2002 PONTIAC BONNEVILLE display

3-18
Your tape bias is set automatically when a metal or chrome
tape is inserted. If you want to insert a tape when the
ignition is off, first press the eject button or the RCL knob.
If an error appears on the display, see ªCassette Tape
Messagesº later in this section.


1 (Forward): Press this pushbutton to advance
quickly to another part of the tape. Press it again to
return to playing speed. The radio will play the last
selected station while the tape advances. You may select
stations during forward operation by using TUNE.
While in forward mode the display will show FREQ and
FWD and two right arrows. If the radio is playing a
RDS station the display will only show FREQ.
 2 (Side): Press this pushbutton to play the other
side of the tape.
4
 (Reverse): Press this pushbutton to reverse the
tape rapidly. Press it again to return to playing speed.
The radio will play the last selected station while the
tape reverses. You may select stations during reverse
operation by using TUNE.
6
(Dolby): Press this pushbutton to reduce
background noise. DOLBY NR ON will appear on the
display. Press it again to turn Dolby NR off.Dolby Noise Reduction is manufactured under a license
from Dolby Laboratories Licensing Corporation. Dolby
and the double
-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
EQ (Equalizer): Press EQ to select the desired preset
equalization setting while playing a cassette. The
equalization will be automatically set whenever you
play a cassette tape. See ªEQº listed previously for
more information.
 SEEK : Press the up or down arrow to search for
the next or previous selection on the tape. Your tape
must have at least three seconds of silence between each
selection for SEEK to work. You can skip nine
selections up or down on the tape. Choose how many
selections you want to skip. Press the SEEK arrow that
many times. The number of selections to be skipped will
appear on the display.

 SCAN : Press and hold one of the SCAN arrows
for more than two seconds until SCAN appears on the
display and you hear a beep. The tape will go to the next
selection, play for a few seconds, then go on to the next
selection. The tape will only scan forward. Press this
button again to stop scanning. The sound will mute
while scanning.

3-19
AM FM: Press this button to listen to the radio
when a tape is playing. The tape will stop but remain
in the player.
TAPE AUX (Auxiliary): Press this button to play a
cassette tape when listening to the radio. The inactive
tape will remain safely inside the radio for future
listening. The tape icon will appear on the display when
a cassette tape is loaded. If you have the optional CD
changer and the CD changer is loaded, the TAPE AUX
button will activate the changer and an icon will be lit in
the display.
(Eject): Press this button to stop a tape when it is
playing and to remove a tape when it is not playing.
Eject may be activated with either the ignition or radio
off. Cassettes may be loaded with the radio and ignition
off if this button is pressed first.CD Adapter Kits
It is possible to use a portable CD player adapter kit
with your cassette tape player after activating the bypass
feature on your tape player.
To activate the bypass feature, perform the
following steps:
1. Turn the ignition to ON or ACC.
2. Turn the radio off.
3. Press and hold the TAPE AUX button for three
seconds. The tape symbol on the display will flash
for five seconds and READY will appear on the
display, indicating the feature is active.
4. Insert the adapter into the cassette slot. It will power
up the radio and begin playing.
This override routine will remain active until the eject
button is pressed.

3-20
Cassette Tape Messages
If an error appears while trying to play a cassette tape, it
could be for one of the following reasons:
TIGHT TAPE: This message is displayed when the
tape is tight and the player can't turn the tape hubs.
Remove the tape. Hold the tape with the open end down
and try to turn the right hub counterclockwise with a
pencil. Turn the tape over and repeat. If the hubs do not
turn easily, your tape may be damaged and should not be
used in the player. Try a new tape to make sure your
player is working properly.
BROKEN TAPE: If this message is displayed, the tape
is broken. Try a new tape.
WRAPPED TAPE: When this message is displayed,
the tape is wrapped around the tape head. Attempt to get
the cassette out. Try a new tape.
CLEAN PLAYER: If this message appears on the
display, the cassette tape player needs to be cleaned. It
will still play tapes, but you should clean it as soon as
possible to prevent damage to the tapes and player.
See ªCare of Your Cassette Tape Playerº in the Index.
If any error occurs repeatedly or if an error can't be
corrected, contact your dealer. If your radio displays an
error message, write it down and provide it to your
dealer when reporting the problem.AM-FM Stereo with Compact Disc Player
with Programmable Equalization and
Radio Data System (RDS) (If Equipped)
Playing the Radio
PWR (Power): Push this knob to turn the system on
and off.
VOL (Volume): Turn the knob clockwise to increase
volume. Turn it counterclockwise to decrease volume.

