2002 PONTIAC BONNEVILLE display

2-96
Driver Information Center (DIC)
(If Equipped)
Your vehicle may have a Driver Information Center
(DIC). The DIC will display information about how
your vehicle is functioning, as well as warning messages
if a system problem is detected.
DIC Displays and Controls
There are two lines in the
DIC display. The bottom
line on the display area is
left blank when the DIC
displays the driver number
identified when entering
the vehicle.You can have your dealer program your name
to replace the driver identifier. See your dealer for
more information.
When you turn the ignition on, the DIC will display
your DRIVER NUMBER, which corresponds to the
number on the back of the remote keyless entry
transmitter (if equipped). The system will then perform
a status check and display any messages if a problem
is detected.
If there are no problems detected, the display will return
to the mode selected by that driver the last time the
ignition was turned off.
If a problem is detected, a diagnostic message will
appear in the display. The following information will
show the messages you may see on the DIC display.
The message center is continuously updated with the
vehicle's performance status.

2-97
The following buttons are on the DIC control
panel which is located to the right of the instrument
panel cluster:
E/M (English/Metric): This button allows you to
change the display between English and metric units.
TRIP RESET: This button allows you to reset your trip
odometer. To reset the trip odometer, press the TRIP
RESET button. The trip odometer will now accumulate
miles (kilometers) until the next reset.MODE: This button allows you to toggle through the
DIC modes (Vehicle Data, Personalization
Programming, Compass Calibration).
SELECT: This button allows you to select a DIC mode.
RESET: This button, when used along with other
buttons, will allow you to reset system functions.
Vehicle Data
Average Fuel Economy: Press the SELECT button
until the display shows AVG FUEL ECONOMY.
Average fuel economy is viewed as a long term
approximation of your overall driving conditions. To
learn the average fuel economy from a new starting
point, press the RESET button for five seconds while
the average fuel economy is displayed on the DIC.
Instantaneous Fuel Economy: Press the SELECT
button until the display shows INST FUEL ECONOMY.
Instantaneous fuel economy varies with your driving
conditions, such as acceleration, braking and the grade
of the road being traveled. The RESET button does not
function in this mode.

2-98
Fuel Range: Press the SELECT button until the display
shows FUEL RANGE. The fuel range will calculate the
remaining distance you can drive without refueling. This
calculation is based on the average fuel economy for the
last 25 miles (40.25 km) driven, and the fuel remaining
in the fuel tank. If the fuel range drops below 40 miles
(64.4 km), the display will show FUEL RANGE LOW.
The RESET button does not function in this mode.
Fuel Used: Press the SELECT button until the display
shows FUEL USED. The value indicates how much fuel
has been used since the last reset. Don't confuse fuel
used with the amount of fuel in your tank. To learn how
much fuel will be used from a specific starting point,
press the RESET button for five seconds while the fuel
used is displayed on the DIC.
Battery Volts: On vehicles with a supercharged engine,
press the SELECT button until the display shows
BATTERY VOLTS. If the voltage is normal the display
will show BATTERY ## VOLTS. If the voltage drops
below 10.5 volts for 30 seconds, the battery volts
display will show BATTERY LOW. If the voltage is
above 16.2 volts for 30 seconds, the battery volts display
will show BATTERY HIGH. If the display shows the
high or low message, you need to have your battery
and/or electrical system checked.GM Oil Life System
: Press the SELECT button until
OIL LIFE appears in the display. The OIL LIFE
NORMAL display will show an estimate of the oil's
remaining useful life. When the oil life index is less than
10%, an ENGINE OIL CHANGE SOON message will
be displayed and the oil life display will show OIL LIFE
CHANGE. When you have the oil changed according to
the maintenance schedule, you will have to reset the Oil
Life System. To reset the Oil Life System, see ªOil Life
Systemº in the Index. Also, see ªEngine Oil, When to
Changeº and ªMaintenance Scheduleº in the Index.
Tire Pressure Status: Press the SELECT button until
TIRE PRESSURE appears in the display. TIRE
PRESSURE NORMAL is displayed when the Check
Tire Pressure System believes your vehicle's tire
pressures are normal. If a potential problem is detected,
the display will show CHECK TIRE PRESSURE and
the tire pressure status will show TIRE PRESSURE
LOW. If you see the CHECK TIRE PRESSURE
message, you should stop as soon as you can and check
all your tires for damage. (If a tire is flat, see ªIf a Tire
Goes Flatº in the Index.) Also check the tire pressure in
all four tires as soon as you can. See ªInflation
-- Tire
Pressureº and ªCheck Tire Pressure Systemº in
the Index.

