2001 CADILLAC ELDORADO Owners Manual

2-84
STARTING DISABLED REMOVE KEY - 33: This
message will appear when the Personalized Automotive
Security System (PASS
-Key
II) senses that an
improper ignition key is being used to try to start the
vehicle. Check the ignition key for damage. If it is
damaged, it may need to be replaced. If you see no
damage, clean the pellet contacts with a soft cloth or
napkin. Remove the ignition key and wait for the DIC to
display WAIT 3 MINUTES. The instrument panel
cluster will then run a timer and change the messages to
WAIT 2 MINUTES, WAIT 1 MINUTE and then
START CAR. When the START CAR message is
displayed, try again to start the engine.
THEFT SYSTEM PROBLEM, CAR MAY NOT
RESTART
- 34: This message means there is a problem
in the Personalized Automotive Security System
(PASS
-Key
II). A fault has been detected in the
system which means that the PASS
-Key
II system is
disabled and is not protecting the vehicle. The vehicle
usually restarts, however, you may want to take your
vehicle to a proper service center before turning off
the engine.TOP SPEED FUEL OFF
- 111 : This message will
appear when the PCM senses that the maximum speed
for your vehicle has been reached. The speed of your
vehicle will decrease several mph as the fuel supply is
cut off. This allows your vehicle to stay in a stable
operating range.
TRACTION ENGAGED
- 91 : When your traction
control system is limiting wheel spin, the TRACTION
ENGAGED message will be displayed. Slippery road
conditions may exist if this message is displayed, so
adjust your driving accordingly. This message will stay
on for a few seconds after the traction control system
stops limiting wheel spin.
TRACTION OFF
- 89: This message will be displayed
after the traction control has been turned off.
TRACTION READY
- 90: This message informs the
driver that the traction control system is available. This
occurs when the traction on/off button in the glove box
has been returned to ON (pressing the button once turns
the traction control system off: pressing the button again
turns the system back on). This message also
self
-cancels after five seconds.

2-85
TRACTION SUSPENDED - 56: This message
displays when the traction control system has been
temporarily shut off because your vehicle's brakes have
overheated. This message does not indicate a problem
with your vehicle's traction control system. After a
few minutes, the traction control system will be
available again and the TRACTION READY message
will appear.
TRANS FLUID RESET
- 48: With the engine not
running and the ignition on, press and hold the OFF
and rear defog buttons until the TRANS FLUID
RESET message appears on the DIC (between five
and 20 seconds).
TRANS HOT IDLE ENG
- 112: This message
indicates that the transaxle fluid in your vehicle is too
hot. Stop and allow your vehicle to idle until it cools
down or until this message is removed.TRUNK OPEN
- 24: This message indicates that the
trunk is open when your vehicle's ignition is in RUN.
TURN SIGNAL ON
- 20: This message is a reminder,
after driving about 1 mile (1.6 km/h), that you have the
turn signal on. A multiple chime will also sound when
this message is displayed.
VEHICLE OVERSPEED
- 52: This message is
displayed when the vehicle speed exceeds a certain limit
as required by some export countries. A continuous
chime will also sound when this message is displayed.
VEHICLE SPEED LIMITED TO XXX MPH
(KM/H)
- 113: A failure in the suspension control
system has occurred when this message appears. The
Powertrain Control Module (PCM) determines the speed
your vehicle is limited to. Have your vehicle serviced if
this message appears. (The XXX indicates the speed
your vehicle is limited to.)

2-86 Memory and Personalization Features
(If Equipped)
Your vehicle may be equipped with the following
features that can be individually programmed,
memorized or personalized for up to two drivers.
For a brief description of each feature, look up each
feature for a page reference in the Index.
Memory Seat and Mirrors
To begin programming,
adjust the driver's seat
(including lumbar
adjustments) and both
outside mirrors to a
comfortable position and
then press the SET button.
Within five seconds,
press button ª1.º
A second mirror and seating position may be
programmed by repeating the above steps and pressing
button ª2º instead of button 1. Each time a memory
button is pressed, a single beep will sound through the
left front speaker.If your vehicle is in PARK (P), you can recall mirror
and seating positions by briefly pressing button 1 or 2.
This will adjust the seat and mirrors to where you have
previously programmed them. If you have accidentally
pressed one of the memory recall buttons and want to stop
seat or mirror movement, press one of the manual seat or
mirror control buttons. This cancels a memory recall.
You can also recall a seat and mirror position if your
vehicle is not in PARK (P). Press and hold either the
1 or 2 button until seat and mirror movement is
complete. Releasing the buttons will stop adjustment.
The EXIT button can be programmed to allow easy exit
for up to two drivers. Adjust the seat to a comfortable
ªexitº position and then press the SET button followed
by the EXIT button. While your vehicle is in PARK (P),
briefly press the EXIT button to recall your programmed
exit position.
Programmable Automatic Door Locks
Your vehicle's ignition must be in RUN. To begin
programming, press and hold the SKIP INFO and NO
INFO RESET buttons at the same time to display the
following prompts.

