2002 MERCEDES-BENZ C320 WAGON Owner's Manual

206 Interior equipment
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
8. Connect snap hook (6) of front strap to eye (7)
located on center tunnel in front of rear seat bench.Unloading and folding
1. Loosen strap, open clasp by pressing tabs (arrows)
together, and unload skis.
2. Close flap in trunk.
3. Disconnect snap hook (6) from eye (7).
4. Fold and flatten ski sack lengthwise and place
folded ski sack inside recess of backrest.
S203.book Seite 206 Freitag, 19. Oktober 2001 1:25 13

207 Interior equipment
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index 5. Close ski sack compartment cover.Removal of ski sack
For removal of the ski sack we recommend that you
contact an authorized Mercedes-Benz Center.
Note:
To prevent unauthorized persons from access to the
trunk, always close the pass-through.
Wa r n i n g !
Never drive vehicle with trunk lid open while the
ski sack is removed. Deadly carbon monoxide (CO)
gases may enter vehicle interior resulting in
unconsciousness and death.
S203.book Seite 207 Freitag, 19. Oktober 2001 1:25 13

208 Interior equipment
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Parcel net in trunk
There is a parcel net located on left side of the trunk.
Dependent on the equipment of your vehicle, there is
another parcel net located on right side of the trunk.
Removal of parcel net:
Slide rails (1) upward and remove.
Installation of parcel net:
Place mounting lugs (2) in opening and slide rails (1)
down as far as they can go.
Wa r n i n g !
The parcel net is designed only to carry light loads.Do not place heavy or fragile objects, or objects
having sharp edges, in the parcel net.In an accident, during hard braking or sudden
maneuvers, they could be thrown around inside
the vehicle, and cause injury to vehicle occupants.
S203.book Seite 208 Freitag, 19. Oktober 2001 1:25 13

209 Interior equipment
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Electrical outlet
The electrical outlet is located in the rear compartment.
Electronic key in starter switch position 1 or 2.
Flip up cover and insert electrical plug (cigar lighter
type).
Note:
The electrical outlet can be used to accommodate
accessories (e.g. air pump, auxilary lamps) up to a
maximum 180 W.Storage compartment under trunk floor
To o p e n t r u n k f l o o r :
Press handle (1) on the recess and lift trunk cover.
The compartment can be used to store small, light or flat
objects.
P68.00-2480-26
1
S203.book Seite 209 Freitag, 19. Oktober 2001 1:25 13

210 Interior equipment
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
To close trunk floor:
Lower the cover and lock by applying light pressure to
the handle (1).Retractable luggage cover and partition net
The twin reel roller blind comprises a luggage cover and
a partition net. It is mounted on the backrest of the rear
seat and can also be used with backrest folded down.
Partition net
Wa r n i n g !
If items are stored in the compartment, make sure
compartment is securely closed.In an accident, during hard braking or sudden
maneuvers, they could be thrown around inside the
vehicle, and cause injury to vehicle occupants.
Wa r n i n g !
To help avoid personal injury during a collision or
sudden maneuver, always use partition net when
transporting cargo.
S203.book Seite 210 Freitag, 19. Oktober 2001 1:25 13

211 Interior equipment
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Partition net with rear seats folded up
1Ta b
2Eyelets on roof
Pull out upper blind (safety net)by tabs (1) and engage
into eyelets on the roof (2).Partition net with rear seats folded down
1Ta b
2Eyelets on roof
Pull out upper blind (safety net) by tabs (1) until it
engages.
Fold seat forward, see page 213.
Pull out upper blind fully and clip into eyelets on the
roof (2).
P68.00-2481-26
2
1
2
P68.00-2487-26
2
1
2
S203.book Seite 211 Freitag, 19. Oktober 2001 1:25 13

212 Interior equipment
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index
Luggage cover
1Handle
2To lock – pull luggage cover back by handle (1) until
it locks into position.
3To unlock – press handle (1) down and release. The
luggage cover retracts automatically.
Note:
With the luggage cover rolled up, fold the lip down.Removal, installation of twin-reel roller blind
The safety net and luggage cover must be retracted.
Removal:
Fold up split rear bench seat, see page 213.
Slide twin-reel roller blind (1) to left and remove.
Installation:
Fold up split rear bench seat.
Place twin-reel roller blind into right and left guide
rails (2) and slide towards right to the end stop.
P68.00-2488-26
2
13
2
P68.00-2489-26
S203.book Seite 212 Freitag, 19. Oktober 2001 1:25 13

213 Interior equipment
Te ch n i c a l
data Instruments
and controlsOperationDrivingInstrument
cluster displayPractical hints Car care Index Split rear bench seat
The two sections can be folded down separately to
enlarge the cargo area.Folding the backrest forward
Pull release handle (1) and fold seat cushion (2)
forward.
Wa r n i n g !
When expanding the luggage compartment, always
fold the seat cushions fully forward and always use
the partition net when transporting cargo.Unless you are transporting cargo, the backrests
must remain properly locked in the upright
position.In an accident, during hard braking or sudden
maneuvers, loose items will be thrown around
inside the vehicle, and cause injury to vehicle
occupants unless the items are securely fastened in
the vehicle.Always use the cargo tie down rings, see page 218.
P91.10-2302-26
S203.book Seite 213 Freitag, 19. Oktober 2001 1:25 13
