2003 CHEVROLET C/K load capacity

2-33
On the highway, with the axle in low range and the
transmission in top gear, you may shift the axle to high
range by raising the switch and releasing the accelerator
momentarily. Reapply the accelerator after you shift.
Under light load conditions, first shift the axle into the
high range with the vehicle at a standstill and then
operate the transmission normally.
Air Shift Control (Automatic Transmission)
The switch for the rear axle
shift control is located in the
instrument panel
switchbank.
Press the bottom of the switch to get to the low range.
Press the top of the switch to return to the high range.The two
-speed axle should be in low when you park
the vehicle.
You'll need to engage the transmission, even moving the
vehicle a little, to be sure the axle is in low range. Then
shift into PARK (P), apply the parking brake and shut
off the engine.
Also, always start the vehicle in motion with the
two
-speed axle in the low position. To shift up from
low to high, press the top of the rear axle shift control
switch and press down on the accelerator. When you
shift the axle from high to low, press the bottom of the
switch, release the accelerator and then quickly press it
down again.
Air Suspension (If Equipped)
Your vehicle may be equipped with the Hendrickson
HAS Series single
-axle air suspension which is designed
for single
-axle on-highway use. The feature is available
in 19,000 lb. (8 618.3 kg), 21,000 lb. (9 525.4 kg) and
23,000 lb. (10 432.6 kg) capacities for operations which
require extra cubic capacity and a reduced deck height.

4-30
If you have a diesel engine, you may have to run it at a
higher speed to get enough heat. Then, shut the engine
off and close the window almost all the way to preserve
the heat. Start the engine again and repeat this only
when you feel really uncomfortable from the cold. But
do it as little as possible. Preserve the fuel as long as you
can. To help keep warm, you can get out of the vehicle
and do some fairly vigorous exercises every half hour or
so until help comes.Loading Your Vehicle
There is a GVW Rating label on your vehicle that shows
how much weight it may properly carry. It also shows
the size of your original tires and the inflation pressures
needed to obtain the gross weight capacity of your
vehicle. This is called the Gross Vehicle Weight
Rating (GVWR).

6-66 Wheel Replacement
Replace any wheel that is bent, cracked or badly rusted.
If wheel nuts keep coming loose, replace the wheel. If
the wheel leaks air, replace it.
Your dealer will know the kind of wheel you need.
CAUTION:
A leaking wheel could fail without warning. A
wheel designed for tubeless tires could be leaking
because it is damaged. Don't use an inner tube or
some other thing to try to stop the leaking. Get a
new wheel of the proper type.
CAUTION:
Without the correct wheel, you may not be able
to stop properly, and you could have other
problems like a tire air
-out. You could have a
collision. If you don't go to your dealer to get a
new wheel, be sure you get the correct one. Each
new wheel should match the original wheel in
load
-carrying capacity, inflation pressure
capacity, diameter, width, offset and mounting
configuration.
Using wheels and tires with higher load-carrying limits
than the original wheels and tires doesn't change the
GAWR or the GVWR of your vehicle.
