Engine compartment (with daytime run-
ning light system)
7. HEAD (LO LH) 10 A: Lefthand head-
light (low beam)
8. TAIL 10 A: Tail lights, licence plate
lights
9. A.C 10 A: Air conditioning system
10. FOG 15 A: No circuit
11. DOME 15 A: Car audio system, interior
light, clock, personal lights, door cour-
tesy light, day time running light sys-
tem, gauges and meters
12. OBD 7.5 A: Onboard diagnosis sys-
tem
Instrument panel
13. EFI 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
14. ALTS 7.5 A: Charging system
15. PWR OUTLET 15 A: Power outlet
16. ECUIG 15 A: Cruise control system,
antilock brake system, automatic
transmission shift lock system, SRS
airbag system
17. TURN 10 A: Turn signal lights, emer-
gency flashers
18. WIPER 20 A: Windshield wipers and
washer 19. 4WD 20 A:
A.D.D. control system,
fourwheel drive control system, rear
differential lock system
20. ACC 15 A: Cigarette lighter, clock,
power rear view mirrors, backup
lights, automatic transmission shift lock
system, SRS airbag system, seat belt
pretensioners, car audio system
21. GAUGE 10 A: Day time running light
system, backup lights, cruise control
system, rear differential lock system,
electronically controlled automatic
transmission system, starting system,
charging system, air conditioning sys-
tem
22. IGN 7.5 A: Gauges and meters, SRS
airbag system, seat belt pretensioners,
multiport fuel injection system/sequen-
tial multiport fuel injection system
23. ECUB 7.5 A: SRS warning light, air
conditioning system
24. HORNHAZ 15 A: Emergency flashers,
horns
25. STA 7.5 A: Clutch start cancel system,
starting system

’02 Tacoma U (L/O 0109)
2922002 MY TACOMA_U (OM35786U)
26. STOP 10 A: Stop lights, high mounted
stoplight, cruise control system, anti
lock brake system, multiport fuel injec-
tion system/sequential multiport fuel in-
jection system
Fuses (type B)
27. POWER 30 A: Power windows, power
seat
28. J/B 50 A: All components in “POWER”,
“HORN.HAZ”, “STOP” and “ECUB”
fuses
29. AM2 30 A: Ignition system, multiport
fuel injection system/sequential fuel in-
jection system
30. HEATER 50 A: All components in “A.C”
fuse
31. AM1 40 A: Starting system
Fuses (type C)
32. ABS 60 A: Antilock brake system
33. ALT 120 A: All components in “AM1”,
“HEATER”, “A.C”, “TAIL”, “ALTS” and
“PWR OUTLET” fuses

’02 Tacoma U (L/O 0109)
2932002 MY TACOMA_U (OM35786U)
REPORTING SAFETY DEFECTS FOR U.S.
OWNERS, UNIFORM TIRE QUALITY
GRADING AND CAMPER INFORMATION
Reporting safety defects for U.S. owners294
. . . . . . . . . . . . . . . . . . . . . .
Uniform tire quality grading 294
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Camper information 295
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
SECTION 9

’02 Tacoma U (L/O 0109)
2942002 MY TACOMA_U (OM35786U)
If you believe that your vehicle
has a defect which could cause a
crash or could cause injury or
death, you should immediately in-
form the National Highway Traffic
Safety Administration (NHTSA) in
addition to notifying Toyota Motor
Sales, U.S.A., Inc. (Tollfree:
18003314331).
If NHTSA receives similar com-
plaints, it may open an investiga-
tion, and if it finds that a safety
defect exists in a group of ve-
hicles, it may order a recall and
remedy campaign. However,
NHTSA cannot become involved
in individual problems between
you, your dealer, or Toyota Motor
Sales, U.S.A., Inc.To contact NHTSA, you may ei-
ther call the Auto Safety Hotline
tollfree at 18004249393 (or
3660123 in Washington, D.C.
area) or write to: NHTSA, U.S.De-
partment of Transportation, Wash-
ington, D.C. 20590. You can also
obtain other information about mo-
tor vehicle safety from the Hotline.This information has been prepared in ac-
cordance with regulations issued by the
National Highway Traffic Safety Adminis-
tration of the U.S. Department of Trans-
portation. It provides the purchasers and/
or prospective purchasers of Toyota
vehicles with information on uniform tire
quality grading.
Your Toyota dealer will help answer any
questions you may have as you read this
information.
DOT quality grades—All passenger car
tires must conform to Federal Safety
Requirements in addition to these
grades. Quality grades can be found
where applicable on the tire sidewall
between tread shoulder and maximum
section width. For example: Treadwear
200 Traction AA Temperature A
Reporting safety defects for
U.S. owners
Uniform tire quality grading

