2001 FORD MUSTANG Owners Manual

Auto eject
Press and momentarily
hold the EJ control to
engage auto eject. All
CDs which are present in the player will be ejected
one at a time. If a CD is ejected and not removed
from the door of the CD player, the player will
automatically reload the CD. This feature may be
used when the ignition is ON or OFF.
Rewind
The rewind control
works in CD modes.
Press and hold the
REW control until the desired selection is reached. If
the beginning of the disc is reached, the CD will
begin play at the first track. Release the control to
disengage rewind mode.
When in rewind mode, your audio system will
automatically lower the volume level of the playing
media.
Fast forward
The fast forward
control works in CD
modes.
Press and hold the FF control until the desired
selection is reached. If the end of the disc is reached,
the CD will return to the first track on the first disc.
Release the control to disengage fast forward mode.
When in fast forward mode, your audio system will
automatically lower the volume level of the playing
media.
Shuffle feature
Press the SHUF control
until the desired
shuffle mode is
displayed. The audio system will then engage the
desired shuffle mode.
Controls and features
41

When engaged, the shuffle feature has two different
modes: SHUFFLE DISC and SHUFFLE TRK.
SHUFFLE DISC randomly plays tracks from all the
discs presently in the audio system.
SHUFFLE TRK plays all the tracks on the current
disc in random order.
Compression feature
The compression
feature operates in CD
mode and brings soft
and loud CD passages
together for a more
consistent listening level.
Press the MENU control until compression status is
displayed. Press the SEL control to enable the
compression feature when COMP OFF is displayed.
Press the SEL control again to disable the feature
when COMP ON is displayed.
Bass adjust
The bass adjust control
allows you to increase
or decrease the audio
system's bass output.
Press the BASS control. Use the SEL control to
increase or decrease the amount of bass.
Treble adjust
The treble adjust
control allows you to
increase or decrease
the audio system's
treble output.
Press the TREB control. Use the SEL control to
increase or decrease the amount of treble.
SEL+MENU
SELBASS
TREB
+
SELBASS
TREB
+
Controls and features
42

Speaker balance adjust
Speaker sound
distribution can be
adjusted between the
right and left speakers.
Press the BAL control. Use the SEL control to adjust
the sound between the speakers.
Speaker fade adjust
Speaker sound can be
adjusted between the
front and rear speakers.
Press the FADE
control. Use the SEL control to adjust the sound
between the front and rear speakers.
Menu mode
The MENU control
allows you to access
many different features
within your audio system. There are three sets of
menus available depending upon which mode or
feature is activated.
While in FM mode, two menus are available. If RDS
is turned off, you can access the following:
²SELECT HOURS Ð Refer toSetting the clock.
²SELECT MINUTES Ð Refer toSetting the clock.
²RDS OFF Ð Refer toRadio data system.
If RDS is turned on, you can access the following:
²
TRAFFIC ON/OFF-Refer toTraffic
announcements.
²FIND type-Refer toRadio data system.
²SHOW (NAME, TYPE, NONE)-Refer toRadio
data system.
²RDS ONÐ Refer toRadio data system.
²SELECT HOURS Ð Refer toSetting the clock.
²SELECT MINUTES ÐRefer toSetting the clock.
BAL
FADESEL+
BAL
FADESEL+
MENU
Controls and features
43

When in CD mode, you can access: SELECT HOURS,
SELECT MINUTES or COMP ON/OFF.
SELECT HOURS, SELECT MINUTESÐ Allows you
to adjust the hours and minutes. Refer toSetting
the clock.
TRAFFIC ON/OFFÐ Traffic announcements can be
programmed as local or distant. Refer toTraffic
announcements.
RDS ON/OFFÐ This feature allows your audio
system to receive text information from
RDS-equipped FM radio stations. Refer to .RDS
feature.
FIND type Ð Allows you to select your desired FM
program type and search for that selection.
SHOW Ð Allows you to select from NAME (displays
the name of the radio station), TYPE (displays the
RDS program type: rock, jazz, etc.), or NONE
(deactivates the RDS display).
Radio data system (RDS) feature
This feature allows your
audio system to receive
text information from
RDS-equipped FM radio stations.
To activate RDS:
²When in FM mode, press the MENU control until
RDS OFF displays.
²Press the SEL control to engage this feature (RDS
ON).
RDS features:
Once the RDS feature is on, press the MENU control
to scroll through the following selections:
Traffic announcements
This feature allows you to hear traffic
announcements while in CD mode. These
announcements are broadcast by traffic capable RDS
stations.
SEL+MENU
Controls and features
44

