2003 DAEWOO MATIZ Distributor

ENGINE ELECTRICAL 1E–9
DAEWOO M-150 BL2
IGNITION SYSTEM
D102E404
1 Ignition Coil
2 Spark Pulg
3 Ignitoin Wire (#0)
4 Ignition Wires (#1, #2, #3)
5 Support Clamp
6 Mounting Clamp
7 Distributor Assembly
8 Coupling
9 Distributor Oil Seal
10 Distributor Housing
11 Distributor Shaft12 Plate
13 Optical Sensor Unit
14 Plate
15 Bushing
16 Disc Wheel
17 Inner Cover
18 Outer Cover
19 Distributor Rotor
20 Distributor Cap Seal
21 Distributor Cap

ENGINE ELECTRICAL 1E–11
DAEWOO M-150 BL2
IGNITION SYSTEM (Cont’d)
ConditionProbable CauseCorrection
Hard to Starting the Engine
Faulty ignition coil.
Replace the ignition coil.

Faulty distributor (include the
optical sensor).
Replace the distributor or the
optical sensor.

Faulty spark plug.
Replace the spark plug or Adjust
the gap.

Poor ignition timing.
Reset the valve timing.
Engine Idling State is Unstable
Faulty spark plug.
Replace the spark plug or Adjust
the gap.

Faulty ignition coil.
Replace the ignition coil.

Poor ignition timing.
Reset the valve timing.
Poor Engine Accelerating
Poor ignition timing.
Reset the valve timing.

ENGINE ELECTRICAL 1E–17
DAEWOO M-150 BL2
D12E513A
Installation Procedure
1. Install in the reverse order of removal.
2. Install the battery rod and cable nuts.
Tighten

Tighten the battery rod nut to 6–8 Nm (53–71 lb-
in) (a).

Tighten the battery cable nut to 9-12 Nm (80–106
lb-in) (b).
D12E514A
DISTRIBUTOR
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the air filter, resonator with snorkel assem-
bly. Refer to Section 1B, SOHC Engine Mechanical.
3. Disconnect the ignition wires and electrical connec-
tor.

Disconnect the optical sensor connector (1).

Disconnect the ignition wires (2).

Remove the ignition wire clip (3).
D102E515
4. Remove the distributor.
Important: Mark on the distributor housing and case
before remove distributor (a).

Remove the distributor bolts (1).

Carefully remove the distributor assembly (2).
D12E516A
10–16 Nm
Installation Procedure
1. Install in the reverse order of removal.
2. Install the distributor bolts.
Tighten
Tighten the distributor bolts to 10–16 Nm (89–142 lb-
in).

1E–34 ENGINE ELECTRICAL
DAEWOO M-150 BL2
D12E760A
4–7 Nm
4–6 Nm
Tighten the through-bolts to 4–6 Nm (35–53 lb-in)
(f).

Tighten the battery positive terminal nut to 4–7
Nm (35–62 lb-in) (g).
D102E761
DISTRIBUTOR ASSEMBLY
Disassembly Procedure
1. Remove the distributor. Refer to “Distributor” in this
section.
2. Remove the cap, seal and rotor from the distributor
housing.

Remove the bolts (1).

Remove the distributor cap (2).

Remove the seal (3).

Remove the rotor (4).
D102E762

Inspect the cap for cracks or damage (a).

Inspect the cap electrode for damage / wear or car-
bon traces (b).

Inspect the rotor for damage or carbon traces (c).
D102E763
3. Remove the inner / outer cover from the distributor
housing.

Remove the outer cover (1).

Remove the screws (2).

Remove the inner cover (3).

ENGINE ELECTRICAL 1E–35
DAEWOO M-150 BL2
D102E764
4. Remove the optical sensor cover and adaptor from
the distributor housing.

Remove the screw (1).

Remove the adaptor (2).

Remove the screws (3).

Remove the cover (4).

Remove the gasket (5).
D102E765
5. Remove the optical sensor unit from the distributor
housing.

Carefully remove the disc wheel (1).

Remove the bushing (2).

Remove the screws (3).

Remove the optical sensor unit plate (4).

Remove the optical sensor unit (5).
D102E766
6. Remove the bearing plate from the distributor hous-
ing.