2-87
DOORS LOCK IN GEAR: All doors automatically
lock when shifted out of PARK (P). No automatic
door unlock.
DRIVR UNLOCK IN PARK: All doors automatically
lock when shifted out of PARK (P). Only the driver's
door automatically unlocks when shifted into PARK (P).
DRIVR UNLOCK KEY OFF: All doors automatically
lock when shifted out of PARK (P). Only the driver's
door automatically unlocks when the ignition key is
turned to OFF.
DOORS UNLOCK IN PARK: All doors automatically
lock when shifted out of PARK (P) and unlock when
shifting into PARK (P).
DOORS UNLOCK KEY OFF: All doors
automatically lock when shifted out of PARK (P). All
doors automatically unlock when the ignition key is
turned to OFF.
A ªyesº or ªnoº response must be made after each
prompt is displayed in order to continue on to the next
prompt or personalization feature. Press the YES TRIP
RESET button to choose yes, press the NO INFO
RESET button to choose no or press the SKIP INFO
button to ªskipº to the next personalization feature.FEATURE ON appears when a yes response is made
and FEATURE OFF appears with a no response.
If a no response is made after the DOORS LOCK IN
GEAR prompt is displayed, FEATURE OFF will appear.
The automatic door locking system has been disabled
and no other door lock messages will be displayed.
LGHTS FLSH AT UNLOCK, which is the next
available personalization feature to display, will appear
next. See ªLock/Unlock Confirmationº in the Index for
more information.
If a yes response is made after the DOORS LOCK IN
GEAR prompt is displayed, FEATURE ON appears.
The automatic door locking system is enabled and
allows the DRIVR UNLOCK IN PARK prompt to
appear. Choosing this prompt advances you to LGHTS
FLSH AT UNLOCK whereas a no response will display
the DRIVR UNLOCK KEY OFF prompt.
If DRIVR UNLOCK KEY OFF is chosen, FEATURE
ON appears. You will advance to the LGHTS FLSH
AT UNLOCK prompt. If you don't choose this prompt,
FEATURE OFF appears as well as the next
prompt
-- DOORS UNLOCK IN PARK. If this
prompt is chosen, FEATURE ON appears. If a no
response was made, DOORS UNLOCK KEY OFF will
appear. At this point, a yes or no response automatically
brings up the LGHTS FLSH AT UNLOCK feature.

2-88
Lock/Unlock Confirmation
This personalization feature allows the driver to
program the parking lamps to blink when the lock or
unlock buttons on the remote keyless entry transmitter
are pressed, to program the horn to sound when the lock
button is pressed and/or to program the exterior lamps to
turn on when the unlock button is pressed. Press the
YES TRIP RESET button to answer yes, press the NO
INFO RESET button to indicate no or press the SKIP
INFO button to skip to the next personalization feature.
To begin programming, your vehicle's ignition must be
in RUN. Press and hold the SKIP INFO and NO INFO
RESET buttons at the same time to display the
following prompts. LOCK/UNLOCK confirmation is
the second feature to appear. To skip past the first
personalization feature, press the SKIP INFO button.
LGHTS FLSH AT UNLOCK: Parking lamps blink
twice when the unlock button on the remote keyless
entry transmitter is pressed.
LIGHTS FLASH AT LOCK: Parking lamps blink
once when the lock button on the remote keyless entry
transmitter is pressed.
HORN SOUNDS AT LOCK: Horn sounds when
the lock button on the remote keyless entry transmitter
is pressed.EXT LIGHTS AT UNLOCK: Exterior lamps (parking
lamps, taillamps, sidemarker lamps, license plate lamps,
low
-beam headlamps, etc.) turn on when the unlock
button on the remote keyless entry transmitter is pressed
and it is dark outside. These lamps stay on for about
20 seconds or until the key is turned OFF.
The prompts listed here appear in the same order as
displayed on the DIC. FEATURE ON appears when a
yes response is made and FEATURE OFF appears with
a no response. To skip to the next personalization feature
(REMOTE RECALL MEMORY), press the SKIP
INFO button.
Remote Recall Memory (If Equipped with Memory
Personalization)
Memory settings that have been previously programmed
(climate control settings, radio preset settings, exterior
lighting choices, remote confirmation choices and
programmable automatic door lock choices) can be
recalled by using the remote keyless entry transmitter or
by placing the key in your vehicle's ignition.
Before you begin programming, make sure that your
vehicle's ignition is in RUN. To begin programming,
press the SKIP INFO and NO INFO RESET buttons at
the same time for about two seconds. As mentioned,
remote recall memory is the third feature to appear.

