2003 CHEVROLET SSR Owners Manual

A. Remote Positive Terminal. SeeJump Starting
on page 5-36for more information.
B. Coolant Surge Tank. SeeEngine Coolant
on page 5-24for more information.
C. Engine Oil Dipstick. SeeEngine Oil on page 5-14
for more information.
D. Engine Oil Fill Cap. SeeEngine Oil on page 5-14
for more information.
E. Automatic Transmission Fluid Dipstick. See
Automatic Transmission Fluid on page 5-21
for more information.
F. Engine Cover. SeeEngine Cover on page 5-19
for more information.G. Engine Air Cleaner/Filter. SeeEngine Air
Cleaner/Filter on page 5-20for more information.
H. Remote Negative Terminal. SeeJump Starting
on page 5-36for more information.
I. Power Steering Reservoir. SeePower Steering Fluid
on page 5-31for more information.
J. Brake Master Cylinder. SeeBrakes on page 5-33
for more information.
K. Underhood Fuse Block Cover. SeeFuses and
Circuit Breakers on page 5-82for more information.
L. Windshield Washer Fluid Reservoir. SeeWindshield
Washer Fluid on page 5-32for more information.
5-13

Engine Oil
Checking Engine Oil
It’s a good idea to check your engine oil every time you
get fuel. In order to get an accurate reading, the oil
must be warm and the vehicle must be on level ground.
The engine oil dipstick
handle is a yellow ring
located in the engine
compartment toward the
passenger’s side of
the vehicle. SeeEngine
Compartment Overview
on page 5-12for more
information on location.Turn off the engine and give the oil several minutes
to drain back into the oil pan. If you don’t, the oil dipstick
might not show the actual level.
Pull out the dipstick and clean it with a paper towel or
cloth, then push it back in all the way. Remove it again,
keeping the tip down, and check the level.
5-14

When to Add Engine Oil
If the oil is at or below the hole at the tip of the dipstick,
then you’ll need to add at least one quart of oil. But
you must use the right kind. This part explains what
kind of oil to use. For engine oil crankcase capacity,
seeCapacities and Specications on page 5-90.
Notice:Do not add too much oil. If your engine has
so much oil that the oil level gets above the upper
hole, your engine could be damaged.The engine oil ll cap is
located in the engine
compartment toward the
passenger’s side of
the vehicle. SeeEngine
Compartment Overview
on page 5-12for more
information on location.
Be sure to ll it enough to put the level somewhere in
the proper operating range. Push the dipstick all the
way back in when you’re through.
5-15

What Kind of Engine Oil to Use
Oils recommended for your vehicle can be identied
by looking for the starburst symbol.
This symbol indicates that the oil has been certied by
the American Petroleum Institute (API). Do not use
any oil which does not carry this starburst symbol.
If you choose to perform
the engine oil change
service yourself, be sure
the oil you use has
the starburst symbol
on the front of the oil
container. If you have
your oil changed for you,
be sure the oil put into
your engine is American
Petroleum Institute certied
for gasoline engines.
You should also use the proper viscosity oil for your
vehicle, as shown in the viscosity chart.
5-16

As in the chart shown previously, SAE 5W-30 is the
only viscosity grade recommended for your vehicle.
You should look for and use only oils which have the
API Starburst symbol and which are also identied
as SAE 5W-30. If you cannot nd such SAE 5W-30 oils,
you can use an SAE 10W-30 oil which has the API
Starburst symbol, if it’s going to be 0°F (−18°C)
or above. Do not use other viscosity grade oils, such
as SAE 10W-40 or SAE 20W-50 under any conditions.
Notice:Use only engine oil with the American
Petroleum Institute Certied For Gasoline Engines
starburst symbol. Failure to use the recommended
oil can result in engine damage not covered by
your warranty.
GM Goodwrench
®oil meets all the requirements for
your vehicle.
If you are in an area of extreme cold, where the
temperature falls below−20°F (−29°C), it is
recommended that you use either an SAE 5W-30
synthetic oil or an SAE 0W-30 oil. Both will provide
easier cold starting and better protection for your
engine at extremely low temperatures.
Engine Oil Additives
Don’t add anything to your oil. The recommended
oils with the starburst symbol are all you will need for
good performance and engine protection.
When to Change Engine Oil
(GM Oil Life System)
Your vehicle has a computer system that lets you
know when to change the engine oil and lter. This is
based on engine revolutions and engine temperature,
and not on mileage. Based on driving conditions,
the mileage at which an oil change will be indicated
can vary considerably. For the oil life system to
work properly, you must reset the system every time
the oil is changed.
When the system has calculated that oil life has been
diminished, it will indicate that an oil change is
necessary. A change engine oil light will come on.
Change your oil as soon as possible within the next
two times you stop for fuel. It is possible that, if you are
driving under the best conditions, the oil life system
may not indicate that an oil change is necessary for
over a year. However, your engine oil and lter must be
changed at least once a year and at this time the
system must be reset. Your dealer has GM-trained
service people who will perform this work using genuine
GM parts and reset the system. It is also important to
check your oil regularly and keep it at the proper level.
If the system is ever reset accidentally, you must
change your oil at 3,000 miles (5 000 km) since your
last oil change. Remember to reset the oil life system
whenever the oil is changed.
5-17

