2003 CHEVROLET SSR Owners Manual

Side-Saddle Storage
Your vehicle may have a side-saddle storage system to
store items on either side of the rear cargo area. For
more information on this feature, see your dealer.
Convertible Top
Roof Tonneau
Your vehicle has a roof tonneau that is raised or
lowered along with the convertible top using the
convertible top switch located on the center console
switchbank. See “Convertible Top Operation” following
in this section for more information.
If you are unable to raise or lower your roof tonneau
using the convertible top switch, verify that the
cargo cover is closed. The roof tonneau will not raise or
lower if the cargo cover is open. SeeCargo Cover on
page 2-32and for more information. There will also be a
message displayed on the on the Driver Information
Center (DIC). SeeDIC Warnings and Messages
on page 3-45for more information on possible DIC
messages and how to clear them from the display.
If the cargo area is closed and you still cannot operate
the roof tonneau, check to see if a fuse is blown.
SeeFuses and Circuit Breakers on page 5-82for more
information.
Contact your dealer if you are still unable to operate the
roof tonneau.
You may need to raise the roof tonneau manually in the
event of a power loss. See “Convertible Top Operation”
for instructions.
2-37

Convertible Top Operation
Notice:If you operate the convertible top switch
continuously while the ignition is in ACCESSORY,
the battery will drain and you might not be able
to start your vehicle. Do not use the convertible top
switch for extended periods of time when the
ignition is in ACCESSORY.
The ignition must be in RUN or ACCESSORY and your
foot must be on the brake in order to raise or lower
the convertible top. The cargo cover must also be closed
for the convertible top to work properly.
Operate the convertible top by pressing the convertible
top switch located on the console switchback. See
Center Console Switchbank on page 3-16for more
information on location.
{CAUTION:
Moving parts of the convertible top can be
dangerous. People can be injured by the
convertible top and its mechanism. Keep
people away from your vehicle when you are
lowering or raising the top.
a(Top Open):Press and hold this symbol on
the convertible top switch to open the convertible
top. The windows will lower automatically when the top
begins to lower. Two chimes will sound when the
convertible top is fully opened.
b(Top Closed):Press and hold this symbol on
the convertible top switch to close the convertible
top. Two chimes will sound when the top is fully closed.
If you cannot raise or lower the convertible top by
using your convertible top switch, you may need to
replace the fuse. SeeFuses and Circuit Breakers
on page 5-82for more information.
If you still cannot operate your convertible top, contact
your dealer.
You may need to raise the roof tonneau and convertible
top manually in the event of a power loss. You will
need two people to lift the roof tonneau and convertible
top when using the following procedure. To manually
raise the roof tonneau and convertible top, do the
following:
1. Turn the ignition to OFF.
2. Be sure the cargo cover is closed. SeeCargo
Cover on page 2-32andRemote Keyless Entry
System Operation on page 2-5for more information.
3. Open both doors.
2-38

4. In the area behind the seats, locate the two sets of
cables behind the carpet aps. The cables on the
driver’s side of the vehicle are located behind
the tire inator kit. The tire inator kit must be
removed to access the cables. SeeTire Inator Kit
on page 5-66for instructions on how to remove
the tire inator kit.
5. Locate the loops at the ends of the cables.
One has a red band on it, and the other has
a green band.
The cable with the green band opens the tonneau
latch, and the cable with the red band closes it.6. Using the release tool from the convertible top,
hook the tool into the green loop.
The convertible top release tool is provided when
you purchase your new SSR from the dealer.
It is stored in the glovebox.
7. Pull the green cable with the release tool upward at
a 45 degree angle until the cable is pulled tight and
the roof tonneau latch is released.
8. Repeat Steps 4 through 7 on the other side of
the vehicle.
2-39

9. You will know the latches have been released when
the roof tonneau can be raised. If you cannot raise
the roof tonneau, repeat Steps 4 through 7 on
both sides of the vehicle until the roof tonneau can
be raised.
10. Lift up on the roof tonneau and raise it to the
upright position.11. Grasp the front panel of the convertible top and
pull up.
You will need more than one person to do this.
One person working on each side of the vehicle
is best.
2-40

12. Insert the front panel into the roof latches.
One person should hold the convertible top in the
closed position by pushing it up in the rear,
while another person performs the next steps.13. Remove the plastic cap
located between the
sun visors. Turn
the cap in either
direction about a
quarter of a turn, then
pull downward to
remove it.
14. Slide the tool side of
the convertible top
release tool until
the entire tool forms
a right angle
as shown. Driver’s side roof latch shown, passenger’s
side similar
2-41

15. Insert the convertible top release tool into the latch
closing mechanism between the sun visors and turn
it counterclockwise until the roof latches are
secured and the convertible top is fully closed.
Then replace the plastic cap.16. From the upright position, push down on the outer
area of the boot cover panel where the hinges and
hydraulic cylinders are located to separate it
from the roof tonneau. Then, continue to push the
boot cover panel down as far as it will go.
2-42

17. Push down the roof tonneau cover. Be sure the
boot cover clears the rear roof panel.18. Latch the tonneau panel. Pull the red cable with the
release tool until the cable is pulled tight and the
roof tonneau latch engages.
19. Repeat Step 18 on the other side of the vehicle.
20. You will know the latches are engaged if the
roof tonneau cannot be raised. If the roof tonneau
can be raised, repeat Step 18 on both sides of
the vehicle until the roof tonneau cannot be raised.
21. Once the roof tonneau is closed, adjust the cables
located behind the seats. Pull the cable with the red
band until both cables are the same length.
Repeat this step on the other side of the vehicle.
22. Check the roof tonneau to make sure it is secure
before driving.
Boot cover panel down, roof tonneau up
2-43

Vehicle Personalization
Memory Seat
Your vehicle may have a memory driver’s seat. The
controls are located on the outboard of the driver’s seat,
and are used to program and recall memory settings
for the driver’s seating positions.
Adjust the driver’s seat to the desired position. Press
the SET button, then press and hold button 1 (for
Driver 1) for three seconds. A double chime will sound
to let you know that the position has been stored.A second seating position can be programmed by
repeating the procedure with a second driver and
pressing button 2 for three seconds. Each time
button 1 or 2 is pressed and released while the vehicle
is in PARK (P), a single chime will sound, and the
memory position will be recalled.
If you use the unlock button on the remote keyless entry
transmitter to enter your vehicle, the preset driver’s
seat positions will be recalled if programmed to do so
through the Driver Information Center (DIC). The
numbers on the back of the transmitters, 1 or 2,
correspond to the numbers on the memory controls.
The seat positions can also be recalled by placing the
key in the ignition if programmed to do so through
the Driver Information Center (DIC).
To stop recall movement of the memory feature at
any time, press one of the power seat controls or
memory buttons.
Further programming for automatic seat can be done
through the Driver Information Center (DIC). See
DIC Vehicle Personalization on page 3-52for more
information.
2-44
