2003 HONDA ACCORD SEDAN Owner's Manual (in English)

The air cleaner element should be
cleaned or replaced according to the
time and distance recommendations
in the maintenance schedule.
Clean the air cleaner element by
blowing compressed air through it in
the opposite direction to normal air
f low. If you do not have access to
compressed air (such as a service
station), ask your Honda dealer to do
this service.
Follow the replacement procedure
for removal and reinstallation.
Always use Honda Power Steering
Fluid. If it is not available, you may
use another power steering f luid as
an emergency replacement.
However, continued use can cause
increased wear and poor steering in
cold weather. Have the power
steering system f lushed and ref illed
with Honda PSF as soon as possible.
A low power steering f luid level can
indicate a leak in the system. Check
the f luid level f requently and have
the system inspected as soon as
possible.
A ir Cleaner Element
Cleaning (Severe Condit ions)
Power Steering, A ir Cleaner Element
Maint enance286
T urning the steering wheel to f ull lef t
or right lock and holding it there can
damage the power steering pump.

Place the new air cleaner element
in the air cleaner housing.
Loosen the f our bolts, and remove
the air cleaner housing cover.
Remove the old air cleaner
element.
Caref ully clean the inside of the
air cleaner housing with a damp
rag. Reinstall the air cleaner housing
cover, and tighten the four bolts.
The air cleaner element is inside the
air cleaner housing on the driver’s
side of the engine compartment.
To replace it:
1.
3.4.
5.
2.
CONT INUED
Replacement
A ir Cleaner Element (4-cylinder Models)
Maint enance287
BOLTS
AIR CLEANER ELEMENT

Place the new air cleaner element
in the air cleaner housing.
Reinstall the air cleaner housing
cover, and tighten the four bolts.
The air cleaner element is inside the
air cleaner housing on the driver’s
side of the engine compartment.
To replace it:
Disconnectthehosefromtheair
cleaner housing cover with f lat-
tipped screwdriver.
Loosen the f our bolts, and remove
the air cleaner housing cover.
Remove the old air cleaner
element.
Caref ully clean the inside of the
air cleaner housing with a damp
rag.Connectthehosetotheair
cleaner housing cover with a f lat-
tipped screwdriver.
1.
3.
4. 5.
2. 6.
7.
Replacement
A ir Cleaner Element (6-cylinder Models)
Maint enance288
BOLTS
AIR CLEANER ELEMENT
HOSE

Clean the hood latch assembly with a
mild cleaner, then lubricate it with a
multipurpose grease. Lubricate all
the moving parts (as shown),
including the pivot. Follow the time
and distance recommendations in
the Maintenance Schedule. If you
are not sure how to clean and grease
the latch, contact your Honda dealer.Remove the f our nuts with a
wrench, then remove the coil
cover.
The spark plugs in your car are a
special iridium-tipped design f or
longer lif e. The spark plugs should
be replaced according to the distance
recommendation in the maintenance
schedule.
1.
CONT INUED
ReplacementSpark Plugs
Hood L atch
Hood L atch, Spark Plugs (4-cylinder Models)
Maint enance289
PIVOTS
LATCH ASSEMBLY NUTS
NUTS
COIL COVER

Clean up any dirt and oil that have
collected around the ignition coils.
Use a wrench to remove the bolt
holding the ignition coil. Pull the
ignition coil up slightly.
Disconnect the wire connector
f rom the ignition coil by pushing
on the lock tab and pulling on the
connector. Pull on the plastic
connector, not the wires.Remove the ignition coil.
Remove the spark plug with
a f ive-eighths inch (16 mm) spark
plug socket.
Torque the spark plug. (If you do
not have a torque wrench, tighten
the spark plug two-thirds of a turn
after it contacts the cylinder head.)
Tightening torque:
Put the new spark plug into the
socket, then screw it into the hole.
Screw it in by hand so you do not
crossthread it.
5.
2.
4. 3. 6.
7.8.
Spark Plugs (4-cylinder Models)
Maint enance290
BOLT
CONNECTOR
IGNITION COIL LOCK TAB
13 lbf·ft (18 N·m , 1.8 kgf·m)

Install the ignition coil into the
hole.
Connect the wire connector to the
ignition coil. Make sure it locks in
place.
Push the ignition coil down all the
way. Install the bolt.
Repeat this procedure f or the
other three spark plugs.
Reinstall the coil cover, and
tighten the f our nuts.The spark plugs in your car are a
special iridium-tipped design f or
longer lif e. The spark plugs should
be replaced according to the distance
recommendation in the maintenance
schedule.
9.
10.
11.
12.
13. NGK:
DENSO:
NGK:
DENSO:
On some models
CONT INUED
Specif ications:
Spark Plugs (6-cylinder Models)
Spark Plugs (4-cylinder Models), Spark Plugs (6-cylinder Models)
Maint enance291
IZFR6K-11
SKJ20DR-M11
IZFR6K-13
SKJ20DR-M13
Tighten the spark plugs caref ully. A
spark plug that is too loose can
overheat and damage the engine.
Overtightening can cause damage to
the threads in the cylinder head.

Disconnect the wire connector
f rom the ignition coil by pushing
on the lock tab and pulling on the
connector. Pull on the plastic
connector, not the wires.Remove the spark plug with
a f ive-eighths inch (16 mm) spark
plug socket. Use a wrench to remove the
hexagonsocketheadcapbolt
holding the ignition coil. Remove
the ignition coil by pulling it
straight out.
Loosen the two holding clips by
turning the heads one-quarter turn
counterclockwise with a f lat-tipped
screwdriver. Remove the cover on
the f ront cylinder bank by pulling
it straight up. Cleanoffanydirtandoilthathas
collected around the ignition coil.
1.
2.
3.4.
5.
Replacement
Spark Plugs (6-cylinder Models)
Maint enance292
HOLDING CLIP CONNECTOR
HEXAGON SOCKET HEAD CAP BOLT
IGNITION COIL

Torque the spark plug. (If you do
not have a torque wrench, tighten
the spark plug two-thirds of a turn
af ter it contacts the cylinder head.)
Tightening torque: Put the new spark plug into the
socket, then screw it into the hole.
Screw it in by hand so you do not
crossthread it.Install the ignition coil. Reinstall
the hexagon socket head cap bolt.Push the wire connector onto the
ignition coil. Make sure it locks in
place.
Reinstall the cover on the front
cylinder bank while putting its
mounting clip in the hole on the
passenger’s side. Secure the cover
by turning the heads of the two
holding clips one-quarter turn
clockwise with a f lat-tipped
screwdriver. Repeat this procedure f or the
other f ive spark plugs.
NGK:
DENSO:
6.
7.
8.9.
10.
11.
Specif ications:
Spark Plugs (6-cylinder Models)
Maint enance293
13 lbf·ft (18 N·m , 1.8 kgf·m) IZFR6K-11
SKJ20DR-M11
Tighten the spark plugs caref ully. A
spark plug that is too loose can
overheat and damage the engine.
Overtightening can cause damage to
the threads in the cylinder head.
