2001 SUBARU FORESTER Owners Manual

Instruments and controls3-9
–
CONTINUED –

Temperature gauge
CAUTION
If the pointer exceeds the normal operating range, safely stop the
vehicle as soon as possible.
See “ In case of emergency ” in this manual.
HS0052
Normal operating range
The temperature gauge shows engine coolant temperature when the
ignition switch is in the
“ON” position.
The coolant temperature will vary in accordance with the outside temper-
ature and driving conditions.
We recommend that you drive moderately until the pointer of the tempera-
ture gauge reaches near the middle of the range. Engine operation is opti-
mum with the engine coolant at this temperature range and high revving
operation when the engine is not warmed up enough should be avoided.
Warning and indicator lights
Several of the warning and indicator lights come on momentarily and
then go out when the ignition switch is initially turned to the “ON” posi-
tion. This permits checking the operation of the bulbs.
Apply the parking brake and turn the ignition switch to the “ON” position.
The following lights come on:

3-10Seatbelt warning light
SRS airbag system warning light
CHECK ENGINE warning light/Malfunction indicator lamp
Charge warning light
Oil pressure warning light
AT OIL TEMP warning light (automatic transmission vehicles)
ABS warning light (if equipped)
Brake system warning light
If any lights fail to come on, it indicates a burned-out bulb or a malfunc-
tion of the corresponding system.
Consult your authorized SUBARU dealer for repair. Seatbelt warning light and chime
When the ignition switch is turned to the “ON” position, the seatbelt
warning light will come on and the reminder chime will sound to remind driver to fasten the seatbelt.
The seatbelt warning light remains on for about six seconds and turns off
automatically after six seconds.
The seatbelt reminder chime will turn off when the driver ’s side seatbelt is
buckled or it will turn off automatically after about six seconds. SRS airbag system warning light AIRBAG
When the ignition switch is turned to the “ON” position, the SRS airbag
system warning light will come on for about six seconds and go out. This
shows the SRS airbag system is in normal operation.
If this light comes on while driving or remains illuminated even after a
lapse of about 6 seconds from when the ignition key has been turned on,
it may indicate that the SRS airbag system is not working properly. Con-
tact your nearest SUBARU dealer immediately.

Instruments and controls3-11
–
CONTINUED –

CHECK ENGINE warning light/ Malfunction indicator lamp
CAUTION
If the CHECK ENGINE light comes on while you are driving, have
your vehicle checked/repaired by your SUBARU dealer as soonas possible. Continued vehicle operation without having the
emission control system checked and repaired as necessarycould cause serious damage, which may not be covered by your
vehicle’ s warranty.
If this light comes on steadily or blinks while the engine is running, it may
indicate that there is a problem or potential problem somewhere in the
emission control system. If the light comes on steadily:
If the light comes on steadily while driving or does not go out after the
engine starts, an emission control system malfunction has been de-tected.
You should have your vehicle checked by an authorized SUBARU
dealer immediately. NOTE This light also comes on when the fuel filler cap is not tightened until it clicks.
If you have recently refueled your vehicle, the cause of the CHECK
ENGINE warning light/malfunction indicator lamp coming on could be
a loose or missing fuel filler cap. Remove the cap and retighten it until
it clicks. Make sure nothing is interfering with the sealing of the cap.
Tightening the cap will not make the CHECK ENGINE warning light
turn off immediately. It may take several driving trips. If the light doesnot go out, take your vehicle to your authorized SUBARU dealer
immediately. If the light is blinking:
If the light is blinking while driving, an engine misfire condition has

3-12been detected which may damage the emission control system.
To prevent serious damage to the emission control system, youshould do the following:
Reduce vehicle speed.
Avoid hard acceleration.
Avoid steep uphill grades.
Reduce the amount of cargo, if possible.
Stop towing a trailer as soon as possible.
The CHECK ENGINE warning light may stop blinking and come on
steadily after several driving trips. You should have your vehicle
checked by an authorized SUBARU dealer immediately.
Charge warning light
If this light comes on when the engine is running, it may indicate that the
charging system is not working properly. If the light comes on while driving or does not go out after the engine
starts, stop the engine at the first safe opportunity and check the alterna-
tor belt. If the belt is loose, broken or if the belt is in good condition but
the light remains on, contact your nearest SUBARU dealer immediately. Oil pressure warning light
CAUTION
Do not operate the engine with the oil pressure warning light on. This may cause serious engine damage.
If this light comes on when the engine is running, it may indicate that the
engine oil pressure is low and the lubricating system is not working prop-
erly.If the light comes on while driving or does not go out after the engine
starts, stop the engine at the first safe opportunity and check the engine
oil level. If the oil level is low, add oil immediately. If the engine oil is at
the proper level but the light remains on, contact your nearest SUBARU
dealer immediately.