3-21
SCV (Speed-Compensated Volume): With SCV, your
audio system adjusts automatically to make up for road
and wind noise as you drive. Set the volume at the
desired level. Press this button to select MIN, MED or
MAX. Each higher choice allows for more volume
compensation at faster vehicle speeds. Then, as you
drive, SCV automatically increases the volume, as
necessary, to overcome noise at any speed. The volume
level should always sound the same to you as you drive.
If you don't want to use SCV, select OFF.
RCL (Recall): Push this knob to display the station
being played and to display the clock. Pressing this knob
with the ignition off will display the clock.
Finding a Station
AM FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE: Turn this knob to choose radio stations.
 SEEK
: Press the up or down arrow to go to the
next or previous station and stay there. The radio will
seek to stations with a strong signal only. The sound will
mute while seeking.
 SCAN
: Press and hold one of the SCAN arrows
for two seconds until SCAN appears on the display and
you hear a beep. The radio will go to a station, play for a
few seconds, then go on to the next station. Press one of
the SCAN arrows again to stop scanning. The radio will
scan to stations with a strong signal only. The sound will
mute while scanning.
To scan preset stations, press and hold one of the SCAN
arrows for more than four seconds until PSCAN and the
preset number appear on the display. You will hear a
double beep. The radio will go to the first preset station
stored on your pushbuttons, play for a few seconds, then
go on to the next preset station. This feature will only
scan the six presets that are in the selected band. Press
one of the SCAN arrows again to stop scanning presets.
The radio will scan preset stations with a strong signal
only. The sound will mute while scanning.

3-22
Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press AM FM to select the band.
3. Tune in the desired station.
4. Press EQ to select the equalization.
5. Press and hold one of the six numbered pushbuttons
until you hear a beep. Whenever you press that
numbered pushbutton, the station you set will return
and the equalization that you selected will also be
automatically selected for that pushbutton.
6. Repeat the steps for each pushbutton.Setting the Tone (Bass/Treble)
TONE: Press and release this button until BASS, MID
or TREB appears on the display. The SELECT LED
indicator will light to show that the tone control can be
adjusted. When adjusting BASS, MID or TREB,
turn the SELECT knob clockwise to increase or
counterclockwise to decrease. If a station is weak or
noisy, you may want to decrease the treble.
To adjust all of the tone controls to the middle position,
press and hold TONE until FLAT appears on the display.
EQ (Equalizer): This feature allows you to choose
preset bass, mid and treble equalization settings
designed for different program types. Press EQ to select
the desired preset equalization setting. Each time you
press EQ, another setting will appear on the display.

3-23
You can preset up to six equalization settings by
performing the following steps:
1. Turn the radio on.
2. Use the TONE button and the SELECT knob to
select the desired equalization.
3. Press and hold EQ for two seconds. SELECT EQ #
will appear on the display. The EQ icon will flash.
4. Press EQ or turn the SELECT knob to select the
desired EQ number. Each time you press EQ or turn
the SELECT knob, another EQ setting will appear on
the display.
5. Press and hold the EQ button or push the SELECT
knob to store the equalization preset. You will hear a
beep and EQ SAVED will appear on the display.
6. Repeat the steps for each EQ setting.
EQ 5 has been programmed at the factory for use with
talk radio, but it can be preset to a different tone.Adjusting the Speakers (Balance/Fade)
BAL (Balance): Press and release this button until BAL
appears on the display. The SELECT LED indicator will
light to show that the speakers can be adjusted. Turn the
SELECT knob to move the sound to the left or right
speakers. The middle position balances the sound
between the speakers.
FADE: Press and release this button until FADE appears
on the display. The SELECT LED indicator will light to
show that the speakers can be adjusted. Turn the
SELECT knob to move the sound to the front or rear
speakers. The middle position balances the sound
between the speakers.
Pressing and holding the BAL FADE button for
two seconds will return all speaker settings to the
middle position.

