2003 DODGE RAM ignition

8W-30 FUEL/IGNITION SYSTEM
Component PageA/C Compressor Clutch Relay...........8W-30-27, 36, 83
A/C Pressure Transducer.......8W-30-19, 20, 21, 48, 53, 70
Accelerator Pedal Position Sensor.............8W-30-55
Adjustable Pedal Motor....................8W-30-87
Adjustable Pedal Relay....................8W-30-87
Adjustable Pedal Switch...................8W-30-87
Ambient Temperature Sensor................8W-30-56
Auto Shut Down Relay..................8W-30-4, 31
Battery..............................8W-30-77
Battery Temperature Sensor............8W-30-28, 39, 81
Brake Lamp Switch.............8W-30-25, 35, 65, 82, 89
Camshaft Position Sensor.......8W-30-17, 18, 37, 55, 70, 71
Capacitor.........................8W-30-6, 11, 43
Clockspring..................8W-30-25, 35, 65, 84, 90
Clutch Interlock Brake Switch...............8W-30-32
Coil On Plug No. 1...................8W-30-8, 42, 61
Coil On Plug No. 2...................8W-30-7, 40, 60
Coil On Plug No. 3...................8W-30-8, 42, 61
Coil On Plug No. 4...................8W-30-7, 40, 60
Coil On Plug No. 5...................8W-30-6, 41, 61
Coil On Plug No. 6...................8W-30-6, 43, 60
Coil On Plug No. 7....................8W-30-41, 61
Coil On Plug No. 8....................8W-30-43, 60
Condenser Fan Relay...................8W-30-27, 36
Controller Antilock Brake...........8W-30-23, 33, 38, 82
Crankshaft Position Sensor.............8W-30-17, 18, 37
Data Link Connector..........8W-30-27, 36, 46, 80, 89, 91
Data Link Connector-Engine................8W-30-75
Electronic Throttle Control Module............8W-30-63
Engine Control Module......8W-30-67, 68, 69, 70, 71, 72, 73,
74, 75, 76, 77, 78, 79, 80, 81, 82,
83, 84, 90, 91
Engine Coolant Temperature
Sensor.................8W-30-19, 20, 21, 48, 64, 72
Engine Oil Pressure Switch......8W-30-19, 20, 21, 29, 78, 81
EVAP/Purge Solenoid...................8W-30-28, 39
Front Control Module.....................8W-30-87
Fuel Heater...........................8W-30-85
Fuel Heater Relay.......................8W-30-85
Fuel Injector No. 1...............8W-30-8, 9, 11, 42, 62
Fuel Injector No. 2...............8W-30-7, 9, 12, 40, 59
Fuel Injector No. 3...............8W-30-8, 9, 11, 42, 62
Fuel Injector No. 4...............8W-30-7, 9, 12, 40, 60
Fuel Injector No. 5...............8W-30-6, 9, 11, 41, 62
Fuel Injector No. 6...............8W-30-6, 9, 12, 43, 59
Fuel Injector No. 7................8W-30-9, 11, 41, 62
Fuel Injector No. 8................8W-30-9, 12, 43, 59
Fuel Injector No. 9.......................8W-30-11
Fuel Injector No. 10......................8W-30-12
Fuel Injector Pack No. 1...................8W-30-67
Fuel Injector Pack No. 2..............8W-30-67, 68, 69
Fuel Injector Pack No. 3...................8W-30-69
Fuel Pump Module................8W-30-3, 30, 79, 83
Fuel Pump Motor.......................8W-30-76
Fuel Pump Relay......................8W-30-3, 30
Fuel Rail Pressure Sensor..................8W-30-74
Fuse 2.............................8W-30-4, 31
Fuse 5............................8W-30-50, 88
Fuse 12.............................8W-30-85
Fuse 17............................8W-30-3, 30
Fuse 19.......................8W-30-2, 29, 77, 90
Fuse 36...........................8W-30-79, 87
Fuse 40.............................8W-30-87
Fuse 49............................8W-30-4, 31
Fuse 50...........................8W-30-28, 88Component PageFusible Link..........................8W-30-77
G103.........................8W-30-3, 25, 30, 35
