2002 MERCEDES-BENZ M-Class key

94
Introduction Audio TelephoneNavigationIndex
System settings
Enter address number:
Select the first number (9) of the desired address num-
ber with the joystick and press . The character will
appear in the text window (10).
To enter more characters repeat this step.
Numbers can also be entered through the number key-
pad.Note:
All unnecessary characters are shaded out. Use “N”, “E”,
“W” or “S” only if the address number contains such a
character. The MCS will automatically differentiate
north, east, west and south street names.
To correct the last character select “Delete” (11) with the
joystick and press .
When the address number has been displayed, select
“Done” with the joystick and press . If the city name
was not entered before, the city name menu will appear.P86-0081-B13 (2-fbg)
Destination input

109
Introduction Audio TelephoneNavigationIndex
System settings
The Confirm Destination menu will appear.
Select “OK to Proceed” with the joystick and press ,
the MCS will begin calculating the route.
Select “Save in Address Book” with the joystick and
press , the address will be stored in the Address
Book, page 110.
Select “Add to Today’s Plan” with the joystick and press
, the entry will be added to Today’s Plan, page 115.Saving the current vehicle position
Press .
Select “Option” with the joystick and press .
The Option Select menu appears. Select “Save Current
Position” with the joystick and press .
The location will be saved in the Recent Route list. The
Select Address menu will appear with the saved entry.
Press one more time to return to the “Option” menu,
or press the softkey “MAP” to return to the map
screen.
P82.85-5116-26
Destination input

125
Introduction Audio TelephoneNavigationIndex
System settings
While the system is guiding you on your route, the dis-
play can be manually changed between modes. The
Guidance Display mode shows an arrow indicating the
next maneuver.
By pressing the joystick to the right the next maneuver
can be previewed. Press the joystick to the left to return
to the current maneuver.The Detailed Map display shows a moving map with the
recommended route highlighted in blue.
The display is changed by pressing the softkey
“MAP”. To activate the softkeys press any softkey. P882.85-5049-26
P82.85-5050-26
Route guidance

126
Introduction Audio TelephoneNavigationIndex
System settings
All maneuvers are announced by voice instructions. The
instructions start a short while before the maneuver is
required. You will, for example, hear an annoucement,
“In one half mile, make a right turn”.
When it is time to perform the maneuver you will hear,
for example, an annoucement, “Right turn ahead“.
To repeat the verbal announcement press the key.
To set the volume, see page 11.
To mute the voice instructions, see page 127.
The maneuver list can be displayed by pressing the soft-
key “LIST”. To activate the softkeys press any soft-
key.
To preview the arrow guidance screen for a particular
maneuver, scroll down the list and select a maneuver
with the joystick and press .
After 10 seconds the display automatically returns to
the original guidance screen or by pressing the softkey
“MAP”.
P82.85-6548-26
Route guidance

127
Introduction Audio TelephoneNavigationIndex
System settings
Once you reach your final destination, the screen will
switch to the Detailed Map display and show the
address and the name, if programmed, of your final des-
tination.Mute voice instructions
To mute the voice instructions press the softkey
“MUTE”. To activate the softkeys press any softkey. The
softkey “MUTE” will be highlighted.
To delete the mute function press the highlighted soft-
key “MUTE”. To activate the softkeys press any
softkey.
If you press the key the system will give the cur-
rent voice instruction regardless whether mute is on or
off.P82.85-5052-26
Route guidance

128
Introduction Audio TelephoneNavigationIndex
System settings
Altering the map scale
In map mode you can zoom the map in or out for more
or less detail.
Press to zoom in.
Press to zoom out.Break off route guidance
To activate the softkeys press any softkey.
Press softkey “STOP”.
A window appears confirming the stop request. To con-
tinue press . If you don’t wish to continue, press
or wait 10 seconds and the stop request will be
cancelled.
The current destination is cancelled.
P82.85-5097-26
Route guidance

130
Introduction Audio TelephoneNavigationIndex
System settings
Select one of the following calculation modes with the
joystick. After selection press .
• “Shortest Route”: The MCS will calculate the short-
est and most efficient way to arrive at your destina-
tion.
• “Maximize Freeways”: The MCS will calculate a
route that makes most efficient use of the freeways.
• “Minimize Freeways”: The MCS will calculate a
route that uses mostly surface streets.
• “Minimize Toll Roads”: The MCS will calculate a
route that uses the least number of toll roads
enroute to the destination.
The “Continue Trip to” menu appears, select “OK to Pro-
ceed” with the joystick and press .Viewing the Maneuver List during guidance
During route guidance, you can display a list of maneu-
vers to preview upcoming turns and street names.
Press the softkey “LIST”. To activate the softkeys
press any softkey.
The Maneuver List menu appears. To preview a specific
maneuver, select a street name/maneuver with the joy-
stick and press .
P82.85-6548-26
Route guidance

131
Introduction Audio TelephoneNavigationIndex
System settings
The maneuver screen for the selected maneuver
appears on the display.
To r e t u rn to t h e G u i d a n c e mode press the softkey
“MAP” or wait 10 seconds, then the system will auto-
matically return to the Guidance mode.Road obstructed
If you encounter a road block or would like to avoid con-
struction, you may choose a different routing option, or
choose to avoid certain roads. This selections only func-
tions during route guidance.
Press .
Select “Route” with the joystick and press .
The Route Select menu appears. Select “Avoid Road”
with the joystick and press .
P82.85-6560-26
Route guidance
