6-24 What Kind of Engine Oil to Use
Oils recommended for your vehicle can be identified by
looking for the starburst symbol.
This symbol indicates that the oil has been certified by
the American Petroleum Institute (API). Do not use any
oil which does not carry this starburst symbol.
If you change your own oil,
be sure you use oil that has
the starburst symbol on the
front of the oil container.
If you have your oil
changed for you, be sure
the oil put into your engine
is American Petroleum
Institute certified for
gasoline engines.
You should also use the proper viscosity oil for your
vehicle, as shown in the viscosity chart.

6-25
As in the chart shown previously, SAE 5W-30 is best for
your vehicle. However, you can use SAE 10W
-30 if it's
going to be 0
F (
-18
C) or above. These numbers on
an oil container show its viscosity, or thickness. Do not
use other viscosity oils, such as SAE 20W
-50.
NOTICE:
Use only engine oil with the American Petroleum
Institute Certified For Gasoline Engines
starburst symbol. Failure to use the
recommended oil can result in engine damage not
covered by your warranty.
GM Goodwrench
oil meets all the requirements for
your vehicle.
If you are in an area where the temperature falls
below
-20F (-29C), consider using either an
SAE 5W
-30 synthetic oil or an SAE 0W-30 oil. Both
will provide easier cold starting and better protection for
your engine at extremely low temperatures.
Engine Oil Additives
Don't add anything to your oil. The recommended oils
with the starburst symbol are all you will need for good
performance and engine protection.
When to Change Engine Oil
(GM Oil Life System)
Your vehicle has a computer system that lets you know
when to change the engine oil and filter. This is based on
engine revolutions and engine temperature, and not on
mileage. Based on driving conditions, the mileage at
which an oil change will be indicated can vary
considerably. For the oil life system to work properly,
you must reset the system every time the oil is changed.
When the system has calculated that oil life has been
diminished, it will indicate that an oil change is
necessary. A change oil light will come on. Change your
oil as soon as possible within the next two times you
stop for fuel. It is possible that, if you are driving under
the best conditions, the oil life system may not indicate
that an oil change is necessary for over a year. However,
your engine oil and filter must be changed at least once
a year and at this time the system must be reset. It is also
important to check your oil regularly and keep it at the
proper level.
If the system is ever reset accidentally, you must change
your oil at 3,000 miles (5 000 km) since your last oil
change. Remember to reset the oil life system whenever
the oil is changed.

6-26
How to Reset the Change Oil Light
The GM Oil Life System
calculates when to change
your engine oil and filter based on vehicle use. Anytime
your oil is changed, reset the system so it can calculate
when the next oil change is required. If a situation
occurs where you change your oil prior to a change oil
light being turned on, reset the system.
To reset the change oil light, do the following:
1. Turn the ignition key to RUN with the engine off.
2. Fully press and release the accelerator pedal three
times within 10 seconds.
If the change oil light flashes for five seconds, the
system is reset. If the light does not display for five
seconds, you will need to repeat the steps.What to Do with Used Oil
Used engine oil contains certain elements that may be
unhealthy for your skin and could even cause cancer.
Don't let used oil stay on your skin for very long. Clean
your skin and nails with soap and water, or a good hand
cleaner. Wash or properly throw away clothing or rags
containing used engine oil. See the manufacturer's
warnings about the use and disposal of oil products.
Used oil can be a threat to the environment. If you
change your own oil, be sure to drain all the oil from the
filter before disposal. Never dispose of oil by putting it
in the trash, pouring it on the ground, into sewers, or
into streams or bodies of water. Instead, recycle it by
taking it to a place that collects used oil. If you have a
problem properly disposing of your used oil, ask your
dealer, a service station or a local recycling center
for help.

6-27
Engine Oil (Caterpillar

Diesel Engines)
See your Caterpillar
Operation & Maintenance Manual
for information on oil quality and viscosities as well as
the temperature range chart.
Engine Oil (DURAMAX Diesel)
Checking Engine Oil
It's a good idea to check your engine oil level every time
you get fuel.
The engine oil dipstick is
located in the engine
compartment on the driver's
side of the vehicle.
In order to get an accurate
reading, the oil must be
warm (at normal operating
temperature) and the vehicle
must be on level ground.Turn off the engine and give the oil at least five minutes
to drain back into the oil pan. With a cool engine, allow
30 minutes. If you don't, the oil dipstick might not show
the actual level.
Pull out the dipstick and clean it with a paper towel or a
cloth, then push it back in all the way. Remove it again,
keeping the tip down.