G104.........................8W-30-3, 25, 30, 35
G105.............................8W-30-81, 86
G106...............................8W-30-85
G107.........8W-30-2, 16, 24, 29, 34, 40, 42, 45, 47, 50, 54
G114 ...............................8W-30-78
G117 ...............................8W-30-91
G120.............................8W-30-75, 85
G201..........................8W-30-23, 33, 91
G203...............................8W-30-87
Generator.......................8W-30-24, 34, 75
Idle Air Control Motor..................8W-30-27, 36
Ignition Coil...........................8W-30-9
Ignition Coil-Left.......................8W-30-10
Ignition Coil-Right.......................8W-30-10
Ignition Switch....................8W-30-23, 33, 46
Inlet Air Temperature/Pressure Sensor..........8W-30-73
Input Speed Sensor......................8W-30-49
Intake Air Heater Relay No. 1...............8W-30-81
Intake Air Heater Relay No. 2...............8W-30-81
Intake Air Temperature Sensor......8W-30-19, 20, 21, 48, 64
Intake Air Temperature/Manifold Absolute Pressure
Sensor............................8W-30-74
Integrated Power Module . . 8W-30-2, 3, 4, 26, 27, 29, 30, 31, 36,
50, 77, 79, 80, 83, 85, 86, 87, 88, 90
Knock Sensor..........................8W-30-22
Knock Sensor-Left.......................8W-30-57
Knock Sensor-Right......................8W-30-57
Leak Detection Pump..................8W-30-24, 34
Lift Pump Motor........................8W-30-75
Line Pressure Sensor.....................8W-30-44
Manifold Absolute Pressure
Sensor.................8W-30-19, 20, 21, 48, 55, 64
Output Speed Sensor................8W-30-26, 49, 88
Overdrive Switch...................8W-30-23, 33, 91
Oxygen Sensor 1/1 Upstream.......8W-30-13, 14, 15, 47, 54
Oxygen Sensor 1/2 Downstream.....8W-30-13, 14, 16, 45, 54
Oxygen Sensor 2/1 Upstream..............8W-30-15, 47
Oxygen Sensor 2/2 Downstream............8W-30-16, 45
Oxygen Sensor Downstream Relay...........8W-30-4, 31
Power Steering Pressure Switch............8W-30-24, 34
Powertrain Control Module . . 8W-30-2, 3, 4, 5, 6, 7, 8, 9, 10, 11,
12, 13, 14, 15, 16 17, 18, 19, 20, 21, 22, 23, 24, 25, 27, 28, 29,
30, 31, 32, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 45, 46,
47, 48, 49, 50, 51, 52, 53, 54, 55, 56, 57, 58, 59, 60, 61, 62, 63,
64, 65, 66, 77, 79, 82, 84, 85, 88, 89, 90, 91
PTCNo.1 ...........8W-30-2, 3, 27, 29, 30, 36, 80, 83, 86
PTO Switch.........................8W-30-23, 33
Speed Control Servo.................8W-30-25, 35, 89
Speed Control Switch-Left.............8W-30-65, 84, 90
Speed Control Switch-Right............8W-30-65, 84, 90
Starter Motor Relay......................8W-30-29
Throttle Position Sensor.................8W-30-22, 44
Throttle Position Switch...................8W-30-72
Transfer Case Control Module...............8W-30-65
Transmission Control Module.......8W-30-17, 23, 33, 38, 66
Transmission Control Relay............8W-30-26, 50, 88
Transmission Range Sensor..................8W-30-5
Transmission Solenoid Assembly.......8W-30-20, 21, 26, 88
Transmission Solenoid/TRS Assembly . . 8W-30-5, 32, 50, 51, 52
Vacuum Pump.........................8W-30-86
Vehicle Speed Sensor.....................8W-30-71
Vistronic Fan Drive......................8W-30-79
Water In Fuel Sensor...................8W-30-72, 76
DR8W-30 FUEL/IGNITION SYSTEM 8W - 30 - 1

8W-31 TRANSMISSION CONTROL SYSTEM
Component Page
Automatic Day/Night Mirror........ 8W-31-7, 15
Brake Lamp Switch................. 8W-31-17
