If the new fuse immediately blows out,
there is a problem with the electrical sys-
tem. Have your Toyota dealer correct it as
soon as possible.
CAUTION
Never use a fuse with a higher am-
perage rating, or any other object, in
place of a fuse. This may cause ex-
tensive damage and possibly a fire.
If any washer does not work, the wash-
er tank may be empty. Add washer
fluid.
You may use plain water as washer fluid.
However, in cold areas where tempera-
tures range below freezing point, use
washer fluid containing antifreeze. This
product is available at your Toyota dealer
and most auto parts stores. Follow the
manufacturer ’s directions for how much to
mix with water.
NOTICE
Do not use engine antifreeze or any
other substitute because it may dam-
age your vehicle’s paint.
The following illustrations show how to
gain access to the bulbs. When replacing
a bulb, make sure the ignition switch and
light switch are off. Use bulbs with the
wattage ratings given in the table.
CAUTION
To prevent yourself from burning,
do not replace the light bulbs while
they are hot.
Halogen bulbs have pressurized gas
inside and require special handling.
They can burst or shatter if
scratched or dropped. Hold a bulb
only by its plastic or metal case.
Do not touch the glass part of a
bulb with bare hands.
NOTICE
Only use a bulb of the listed type.
Adding washer fluidReplacing light bulbs—

’02 Tacoma U (L/O 0109)
2762002 MY TACOMA_U (OM35786U)
The inside of the lens of exterior lights
such as headlights may temporarily fog up
when the lens becomes wet in the rain or
in a car wash. This is not a problem
because the fogging is caused by the
temperature difference between the outside
and inside of the lens, just like the
windshield fogged up in the rain. However,
if there is a large drop of water on the
inside of the lens, or if there is water
pooled inside the light, contact your
Toyota dealer.Light bulbsBulb
No.WTy p e
Headlights—60/55A
Parking lights1685B
Front turn signal
lights4157NAK27/8C
Rear turn signal
lights115627D
Stop/tail lights115727/8D
Backup lights92118B
License plate
lights1943.8B
High mounted
stoplight1685B
Interior light Regular cab
Xtracab and
double cab
—
—5
10E
E
Personal lights—5E
Door courtesy
lights—3E
Glove box light—1.4B
A: HB2 halogen bulbs
B: Wedge base bulbs (clear)
C: Wedge base bulbs (amber)
D: Single end bulbs
E: Double end bulbs

’02 Tacoma U (L/O 0109)
2772002 MY TACOMA_U (OM35786U)
1. Open the hood. Unplug the connec-tor. Remove the rubber cover.
If the connector is tight, wiggle it.2. Release the bulb retaining spring and remove the bulb. Install a new
bulb and the bulb retaining spring.
To install a bulb, align the tabs of the
bulb with the cutouts of the mounting
hole.3. Install the rubber cover with the “TOP PULL” mark upward and
snuggle on the boss. Then plug in
the connector.
Make sure the rubber cover fits snugly on
the connector and the headlight body.
Aiming is not necessary after replacing
the bulb. When aiming adjustment is nec-
essary, contact your Toyota dealer.
—Headlights

’02 Tacoma U (L/O 0109)
2782002 MY TACOMA_U (OM35786U)
Use a Phillipshead screwdriver.
—Parking lights—Front turn signal lights

’02 Tacoma U (L/O 0109)
2792002 MY TACOMA_U (OM35786U)
Inner side
screws
30 mm
(1.2 in.)
Outer side screws
45 mm (1.8 in.)
Use a Phillipshead screwdriver.a: Rear turn signal light
b: Stop/tail light
c: Backup light
—Rear turn signal, stop/tail,
and backup lights —License plate lights
(type A)

’02 Tacoma U (L/O 0109)
2802002 MY TACOMA_U (OM35786U)
Use a Phillipshead screwdriver.Use a Phillipshead screwdriver.
—License plate lights
(type B)—High mounted stoplight

’02 Tacoma U (L/O 0109)
2812002 MY TACOMA_U (OM35786U)

SPECIFICATIONS
Dimensions282
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Payload 284
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . .
Engine 286
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . .
Fuel 286
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . .
Service specifications 286
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
Tires 290
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . .
Fuses 290
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . .
SECTION 8

’02 Tacoma U (L/O 0109)
2822002 MY TACOMA_U (OM35786U)
Dimensions
Regular cab models Xtracab models
Overall length
Overall height
∗ 8
Front tread
Rear tread Overall width
Wheelbase 4540 (178.7)
∗
1
4685 (184.4)∗25010 (197.2)∗1
5155 (203.0)∗2
1690 (66.5)
1765 (69.5)∗3, 41690 (66.5)
1625 (64.0)
∗4, 6
1615 (63.6)∗5, 6
1620 (63.8)∗4, 7
1630 (64.2)∗5, 7
3095 (121.9)
1450 (57.1)
1455 (57.3)
1455 (57.3) 1450 (57.1)
2625 (103.3) 1590 (62.5)
∗
3, 4
1605 (63.2)∗4
1615 (63.6)∗5
∗ 1
: Without rear step bumper∗2: With rear step bumper∗3: With 5VZFE engine∗4: With P235/55R16 tires∗5: With P205/75R15 tires∗6: With automatic transmission∗7: With manual transmission∗8: Unladen vehicle
TWOWHEEL DRIVE MODELS EXCEPT PRE RUNNER mm (in.)