2-99 DIC Warnings and Messages
Other messages or warnings may appear in the DIC
display. For Canadian drivers, in addition to the DIC
message your DIC will display EXP with a number after
it which reflects the following messages:
EXP (Export ID) Warning Message. . . . . . . . . . . .
3 SERVICE VEHICLE SOON. . . . . . . . . . . . . . . . .
9 CHECK GAGES VOLT. . . . . . . . . . . . . . . . . . . . .
11 CHECK GAGES LOW FUEL. . . . . . . . . . . . . . .
16 ENGINE HOT A/C DISABLED. . . . . . . . . . . . .
20 TURN SIGNAL ON?. . . . . . . . . . . . . . . . . . . . . .
24 TRUNK AJAR. . . . . . . . . . . . . . . . . . . . . . . . . . .
25 WASHER FLUID LOW. . . . . . . . . . . . . . . . . . . .
27 BATTERY SAVER ACTIVE. . . . . . . . . . . . . . . .
33 STARTING DISABLED
- THEFT * . . . . . . . . . .
34 SERVICE THEFT SYSTEM. . . . . . . . . . . . . . . .
35 CHECK GAGES OIL PRESSURE *. . . . . . . . . .
36 OIL LEVEL LOW. . . . . . . . . . . . . . . . . . . . . . . .
37 BRAKE FLUID LOW *. . . . . . . . . . . . . . . . . . . .
40 ALARM OCCURRED. . . . . . . . . . . . . . . . . . . . .
44 CHECK GAGES TEMPERATURE *. . . . . . . . .
54 SERVICE STABILITY SYSTEM. . . . . . . . . . . .
55 STABILITY SYSTEM ACTIVE. . . . . . . . . . . . .
61 CHECK GAS CAP. . . . . . . . . . . . . . . . . . . . . . . . EXP (Export ID) Warning Message. . . . . . . . . . . .
81 ENGINE OIL CHANGE SOON. . . . . . . . . . . . .
83 SERVICE AIR BAG. . . . . . . . . . . . . . . . . . . . . . .
102 CHECK CHARGE SYSTEM. . . . . . . . . . . . . . .
140 DRIVER DOOR AJAR. . . . . . . . . . . . . . . . . . .
141 FRONT PASSENGER DOOR AJAR. . . . . . . .
142 LEFT REAR DOOR AJAR. . . . . . . . . . . . . . . .
143 RIGHT REAR DOOR AJAR. . . . . . . . . . . . . . .
144 CHECK TIRE PRESSURE. . . . . . . . . . . . . . . .
147 PARK BRAKE SET *. . . . . . . . . . . . . . . . . . . .
The EXP codes are used to make translation from
English to other languages easier.
Pressing any of the DIC control buttons will remove the
above messages or warnings from the DIC display,
unless noted by an asterisk (*).
SERVICE STABILITY SYSTEM
- 54: If you ever
see the SERVICE STABILITY SYSTEM message,
it means there may be a problem with your stability
enhancement system. If you see this message, try to
reset the system (stop; turn off the engine; then start the
engine again). If the SERVICE STABILITY SYSTEM
message still comes on, it means there is a problem.
You should see your dealer for service. Reduce your
speed and drive accordingly.

2-101
Choosing Your Zone Number
Locate your zone number on the above map. If your
number is different than the one shown when you
turn the key on, follow the steps to change your
zone number.
If you live on the line, you can pick the zone area you
are most likely to drive in. (In Alaska, use Zone 9 or 10.
In Hawaii, use Zone 7.)Changing Your Zone Number
1. Press MODE to display COMPASS CALIBRATION.
2. Press SELECT to display RESET CHANGES ZONE.
3. Press RESET until your number appears.
4. Press MODE to exit the COMPASS CALIBRATION
MODE and store the new zone number. When the
MODE button is pressed, the DIC will return to the
VEHICLE DATA mode.
Calibrating the Compass
All electronic compasses need to know the magnetic
profile of your vehicle. This is called calibration and is
done automatically by your compass. But, the feature is
available if you would like to manually calibrate.
Sometimes, strong magnetic fields can affect the
compass. If the compass display does not show a
direction, and CALIBRATE COMPASS is displayed on
the DIC, try calibrating the compass as follows:
1. Drive the vehicle to an open, flat area.
2. Press MODE to display COMPASS CALIBRATION.