Clockspring........................ 8W-31-18
Clutch Interlock Brake Switch......... 8W-31-20
Data Link Connector....... 8W-31-5, 8, 17, 19, 25
Engine Control Module............ 8W-31-18, 19
Front Control Module.............. 8W-31-7, 10
Fuse 5.................... 8W-31-2, 10, 13, 16
Fuse 19........................... 8W-31-18
Fuse 28........................... 8W-31-23
Fuse 38...................... 8W-31-7, 10, 15
Fuse 43........................... 8W-31-20
Fuse 50........................... 8W-31-16
G107......................... 8W-31-2, 4, 10
G117............................. 8W-31-19
G201..................... 8W-31-9, 11, 19, 23
G203.......................... 8W-31-20, 25
Ignition Switch...................... 8W-31-5
Input Speed Sensor............... 8W-31-6, 14
Instrument Cluster............. 8W-31-5, 15, 23
Integrated Power Module . . . 8W-31-2, 7, 10, 13, 15,
16, 18, 20, 23
Line Pressure Sensor................. 8W-31-6
Output Speed Sensor........ 8W-31-6, 13, 14, 16Component Page
Overdrive Switch.............. 8W-31-9, 11, 19
Powertrain Control
Module . . 8W-31-3, 5, 8, 9, 10, 11, 12, 13, 14, 15,
16, 17, 18, 19
Speed Control Servo................. 8W-31-17
Speed Control Switch-Left............ 8W-31-18
Speed Control Switch-Right........... 8W-31-18
Starter Motor Relay................. 8W-31-20
Tail/Stop/Turn Signal Lamp-Left........ 8W-31-7
Tail/Stop/Turn Signal Lamp-Right....... 8W-31-7
Throttle Position Sensor............... 8W-31-9
Transfer Case Control
Module........... 8W-31-20, 21, 22, 23, 24, 25
Transfer Case Mode Sensor........ 8W-31-21, 22
Transfer Case Selector Switch...... 8W-31-23, 24
Transfer Case Shift Motor............ 8W-31-25
Transmission Control
Module.............. 8W-31-2, 3, 4, 5, 6, 8, 9
Transmission Control Relay . . . 8W-31-2, 10, 13, 16
Transmission Range Sensor........... 8W-31-15
Transmission Solenoid Assembly.... 8W-31-13, 16
Transmission Solenoid/TRS
Assembly........ 8W-31-2, 3, 4, 6, 7, 10, 11, 12
DR8W-31 TRANSMISSION CONTROL SYSTEM 8W - 31 - 1

8W-40 INSTRUMENT CLUSTER
Component Page
A/C-Heater Control.................. 8W-40-11
Brake Transmission Shift Interlock
Solenoid........................ 8W-40-10
Center High Mounted Stop Lamp/Cargo
Lamp........................ 8W-40-5, 11
Clockspring..................... 8W-40-10, 13
Cylinder Lock Switch- Driver........... 8W-40-6
Cylinder Lock Switch- Passenger........ 8W-40-6
Data Link Connector................. 8W-40-5
Dome Lamp....................... 8W-40-11
Door Ajar Switch-Driver.............. 8W-40-12
Door Ajar Switch-Left Rear........... 8W-40-12
Door Ajar Switch-Passenger........... 8W-40-12
Door Ajar Switch-Right Rear.......... 8W-40-12
Door Lock Motor/Ajar Switch-Driver..... 8W-40-7
Door Lock Motor/Ajar Switch-Left Rear . . . 8W-40-7
Door Lock Motor/Ajar Switch-
Passenger...................... 8W-40-6, 8
Door Lock Motor/Ajar Switch-
Right Rear..................... 8W-40-7, 8
Door Lock Switch-Passenger........... 8W-40-6
Driver Door Module.................. 8W-40-8
Fog Lamp Relay..................... 8W-40-3
Fog Lamp-Left...................... 8W-40-3
Fog Lamp-Right..................... 8W-40-3
Fuse 18............................ 8W-40-5
Fuse 22............................ 8W-40-5Component Page
Fuse 41............................ 8W-40-3
G201........................... 8W-40-3, 11
G202............................. 8W-40-10
G301....................... 8W-40-2, 6, 7, 12
Glove Box Lamp And Switch.......... 8W-40-11
Headlamp Switch.................... 8W-40-3
