engine braking
NOTE: When the cruise control is being used, even if you downshift from \
“D” to “4”, engine braking will not be enabled
because the cruise control is not cancelled. For the operation to decre\
ase the vehicle speed, see page 313.
QUICK REFERENCE
3
3. AUTOMATIC TRANSMISSION
