CONTENTS
CONTENTS 5
Description ...................................................................................................................................... 12-2-6
ADJUSTMENTS
Engine oil pressure check .............................................................................................................. 12-2-11
REPAIRS
Seal - crankshaft - rear .................................................................................................................. 12-2-13
Gasket - cylinder head - LH ........................................................................................................... 12-2-14
Gasket - cylinder head - RH ............................................................................................................ 12-2-16
Gasket - rocker cover - LH ............................................................................................................ 12-2-19
Gasket - rocker cover - RH ............................................................................................................ 12-2-20
Mounting - front - LH ...................................................................................................................... 12-2-22
Mounting - front - RH ..................................................................................................................... 12-2-23
Mounting - rear - LH ....................................................................................................................... 12-2-24
Mounting - rear - RH ...................................................................................................................... 12-2-25
Engine assembly............................................................................................................................. 12-2-26
Flywheel ........................................................................................................................................ 12-2-31
Plate - drive - automatic ................................................................................................................ 12-2-32
Ring gear - starter ......................................................................................................................... 12-2-33
Filter - oil ....................................................................................................................................... 12-2-34
Strainer - oil pick-up ...................................................................................................................... 12-2-35
Pump - oil ...................................................................................................................................... 12-2-35
Gasket - sump ................................................................................................................................ 12-2-36
Switch - oil pressure ....................................................................................................................... 12-2-38
Cooler - engine oil .......................................................................................................................... 12-2-39
Gasket - timing gear cover ............................................................................................................ 12-2-40
Seal - cover - timing gears ............................................................................................................ 12-2-42
OVERHAUL
Gasket - inlet manifold ................................................................................................................... 12-2-45
Gasket - exhaust manifold ............................................................................................................. 12-2-48
Seal - crankshaft - rear - automatic models .................................................................................... 12-2-49
Seal - crankshaft - rear - manual models ........................................................................................ 12-2-50
Bearing - spigot - crankshaft .......................................................................................................... 12-2-52
Gasket - engine sump .................................................................................................................... 12-2-53
Strainer - oil pick-up ....................................................................................................................... 12-2-54
Seal - timing gear cover ................................................................................................................. 12-2-54
Gasket - timing gear cover ............................................................................................................. 12-2-55
Timing chain and gears .................................................................................................................. 12-2-57
Rocker shaft - overhaul ................................................................................................................. 12-2-59
Gasket - cylinder head .................................................................................................................... 12-2-60
Cylinder head - overhaul ................................................................................................................ 12-2-62
Piston assemblies ........................................................................................................................... 12-2-67
Bearings - connecting rods ............................................................................................................ 12-2-71
Crankshaft and main bearings ........................................................................................................ 12-2-72
Camshaft ....................................................................................................................................... 12-2-76
EMISSION CONTROL - Td5..................................................................... 17-1-1
DESCRIPTION AND OPERATION
EGR system components - type 1 .................................................................................................. 17-1-1
EGR system components - type 2 .................................................................................................. 17-1-2
Emission Control Systems .............................................................................................................. 17-1-4
Crankcase emission control ............................................................................................................ 17-1-4
Exhaust gas recirculation ................................................................................................................ 17-1-5