Heated Seat Switch- Driver......... 8W-40-8, 11
Heated Seat Switch- Passenger...... 8W-40-8, 11
Horn Switch....................... 8W-40-13
Ignition Switch................... 8W-40-5, 13
Instrument Cluster........ 8W-40-2, 3, 4, 5, 6, 7,
8, 9, 10, 11, 12, 13
Integrated Power Module........ 8W-40-2, 3, 5, 9
Multi-Function Switch................ 8W-40-4
Park Brake Switch.................. 8W-40-13
Powertrain Control Module........... 8W-40-13
PTCNo.2........................ 8W-40-2, 9
Radio.......................... 8W-40-9, 11
Remote Radio Switch-Left............ 8W-40-10
Remote Radio Switch-Right........... 8W-40-10
Seat Belt Switch-Driver............... 8W-40-2
Seat Belt Tensioner Reducer........... 8W-40-2
Transfer Case Selector Switch......... 8W-40-13
Transmission Control Module.......... 8W-40-13
Transmission Range Sensor............ 8W-40-5
DR8W-40 INSTRUMENT CLUSTER 8W - 40 - 1

8W-42 AIR CONDITIONING
Component Page
A/C Compressor Clutch............... 8W-42-7
A/C Compressor Clutch Relay.......... 8W-42-7
A/C Pressure Transducer............ 8W-42-8, 9
A/C-Heater Control........... 8W-42-2, 3, 4, 5, 6
Blend Door Actuator.................. 8W-42-6
Blower Motor....................... 8W-42-2
Blower Motor Resistor Block........... 8W-42-2
Condenser Fan..................... 8W-42-10
Condenser Fan Relay................ 8W-42-10
Data Link Connector............. 8W-42-3, 4, 8
Driver Blend Door Actuator............ 8W-42-5
Engine Control Module.............. 8W-42-7, 9
Evaporator Temperature Sensor......... 8W-42-4
Fuse 12........................... 8W-42-10
Fuse 16............................ 8W-42-7
Fuse 36............................ 8W-42-3
Fuse 36............................ 8W-42-4Component Page
G107.............................. 8W-42-7
G120.............................. 8W-42-7
G202.............................. 8W-42-3
G202.............................. 8W-42-4
G203.............................. 8W-42-2
Heated Mirror Relay............... 8W-42-3, 4
Ignition Switch...................... 8W-42-2
Instrument Cluster................... 8W-42-2
Integrated Power Module....... 8W-42-3, 4, 7, 10
Mode Door Actuator 1............... 8W-42-5, 6
Mode Door Actuator 2............... 8W-42-5, 6
Passenger Blend Door Actuator......... 8W-42-5
Powertrain Control Module........ 8W-42-7, 8, 10
PTCNo.1.......................... 8W-42-7
Recirculation Door Actuator.......... 8W-42-5, 6
DR8W-42 AIR CONDITIONING 8W - 42 - 1

8W-60 POWER WINDOWS
Component Page
Circuit Breaker................... 8W-60-2, 4
Driver Door Module........ 8W-60-2, 3, 4, 5, 6, 7
G302............................ 8W-60-2, 4
Ignition Switch...................... 8W-60-2
Power Window Circuit Breaker....... 8W-60-2, 4
Power Window Motor-Driver......... 8W-60-2, 4
Power Window Motor-Left Rear......... 8W-60-7Component Page
Power Window Motor-Passenger....... 8W-60-3, 5
Power Window Motor-Right Rear........ 8W-60-6
Power Window Switch-Left Rear...... 8W-60-4, 7
Power Window Switch-Passenger.... 8W-60-3, 4, 5
Power Window Switch-Right Rear..... 8W-60-4, 6
DR8W-60 POWER WINDOWS 8W - 60 - 1

Component Page
Glove Box Lamp And Switch.......... 8W-80-63
Headlamp Switch................... 8W-80-63
Headlamp-Left..................... 8W-80-64
Headlamp-Right.................... 8W-80-64
Heated Seat Cushion-Passenger........ 8W-80-64
Heated Seat Switch-Driver............ 8W-80-64
Heated Seat Switch-Passenger......... 8W-80-65
Horn Switch....................... 8W-80-65