How to Reset the Change Engine Oil Light
The GM Oil Life System calculates when to change
your engine oil and lter based on vehicle use.
Anytime your oil is changed, reset the system so it
can calculate when the next oil change is required.
If a situation occurs where you change your oil prior
to a change engine oil light being turned on, reset
the system.
To reset the change engine oil light, do the following:
1. Press the fuel information button until ENGINE
OIL LIFE appears on the Driver Information
Center (DIC). SeeDIC Controls and Displays
on page 3-41for more information.
2. Press and hold the select button. The engine oil
life percentage will return to 100.
3. Turn the key to OFF.
If the change engine oil light comes back on when you
start your vehicle, the engine oil life system has not
reset. Repeat the procedure.
What to Do with Used Oil
Used engine oil contains certain elements that may be
unhealthy for your skin and could even cause cancer.
Don’t let used oil stay on your skin for very long. Clean
your skin and nails with soap and water, or a good
hand cleaner. Wash or properly dispose of clothing or
rags containing used engine oil. See the manufacturer’s
warnings about the use and disposal of oil products.
Used oil can be a threat to the environment. If you
change your own oil, be sure to drain all the oil from the
lter before disposal. Never dispose of oil by putting it
in the trash, pouring it on the ground, into sewers, or
into streams or bodies of water. Instead, recycle it
by taking it to a place that collects used oil. If you have
a problem properly disposing of your used oil, ask
your dealer, a service station or a local recycling center
for help.
5-18

Engine Cover
Your vehicle has a removable engine cover.
To remove the engine cover do the following:
1. Remove the engine cover insert if your vehicle
has one. See “Engine Cover Insert” following for
instructions.
2. Unscrew the three bolts from the engine and lift
off the cover.
3. To reinstall the engine cover, reverse the steps.
Engine Cover Insert
Your vehicle may have
an engine cover insert.
The engine cover insert must be removed to access the
bolts that secure the engine cover to the vehicle.
Use the following procedure to remove the engine cover
insert:
1. Using a at-bladed tool, lift up on the front outboard
edges of the engine cover insert to release the clips.
2. Slide the engine cover insert rearward to release
the insert from the two hooks located at the rear
outboard edges of the insert.
3. Lift off the engine cover insert.
4. To reinstall the insert, reverse the steps.
5-19

Engine Air Cleaner/Filter
The engine air cleaner/lter is located at the center front
of the engine compartment. SeeEngine Compartment
Overview on page 5-12for location of the engine
air cleaner/lter.
When to Inspect the Engine
Air Cleaner/Filter
Inspect the air cleaner/lter at each oil change and
replace it at the rst oil change after 25,000 miles
(41 500 km). SeeScheduled Maintenance on page 6-5
for more information.
How to Inspect the Engine
Air Cleaner/Filter
To inspect the air cleaner/lter, remove the lter from
the vehicle and lightly shake the lter to release
loose dust and dirt. If the lter remains caked with dirt,
a new lter is required.
To inspect or replace the lter, do the following:
1. Remove the two bolts on the engine air cleaner/lter
and lift off the cover.
2. Twist out the old engine air cleaner/lter and
replace it, if necessary.
3. Reinstall the cover.
5-20
