2001 CADILLAC ELDORADO interior lights

ii
Table of Contents
Windows
Keys and Door Locks
Remote Keyless Entry System
Trunk Release
Automatic Transaxle
Parking Brake
Tilt Wheel
Turn Signal/Multifunction Lever
Windshield Wipers
Cruise Control
Exterior and Interior LampsMirrors
Storage Compartments
Convenience Net
Accessory Power Outlets
OnStar® System (If Equipped)
Sunroof (Option)
HomeLink® Transmitter (Option)
Instrument Panel, Warning Lights and Gages
Driver Information Center
Memory and Personalization Features (If Equipped) Seats and Seat Controls
Safety BeltsAir Bag Systems
Restraint Systems for Children
Section
1
Section
2
Seats and Restraint Systems
Features and Controls

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2
-4 Keys
2
-6 Door Locks
2
-8 Remote Keyless Entry System
2
-12 Trunk
2
-14 Theft
2
-15 Theft-Deterrent System
2
-17 PASS-Key
II
2
-18 New Vehicle ªBreak-Inº
2
-19 Ignition Positions
2
-20 Starting Your Engine
2
-21 Engine Coolant Heater (If Equipped)
2
-23 Automatic Transaxle Operation
2
-26 Parking Brake
2
-28 Shifting Into PARK (P)
2
-30 Shifting Out of PARK (P)2
-31 Parking Over Things That Burn
2
-31 Engine Exhaust
2
-32 Running Your Engine While You're Parked
2
-33 Tilt Wheel
2
-33 Turn Signal/Multifunction Lever
2
-41 Exterior Lamps
2
-46 Interior Lamps
2
-47 Mirrors
2
-51 Storage Compartments
2
-53 Sun Visors
2
-54 OnStar
System (If Equipped)
2
-57 Sunroof (Option)
2
-58 HomeLink
Transmitter (Option)
2
-62 The Instrument Panel -- Your
Information System
2
-66 Warning Lights, Gages and Indicators
2
-76 Driver Information Center (DIC)

2-41
Using Cruise Control on Hills
How well your cruise control will work on hills depends
upon your speed, load and the steepness of the hills.
When going up steep hills, you may have to step on the
accelerator pedal to maintain your speed. When going
downhill, you may have to brake or shift to a lower gear
to keep your speed down. Of course, applying the brakes
or downshifting into FIRST (1) takes you out of cruise
control. Many drivers find this to be too much trouble
and don't use cruise control on steep hills.
Ending Cruise Control
There are two ways to end cruise control:

Step lightly on the brake pedal.

Move the CRUISE switch to OFF.
Erasing Speed Memory
The cruise control set speed memory is erased when you
turn off the cruise control or the ignition.Exterior Lamps
The control located on
the left side of the
instrument panel controls
these lamp systems:

Headlamps

Taillamps

Parking Lamps

Sidemarker Lamps

License Plate Lamp

Underhood Lamp

Fog Lamps

Instrument Panel Lights

Interior Courtesy Lamps
Instrument panel backlighting will activate whenever
the lamps or lights are turned on.

2-46
Interior Lamps
Instrument Panel
Intensity/Brightness Control
The digital displays automatically dim when it becomes
dark outside and your lights are on. When it's dark, the
brightness control can be manually adjusted by turning
the exterior lamps control knob counterclockwise to dim
and clockwise to brighten the lighting. The digital
displays automatically brighten when it becomes light
outside, although backlighting will remain active at the
selected brightness as long as the lights are on.
Illuminated Entry
The illuminated entry system turns on the courtesy
lamps and the backlighting to the door controls and to
the exterior lamps control knob when a door is opened
or if you press a remote keyless entry transmitter button.
Since the illuminated entry system has a photocell, this
means that it must be dark outside in order for the
courtesy lamps or backlighting to turn on. The courtesy
lamps turn off approximately 20 seconds after the last
door is closed or after the ignition is turned to RUN.
Parade Dimming
This feature prohibits the dimming of the instrument
panel lights during daylight while the headlamps are on.
This feature operates with the light sensor for the
Twilight Sentinel and is fully automatic. When the light
sensor reads darkness outside, the instrument panel
lights can be adjusted by turning the exterior lamps
control knob counterclockwise to dim and clockwise to
brighten lighting. Backlighting to the instrument panel
will turn on, regardless of light conditions.
Reading Lamps
The reading lamps are located either in the headliner or
above the windows if you have a sunroof. To turn them
on, turn the exterior lamps control knob all the way
clockwise. These lamps and the interior courtesy lamps
automatically come on when either door is opened and it
is dark outside. For manual operation, press the button
to turn them on. Press it again to turn them off.
If the reading lamps are left on, they automatically shut
off 10 minutes after the ignition has been turned off.
