2001 CHEVROLET IMPALA Owners Manual

2-19
Content Theft-Deterrent (Option)
Your vehicle may have the optional content
theft
-deterrent alarm system.
With this system, a light on the radio will flash.
This light reminds you to activate the theft
-deterrent
system. Here's how to do it:
1. Open the door.
2. Lock the door with the power door lock switch or the
remote keyless entry transmitter. The light on the
radio should come on and stay on. If you are using
the remote keyless entry transmitter, the door does
not need to be open.
3. Close all doors. The light on the radio will slowly
flash once the system is armed.
Once armed, the alarm will go off if someone tries to
enter the vehicle (without using the remote keyless entry
transmitter or a key) or turns the ignition on with an
incorrect key. The horn will sound and the headlamps
and back
-up lamps will flash for approximately
two minutes.When the alarm is armed, the trunk may be opened with
the remote keyless entry transmitter. If you use the key
to open the trunk, the alarm will sound. The power door
lock switches are also disabled. You must use your
remote keyless entry transmitter or your key to unlock
the doors when the system is armed.
Arming with the Power Lock Switch
Your alarm system will arm when you use either power
lock switch to lock the doors while any door or the trunk
is open and the key is removed from the ignition.
The light on the radio flashes quickly to let you know
when the system is ready to arm with the power door
lock switches. The light on the radio will stop flashing
and stay on when you press the bottom of the power
lock switch, to let you know the system is arming. After
all doors and the trunk are closed and locked, the light
on the radio will flash slowly to let you know the system
is armed.

2-20 Arming with the Remote Keyless
Entry Transmitter
Your alarm system will arm when you use your remote
keyless entry transmitter to lock the doors, if the key is
not in the ignition. The light on the radio will turn on to
let you know the system is arming. After all doors and
the trunk are closed and locked, the light on the radio
will begin flashing at a very slow rate to let you know
the system is armed.
Disarming with the Remote Keyless
Entry Transmitter
Your alarm system will disarm when you use your
remote keyless entry transmitter to unlock the doors.
The light on the radio will go off to let you know the
system is no longer armed.
The first time a remote UNLOCK command is
received, three flashes will be seen and three horn chirps
heard to indicate an alarm condition has occurred since
last arming.
Disarming with Your Key
Your alarm system will disarm when you use your key
to unlock the doors. The light on the radio will go off to
let you know the system is no longer armed.
Vehicle Customization Settings
Some of the convenience features can be reset or
customized to perform according to your preference.
Customization cannot be changed with the AM
-FM
stereo radio. See your dealer to have the settings
changed. The features you can program depend upon
the options that came with your vehicle. The following
list shows the features that can be reset or customized
along with the option you need to program that feature:

Settings (Available for All)

Oil Life Reset (Available for All)

Low Tire Pressure Reset (If Equipped)

Delayed Headlamp Illumination (Available for All)

Automatic Door Lock and Unlock (Available for All)

Remote Visual Verification (Available with Remote
Keyless Entry)

Remote Audible Verification (Available with Remote
Keyless Entry)

Content Theft Operation (Optional with Content
Theft System)

Trunk Jamb (Optional with Content Theft System)

2-21

Horn Chirp On Timer (Available with Remote
Keyless Entry)

Remote Keyless Entry Transmitter Programming
(Available with Remote Keyless Entry)

Return to Original Factory Settings
(Available for All)

Exit Vehicle Customization Mode
Entering Programming Mode: To reset or customize
the features, you must first enter the vehicle
customization main menu. To enter the main menu, do
the following:
1. Turn the ignition to ACC or ON and the radio to off.
2. Press and hold the DISP button on the radio for at
least five seconds until SETTINGS is displayed.
3. Press the SEEK up or down arrows to scroll through
each available feature on your main menu.
4. Press the PREV or NEXT buttons to scroll through
the lower menu. An asterisk will appear next to the
item that is the current setting.The following information shows how to reset or
customize features after entering the main menu:
SETTINGS
-- Display Current Settings
OIL LIFE
-- Oil Life Reset: This feature allows you
to reset the GM Oil Life System Monitor after an oil
change, see ªEngine Oilº in the Index. Be careful not
to reset the OIL LIFE accidentally at any time other
than when the oil has been changed. It can't be reset
accurately until the next oil change. To clear the
CHANGE ENGINE OIL light from the instrument panel
cluster and reset the oil life monitor:
1. Scroll, using the SEEK up or down arrows, until OIL
LIFE appears on the display.
2. Press the PREV or NEXT button to enter the
submenu. RESET will then be displayed.
3. Press the DISP button to reset. A chime will be heard
to verify the new setting and DONE will be
displayed for one second.
The CHANGE ENGINE OIL light is now reset.
You can either exit the programming mode by following
the instructions later in this section or program the next
feature available on your vehicle.

