2001 TOYOTA AVALON headrest

H12205H12206H12660
Bench type:
Separate type:
H12207
- BODYFRONT SEAT (Power Adjuster Type)
BO-107
1892 Author
: Date
:
2001 AVALON (RM808U)
6. REMOVE FRONT SEAT INNER BELT
(a) Disconnect the connector.
(b) Remove the connector, then remove the nut, washer and
front seat inner belt.
Torque: 41 N´m (420 kgf´cm, 30 ft´lbf)
7. REMOVE SEAT CUSHION INNER SHIELD
8. REMOVE SEATBACK COVER
(a) Remove the headrest supports.
(b) Remove the hog rings.
(c) Disengage the hook as shown in the illustration.
(d) Remove the seatback cover with pad.
(e) Remove the seatback cover from the seatback pad.
9. REMOVE FRONT POWER ADJUSTER SHIELD
10. Bench type:
REMOVE FRONT SEAT CENTER BELT
Torque: 41 N´m (420 kgf´cm, 30 ft´lbf)
11. REMOVE SEAT CUSHION COVER
(a) Remove the seat wire clamp from the seat cushion as-
sembly.
(b) Separate type:
Remove the 4 bolts and seat cushion assembly.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)
(c) Bench type:
Remove the 5 bolts and seat cushion assembly.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)
(d) Remove the seat cushion cover with pad from the seat
cushion frame.
(e) Remove the seat cushion cover from the seat cushion
pad.
12. REMOVE POWER SEAT SWITCH
13. REMOVE SEAT WIRE

BO2QD-01
H12219
Center Armrest
Seat Cushion Pad
with Frame Seat Cushion Cover
Center Armrest Bracket
Center Armrest Hinge

Hog Ring
Shoulder Belt Guide
Headrest
Headrest Support
Headrest Support
Seatback Pad with Frame

Hog Ring
N´m (kgf´cm, ft´lbf): Specified torque

Non-reusable partSeatback Cover
5.9 (60, 52 in.´lbf)
18 (185, 13)
41 (420, 30)
18 (185, 13)
- BODYREAR SEAT
BO-1 19
1904 Author
: Date
:
2001 AVALON (RM808U)
REAR SEAT
COMPONENTS

BO2QF-01
H03147
- BODYREAR SEAT
BO-121
1906 Author
: Date
:
2001 AVALON (RM808U)
DISASSEMBLY
1. REMOVE HEADRESTS
2. REMOVE CENTER ARMREST
Remove the 2 nuts and center armrest.
Torque: 5.9 N´m (60 kgf´cm, 52 in.´lbf)
3. REMOVE SHOULDER BELT GUIDES
Remove the 4 screws and 2 shoulder belt guides.
4. REMOVE HEADREST SUPPORTS
5. REMOVE SEATBACK COVER
Remove the hog rings and seatback cover from the seatback
pad with frame.
6. REMOVE SEAT CUSHION COVER
Remove the hog rings and seat cushion cover from the seat
cushion pad.

RS0LF-01
H11926
N´m (kgf´cm, ft´lbf): Specified torque
43 (440, 32)
Seatback Frame Headrest
Headrest Support
Seatback Cover (w/ Pad)
Hog Ring

37 (375, 27)
43 (440, 32)
Front Seat Cushion Shield

Non-reusable partInner Front Seat Cushion Shield
Reclining adjuster
Release Handle
37 (375, 27)
Side Airbag
Assembly
- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
RS-55
1575 Author
: Date
:
2001 AVALON (RM808U)
SIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
COMPONENTS

RS0LK-01
H11929
H11928
H11930
RS-60
- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
1580 Author
: Date
:
2001 AVALON (RM808U)
INSTALLATION
NOTICE:
Never use airbag parts from another vehicle. When replac-
ing parts, replace them with new parts.
1. INSTALL SEATBACK ASSEMBLY
(a) Install the 4 bolts.
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
NOTICE:

Make sure that the seatback assembly is installed
with the specified torque.

