2003 HONDA ACCORD SEDAN Owner's Manual (in English)

If you want to adjust the sound while
the radio/CD is playing, push the
AUDIO DISPLAY button, then touch
the SOUND icon in the display.To return to the previous display,
push the AUDIO DISPLAY button
again.The upper display shows the time
when the ignition switch is in
ACCESSORY (I) or ON (II). Ref er to
the Navigation System Owner’s
Manual to set up the time.
Audio System
Comf ort and Convenience Feat ures
Digital Clock
174
DIGITAL CLOCK
SOUND ICON AUDIO DISPLAY
BUTTON UPPER DISPLAY

Your Honda’s radio can receive the
complete AM and FM bands.
Those bands cover these f requen-
cies:
AM band:
530 to 1,710 kilohertz
FM band:
87.7 to 107.9 megahertz
Radio stations on the AM band are
assigned f requencies at least ten
kilohertz apart (530, 540, 550).
Stations on the FM band are
assigned f requencies at least 0.2
megahertz apart (87.9, 88.1, 88.3).
Stations must use these exact
f requencies. It is f airly common f or
stations to round-of f the f requency in
their advertising, so your radio could
display a f requency of 100.9 even
though the announcer may identif y
the station as ‘‘FM101.’’How well your Honda’s radio
receives stations is dependent on
many f actors, such as the distance
from the station’s transmitter,
nearby large objects, and atmos-
pheric conditions.
A radio station’s signal gets weaker
as you get f arther away f rom its
transmitter. If you are listening to an
AM station, you will notice the sound
volume becoming weaker, and the
stationdriftinginandout.If youare
listening to an FM station, you will
see the stereo indicator f lickering of f
and on as the signal weakens.
Eventually, the stereo indicator will
go of f and the sound will f ade
completely as you get out of range of
the station’s signal.
Driving very near the transmitter of
a station that is broadcasting on a
f requency close to the f requency of
the station you are listening to can
also af f ect your radio’s reception.
You may temporarily hear both
stations,orhearonlythestationyou
are close to.
CONT INUED
Radio Frequencies
Radio Reception
Audio System
Comf ort and Convenience Feat ures175

Radio signals, especially on the FM
band, are def lected by large objects
such as buildings and hills. Your
radio then receives both the direct
signal f rom the station’s transmitter,
and the def lected signal. This causes
the sound to distort or flutter. This is
a main cause of poor radio reception
in city driving.Radio reception can be af f ected by
atmospheric conditions such as
thunderstorms, high humidity, and
even sunspots. You may be able to
receive a distant radio station one
day and not receive it the next day
because of a change in conditions.
Electrical interf erence f rom passing
vehicles and stationary sources can
cause temporary reception problems.
As required by the FCC:
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
Audio System
Comf ort and Convenience Feat ures176

Your Honda’s audio system has an
in-dash CD changer that holds up to
six discs, providing several hours of
continuous entertainment. You
operate this CD changer with the
same controls used f or the radio.
To load CDs or operate the CD
changer, the ignition switch must be
in ACCESSORY (I) or ON (II).
Load and play only standard round
discs. Odd-shaped CDs may jam in
the drive or cause other problems.
You cannot load and play 3-inch
(8-cm)discsinthissystem.
For best results when using CD-R
discs, use only high quality discs
labeled f or audio use. When
recording a CD-R, the recording
must be closed in order f or the disc
to be used by CD players. CD-RW
discs will not work in this unit.
CONT INUED
Operating the CD Changer
Audio System
Comf ort and Convenience Feat ures177
LOAD BUTTON CD/AUX
BUTTON
PWR/VOL
KNOBCD LOAD
INDICATOR
UPPER DISPLAY