2-22
TIRE MON (Tire Inflation Monitor Reset): This
feature allows you to reset the tire pressure monitor after
checking all tire pressures, see ªTiresº in the Index.
To clear the LOW TIRE PRESSURE light from
the instrument panel cluster and reset the low tire
pressure monitor:
1. Scroll, using the SEEK up or down arrows, until
TIRE MON appears on the display.
2. Press the PREV or NEXT button to enter the
submenu. RESET will be displayed.
3. Press the DISP button to reset. A chime will be
heard to verify the new setting and DONE will be
displayed for one second.
The low tire pressure monitor is now reset. You can
either exit the programming mode by following the
instructions later in this section or program the next
feature available on your vehicle.
LT DELAY (Delayed Headlamp Illumination): This
feature allows the headlamps and parking lamps to stay
on for a fixed amount of time after you exit the vehicle.
Programmable Modes
Mode 1: OFF
-- Turns feature off.
Mode 2: 30 SEC
-- 30 seconds.Mode 3: 60 SEC
-- 60 seconds.
When your vehicle was shipped from the factory, it was
programmed to Mode 2. The mode to which your
vehicle was programmed may have been changed since
it left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Scroll, using the SEEK up or down arrows, until
LT DELAY appears on the display.
2. Press the PREV or NEXT button to enter the
submenu. The current selection will have an asterisk
next to it. (If you do not wish to change the current
mode, you can either exit the programming mode by
following the directions later in this section or
program the next feature available on your vehicle.)
3. Scroll, using the PREV or NEXT buttons, through
the modes to change the current mode.
4. With your preference displayed, press the DISP
button to select. A chime will be heard to verify the
new setting. The new selection will be displayed
with an asterisk for one second.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.

2-23
AUTOLOCK (Automatic Door Lock and Unlock):
With the ignition in ON and the doors closed, this
feature allows the vehicle doors to automatically lock
and unlock when the driver shifts the transaxle into
and out of PARK (P).
Programmable Modes
Mode 1: OFF
-- Turns feature off.
Mode 2: LCK ONLY
-- Automatic door lock
on/automatic door unlock off.
Mode 3: DRVR UNL
-- Automatic door lock
on/automatic door unlock on (driver's door only).
Mode 4: ALL UNL
-- Automatic door lock
on/automatic door unlock on.
When your vehicle was shipped from the factory, it
was programmed to Mode 4. The mode to which your
vehicle was programmed may have been changed since
it left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Scroll, using the SEEK up or down arrows, until
AUTOLOCK appears on the display.2. Press the PREV or NEXT button to enter the
submenu. The current selection will have an asterisk
next to it. (If you do not wish to change the current
mode, you can either exit the programming mode
by following the directions later in this section or
program the next feature available on your vehicle.)
3. Scroll, using the PREV or NEXT buttons, through
the modes to change the current mode.
4. With your preference displayed, press the DISP
button to select. A chime will be heard to verify the
new setting. The new selection will be displayed
with an asterisk for one second.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
FOB LIGHT (Remote Visual Verification): This
feature allows the exterior lights to flash when the
remote keyless entry transmitter is used to lock or
unlock the vehicle.
Programmable Modes
Mode 1: OFF
-- Turns feature off.