GENERAL INFORMATION
03-3
Environmental Precautions
General
This section provides general information which can
help to reduce the environmental impacts from the
activities carried out in workshops.
Emissions to air
Many of the activities that are carried out in
workshops emit gases and fumes which contribute to
global warming, depletion of the ozone layer and/or
the formation of photochemical smog at ground
level. By considering how the workshop activities are
carried out, these gases and fumes can be
minimised, thus reducing the impact on the
environment.
Exhaust fumes
Running car engines is an essential part of workshop
activities and exhaust fumes need to be ventilated to
atmosphere. However, the amount of time engines
are running and the position of the vehicle should be
carefully considered at all times, to reduce the
release of poisonous gases and minimise the
inconvenience to people living nearby.
Solvents
Some of the cleaning agents used are solvent based
and will evaporate to atmosphere if used carelessly,
or if cans are left unsealed. All solvent containers
should be firmly closed when not needed and
solvent should be used sparingly. Suitable
alternative materials may be available to replace
some of the commonly used solvents. Similarly,
many paints are solvent based and the spray should
be minimised to reduce solvent emissions.
Refrigerant
It is illegal to release any refrigerants into the
atmosphere. Discharge and replacement of these
materials from air conditioning units should only be
carried out using the correct equipment.
Checklist
Always adhere to the following.
Engines:
ldon't leave engines running unnecessarily;
lminimise testing times and check where the
exhaust fumes are being blown.
Materials:
lkeep lids on containers of solvents;
lonly use the minimum quantity;
lconsider alternative materials;
lminimise over-spray when painting. Gases:
luse the correct equipment for collecting
refrigerants;
ldon't burn rubbish on site.
Discharges to water
Most sites will have two systems for discharging
water: storm drains and foul drains. Storm drains
should only receive clean water, foul drains will take
dirty water.
The foul drain will accept many of the normal waste
waters such as washing water, detergents and
domestic type wastes, but oil, petrol, solvent, acids,
hydraulic oil, antifreeze and other such substances
should never be poured down the drain. If in any
doubt speak to the Water Company first.
Every precaution must be taken to prevent spillage of
oil, fuel, solvents etc. reaching the drains. All
handling of such materials must take place well away
from the drains and preferably in an area with a kerb
or wall around it, to prevent discharge into the drain.
If a spillage occurs it should be soaked up
immediately. Having a spill kit available will make
this easier.
Additional precautions
Check whether the surface water drains are
connected to an oil water separator, this could
reduce the pollution if an incident was to occur. Oil
water separators do need regular maintenance to
ensure effectiveness.
Checklist
Always adhere to the following.
Disposal:
lnever pour anything down a drain without first
checking that it is environmentally safe to do so,
and that it does not contravene any local
regulations or bye-laws;
l have oil traps emptied regularly.
Spillage prevention:
lstore liquids in a walled area;
lmake sure that taps on liquid containers are
secure and cannot be accidentally turned on;
lprotect bulk storage tanks from vandalism by
locking the valves;
ltransfer liquids from one container to another in
an area away from open drains;
lensure lids are replaced securely on containers;
lhave spill kits available near to points of storage
and handling of liquids.

GENERAL INFORMATION
03-5
Electricity and heating:
lkeep doors and windows closed in the winter;
lswitch off machinery or lights when not needed;
luse energy efficient heating systems;
lswitch off computers and photocopiers when
not needed.
Fuel:
ldon't run engines unnecessarily;
lthink about whether journeys are necessary and
drive to conserve fuel.
Water:
ldon't leave taps and hose pipes running;
lmend leaks quickly, don't be wasteful.
Compressed air:
ldon't leave valves open;
lmend leaks quickly;
ldon't leave the compressor running when not
needed.
Use of environmentally damaging materials:
lcheck whether a less toxic material is available.
Handling and storage of materials:
lhave the correct facilities available for handling
liquids to prevent spillage and wastage as listed
above;
lprovide suitable locations for storage to prevent
frost damage or other deterioration.
Waste Management
One of the major ways that pollution can be reduced
is by the careful handling, storage and disposal of all
waste materials that occur on sites. Legislation
makes it illegal to dispose of waste materials other
than to licensed waste carriers and disposal sites.
This means that it is necessary to not only know what
the waste materials are, but also to have the
necessary documentation and licenses.
Handling and storage of waste
Ensure that waste materials are not poured down the
drain or onto soils. They should be stored in such a
way as to prevent the escape of the material to land,
water or air.
They must also be segregated into different types of
waste e.g. oil, metals, batteries, used vehicle
components. This will prevent any reaction between
different materials and assist in disposal.
Disposal of waste
Disposal of waste materials must only be to waste
carriers who are licensed to carry those particular
waste materials and all the necessary
documentation must be completed. The waste
carrier is responsible for ensuring that the waste is
taken to the correct disposal sites.Dispose of waste in accordance with the following
guidelines.
lFuel, hydraulic fluid, anti-freeze and oil: keep
separate and dispose of to specialist contractor.
lRefrigerant: collect in specialist equipment and
reuse.
lDetergents: safe to pour down the foul drain if
diluted.
lPaint, thinners: keep separate and dispose of
to specialist contractor.
lComponents: send back to supplier for
refurbishment, or disassemble and reuse any
suitable parts. Dispose of the remainder in
ordinary waste.
lSmall parts: reuse any suitable parts, dispose
of the remainder in ordinary waste.
lMetals: can be sold if kept separate from
general waste.
lTyres: keep separate and dispose of to
specialist contractor.
lPackaging: compact as much as possible and
dispose of in ordinary waste.
lAsbestos-containing: keep separate and
dispose of to specialist contractor.
lOily and fuel wastes (e.g. rags, used spill kit
material): keep separate and dispose of to
specialist contractor.
lAir filters: keep separate and dispose of to
specialist contractor.
lRubber/plastics: dispose of in ordinary waste.
lHoses: dispose of in ordinary waste.
lBatteries: keep separate and dispose of to
specialist contractor.
lAirbags - explosives: keep separate and
dispose of to specialist contractor.
lElectrical components: send back to supplier
for refurbishment, or disassemble and reuse
any suitable parts. Dispose of the remainder in
ordinary waste.
lElectronic components: send back to supplier
for refurbishment, or disassemble and reuse
any suitable parts. Dispose of the remainder in
ordinary waste.
lCatalysts: can be sold if kept separate from
general waste
lUsed spill-absorbing material: keep separate
and dispose of to specialist contractor.
lOffice waste: recycle paper and toner and ink
cartridges, dispose of the remainder in ordinary
waste.