If the seatback assembly has been dropped, or there
are cracks, dents or other defects in the case or con-
nector, replace the seatback assembly with a new
one.

When installing the seatback assembly, take care it is
not pinched between other parts.
(b) Install 3 new hog rings as shown in the illustration.
HINT:
When installing the hog rings, take care to prevent wrinkles as
little as possible.
(c) Install the wire harness of the side airbag assembly to the
seat cushion assembly.
2. INSTALL INNER FRONT SEAT CUSHION SHIELD
Install the inner front seat cushion shield with the 2 screws.
3. INSTALL FRONT SEAT CUSHION SHIELD
Install the front seat cushion shield with the 2 screws.
4. INSTALL RECLINING ADJUSTER KNOBS
5. INSTALL HEADREST

RS0LG-01
H11931
H11927
H11928
H11929
RS-56
- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
1576 Author
: Date
:
2001 AVALON (RM808U)
REMOVAL
NOTICE:

If the wiring connector of the SRS is disconnected
and the ignition switch is at ON or ACC position, DTCs
will be recorded.

Never use the airbag parts from another vehicle.
When replacing parts, replace them with new parts.
1. REMOVE FRONT SEAT
(a) Remove the 4 seat track covers and 4 bolts.
(b) Disconnect the side airbag connector.
NOTICE:
When handling the airbag connector, take care not to dam-
age the airbag wire harness.
(c) Remove the front seat.
2. REMOVE HEADREST
3. REMOVE RECLINING ADJUSTER KNOB
4. REMOVE FRONT SEAT CUSHION SHIELD
Remove the 2 screws and front seat cushion shield.
5. REMOVE INNER FRONT SEAT CUSHION SHIELD
Remove the 2 scerws and front seat cushion inner shield.
6. REMOVE SEATBACK ASSEMBLY
(a) Remove the hog rings.
(b) Remove the wire harness of the side airbag assembly.
NOTICE:
When handling the airbag wire harness, take care not to
damage the airbag wire harness.
(c) Remove the 4 bolts and seatback assembly.

RS0L9-01
H11925
N´m (kgf´cm, ft´lbf): Specified torque
43 (440, 32)
19 (194, 14)
Driver's seat with bench type:
Driver's seat with bench type: No. 1 Seat Armrest CoverSeatback Frame
AssemblyHeadrest
Headrest Support
Seatback Board
Side Airbag Assembly
Seatback Cover (w/ Pad) Hog Ring Reclining Adjuster
Inside Cover


Front Seat Cushion
Inner Shield
Seat Cushion Assembly
Seat Cushion Assembly
19 (194, 14)
43 (440, 32)
42 (430, 31)
Seat Armrest Assembly
Front Seat Cushion Shield
Power Seat Switch Knob
Front Seat Inner Belt

Non-reusable part
37 (375, 27)
41 (420, 30)
- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
RS-41
1561 Author
: Date
:
2001 AVALON (RM808U)
SIDE AIRBAG ASSEMBLY (Power Adjuster Type)
COMPONENTS

H11918
H11917
H11924
H11920
H11919
- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
RS-53
1573 Author
: Date
:
2001 AVALON (RM808U)
3. INSTALL SEAT CUSHION ASSEMBLY
(a) Driver's seat with bench type:
Install the seat cushion assembly with the 5 bolts.
(b) Except driver's seat with bench type:
Install the seat cushion assembly with 4 bolts.
(c) Install the wire harness to the seat cushion assembly.
4. INSTALL FRONT SEAT CUSHION INNER SHIELD
Install the front seat inner shield with the 2 screws.
5. INSTALL FRONT SEAT INNER BELT
6. INSTALL FRONT SEAT CUSHION SHIELD
Install the front seat cushion shield with the 5 screws.
7. INSTALL POWER SEAT SWITCH KNOBS
8. Driver 's seat with bench type:
INSTALL SEAT ARMREST ASSEMBLY
Install the seat armrest assembly with bolt and cover.
9. INSTALL HEADREST