6-28 When to Add Engine Oil
If the oil is at or below the ADD line, then you'll need
to add at least one quart of oil. But you must use the
right kind. This part explains what kind of oil to use.
For engine oil crankcase capacity, see ªCapacities and
Specificationsº in the Index.
NOTICE:
Don't add too much oil. If your engine has so
much oil that the oil level gets above the proper
operating range, your engine could be damaged.
Be sure to fill it enough to put the level somewhere in
the proper operating range. Push the dipstick all the way
back in when you're through.
What Kind of Engine Oil to Use
Look for these two things:

CH
-4
Oils designated as API CH
-4 are best for your
vehicle. The CH
-4 designation may appear either
alone or in combination with other API designations,
such as API CH
-4/SJ or CH-4/CG-4/SJ.
These letters show American Petroleum Institute
(API) levels of quality.
NOTICE:
If you use oil that doesn't have this designation,
CH
-4, you can cause engine damage which is not
covered by your warranty.

6-30 Engine Oil Additives
Don't add anything to your oil. The recommended oils
with the API service symbol are all you will need for
good performance and engine protection.
When to Change Engine Oil
Change engine oil and filter every 10,000 miles
(16 000 km) or every 12 months, whichever occurs first.
What to Do with Used Oil
Used engine oil contains certain elements that may be
unhealthy for your skin and could even cause cancer.
Don't let used oil stay on your skin for very long. Clean
your skin and nails with soap and water, or a good hand
cleaner. Wash or properly throw away clothing or rags
containing used engine oil. See the manufacturer's
warnings about the use and disposal of oil products.
Used oil can be a threat to the environment. If you
change your own oil, be sure to drain all the oil from
the filter before disposal. Never dispose of oil by putting
it in the trash, pouring it on the ground, into sewers, or
into streams or bodies of water. Instead, recycle it by
taking it to a place that collects used oil. If you have a
problem properly disposing of your used oil, ask your
dealer, a service station or a local recycling center
for help.
Engine Air Cleaner/Filter
Refer to the Maintenance Schedule to determine when to
replace the engine air cleaner/filter. See ªScheduled
Maintenanceº in the Index.
The engine air cleaner/filter
is located in the center of
the engine compartment.
Your gasoline or diesel engine has a restriction indicator
that lets you know when the engine air cleaner/filter
needs to be serviced.

6-31
The restriction indicator
is located in the engine
compartment near the
engine air cleaner/filter,
on the passenger's side of
the vehicle.
When the yellow indicator reaches the red ring in the
sight glass, it's time to service the engine air
cleaner/filter.
After the engine air cleaner/filter is properly serviced,
the indicator can be reset by pressing the button on top
of the indicator.
CAUTION:
Gasoline Engines Only: Operating the engine
with the air cleaner/filter off can cause you or
others to be burned. The air cleaner not only
cleans the air, it stops flame if the engine
backfires. If it isn't there, and the engine
backfires, you could be burned. Don't drive with
it off, and be careful working on the engine with
the air cleaner/filter off.
NOTICE:
Gasoline Engines Only: If the air cleaner/filter is
off, a backfire can cause a damaging engine fire.
And, dirt can easily get into your engine, which
will damage it. Always have the air cleaner/filter
in place when you're driving.
Your vehicle may be equipped with an optional instrument
panel mounted air filter restriction indicator. See ªWarning
Lights, Gages and Indicatorsº in the Index.

6-32
Automatic Transmission Fluid
When to Check
A good time to have it checked is when the engine oil is
checked. See your Allison Automatic Transmission
Operator's Manual to find out when to change your
transmission fluid and filters.
How to Check and What to Use
The Allison Automatic Transmission Operator's Manual
that came with the vehicle shows how to check the
automatic transmission fluid and what fluid to use.
Automatic Transmission External Filter
Your automatic transmission filter requires periodic
replacement.
Consult the Allison Automatic Transmission
Operator's Manual that came with the vehicle for
proper change intervals.
Manual Transmission Fluid
Refer to the Maintenance Schedule to determine how
often to check the lubricant and when to change it. See
ªScheduled Maintenance Servicesº in the Index.
Refer to the Maintenance Schedule to determine what
kind of fluid to use. See ªRecommended Fluids and
Lubricantsº in the Index.
When to Check
A good time to have it checked is when the engine oil is
checked. See your Maintenance Schedule to find out
when to change your transmission fluid.