GENERAL INFORMATION
03-6
General Fitting Instructions
Component removal
Whenever possible, clean components and
surrounding area before removal.
lBlank off openings exposed by component
removal.
lImmediately seal fuel, oil or hydraulic lines when
apertures are exposed; use plastic caps or
plugs to prevent loss of fluid and ingress of dirt.
lClose the open ends of oilways exposed by
component removal with tapered hardwood
plugs or conspicuous plastic plugs.
lImmediately a component is removed, place it in
a suitable container; use a separate container
for each component and its associated parts.
lClean bench and provide marking materials,
labels and containers before dismantling a
component.
Dismantling
Observe scrupulous cleanliness when dismantling
components, particularly when brake, fuel or
hydraulic system parts are being worked on. A
particle of dirt or a cloth fragment could cause a
serious malfunction if trapped in these systems.
lBlow out all tapped holes, crevices, oilways and
fluid passages with an air line. Ensure that any
'O' rings used for sealing are correctly replaced
or renewed, if disturbed during the process.
lUse marking ink to identify mating parts and
ensure correct reassembly. Do not use a centre
punch or scriber to mark parts, they could
initiate cracks or distortion in marked
components.
lWire together mating parts where necessary to
prevent accidental interchange (e.g. roller
bearing components).
lWire labels on to all parts which are to be
renewed, and to parts requiring further
inspection before being passed for reassembly;
place these parts in separate containers from
those containing parts for rebuild.
lDo not discard a part due for renewal until after
comparing it with a new part, to ensure that its
correct replacement has been obtained.Cleaning components
Always use the recommended cleaning agent or
equivalent. Ensure that adequate ventilation is
provided when volatile degreasing agents are being
used. Do not use degreasing equipment for
components containing items which could be
damaged by the use of this process.
General inspection
All components should be inspected for wear or
damage before being reassembled.
lNever inspect a component for wear or
dimensional check unless it is absolutely clean;
a slight smear of grease can conceal an
incipient failure.
lWhen a component is to be checked
dimensionally against recommended values,
use the appropriate measuring equipment
(surface plates, micrometers, dial gauges etc.).
Ensure the measuring equipment is calibrated
and in good serviceable condition.
lReject a component if its dimensions are
outside the specified tolerances, or if it appears
to be damaged.
lA part may be refitted if its critical dimension is
exactly to its tolerance limit and it appears to be
in satisfactory condition. Use 'Plastigauge' 12
Type PG-1 for checking bearing surface
clearances.

