2001 TOYOTA CAMRY Owners Manual

’01Camry_U (L/O 0009)
2412001 MY CAMRY (OM33528U)
Use a Phillips−head screwdriver. Remove
and install the cover clips as shown in
the following illustrations.Removing the cover clips
Installing the cover clips
—Rear side maker, rear turn
signal and stop/tail lights
ProCarManuals.com

’01Camry_U (L/O 0009)
2422001 MY CAMRY (OM33528U)
a: Rear side marker light
b: Rear turn signal light
c: Stop/tail light
—Stop/tail lights (type A)
ProCarManuals.com

’01Camry_U (L/O 0009)
2432001 MY CAMRY (OM33528U)
—Back−up lights (type A)
ProCarManuals.com

’01Camry_U (L/O 0009)
2442001 MY CAMRY (OM33528U)
Use a Phillips−head screwdriver. Remove
and install the cover clips as shown in
the following illustrations.Removing the cover clips
Installing the cover clipsa: Stop/tail light
b: Back−up light
—Stop/tail, and back−up
lig h t s (t yp e B)
ProCarManuals.com

’01Camry_U (L/O 0009)
2452001 MY CAMRY (OM33528U)
—License plate lights
Remove and install the cover clips as
shown in the following illustrations.
Type B—Use a Phillips−head screwdriver.Removing the cover clips (Type A)
Installing the cover clips (Type A)
Removing the cover clips (Type B)
Installing the cover clips (Type B)
ProCarManuals.com

’01Camry_U (L/O 0009)
2462001 MY CAMRY (OM33528U)
—High mounted stoplight
ProCarManuals.com

’01Camry_U (L/O 0009)
2472001 MY CAMRY (OM33528U)
SPECIFICATIONS
Dimensions and weight248 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine249 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel249 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service specifications249 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires252 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses253 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 8
ProCarManuals.com

’01Camry_U (L/O 0009)
2482001 MY CAMRY (OM33528U)
Dimensions and weight
P205/65R15 tireP205/60R16 tire
Overall length mm (in.)4790 (188.6)4790 (188.6)
Overall width mm (in.)1780 (70.1)
1785 (70.3)∗
11785 (70.3)
Overall height mm (in.)1419 (55.9)∗
21419 (55.9)∗
2
Wheelbase mm (in.)2670 (105.1)2670 (105.1)
Front tread mm (in.)1547 (61.0)1547 (61.0)
Rear tread mm (in.)1520 (59.8)1520 (59.8)
Vehicle capacity weight
(occupants + luggage) kg (lb)410 (900)410 (900)
∗
1: “XLE” grade models∗
2: Unladen vehicle