3-24
Using RDS
Your audio system is equipped with a Radio Data
System (RDS). RDS is a system that sends data along
with the audio of the FM station you are currently tuned
to. You can use RDS to display program information
and to control your radio. With RDS, the radio can do
the following:

Seek only to stations with the types of programs you
want to listen to,

seek to stations with traffic announcements,

receive announcements concerning local and
national emergencies, and

receive and display messages from radio stations.
RDS is always on. RDS features are only available for
use on FM stations which broadcast RDS information.
The RDS features of your radio rely upon receiving
specific RDS information from these stations. These
features will only work when the RDS information is
available. In rare cases, a radio station may broadcast
incorrect information that will cause the radio features
to work improperly. If this happens, contact the
radio station.When you are tuned to an RDS station, the station name
will appear on the display, instead of the frequency.
Most RDS stations provide their station name, the time
of day and a Program Type (PTY) for their current
programming. Some stations also provide the name of
the current program.
Finding a PTY Station
PROG TYPE (Program Type): This button is used to
turn on and off Program Type (PTY) select. P
-TYPE
will appear on the display and the SELECT LED
indicator will light. The last selected PTY will appear on
the display for five seconds. Turn the SELECT knob to
select the PTY you want to listen to. Press the SEEK up
arrow and the radio will search for an RDS station that
is broadcasting the PTY that you have selected. The last
PTY selected will be used for seek or scan modes. When
the SELECT LED indicator is on and a PTY is not
displayed, the first time seek is pressed, the last selected
PTY will be displayed. Press the SEEK up arrow again
to seek. If a station with the selected PTY is not found,
NOT FOUND will appear on the display.

3-25
To use the PTY interrupt feature, press and hold PROG
TYPE until you hear a beep on the PTY you want to
interrupt. An asterisk will appear next to the PTY name,
for example (CLASSICAL*). The radio will also
display brackets around the PTY when the PTY
interrupt is active. To disable the PTY interrupt, select
the interrupt format and press and hold the PROG TYPE
button until you hear a beep. The asterisk will be
removed from the display and so will the brackets.
When you are listening to a compact disc, the last
selected RDS FM station will interrupt play if that
selected PTY format is broadcast.
AM FM (Alternate Frequency): Alternate frequency
allows the radio to switch to a stronger station with the
same programming. Press and hold AM FM for two
seconds to turn alternate frequency on. AF ON will
appear on the display. The radio may switch to stronger
stations. Press and hold AM FM again for two seconds
to turn alternate frequency off. AF OFF will appear on
the display. The radio will not switch to other stations.Setting Preset PTY Stations
The six numbered pushbuttons let you return to your
favorite Program Types (PTYs). These pushbuttons have
factory PTY presets. You can set up to 12 PTYs
(six FM1 and six FM2) by performing the
following steps:
1. Press AM FM to select FM1 or FM2.
2. Press PROG TYPE, if it is not already on.
3. Turn the SELECT knob to select a PTY.
4. Press and hold one of the six numbered pushbuttons
until you hear a beep. Whenever you press that
numbered pushbutton, the PTY you set will return.
5. Repeat the steps for each pushbutton.
RDS Messages
ALERT!: This type of announcement warns of national
or local emergencies. You will not be able to turn off
alert announcements. ALERT! appears on the display
when an alert announcement plays. When an alert
announcement comes on the current radio station, you
will hear it, even if the volume is muted or a compact
disc is playing. If the compact disc player is playing,
play will stop for the announcement and resume when
the announcement is finished.