GENERAL INFORMATION
03-25
lComponents must not remain uncapped for
longer than 15 minutes. In the event of a delay,
the caps must be fitted.
lWhen disconnecting, immediately cap all air
conditioning pipes to prevent ingress of dirt and
moisture into the system.
lThe receiver/drier contains desiccant which
absorbs moisture. It must be positively sealed at
all times. A receiver/drier that has been left
uncapped must not be used, fit a new unit.
lThe receiver/drier should be the last component
connected to the system to ensure optimum
dehydration and maximum moisture protection
of the system.
lWhenever the refrigerant system is opened, the
receiver/drier must be renewed immediately
before evacuating and recharging the system.
lUse alcohol and a clean lint-free cloth to clean
dirty connections.
lEnsure that all new parts fitted are marked for
use with R134a.
When a major repair has been completed, a leak test
should be conducted; refer to the Air Conditioning
section of this manual for the correct procedure.
Refrigerant oil
Refrigerant oil easily absorbs water and must not
be stored for long periods. Do not pour unused
refrigerant oil back into the container. Always
use an approved refrigerant oil.

+ CAPACITIES, FLUIDS AND
LUBRICANTS, Lubrication.
When replacing components in the A/C system,
drain the refrigerant oil from the component being
replaced into a graduated container. On assembly,
add the quantity of refrigerant oil drained to the new
component.
Compressor
A new compressor is sealed and pressurised with
Nitrogen gas. When fitting a new compressor, slowly
release the sealing cap; gas pressure should be
heard to vent as the seal is broken.
CAUTION: A new compressor should always be
sealed and could be pressurised with nitrogen
gas. To avoid possible oil loss, release the
sealing cap(s) slowly. Do not remove the cap(s)
until immediately prior to connecting the air
conditioning pipes to the compressor.Rapid refrigerant discharge
If the air conditioning system is involved in accident
damage and the system is punctured, the refrigerant
will discharge rapidly. The rapid discharge of
refrigerant will also result in the loss of most of the oil
from the system. The compressor must be removed
and all the remaining oil in the compressor drained
and refilled as instructed in the air conditioning
section of this manual.
Precautions for refrigerant recovery, recycling
and recharging
When the air conditioning system is recharged, any
existing refrigerant is first recovered from the system
and recycled. The system is then charged with the
required weight of refrigerant and volume of
refrigerant oil.
WARNING: Refrigerant must always be recycled
before re-use to ensure that the purity of the
refrigerant is high enough for safe use in the air
conditioning system.
Recycling should always be carried out with
equipment which is design certified by
Underwriter Laboratory Inc. for compliance with
SAE J1991. Other equipment may not recycle
refrigerant to the required level of purity.
A R134a Refrigerant Recovery Recycling
Recharging Station must not be used with any
other type of refrigerant.
Refrigerant R134a from domestic and
commercial sources must not be used in motor
vehicle air conditioning systems.
CAUTION: The system must be evacuated
immediately before recharging commences.
Delay between evacuation and recharging is not
permitted.

GENERAL DATA
04-2
Lubrication
Type Wet sump, pressure fed
Pump type Eccentric rotor, crankshaft driven integral with stiffener plate.
Filter type:

Primary Centrifuge filter

Secondary Disposable canister with full flow by-pass
Pressure at idle (Cold) 3.0 bar (43.5 lbf.in
2)
Pressure at 3500 rev/min (Hot) 1.5-3.0 bar (21.75-43.5 lbf.in
2)
Relief valve opening pressure 4.0 bar (58 lbf.in
2)
Low oil pressure switch opening pressure 0.2-0.6 bar (3.0-8.8 lbf.in
2)
Crankshaft
Main journal diameter 61.9875-62.0125 mm (2.4404-2.4414 in)
Crankpin journal diameter 53.99-54.01 mm (2.125-2.131 in)
End float 0.020 - 0.250 mm (0.0008 - 0.0098 in)