2-24
Mode 2: ON -- One flash for each remote lock/two
flashes for each remote unlock.
When your vehicle was shipped from the factory, it was
programmed to Mode 2. The mode to which the vehicle
was programmed may have been changed since it left
the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle
to a different mode, do the following:
1. Scroll, using the SEEK up or down arrows, until
FOB LIGHT appears on the display.
2. Press the PREV or NEXT button to enter the
submenu. The current selection will have an asterisk
next to it. (If you do not wish to change the current
mode, you can either exit the programming mode
by following the directions later in this section or
program the next feature available on your vehicle.)
3. Scroll, using the PREV or NEXT buttons, through
the modes to change the current mode.
4. With your preference displayed, press the DISP
button to select. A chime will be heard to verify the
new setting. A new selection will be displayed with
an asterisk for one second.If your vehicle has the optional content theft-deterrent
system, the first time a remote UNLOCK command is
received, three flashes will be seen and three horn chirps
heard to indicate an alarm condition has occurred since
last arming. See ªContent Theft
-Deterrent Systemº
in the Index.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
FOB HORN (Remote Audible Verification): This
feature allows the horn to chirp when the remote keyless
entry transmitter is used to lock or unlock the vehicle.
Programmable Modes
Mode 1: OFF
-- Turns feature off.
Mode 2: PARTIAL
-- One chirp for each remote LOCK
command/no chirp for remote UNLOCK command.
Mode 3: FULL
-- One chirp for each remote
LOCK command/two chirps for the first remote
UNLOCK command.

2-25
When your vehicle was shipped from the factory, it was
programmed to Mode 1. The mode to which the vehicle
was programmed may have been changed since it left
the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle
to a different mode, do the following:
1. Scroll, using the SEEK up or down arrows, until
FOB HORN appears on the display.
2. Press the PREV or NEXT button to enter the
submenu. The current selection will have an asterisk
next to it. (If you do not wish to change the current
mode, you can either exit the programming mode
by following the directions later in this section or
program the next feature available on your vehicle.)
3. Scroll, using the PREV or NEXT buttons, through
the modes to change the current mode.
4. With your preference displayed, press the DISP
button to select. A chime will be heard to verify the
new setting. The new selection will be displayed
with an asterisk for one second.
If your vehicle has the optional content theft
-deterrent
system, the first time the remote UNLOCK command is
received three chirps will be heard to indicate an alarm
condition has occurred since last arming. See ªContent
Theft
-Deterrent Systemº in the Index.The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
ALARM (Content Theft Operation): This feature
allows the content theft
-deterrent system to be turned
on or off.
Programmable Modes
Mode 1: ALRM OFF
-- Turns feature off.
Mode 2: ALRM ON
-- Turns feature on.
When your vehicle was shipped from the factory, it was
programmed to Mode 2. The mode to which your
vehicle was programmed may have been changed since
it left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Scroll, using the SEEK up or down arrows, until
ALARM appears on the display.
2. Press the PREV or NEXT button to enter the
submenu. The current selection will have an asterisk
next to it. (If you do not wish to change the current
mode, you can either exit the programming mode by
following the directions later in this section or
program the next feature available on your vehicle.)

2-26
3. Scroll, using the PREV or NEXT buttons, through
the modes to change the current mode.
4. With your preference displayed, press the DISP
button to select. A chime will be heard to verify the
new setting. The new selection will be displayed
with an asterisk for one second.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
TRNKJAMB (Trunk Jamb): This feature allows the
content theft system trunk lock sensor to be disabled
or enabled.
Programmable Modes
Mode 1: TRNK OFF
-- Turns feature off.
Mode 2: TRNK ON
-- Turns feature on.
When your vehicle was shipped from the factory, it was
programmed to Mode 2. The mode to which your
vehicle was programmed may have been changed since
it left the factory. To determine the mode to which your
vehicle is programmed or to program your vehicle to a
different mode, do the following:
1. Scroll, using the SEEK up or down arrows, until
TRNKJAMB appears on the display.2. Press the PREV or NEXT button to enter the
submenu. The current selection will have an asterisk
next to it. (If you do not wish to change the current
mode, you can either exit the programming mode by
following the directions later in this section or
program the next feature available on your vehicle.)
3. Scroll, using the PREV or NEXT buttons, through
the modes to change the current mode.
4. With your preference displayed, press the DISP
button to select. A chime will be heard to verify the
new setting. The new selection will be displayed
with an asterisk for one second.
The mode you selected is now set. You can either exit
the programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
CHIRP (Horn Chirp Timer): This feature allows you
to choose between short or long horn chirp sounds when
the remote keyless entry transmitter is used.
Programmable Modes
Mode 1: SHORT
-- Short Chirp (16 msec)
Mode 2: LONG
-- Long Chirp (32 msec)
