2001 SUBARU FORESTER Owners Manual

Starting and operating7-15
–
CONTINUED –

Selector lever
OM-H0149
Release button With the brake pedal depressed, shift while pressing the button in Shift while pressing the button in Shift without pressing the button
HS0129
The selec tor lever has seven p ositions.
The release b utton must b e p ushed to selec t the “P ”, “R ”, or “2 ” p osi-
tions.
P (Park)
This p osition is for p arking the vehic le and starti ng the eng ine.
In this p osition, the transmission is mec hanic ally loc ked to p revent the
vehic le from rolling freely.
When you p ark the vehic le, first set the p arking b r ake fully, then shift
into the “P ” p osition. Do not hold the vehic le with only the tr ansmis-
sion.
A shift interloc k func tion is emp loyed in the autom atic transmission
system to ensure safe starting of the vehic le.
To shift the selec tor lever from the “P ” to the any other p osition, you
have to d ep ress the b rake p ed al fully then p ush the release b utton on
the selec tor lever when the ig nition switc h is in t he “ON ” p osition. This
p revents the vehic le from lurc hing when it is start ed .
If the shift lever d oes not move from the “P ” p osition with the b rake
p ed al d ep ressed and the release b utton p ushed in, r efer to the “Shift
loc k release ” sec tion in c hap ter 3.

7-16
R (Reverse)
This p osition is for b ac king the vehic le.
To shift from the “N ” to “R ” p osition, first stop the vehic le c omp letely
then move the lever to the “R ” p osition while p ushing the release b ut-
ton. N (Neutral)
WARNING
Do not drive the vehicle with the selector lever in the “N” (neutral)
position. Engine braking has no effect in this condition and the risk of an accident is consequently increased.
This p osition is for restarting a stalled eng ine.
In this p osition the wheels and transmission are no t loc ked . In this
p osition, the transmission is neutral; the vehic le will roll freely, even on
the slig htest inc line unless the p arking b rake or f oot b rake is on.
Avoid c oasting with the transmission neutral.
During c oasting , the eng ine b raking d oes not ac t. D (Drive)
This p osition is for normal d riving .
The transmission automatic ally shifts into a suitab le g ear from 1st to
4th ac c ord ing to the vehic le sp eed and the ac c elera tion you req uire.
When more ac c eleration is req uired in this p osition , p ress the ac c eler-
ator p ed al fully to the floor and hold that p ositio n. The transmission
will automatic ally d ownshift to 3rd , 2nd or 1st g ea r. When you release
the p ed al, the transmission will return to the orig inal g ear p osition.
n While climbing a grade
When d riving up a hill, und esired up shift to 4th g e ar is p revented from
taking p lac e when the ac c elerator is released . This minimizes the
c hanc e of sub seq uent d ownshifting to a lower g ear w hen ac c elerat-
ing ag ain. This p revents rep eated up shifting and d o wnshifting result-
ing in a smoother op eration of the vehic le.

Starting and operating7-17
–
CONTINUED –
NOTE
The transmission may downshift to 2nd or 1st gear, depending on the way the accelerator pedal is pressed to accelerate the vehicleagain. n
While going down a hill
When d esc end ing a steep hill, d ep ressing the b rake p ed al will c ause
the transmission to d ownshift to 3rd g ear, thus ap p lying eng ine b rake-
ing . Reac c eleration for a short time will c ause the transmission to up -
shift normally. NOTE In some cases, depressing the brake pedal on a downhill grade
does not result in an automatic downshift to 3rd gear. This canhappen when the automatic transmission fluid temperature is
very low, for example, during driving shortly after the vehicle has
been parked for an extended period of time. When the ATF tem-perature has risen to a certain level, automatic downshift normal-ly takes place. In the meantime, downshift manually for enginebraking as required.Also, downshifting when braking downhill will not occur at
speeds above approximately 50 mph (80 km/h). 3 (Third)
This p osition is for using eng ine b raking when g oin g d own a hill or for
c limb ing a g rad e.
The transmission automatic ally shifts into a suitab le g ear from 1st to
3rd ac c ord ing to the vehic le sp eed and the ac c elera tion you req uire.
When more ac c eleration is req uired in this p osition , p ress the ac c eler-
ator p ed al fully to the floor and hold that p ositio n. The transmission
will automatic ally d ownshift to 2nd or 1st g ear. Wh en you release the
p ed al, the transmission will return to the orig inal g ear p osition.

7-18
2 (Second)
To shift from the “3 ” to “2 ” p osition, p ush the release b utton.
This p osition is for using eng ine b raking when g oin g d own a hill or for
c limb ing a steep g rad e.
In this p osition, the transmission hold s in the 2nd g ear.
Use this p osition when starting off from a stand sti ll on slip p ery road
surfac es suc h as mud or snow. It will ensure g reate r trac tion.
1 (First)
This p osition is for d riving up or d own very steep g rad es, or d riving
throug h mud or sand , or on slip p ery surfac es. In th is p osition, the
transmission hold s in the 1st g ear. Maximum speeds
WARNING
When shifting down a gear, ensure that the vehicle is not travel- ling at a speed exceeding the Maximum Allowable Speed for thegear which is about to be selected. Failure to observe this pre-caution can lead to engine over-revving and this in turn canresult in engine damage.In addition, sudden application of engine brakes when the vehicleis travelling on a slippery surface can lead to wheel locking; as a
consequence, control of the vehicle may be lost and the risk ofan accident increased.
The following tab les show the maximum sp eed s that a re p ossib le with
eac h d ifferent g ear. The tac hometer ’s (if so eq uip p ed ) need le will
enter the red area if these sp eed s are exc eed ed .
When shifting d own a g ear, it is imp ortant to c onfi rm that the c urrent
vehic le sp eed is not in exc ess of the Maximum Allow ab le Sp eed of
the g ear whic h is ab out to b e selec ted .
Exc eed ing the Maximum Allowab le Sp eed s will result in over-revving
of the eng ine. In ad d ition a p owerful eng ine b rake will eng ag e and
c ontrol of the vehic le may b e lost.