’02 Tacoma U (L/O 0109)
2952002 MY TACOMA_U (OM35786U)
Treadwear—The treadwear grade is a
comparative rating based on the wear rate
of the tire when tested under controlled
conditions on a specified government test
course. For example, a tire graded 150
would wear one and a half (11/2) times
as well on the government course as a
tire graded 100. The relative performance
of tires depends upon the actual condi-
tions of their use, however, and may de-
part significantly from the norm due to
variations in driving habits, service prac-
tices and differences in road characteris-
tics and climate.
Traction AA, A, B, C— The traction
grades, from highest to lowest, are AA, A,
B, and C, and they represent the tire’s
ability to stop on wet pavement as mea-
sured under controlled conditions on spe-
cified government test surfaces of asphalt
and concrete. A tire marked C may have
poor traction performance.
Warning: The traction grade assigned to
this tire is based on braking (straight
ahead) traction tests and does not include
cornering (turning) traction. Temperature A, B, C—
The temperature
grades are A (the highest), B, and C,
representing the tire’s resistance to the
generation of heat and its ability to dissi-
pate heat when tested under controlled
conditions on a specified indoor laboratory
test wheel. Sustained high temperature
can cause the material of the tire to de-
generate and reduce tire life, and exces-
sive temperature can lead to sudden tire
failure. The grade C corresponds to a lev-
el of performance which all passenger car
tires must meet under the Federal Motor
Vehicle Safety Standard No.109. Grades B
and A represent higher levels of perfor-
mance on the laboratory test wheel than
the minimum required by law.
Warning: The temperature grades for this
tire are established for a tire that is prop-
erly inflated and not overloaded. Exces-
sive speed, underinflation, or excessive
loading, either separately or in combina-
tion, can cause heat buildup and possible
tire failure. This information has been prepared in ac-
cordance with regulation issued by the Na-
tional Highway Traffic Safety Administra-
tion of the U.S. Department of
Transportation. It provides the purchasers
and/or prospective purchasers of Toyota
vehicles with information on truckcamper
loading. Your Toyota dealer will help an-
swer any questions you may have as you
read this information.
Camper information—

’02 Tacoma U (L/O 0109)
2962002 MY TACOMA_U (OM35786U)
B
A
Rear end of truck bed
Recommended location
for cargo center of
gravity for cargo
weight rating
Twowheel drive models
except Pre Runner mm (in.)
AB
Regular cab
models1397
(55.0)965
(38.0)
Xtracab models 2RZFE engine
5VZFE engine
1372
(54.0) 1397
(55.0)927
(36.5) 927
(36.5)
Fourwheel drive models
and Pre Runner mm (in.)
A
B
1257
(49.5)901
(35.5)
The figures given in the illustration indi-
cate the recommended center of gravity
zone.
CAUTION
If a load is too far back, it can cause
dangerous handling. If it is too far
forward, the front axle may be over-
loaded.
Camper center of gravity
Recommended center of
gravity location zone
Cargo weight rating
Twowheel drive models
except Pre Runner Regular cab models with full options’
weight of 90 kg (205 lb.) With 2 occupants 430 kg (950 lb.)
With 3 occupants 375 kg (830 lb.)
—Center of gravity location —Cargo weight rating and
proper matching

’02 Tacoma U (L/O 0109)
2972002 MY TACOMA_U (OM35786U)
Xtracab models with full options’
weight of 85 kg (195 lb.)With 2 occupants in the front
seats and no occupants in the
rear seats 365 kg (815 lb.)
With 3 occupants in the front
seats and no occupants in the
rear seats 365 kg (810 lb.)
With 3 occupants in the front
seats and 2 occupants in the rear
seats 265 kg (590 lb.)
Fourwheel drive models
and Pre Runner Regular cab models with full options’
weight of 120 kg (265 lb.)
With 2 occupants 500 kg (1100 lb.)
With 3 occupants 465 kg (1025 lb.) Xtracab models with full options’
weight of 125 kg (280 lb.)
Vehicles with off road package
With 2 occupants in the front
seats and no occupants in the
rear seats 340 kg (750 lb.)
With 2 occupants in the front
seats and 2 occupants in the rear
seats 135 kg (300 lb.)
Vehicles without off road package With 2 occupants in the front
seats and no occupants in the
rear seats 440 kg (975 lb.)
With 3 occupants in the front
seats and no occupants in the
rear seats 370 kg (825 lb.)
With 3 occupants in the front
seats and 2 occupants in the rear
seats 235 kg (525 lb.) When the truck is used to carry a slidein
camper, the total cargo load of the truck
consists of the manufacturer ’s camper
weight figure, the weight of installed addi-
tional camper equipment not included in
the manufacturer ’s camper weight figure,
the weight of camper cargo, and the
weight of passengers in the camper.
The total cargo load should not exceed
the truck’s cargo weight rating and the
camper ’s center of gravity should fall with-
in the truck’s recommended center of
gravity zone when installed.
CAUTION
Be careful—overloading can cause
dangerous braking and handling prob-
lems, and can damage your vehicle
and its tires.

’02 Tacoma U (L/O 0109)
2982002 MY TACOMA_U (OM35786U)
Gross axle weight ratingFront GAWR Rear GAWR
Secure loose items to prevent weight
shifts that could affect the balance of your
vehicle. When the truck camper is loaded,
drive to a scale and weigh on the front
and on the rear wheels separately to de-
termine axle loads. Individual axle loads
should not exceed either of the Gross
Axle Weight Ratings (GAWR). The total of
the axle loads should not exceed the
Gross Vehicle Weight Rating (GVWR).
These ratings are given on the vehicle
Certification Label which is located on the
door latch post on the left side of the
vehicle. See “Your Toyota’s identification”
in Section 2 for the Certification Label
location. If weight ratings are exceeded,
move or remove items to bring all weights
below the ratings.
Gross vehicle weight rating
Not exceed GVWR
GAWR
Twowheel drive models
except Pre RunnerFront 1000 kg (2200 lb.)
Rear 1135 kg (2500 lb.)
Fourwheel drive models
and Pre Runner Front 1200 kg (2650 lb.)
Rear 1270 kg (2800 lb.) GVWR
Twowheel drive models
except Pre Runner
Regular cab models 1920 kg (4250 lb.)
Xtracab models
2040 kg (4500 lb.)
Fourwheel drive models
and Pre Runner 2315 kg (5100 lb.)
If weight ratings are exceeded, move or
remove items to bring all weights below
the ratings.
—Gross axle and vehicle
weight ratings