When in this mode, traffic announcements will
interrupt radio and CD play.
²Press the MENU control until TRAFFIC is
displayed.
²Press the SEL control to engage the feature. The
display will read TRAFFIC ON.
This feature also allows you to control the volume of
traffic announcements. With the display reading
TRAFFIC ON, adjust the volume using the volume
control to the desired level. The volume level will
show at the bottom of the display. Interrupting traffic
announcements will be at the selected volume level.
To disengage the feature, press the MENU control
until TRAFFIC ON displays. Press the SEL control.
The display will read TRAFFIC OFF.
Traffic announcements not available in most
U.S. markets.
Program type
This feature allows you to search for RDS stations
selectively by their program type.
Press the MENU control
until FIND program
type is displayed.
Use the SEL control to
select the program type. With the feature on, use
the SEEK or SCAN control to find the desired
program type from the following selections:
²Classic
²Country
²Info
²Jazz
²Oldies
²R&B
²Religious
²Rock
²Soft
²To p 4 0
SEL+MENU
Controls and features
45

Show
This feature allows you
to select the type of
RDS broadcast
information the radio
will regularly show in
the display.
With RDS activated,
press the MENU
control until SHOW is
displayed.
Use the SEL control to select TYPE (displays the
RDS program type: rock, jazz, etc), NAME (displays
the name of the radio station) or NONE (deactivates
the RDS display).
Digital signal processing (if equipped)
The digital signal processing (DSP) feature allows
you to change the signal mode to suit your listening
tastes.
Press the DSP control
to access the DSP
menu. Press the SEL
control to enter one of
the following modes:
²DSP OFF
²SIGNAL MODE
²OCCUPANCY MODE
Use the SEL control to
select the desired
signal mode (the
selected mode will
appear in the display).
The following signal modes can be selected:
²DSP OFFÐdisengages the feature
²NEWSкvoice-onlyº type of sound with a limited
audio band
SEL+MENU
SEL
+MENU
DSP
SEL+
SEL
Controls and features
46

²JAZZ CLUBÐjazz club with clearly reflected
sounds
²HALLÐrectangular concert hall capacity of about
2 000
²CHURCHÐchurch with a high vault
²STADIUMÐoutdoor stadium with a capacity of
about 30 000
Press the DSP control again to access the occupancy
modes. Use the SEL control to optimize the sound
based upon the occupants in the vehicle. The
following occupancy modes can be selected:
²ALL SEATS
²DRIVER SEAT
²REAR SEATS
Mute mode
Press the control to
mute the playing
media. Press the
control again to return to the playing media.
Setting the clock
Press the MENU
control until SELECT
HOUR or SELECT
MINUTE is displayed.
Use the SEL control to
manually set the time.
²Press
to
increase
hours/minutes.
²Press
to decrease hours/minutes.
SEL
Controls and features
47

Troubleshooting the CD player (if equipped)
The laser beam used in the compact disc
player is harmful to the eyes. Do not
attempt to disassemble the case.
If sound skips:
²You may be traveling on a rough road, playing
badly scratched discs or the disc may be dirty.
Skipping will not scratch the discs or damage the
player.
If your changer does not work, it may be that:
²A disc is already loaded where you want to insert
a disc.
²The disc is inserted with the label surface
downward.
²The disc is dusty or defective.
²The player's internal temperature is above 60ÉC
(140ÉF). Allow the player to cool down before
operating.
²A disc with format and dimensions not within
industry standards is inserted.
Cleaning compact discs
Inspect all discs for contamination before playing. If
necessary, clean discs only with an approved CD
cleaner and wipe from the center out to the edge.
Do not use circular motion.
CD and CD player care
²Handle discs by their edges only. Never touch the
playing surface.
²Do not expose discs to direct sunlight or heat
sources for extended periods of time.
²Do not insert more than one disc into the slot of
the CD player (if equipped).
Controls and features
48