Remove the screws (1).

Remove the bearing plate (2).
D102E767
7. Remove the coupling, shaft and bearing from the dis-
tributor housing.

Remove the coupling (1).

Remove the shaft using the press (2).

Remove the bearing (3).

ENGINE ELECTRICAL 1E–41
DAEWOO M-150 BL2
SPECIFICATIONS
STARTER SPECIFICATIONS
ApplicationDescriptionUnitStandardLimit
Starter MotorType–SD 80–
Output(Capacity)kW0.8–
No Load Test @ 9 volts
Drive Pinion SpeedA
RPM150
2,000–
Brushes Lengthmm (in.)11.3–11.5
(0.445–0.453)7.0–7.25
(0.275–0.285)
GENERATOR SPECIFICATIONS
ApplicationDescriptionUnitStandardLimit
GeneratorTypeA-Type–J114D(MANDO)–GeneratorTypeA-Type
B-Type–J114D(MANDO)
CS114D(DAC)–
RegulatorA-TypeV14.4–15.0–Regulator
VoltageA-Type
B-TypeV14.4–15.0
14.3–4.9–
Brushes
LengthA-Type
B-Typemm (in.)18.5 (0.728)
20.0 (0.787)13.5 (0.531)
14 (0.551)
OutputA-Type–12V, 65A–Output
(Capacity)A-Type
B-Type–12V, 65A
12V, 65A–
IGNITION SYSTEM SPECIFICATIONS
ApplicationDescriptionUnitStandardLimit
Ignition CoilType–Closed
Magnetic Type–
First Coil ResistanceΩ1.2
10%–
Second Coil ResistanceKΩ12.1
15%–
DistributorType–Optical Sensor
Type–
Spark PlugTypeUnlead–BPR5EY-11–
RN9YC4–
WR8DCX–
TypeLead–BPR5EY–
RN9YC–
WR8DC–
Spark PlugGapUnleadmm (in.)1.1 (0.043)–
1.2 (0.047)–
Leadmm (in.)0.8 (0.031)–
Ignition WireIgnition Wire ResistanceKΩ/m2.5–12.0–

1E–42 ENGINE ELECTRICAL
DAEWOO M-150 BL2
BATTERY SPECIFICATIONS
ApplicationDescriptionUnitStandardLimit
BatteryType–MF–
CapacityAH35–
Cold Cranking AmpsCCA246–
FASTENER TIGHTENING SPECIFICATIONS
ApplicationNmLb-FtLb-In
Distributor Bolts10–16–89–142
Battery Retainer Clamp–to–Battery Rod Nuts6–8–53–71
Battery Carrier Tray Bolts9–12–80–106
Battery Cable Nuts9–12–80–106
Starter field Connector Nut9–12–80–106
Starter Through–Bolts4–6–35–53
Starter Mounting Bolts55–6541–48–
Starter Solenoid Assembly Screws6–8–53–71
Starter Solenoid Nuts9–12–80–106
Spark Plug20–3015–22–
Generator Through–Bolts4–6–35–53
Generator Drive End Nut80–11 059–81–
Generator Battery Lead Connector Nut4–7–35–62
Generator Bearing Plate Bolt6–8–53–71
Generator Brush Holder / Rectifier Screw9–12–80–106
Generator Belt Tension Adjusting Bolt18–2813–21–
Generator Shackle Bracket Bolt45–5533–41–
Generator Lower Bracket–to–Generator Bolt/Nut18–2813–21–
Ground Bolt35–4126–30–
Ignition Coil Screw4–7–35–62
Ignition Coil Bracket Bolt9–12–80–106

1F–4 ENGINE CONTROLS
DAEWOO M-150 BL2
DESCRIPTION AND OPERATION
IGNITION SYSTEM OPERATION
This ignition system does not use a conventional distrib-
utor and coil. It uses a crankshaft position sensor input
to the Engine Control Module (ECM). The ECM then de-
termines Electronic Spark Timing (EST) and triggers the
electronic ignition system ignition coil.
This type of distributorless ignition system uses a “waste
spark’’ method of spark distribution. Each cylinder is in-
dividural with coil per cylinder.
These systems use the EST signal from the ECM to
control the EST. The ECM uses the following informa-
tion:

Engine load (manifold pressure or vacuum).