Main bearings
Quantity 6 (5 main, 1 thrust)

Pistons
Type Graphite compound skirt with combustion chamber in crown
Clearance in cylinder bore.
Measured at bottom of skirt, 90° to gudgeon pin0.172-0.206 mm (0.007-0.008 in)
Diameter
(Measured at right angles to gudgeon pin and 40.0
mm (1.5 in) from bottom of skirt)84.270-85.254 mm (3.321-3.361 in)
Gudgeon pins Fully floating, offset towards piston thrust side
Piston rings
Type: 2 compression, 1 oil control

Upper compression ring Barrel edge, chrome plated

Lower compression ring Taper faced

Oil control ring Bevelled ring with spring
New ring to groove clearance:

Upper compression Not measured

Lower compression 0.050-0.082 mm (0.002-0.003 in)

Oil control 0.050-0.082 mm (0.002-0.003 in)
Piston ring fitted gap in cylinder bore:

Upper compression 0.30-0.45 mm (0.0118-0.0177 in)

Lower compression 0.40-0.60 mm (0.0157-0.0236 in)

Oil control 0.25-0.40 mm (0.0098-0.0157 in)

GENERAL DATA
04-3
Camshaft
Bearings 6
Drive Duplex chain
End float 0.06-0.16 mm (0.002-0.006 in)

Tappets
Type Hydraulic lash adjusters with followers

Valves
Stem diameter:

Exhaust 6.905 ± 0.008 mm (0.271 ± 0.0003 in)

Inlet 6.915 ± 0.008 mm (0.272 ± 0.0003 in)
Head diameter:

Exhaust 31.7 mm (1.25 in)

Inlet 34.7 mm (1.37 in)
Seat face angle:

Exhaust 45°

Inlet 30°
Valve face angle:

Exhaust 44° 48' ±12'

Inlet 29° 48' ±12'

Valve springs
Type Parallel, single coil

GENERAL DATA
04-4
Engine - V8
General
Cylinder arrangement 90° V8, numbered from the front of the engine:

Left bank cylinders 1, 3, 5 and 7

Right bank cylinders 2, 4, 6 and 8
Bore 94.00 mm (3.70 in)
Stroke:

4.0 litre

4.6 litre71.04 mm (2.80 in)
81.92 mm (3.22 in)
Capacity:

4.0 litre

4.6 litre3950 cm
3 (241 in3)
4554 cm3 (278 in3)
Firing order 1 - 8 - 4 - 3 - 6 - 5 - 7 - 2
Compression ratio:

Low - 4.0 litre 8.23:1

High - 4.0 and 4.6 litre 9.35:1
Direction of rotation Clockwise viewed from the front of the engine
Maximum power - 4.0 litre:

Low compression ratio 132 kW (177 bhp) at 4750 rev/min

High compression ratio - UK/Japan/ROW 136 kW (182 bhp) at 4750 rev/min

High compression ratio - NAS 140 kW (187 bhp) at 4750 rev/min
Maximum power - 4.6 litre 162 kW (217 bhp) at 4750 rev/min
Maximum engine speed:

Continuous5000 rev/min

Intermittent 5250 rev/min
Weight (fully dressed, wet)

Manual 194 Kg (435 lb)

Automatic 179 Kg (402 lb)
Dimensions:

Length - Manual 767 mm (30.2 in) (Including fan)

Length - Automatic 777 mm (30.5 in) (Including fan and drive plate)

Width 652 mm (25.7 in)

Height 746 mm (29.4 in)
Spark plugs:

Make/Type - 4.0 litre Champion RC11 PYP B4

Make/type - 4.6 litre Champion RN11 YCC

Gap - 4.0 and 4.6 litre 1.00 ± 0.05 mm (0.040 ± 0.002 in) Non-adjustable
Coils:

Make Bosch 0221 503 407

Type Twin coils
Fuel injection system:

Make Bosch Motronic 5.2.1 Type 4146

Type Multiport fuel injection, electronically controlled with electro-
mechanical injectors