Horn-High Note.................... 8W-80-65
Horn-Low Note..................... 8W-80-65
Idle Air Control Motor (3.7L/5.9L/8.0L) . . 8W-80-65
Idle Air Control Motor (NGC).......... 8W-80-66
Ignition Coil (5.9L).................. 8W-80-66
Ignition Coil-Left (8.0L).............. 8W-80-66
Ignition Coil-Right (8.0L)............. 8W-80-66
Ignition Switch..................... 8W-80-67
Inlet Air Temperature/ Pressure Sensor
(Diesel)......................... 8W-80-67
Input Speed Sensor (3.7L/4.7L/5.7L)..... 8W-80-67
Instrument Cluster C1............... 8W-80-68
Instrument Cluster C2............... 8W-80-68
Instrument Cluster C3............... 8W-80-69
Intake Air Temperature Sensor........ 8W-80-69
Intake Air Temperature/Manifold Absolute
Pressure Sensor (Diesel)............ 8W-80-69
Integrated Power Module C1.......... 8W-80-70
Integrated Power Module C2.......... 8W-80-70
Integrated Power Module C3.......... 8W-80-71
Integrated Power Module C4.......... 8W-80-71
Integrated Power Module C5.......... 8W-80-72
Integrated Power Module C6.......... 8W-80-72
Integrated Power Module C7.......... 8W-80-73
Knock Sensor (3.7L)................. 8W-80-73
Knock Sensor-Left (5.7L)............. 8W-80-74
Knock Sensor-Right (5.7L)............ 8W-80-74
Leak Detection Pump (NGC).......... 8W-80-74
Leak Detection Pump................ 8W-80-74
License Lamp-Left.................. 8W-80-74
License Lamp-Right................. 8W-80-75
Lift Pump Motor (Diesel)............. 8W-80-75
Line Pressure Sensor (3.7L/5.7L)....... 8W-80-75
Line Pressure Sensor (4.7L)........... 8W-80-75
Lumbar Motor-Driver................ 8W-80-76
Lumbar Motor-Passenger............. 8W-80-76
Manifold Absolute Pressure Sensor
(3.7L/4.7L/5.7L).................. 8W-80-76
Manifold Absolute Pressure Sensor
(5.9L/8.0L)...................... 8W-80-76
Mode Door Actuator 1 (Panel To Floor) . . . 8W-80-77
Mode Door Actuator 2 (Defrost To Floor) . 8W-80-77
Multi-Function Switch............... 8W-80-77
Output Speed Sensor (3.7L/4.7L/5.7L) . . . 8W-80-77
Output Speed Sensor (5.9L)........... 8W-80-77
Output Speed Sensor (Diesel).......... 8W-80-78Component Page
Overdrive Switch................... 8W-80-78
Overhead Map/Reading Lamp (Except
Base).......................... 8W-80-78
Oxygen Sensor 1/1 Upstream.......... 8W-80-78
Oxygen Sensor 1/2 Downstream........ 8W-80-79
Oxygen Sensor 2/1 Upstream (California 4.7L/
California 5.9L).................. 8W-80-79
Oxygen Sensor 2/2 Downstream (California
4.7L/California 5.9L)............... 8W-80-79
Park/Turn Signal Lamp-Left Front...... 8W-80-80
Park/Turn Signal Lamp-Right Front.... 8W-80-80
Passenger Blend Door Actuator (Dual-
Zone).......................... 8W-80-80
Passenger Lumbar Switch............ 8W-80-80
Power Mirror-Left................... 8W-80-80
Power Mirror-Right................. 8W-80-81
Power Outlet...................... 8W-80-81
Power Outlet-Console (Except Base)..... 8W-80-81
Power Seat Motor-Driver Front Vertical . . 8W-80-81
Power Seat Motor-Driver Horizontal.... 8W-80-82
Power Seat Motor-Driver Rear Vertical . . 8W-80-82
Power Seat Switch-Driver............ 8W-80-82
Power Seat Switch-Passenger.......... 8W-80-82
Power Steering Pressure Switch
(3.7L/4.7L/5.7L).................. 8W-80-83
Power Window Motor-Driver.......... 8W-80-83
Power Window Motor-Left Rear........ 8W-80-83
Power Window Motor-Passenger........ 8W-80-83
Power Window Motor-Right Rear....... 8W-80-83
Power Window Switch-Left Rear....... 8W-80-84
Power Window Switch-Right Rear...... 8W-80-84