To load multiple CDs in one
operation:Repeat this until all six positions
are loaded. The system will then
begin playing the last CD loaded.To load a single CD:
Press and hold the LOAD button
until you hear a beep and see
‘‘LOAd’’ in the upper display, then
release the button. Press and release the LOAD
button.
The system will load the CD, and
begin playing it.
If you stop loading CDs bef ore all six
positions are f illed, the system will
wait f or ten seconds, then stop the
load operation and begin playing the
last CD loaded.
Insert the disc into the CD slot.
Insert it only about halfway; the
drive will pull it in the rest of the
way. You will see ‘‘BUSY’’ in the
display. The CD load indicator
turns red and blinks as the CD is
loaded.
When ‘‘LOAd’’ appears again in
the display, insert the next disc
into the CD slot. The disc number f or an empty
position is highlighted and the
green CD load indicator comes on.
When you see ‘‘LOAd’’ in the
upper display, insert the disc into
the CD slot. Insert it only about
half way; the drive will pull it in the
rest of the way.
1.
2.
3. 4.
1.
2.
3.
L oading CDs in t he Changer
Audio System
Comf ort and Convenience Feat ures178

µ
If you press the LOAD button while
a CD is playing, the system will stop
playing that CD and start the loading
sequence. It will then play the CD
just loaded.
You can also load a CD into an empty
position while a CD is playing by
touching the appropriate disc icon.
Select an empty position (the disc
icon below the disc number is dark),
and touch the icon f or that position
(1 6). The system will stop playing
the current CD and start the loading
sequence. It will then play the CD
just loaded.
CONT INUED
Audio System
Comf ort and Convenience Feat ures179
DISC NUMBER
CD LOAD INDICATOR EJECT
BUTTONDISC BAR AUDIO
DISPLAY
BUTTON
LOAD
BUTTON
CD SLOT CD/AUX
BUTTON
SEEK/SKIP
BAR DISC ICONS

µ
Select the CD changer by pressing
the CD/AUX button. You will see
‘‘CD’’ in the upper display. The
system will begin playing the last
selected disc in the CD changer. You
will see the disc and track numbers
displayed.
When that disc ends, the next disc in
the CD changer is loaded and played.
Af ter the last disc f inishes, the
system returns to disc 1.
To select a dif f erent disc, touch the
appropriate disc icon (1 6) or
press the DISC bar next to the audio
display. If you select an empty
position in the CD changer, the
system will go into the loading
sequence (see page ).
You can use the SKIP bar while a
disc is playing to select passages and
change tracks. Each time you press and release the
top of the SKIP bar, the system
skips forward to the beginning of the
next track. Press and release the
bottom toskipbackwardtothe
beginning of the current track. Press
it again to skip to the beginning of
the previous track. To move rapidly within a track, press
and hold the top or bottom of the
SKIP bar. You will hear a beep and
the system will continue to move
through the track. Press to
move forward, or to move
backward. Release the bar when the
system reaches the point you want.
178
Operat ion
Audio System
Comf ort and Convenience Feat ures180

CONT INUED
When you touch the TRACK SCAN
icon on the audio display or press the
SCAN button next to the display, the
f irst track of the current CD plays
about 10 seconds. You will see
TRACK SCAN in the display (or
SCAN in the upper display). To hear
the rest of the track, touch TRACK
SCAN or press SCAN again, within
10 seconds. If you don’t, the system
advances to the next track, plays
about 10 seconds of it, and continues
through the rest of the tracks the
same way.When you touch the DISC RPT icon
on the audio display, the system
continuously replays the current CD.
As a reminder, you will see DISC
REPEAT in the display (or D-RPT in
the upper display). To turn this
f eature of f , touch Disc RPT again.
When you touch the RANDOM icon
on the audio display, the system
plays the tracks of the current CD in
random order, rather than in the
order they were recorded. As a
reminder, you will see TRACK
RANDOM in the display (or RDM in
the upper display). To turn this
f eature of f , touch RANDOM again,
or select a dif f erent CD with one of
the disc icons.
When you touch the TRACK RPT
icon on the audio display, the system
continuously replays the current
track. As a reminder, you will see
TRACK REPEAT in the display (or
RPT in the upper display). To turn
this feature off, touch TRACK
REPEAT again. When you touch the DISC SCAN
icon on the audio display, the f irst
track of the current CD plays about
10 seconds. You will see DISC SCAN
in the display (or D-SCAN in the
upper display). To hear the rest of
the CD, touch DISC SCAN again,
within 10 seconds. If you don’t, the
system advances to the next CD,
plays about 10 seconds of it, and
continues through the rest of the
CDs the same way.
Audio System
Comf ort and Convenience Feat ures
T rack Scan
Disc Repeat
Random Play
T rack Repeat Disc Scan
181