Instruments and controls3-13
–
CONTINUED –

AT OIL TEMPerature warning light
(for AT vehicles)
If this light comes on when the engine is running, it may indicate that the
automatic transmission fluid temperature is too hot.
If the light comes on while driving, it is unnecessary to stop the vehicle,
but avoid driving up steep grades or in stop and go traffic.
Automatic transmission control system warning
If the light flashes after the engine starts, it may indicate that the auto-
matic transmission control system is not working properly. Contact
your nearest SUBARU dealer for service immediately.
ABS warning light (for vehicles with ABS)
The ABS warning light comes on when the ignition switch is turned to the
“ON” position and goes out after about two seconds.
This is an indication that the ABS system is working properly.
CAUTION
If the warning light behaves as follows, the ABS system may not
work properly. When the warning light is on, the ABS function
shuts down; however, the conventional brake system continues
to operate normally.
The warning light does not come on when the ignition switch
is turned to the “ON” position.
The warning light comes on when the ignition switch is
turned to the “ON” position, but it does not go out even when
the vehicle speed exceeds approximately 8 mph (12 km/h). The warning light comes on during driving.
If this occurs, have the ABS system repaired at the first available
opportunity by your SUBARU dealer.
(U.S.)
(Canada)
ABS

3-14NOTE
If the warning light behavior is as shown below, the ABS system may be considered normal.
The warning light comes on right after the engine is started but
goes out immediately, remaining off. The warning light remains on after the engine has been started,
but it goes out when the vehicle speed reaches about 8 mph (12km/h). The warning light comes on during driving, but it goes out
immediately and remains off.When driving with an insufficient battery voltage such as when theengine is jump started, the ABS warning light may come on. This isdue to the low battery voltage and does not indicate a malfunction.When the battery becomes fully charged, the light will go out. Brake system warning light BRAKE (U.S.)
WARNING
Driving with the brake system warning light on is dangerous.
This indicates your brake system may not be working properly. If the light remains on, have the brakes inspected by a SUBARU
dealer immediately. If at all in doubt about whether the brakes are operating prop-
erly, do not drive the vehicle. Have your vehicle towed to the
nearest SUBARU dealer for repair.
This light has the following two functions: Parking brake warning
The light comes on with the parking brake applied while the ignition switch is in the “ON” position. It goes out when the parking brake is
fully released. Brake fluid level warning
This light comes on when the brake fluid level has dropped to near the “MIN” level of the brake fluid reservoir with the ignition switch in
(Canada)

Instruments and controls3-15
–
CONTINUED –
the
“ON” position and with the parking brake fully released.
If the brake system warning light should come on while driving (with
the parking brake fully released and with the ignition switch posi-
tioned in “ON”), it could be an indication of leaking of brake fluid or
worn brake pads. Have your vehicle checked by a SUBARU dealer
immediately.
Door open warning lights
The door open warning light comes on if any door or the rear gate is not fully closed.
Always make sure this light is out before you start to drive. Front-wheel drive warning light (for AT vehicles)
This light comes on when All Wheel Drive is disengaged and the drive
mechanism is switched to Front Wheel Drive for maintenance or similarpurposes. Security system status indicator light (if equipped)
This light is found at the bottom center of the combination meter panel. On vehicles equipped with a security system, it blinks to show the driver
the operational status of the security system. For detailed information, re-fer to the “Security system ” in Chapter 2.
Turn signal indicator lights
These lights show the operation of the turn signal or lane change signal.
If the indicator lights do not blink or blink rapidly, the turn signal bulb
may be burned out. Replace the bulb as soon as possible. Refer to “Re-
placing bulbs ” section in Chapter 10.
High beam indicator
This light shows that the headlights are in the high beam mode.
This indicator light also comes on when operating headlight flasher.

3-16Light control switch
WARNING
To prevent battery discharge resulting from accidentally leaving your lights on when your vehicle is parked, the light switch oper-ates only when the ignition switch is in the “ON” position. In any
other position, the vehicle ’s lights will be out. If you park your ve-
hicle on a roadside at night, use the hazard warning flasher toalert the other drivers.
HS0054 HS0055
Dimmer
Headlight flasher
The light switch operates only when the ignition switch is in the “ON”
position.
Headlights
To turn on the headlights, turn the knob on the end of the turn signal
lever.
first position
Parking lights, instrument panel illumination, tail lights and license
plate light are on.
second position
Headlights, parking lights, instrument panel illumination, tail lights,
and license plate light are on.
