SPECIFICATIONS
8-2
8
Cooling system capacity
(total amount)
2.55 L
Air filterDry type element
Fuel
Type Regular unleaded gasoline
Fuel tank capacity 18 L
Fuel reserve amount 3.8 L
Carburetor
Manufacturer MIKUNI
Model ´ quantity BDSR40 ´ 4
Spark plug
Manufacturer/model NGK / CR9E or
DENSO / U27ESR-N
Gap 0.7–0.8 mm
Clutch typeWet, multiple-disc
Transmission
Primary reduction system Spur gear
Primary reduction ratio 1.581
Secondary reduction system Chain drive
Secondary reduction ratio 2.688
Number of drive chain
sprocket teeth (rear/front) 16/43
Transmission type Constant-mesh 6-speed
Operation Left footGear ratio
1st 2.500
2nd 1.842
3rd 1.500
4th 1.333
5th 1.200
6th 1.115
Chassis
Frame type Diamond
Caster angle 24°
Trail 92 mm
Tires
Front
Type Tubeless
Size 120/70 ZR17 (58 W)
Manufacturer/
model Metzeler / MEZ3Y Front
Dunlop / D207FQ
Rear
Type Tubeless
Size 190/50 ZR17 (73 W)
Manufacturer/
model Metzeler / MEZ3Y
Dunlop / D207N
E_5jj.book Page 2 Friday, September 8, 2000 3:33 PM

SPECIFICATIONS
8-3
8
Maximum load* 201 kg
Tire air pressure
(measured on cold tires)
Up to 90 kg*
Front 250 kPa (2.50 kg/cm
2, 2.50 bar)
Rear 250 kPa (2.50 kg/cm2, 2.50 bar)
90 kg–maximum*
Front 250 kPa (2.50 kg/cm2, 2.50 bar)
Rear 290 kPa (2.90 kg/cm2, 2.90 bar)
High-speed riding
Front 250 kPa (2.50 kg/cm2, 2.50 bar)
Rear 250 kPa (2.50 kg/cm2, 2.50 bar)
* Total weight of rider, passenger, cargo and accessories
Wheels
Front
Type Cast wheel
Size 17 ´ MT 3.50
Rear
Type Cast wheel
Size 17 ´ MT 6.00
Brakes
Front
Type Dual disc brake
Operation Right hand
Fluid DOT 4Rear
Type Single disc brake
Operation Right foot
Fluid DOT 4
Suspension
Front Telescopic fork
Rear Swingarm (link suspension)
Spring/shock absorber
Front Coil spring / oil damper
Rear Coil spring / gas-oil damper
Wheel travel
Front 135 mm
Rear 130 mm
Electrical system
Ignition system T.C.I. (digital)
Charging system
Type A.C. magneto
Standard output 14 V, 365 W@ 5,000 r/min
Battery
Model GT12B-4
Voltage, capacity 12 V, 10 Ah
Headlight typeQuartz bulb (halogen)
E_5jj.book Page 3 Friday, September 8, 2000 3:33 PM

SPECIFICATIONS
8-4
8
Bulb voltage, wattage ´ quantity
Headlight 12 V, 60/55 W ´ 2
Tail/brake light 12 V, 5/21 W ´ 2
Turn signal light 12 V, 21 W ´ 4
Auxiliary light 12 V, 5 W ´ 2
Meter lighting LED
Neutral indicator light LED
High beam indicator light LED
Turn signal indicator light LED
Fuel level warning light LED
Oil level warning light LED
Fuses
Main fuse 30 A
Headlight fuse 20 A
Signaling system fuse 20 A
Radiator fan fuse 10 A
Ignition fuse 15 A
Odometer fuse 10 A
E_5jj.book Page 4 Friday, September 8, 2000 3:33 PM

SPECIFICATIONS
8-5
8
EAU01064
Conversion tableCS-02E All specification data in this manual are listed in SI and
METRIC UNITS.
Use this table to convert METRIC unit data to IMPERIAL
unit data.
ExampleMETRIC MULTIPLIER IMPERIAL
** mm´ 0.03937 = ** in
2 mm´ 0.03937 = 0.08 in
Conversion tableMETRIC TO IMPERIAL
Metric unit Multiplier Imperial unit
Torquem·kg
m·kg
cm·kg
cm·kg7.233
86.794
0.0723
0.8679ft·lb
in·lb
ft·lb
in·lb
Weightkg
g2.205
0.03527lb
oz
Speed km/h 0.6214 mi/h
Distancekm
m
m
cm
mm0.6214
3.281
1.094
0.3937
0.03937mi
ft
yd
in
in
Volume,
Capacitycc (cm3)
cc (cm3)
L (liter)
L (liter)0.03527
0.06102
0.8799
0.2199oz (IMP liq.)
cu·in
qt (IMP liq.)
gal (IMP liq.)
Miscellaneouskg/mm
kg/cm2
Centigrade (°
C)55.997
14.2234
9/5 + 32 lb/in
psi (lb/in
2)
Fahrenheit (°
F)
E_5jj.book Page 5 Friday, September 8, 2000 3:33 PM

CONSUMER INFORMATION
9
Identification numbers ........................................................................ 9-1
Key identification number ................................................................... 9-1
Vehicle identification number.............................................................. 9-1
Model label ........................................................................................ 9-2
E_5jj.book Page 1 Friday, September 8, 2000 3:33 PM

9-1
9
10
EAU01039
9-CONSUMER INFORMATION
EAU02944
Identification numbersRecord the key identification number,
vehicle identification number and
model label information in the spaces
provided below for assistance when or-
dering spare parts from a Yamaha
dealer or for reference in case the vehi-
cle is stolen.
1. KEY IDENTIFICATION NUMBER:CA-02E2. VEHICLE IDENTIFICATION
NUMBER:CA-02E3. MODEL LABEL INFORMATION:CA-01EEAU01041
Key identification numberThe key identification number is