Power Window-Circuit Breaker........ 8W-80-84
Powertrain Control Module........... 8W-80-84
Powertrain Control Module........... 8W-80-85
Powertrain Control Module........... 8W-80-86
Powertrain Control Module C1 (JTEC) . . . 8W-80-87
Powertrain Control Module C1 (NGC) . . . 8W-80-88
Powertrain Control Module C2 (JTEC) . . . 8W-80-89
Powertrain Control Module C2 (NGC) . . . 8W-80-90
Powertrain Control Module C3 (JTEC) . . . 8W-80-91
Powertrain Control Module C3 (NGC) . . . 8W-80-92
Powertrain Control Module C4 (NGC) . . . 8W-80-93
Radio (Base)....................... 8W-80-94
Radio (Premium)................... 8W-80-94
Recirculation Door Actuator........... 8W-80-95
Remote Radio Switch-Left............ 8W-80-95
Remote Radio Switch-Right........... 8W-80-95
Seat Heater Interface Module.......... 8W-80-95
Sentry Key Immobilizer Module........ 8W-80-96
Speaker-Center Instrument Panel...... 8W-80-96
Speaker-Left Front Door.............. 8W-80-96
Speaker-Left Instrument Panel........ 8W-80-96
Speaker-Left Rear.................. 8W-80-96
Speaker-Right Front Door............ 8W-80-97
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 3

A/C-HEATER CONTROL C1 - BLACK 16 WAY
CAV CIRCUIT FUNCTION
1 F15 20DB FUSED IGNITION SWITCH OUTPUT (RUN)
2 Z120 20WT/BK GROUND
3 C57 20DB/GY SENSOR GROUND
4 C33 20DB/RD MODE DOOR 2 DRIVER
5- -
6 C12 20LG/BK EVAPORATOR TEMPERATURE SENSOR SIGNAL
7- -
8 Y165 20OR/YL PANEL LAMPS DRIVER
9 C62 20DB/PK BLEND DOOR DRIVER
10 C35 20DG/YL MODE DOOR 1 DRIVER
11 C34 20DB/WT COMMON DOOR DRIVER
12 C32 20GY/DB RECIRCULATION DOOR DRIVER
13 C46 20YL/LG PASSENGER BLEND DOOR DRIVER
14 - -
15 C16 20LB/YL HEATED MIRROR RELAY CONTROL
16 D25 20VT/LG PCI BUS
A/C-HEATER CONTROL C2 - BLACK 10 WAY
CAV CIRCUIT FUNCTION
1- -
2 C4 16TN BLOWER MOTOR LOW DRIVER
3 C6 14LB BLOWER MOTOR M2 DRIVER
4- -
5 Z37 10BK/DB GROUND
6- -
7 C5 16LG BLOWER MOTOR M1 DRIVER
8- -
9- -
10 C7 10BK/TN BLOWER MOTOR HIGH DRIVER
ACCELERATOR PEDAL POSITION SENSOR (5.7L/DIESEL M/T NORMAL BUILD)-6WAY
CAV CIRCUIT FUNCTION
1 K81 20DB/DG APPS NO. 2 SIGNAL
2 K6 20VT/WT 5-VOLT SUPPLY
3 K7 20OR 5-VOLT SUPPLY
4 K981 20BR/DG APPS NO. 2 RETURN
5 K255 20WT/DG APPS NO. 1 SIGNAL
6 K223 20PK/DB APPS NO. 1 RETURN
8W - 80 - 6 8W-80 CONNECTOR PIN-OUTSDR

ADJUSTABLE PEDAL MOTOR - WHITE 2 WAY
CAV CIRCUIT FUNCTION
1 Y151 18LG/BR ADJUSTABLE PEDAL MOTOR (DOWN)
2 Y152 18LG/OR ADJUSTABLE PEDAL MOTOR (UP)
ADJUSTABLE PEDAL SWITCH - BLUE 6 WAY
CAV CIRCUIT FUNCTION
1 Y151 18LG/BR ADJUSTABLE PEDAL MOTOR (DOWN)
2 Y153 18DB/RD ADJUSTABLE PEDAL RELAY OUTPUT
3- -
4 Z154 18BK/BR GROUND
5 F15 20DB FUSED IGNITION SWITCH OUTPUT (RUN)
6 Y152 18LG/OR ADJUSTABLE PEDAL MOTOR (UP)
AIRBAG CONTROL MODULE - YELLOW 23 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3- -
4 Z6 18BK/PK GROUND
5 R45 18DG/LB DRIVER SQUIB 1 LINE 2
6 R43 18BK/LB DRIVER SQUIB 1 LINE 1
7 R42 18BK/YL PASSENGER SQUIB 1 LINE 1
8 R44 18DG/YL PASSENGER SQUIB 1 LINE 2
9 R53 18LG/YL RIGHT SEAT BELT TENSIONER LINE 2
10 R55 18LG/DG RIGHT SEAT BELT TENSIONER LINE 1
11 R56 18LB/DG LEFT SEAT BELT TENSIONER LINE 1
12 R54 18LB/YL LEFT SEAT BELT TENSIONER LINE 2
13 - -
14 F14 18LG/YL FUSED IGNITION SWITCH OUTPUT (RUN-START)
15 F23 18DB/YL FUSED IGNITION SWITCH OUTPUT (RUN)
16 - -
17 - -
18 - -
19 R4 18BR/YL PASSENGER AIRBAG MUX SWITCH RETURN
20 R5 18VT/YL PASSENGER AIRBAG MUX SWITCH SENSE
21 D25 20VT/DG PCI BUS
22 R166 18LG/TN PASSENGER AIRBAG INDICATOR DRIVER
23 - -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 7