2-102
3. Press SELECT to display PRESS RESET TO
RECALIBRATE and then press the RESET button.
4. The display will change to SLOWLY DRIVE IN
SMALL CIRCLES. Drive the vehicle in small
circles. Don't drive faster than 10 mph (16 km/h).
5. Continue to drive in circles until the CALIBRATION
COMPLETE is displayed on the DIC and a direction
is shown for the compass.
Your compass should be calibrated. You will know this
when a direction is shown and the CALIBRATE
COMPASS message is no longer displayed.
Compass Accuracy
Your compass may show different headings around
bridges, power lines, large metal objects and steep hills.
This is normal and is true of compasses in general.
If you put large metal objects like golf clubs in the trunk
they could affect accuracy. If the affect is minimal, the
compass will adapt to these objects over time.
If you use an antenna with a magnetic base, it is best
to mount it away from the center of the trunk near the
rear window.The rear defog system can affect accuracy, and the
compass corrects for the rear defog. However, if the rear
defog is turned on while making sharp turns, the
accuracy may be off. When you turn the rear defog off
again, the accuracy returns to normal.
Be aware that metal objects are sometimes buried in the
ground. They can affect accuracy and you may not know
they are there. As an example, many concrete roads
have metal reinforcements inside.
Also, if you drive with the trunk open, this could affect
accuracy and could decalibrate the compass.
Driver Identifier DIC Display
This feature allows two different drivers to store and
recall their own preferred display mode. The
personalization settings displayed on the DIC are
determined by the transmitter used to enter the vehicle.
After the unlock button of a remote keyless entry
transmitter (if equipped) is pressed and the ignition is in
ON, the DIC will display the identified driver. The
settings can also be changed by briefly pressing one of
the MEMORY buttons located on the driver's door.
The DIC is used to program information for DRIVER
#1 and DRIVER #2. The DIC will identify a person as
UNKNOWN DRIVER if they are neither DRIVER #1
nor DRIVER #2.

2-103 DIC Personalization Programming
The DIC can be used to program the following
personalization features available with your vehicle:

Automatic Door Locks

Window Lockout

Security Feedback

Delayed Locking

Perimeter Lighting

Memory Seats

Parallel Park Assist Mirror (Tilt Mirror)

Driver ID
The DIC is used to program the personal choices of two
drivers. The drivers are recognized as DRIVER #1 and
DRIVER #2. You will let the DIC know which driver
you are by using your remote keyless entry transmitter
or by pressing the appropriate memory seat control
button located on the driver's door or by choosing the
driver with the DIC. Each remote keyless entry
transmitter was preprogrammed to belong to DRIVER
#1 or DRIVER #2. Each transmitter may be
programmed differently for each driver.When you press the button with the unlock symbol on
your transmitter, the DIC will automatically change
driver numbers and the vehicle will recall the
personalization settings that were last made to
correspond to your transmitter, including your radio and
comfort control settings. See ªComfort Controls
Personalizationº in the Index.
If you unlock the vehicle using your door key instead of
your transmitter, the DIC will not change drivers and
will recall the information from the last transmitter use
or the last driver change using the memory seat controls.
If this happens and you were not the last driver of the
vehicle, simply press your correct driver number on
the memory seat controls or press the button with the
unlock symbol on your transmitter or select the
personalization programming mode and choose the
correct driver number.
Use the following steps for personalization
programming instructions.
1. Turn the ignition on and keep the transaxle
in PARK (P).
2. Press the MODE button to reach personalization
programming display.

2-104
3. Press the SELECT button to enter personalization
programming mode.
4. The first choice to be made will be DRIVER ID 1
or 2. Press the RESET button to toggle between your
selections within a display and SELECT to choose
the current selection and move on to the next
personalization feature.
You are now in the selection mode and the DIC is ready
to program your personal choices in memory.
Each feature that can be personalized will appear in
the display. Once you have made a selection for a
feature, the DIC will move on to the next
personalization feature.
Scroll through the following messages and
feature options:

AUTO DOOR LOCKS
-- OFF/ON

UNLOCK
-- OFF/ON

UNLOCK
-- KEY OFF/PARK

DOOR TO UNLOCK
-- DRIVER/ALL

WINDOW LOCKOUT
-- R + PASS/REAR

KEYLESS FEEDBACK
-- OFF/ON

LIGHTS FEEDBACK
-- OFF/ON
HORN FEEDBACK
-- OFF/ON

DELAYED LOCKING
-- OFF/ON

PERIMETER LIGHTS
-- OFF/ON

PERIMETER LIGHTS
-- TIMEOUT 15 SEC

SEAT RECALL
-- OFF/ON

RECALL POSITION
-- MEMORY/EXIT

TILT MIRROR
-- OFF/ON

DRIVER ID
-- OFF/ON
If you would like to exit the selection mode without
moving through each of the personalization features,
simply press a different button on the DIC or turn off the
ignition. The personal choices you made will still be
retained, even without passing through each of the
features. In order for your personal choices to save, you
must press SELECT after making your selections.
If you happen to move past a selection you would like to
make a personal choice for, press unlock on your
transmitter or press the appropriate driver number on the
memory seat control. This will return you to the
beginning of the option feature programming mode.
A description of each feature programmable through the
DIC follows.