Atmospheric (barometric) pressure.

Engine temperature.

Intake air temperature.

Crankshaft position.

Engine speed (rpm).
ELECTRONIC IGNITION SYSTEM
IGNITION COIL
The Electronic Ignition (EI) system ignition coil is
mounted near on the cylinder head.
A terminals of the EI system ignition coil provides the
spark for each spark plug. The EI system ignition coil is
not serviceable and must be replaced as an assembly.
CRANKSHAFT POSITION SENSOR
This Electronic Ignition (EI) system uses a magnetic
crankshaft position sensor. This sensor protrudes
through its mount to within approximately 1.3 mm (0.05
inch) of the crankshaft reluctor. The reluctor is a special
wheel attached to the crankshaft with 58 slots machined
into it, 57 of which are equally spaced in 6-degree inter-
vals. The last slot is wider and serves to generate a
“sync pulse.” As the crankshaft rotates, the slots in the
reluctor change the magnetic field of the sensor, creat-
ing an induced voltage pulse. The longer pulse of the
58th slot identifies a specific orientation of the crank-
shaft and allows the Engine Control Module (ECM) to
determine the crankshaft orientation at all times. The
ECM uses this information to generate timed ignition
and injection pulses that it sends to the ignition coils and
to the fuel injectors.
CAMSHAFT POSITION SENSOR
The Camshaft Position (CMP) sensor sends a CMP sig-
nal to the Engine Control Module (ECM). The ECM uses
this signal as a “sync pulse” to trigger the injectors in the
proper sequence. The ECM uses the CMP signal to indi-
cate the position of the #1 piston during its power stroke.
This allows the ECM to calculate true sequential fuel in-jection mode of operation. If the ECM detects an incor-
rect CMP signal while the engine is running, Diagnostic
Trouble Code (DTC) P0341 will set. If the CMP signal is
lost while the engine is running, the fuel injection system
will shift to a calculated sequential fuel injection mode
based on the last fuel injection pulse, and the engine will
continue to run. As long as the fault is present, the en-
gine can be restarted. It will run in the calculated se-
quential mode with a 1-in-6 chance of the injector
sequence being correct.
IDLE AIR SYSTEM OPERATION
The idle air system operation is controlled by the base
idle setting of the throttle body and the Idle Air Control
(IAC) valve.
The Engine Control Module (ECM) uses the IAC valve to
set the idle speed dependent on conditions. The ECM
uses information from various inputs, such as coolant
temperature, manifold vacuum, etc., for the effective
control of the idle speed.
FUEL CONTROL SYSTEM
OPERATION
The function of the fuel metering system is to deliver the
correct amount of fuel to the engine under all operating
conditions. The fuel is delivered to the engine by the in-
dividual fuel injectors mounted into the intake manifold
near each cylinder.
The main fuel control sensors are the Manifold Absolute
Pressure (MAP) sensor, the oxygen sensor (O2S), and
the heated oxygen sensor (HO2S).
The MAP sensor measures or senses the intake man-
ifold vacuum. Under high fuel demands, the MAP sensor
reads a low vacuum condition, such as wide open
throttle. The Engine Control Module (ECM) uses this in-
formation to enrich the mixture, thus increasing the fuel
injector on-time, to provide the correct amount of fuel.
When decelerating, the vacuum increases. This vacuum
change is sensed by the MAP sensor and read by the
ECM, which then decreases the fuel injector on-time
due to the low fuel demand conditions.
The O2S is located in the exhaust manifold. The HO2S
is located in the exhaust pipe. The oxygen sensors indi-
cate to the ECM the amount of oxygen in the exhaust
gas, and the ECM changes the air/fuel ratio to the en-
gine by controlling the fuel injectors. The best air/fuel ra-
tio to minimize exhaust emissions is 14.7:1, which
allows the catalytic converter to operate most efficiently.
Because of the constant measuring and adjusting of the
air/fuel ratio, the fuel injection system is called a “closed
loop” system.
The ECM uses voltage inputs from several sensors to
determine how much fuel to provide to the engine. The