Starting and operating7-19
–
CONTINUED –
mph (km/h)
Vehicle type
PositionLS
134 (54)34 (54)
263 (101)62 (100)
3102 (164)101 (162)
NOTE In order to prevent over-revving during acceleration of the
vehicle, the transmission will automatically shift to the next high- est gear if the Maximum Allowable Speed for the current gear isexceeded. Similarly, in order to prevent over-revving during deceleration
of the vehicle, the transmission will remain in the current gear ifthe speed of the vehicle is in excess of the Maximum AllowableSpeed for the gear to which the selector lever has been moved. Driving tips
Always ap p ly the foot or p arking b rake when the veh ic le is
stop p ed in the “D ”, “3 ”, “2 ”, “1 ”, or “R ” p osition.
Always set the p arking b rake when p arking your vehi c le. Do not
hold the vehic le with only the transmission. Do not keep the vehic le in a stationary p osition on an up hill g rad e
b y using the “D ”, “3 ”, “2 ” or “1 ” p osition. Use the b rake instead .
Shift lock release
If the selec tor lever d oes not move from the “P ” p osition with the b rake
p ed al d ep ressed and the release b utton p ushed in an d the ig nition
switc h in the “ON ” p osition, p erform the following step s:
To overrid e the shift loc k:
1. Set the p arking b rake and stop the eng ine.

7-20
HS0131HS0130
2. Take out the sc rewd river from the tool b ag .
3. Op en the c enter c onsole and remove two sc rews securing the p ark-
ing b rake lever c over.
4. Remove the p arking b rake lever c over b y p ulling u p on the c over’s
rear end .
5. Raise the rear end of the selec tor lever c over.
HS0132
Shaft portion of the screwdriver
6. Draw the shaft p ortion of the sc rewd river from th e g rip and then insert
the shaft into the hole.
7. Push d own on the shaft while p ushing the release b utton and move
the selec tor lever from the “P ” to the “N ” p osition.
8. Remove the shaft from the hole. Dep ress the b rake p ed al and start
the eng ine.
Take your vehic le to the nearest SUBARU d ealer imme d iately to have the
system rep aired .

Starting and operating7-21
–
CONTINUED –
Rear viscous limited slip differential (for S models)
CAUTION
Never start the engine while a tire on one side is jacked up, as
the vehicle may move. If one rear tire is spinning in mud, avoid continued spinning at
high speed as this could adversely affect the LSD. If a different size rear tire is temporarily used (as in an emer-
gency), it will adversely affect the LSD. Always replace it with aregular size tire as soon as possible.
The LSD p rovid es op timum d istrib ution of p ower ac c o rd ing to the d iffer-
enc e in revolutions b etween the rig ht and left rear wheels that may b e
c aused b y c ertain d riving c ond itions, thereb y imp ro ving d riving stab ility
on snow-c overed , mud d y or other slip p ery road s. Power steering
CAUTION
Do not hold the steering wheel at the fully locked position left or right for more than five seconds. This may damage the powersteering pump.
The p ower steering system op erates only when the en g ine is running .
If you lose p ower steering assist b ec ause the eng in e stop s or the system
fails to func tion, you c an steer b ut it will take m uc h more effort.

7-22Braking
Braking tips
WARNING
Never rest your foot on the brake pedal while driving. This can
cause dangerous overheating of the brakes and needless wearon the brake pads and linings.
When the brakes get wet
When d riving in rain, in p ud d le or after washing th e vehic le, the
b rakes may g et wet. As a result, b rake stop p ing d is tanc e will b e long -
er. To d ry the b rakes, d rive the vehic le at a safe sp eed while lig htly
d ep ressing the b rake p ed al to heat up the b rakes. Use of engine braking
Rememb er to make use of eng ine b raking in ad d ition to foot b raking .
When d esc end ing a g rad e, if only the foot b rake is used , the b rakes
may start working imp rop erly b ec ause of b rake fluid overheating ,
c aused b y overheated b rake p ad s. To help p revent th is, shift into a
lower g ear. Braking when a tire is punctured
Do not d ep ress the b rake p ed al sud d enly when a tire is p unc tured .
This c ould c ause a loss of c ontrol of the vehic le. Keep d riving straig ht
ahead while g rad ually red uc ing sp eed . Then slowly p ull off the road
to a safe p lac e.
Brake system Two separate circuits
Your vehic le has two sep arate c irc uit b rake systems . Eac h c irc uit
works d iag onally ac ross the vehic le. If one c irc uit of the b rake system
should fail, the other half of the system still wor ks. If one c irc uit fails,
the b rake p ed al will g oes d own muc h c loser to the f loor than usual
and you will need to p ress it d own muc h hard er. And a muc h long er
d istanc e will b e need ed to stop the vehic le.
