2001 FORD MUSTANG Owners Manual

M
Manual
transmission ............ 119
fluid capacities ...... 206
lubricant
specifications ........ 209
reverse ................... 121
Mirrors
cleaning ................. 201
side view mirrors
(power) ................... 58
Motorcraft
parts ................. 185, 206
O
Octane rating .......... 184
Odometer ................... 16
Oil (see Engine
oil) ............................ 151
Overdrive ........... 58, 115
P
Panic alarm feature,
remote entry
system ........................ 65
Parking brake .......... 110
Parts (see Motorcraft
parts) ....................... 206
Power distribution box
(see Fuses) ............. 135
Power door locks ...... 57
Power steering ........ 113
fluid, checking and
adding .................... 166fluid, refill
capacity ................. 206
fluid,
specifications 208±209
R
Radio .......................... 24
Relays ...................... 131
Remote entry
system .................. 64±65
illuminated entry .... 66
locking/unlocking
doors .................. 64±65
opening the trunk ... 65
panic alarm ............. 65
replacement/additional
transmitters ............. 66
replacing the
batteries .................. 67
S
Safety belts (see Safety
restraints) ........... 13, 76,
78±81
Safety defects,
reporting .................. 227
Safety restraints ........ 76
, 78±81
belt minder ............. 83
cleaning the safety
belts ................. 87, 204
extension
assembly .................. 82
for adults ........... 78±81
for children ....... 93±94
warning light and
chime ....... 9, 13, 82±83
Index
233

Safety seats for
children ...................... 95
Seat belts (see Safety
restraints) .................. 76
Seats .......................... 73
child safety seats .... 95
cleaning ......... 204±205
easy access/easyout
feature ..................... 75
SecuriLock passive
anti-theft
system .................. 67±69
Servicing your
vehicle ...................... 147
Spark plugs,
specifications ........... 206
, 209±210
Special notice .............. 3
Specification chart,
lubricants ......... 208±209
Speed control ............ 53
Speedometer ............. 15
Starting your
vehicle ...... 103±104, 106
jump starting ........ 141
Steering wheel
tilting ....................... 52
T
Tachometer ............... 16
Tires ......... 137, 175±177
changing ........ 137±138
checking the
pressure ................. 177
replacing ................ 178
rotating .................. 177snow tires and
chains .................... 179
tire grades ............. 176
treadwear .............. 175
Towing ..................... 124
recreational
towing .................... 127
trailer towing ........ 124
wrecker .................. 146
Traction
control ............... 50, 111
active light .............. 12
Traction-lok rear
axle .......................... 122
Transmission
automation
operation ............... 113
fluid, checking and
adding
(automatic) ........... 167
fluid, checking and
adding (manual) ... 170
fluid, refill
capacities ............... 206
lubricant
specifications. 208±209
manual operation .. 119
Trip odometer ........... 17
Trunk ......................... 71
remote release .. 50, 65
Turn signal ............ 8, 51
V
Vehicle
dimensions ............... 210
Vehicle Identification
Number (VIN) ......... 211
Index
234

Vehicle loading ........ 122
Ventilating your
vehicle ...................... 107
W
Warning chimes ......... 13
Warning lights (see
Lights) ......................... 8
Washer fluid ............ 157
Water, Driving
through .................... 128Windows
power ....................... 56
Windshield washer fluid
and wipers
checking and adding
fluid ........................ 157
checking and
cleaning ................. 174
operation ................. 51
replacing wiper
blades .................... 174
Wrecker towing ....... 146
Index
235

236

237

238

Item Information
Required fuel Unleaded fuel only - 87
octane
Fuel tank capacity 59.4L (15.7 gallons)
Engine oil capacity (includes
filter change)4.7L (5.0 quarts). Use
Motorcraft SAE 5W-20 Super
Premium Motor Oil, Ford
specification WSS-M2C153-H
Tire size and pressure See label on inside of glove
box door.
Hood release Pull handle under the left
side of the instrument panel.
Coolant capacity-3.8L OHV
V6 engine
111.2L (11.8 quarts)
Coolant capacity-4.6L SOHC
V8 engine
113.3L (14.1 quarts)
Power steering fluid capacity Fill to line on reservoir or
dipstick. Use Motorcraft
MERCONtAT F.
Manual transmission fluid
capacity-3.8L OHV V6 engine
2
2.6L (5.6 pints). Use
Motorcraft MERCONtAT F.3
Manual transmission fluid
capacity-4.6L SOHC V8
engine
2
3.8L (8.0 pints). Use Mobil 1
SynthetictAT F.3
Automatic transmission fluid
capacity-3.8L OHV V6 engine
2
13.1L (13.9 quarts). Use
Motorcraft MERCONtV ATF.
4
Automatic transmission fluid
capacity-4.6L SOHC V8
engine
2
12.0L (12.8 quarts). Use
Motorcraft MERCONtV ATF.
4
Windshield washer fluid 3.8L (4.0 quarts). Use
Ultra-Clear Windshield
Washer Concentrate.
1Use either green-colored Motorcraft Premium Engine
Coolant or yellow-colored Motorcraft Premium Gold
Engine Coolant. DO NOT USE Ford Extended Life Engine
Coolant (orange in color). Refer toAdding engine
coolant, in the Maintenance and Care chapter.
2Ensure the correct automatic transmission fluid is used.
Transmission fluid requirements are indicated on the
dipstick or on the dipstick handle. MERCONtand
Filling station information
239

MERCONtV are not interchangeable. DO NOT mix
MERCONtand MERCONtV. Refer to your scheduled
maintenance guide to determine the correct service
interval.
3Service refill capacity is determined by filling the
transmission to the bottom of the filler hole with the
vehicle on a level surface.
4Indicates only approximate dry-fill capacity. Some
applications may vary based on cooler size and if equipped
with in-tank cooler. The amount of transmission fluid and
fluid level should be set by the indication on the dipstick's
normal operating range.
Filling station information
240