2-89
To skip past the first two personalization features, press
the SKIP INFO button.
When REMOTE RECALL MEMORY appears, the
driver is able to recall memory settings when the unlock
button on the remote keyless entry transmitter is
pressed. Press the YES TRIP RESET button to select or
press the NO INFO RESET button to answer no and to
continue on to the next prompt. FEATURE ON displays
when a yes response is made.
If a no response was made, the KEY IN RECALL
MEMORY prompt will show next. This choice recalls
memory settings when the key is placed in your
vehicle's ignition. FEATURE ON displays for a yes
response, and FEATURE OFF for a no response.
A yes or no response is required.
Curb View Assist Mirror
(If Equipped with Memory)
If your vehicle has this personalization feature,
MIRROR TILT IN REV will be the fourth
personalization prompt to display on the DIC.To program your vehicle, press the SKIP INFO and NO
INFO RESET buttons at the same time for about two
seconds. When MIRROR TILT IN REV appears, a yes
or no response is needed. Press the YES TRIP RESET
button to answer yes or the NO INFO RESET button to
answer no.
FEATURE ON displays when a yes response is made
and FEATURE OFF shows after a no response. If you
do not want this feature, press the SKIP INFO button to
skip to the next personalization feature which is
STORAGE MODE.
Storage Mode Personalization
Before you begin programming, make sure that your
vehicle's ignition is in RUN. To begin programming,
press the SKIP INFO and NO INFO RESET buttons at
the same time for about two seconds. The first message
to appear is DOORS LOCK IN GEAR. Press the SKIP
INFO button after this prompt is displayed until
STORAGE MODE prompt appears on the DIC. Press
the YES TRIP RESET button to answer yes or press the
NO INFO RESET button to indicate a no response.

2-90
FEATURE ON appears when a yes response is made
and FEATURE OFF shows when a no response is made.
Since this is the last personalization feature available, a
yes or no response will end out of the Driver
Information Center (DIC) display.
Once the battery guard has been programmed, your
vehicle will enter the storage mode about 20 minutes
after the ignition key has been turned off.
Your vehicle will stay in the storage mode until the
ignition key is turned out of LOCK. The system will
ªwake
-upº when the door key is inserted into the door,
however, your vehicle will remain in the storage mode.
The ignition must be out of LOCK before the battery
guard is disabled.Comfort Controls and Radio System Personalization
These features allow both drivers to personalize their
own climate control settings as well as their radio
settings. For more information, see ªClimate Control
Personalizationº and ªRadio Personalizationº in
the Index.
Continuous Variable Road Sensing
Suspension (CVRSS) (ETC Only)
The CVRSS automatically adjusts the ride of your
vehicle. Automatic ride control is achieved through a
computer used to control and monitor the suspension
system. The controller receives input from various
sensors to determine the proper system response. If the
controller detects a problem within the system, the
Driver Information Center (DIC) will display a
SERVICE RIDE CONTROL message. If this message
appears, have your vehicle serviced at your dealership.

2-91 Oil Life Indicator
This feature lets you know when to change the engine
oil. It's based on the engine oil temperatures and your
driving patterns. To see the display, press the SKIP
INFO button several times until XX OIL LIFE LEFT
appears. If you see 99% OIL LIFE LEFT, 99 percent of
your current oil life remains.
The Driver Information Center (DIC) may display a
CHANGE ENGINE OIL message. Always keep a
written record of the mileage and date when you
changed your oil. For more information, see the
Maintenance Schedule booklet. If you see CHANGE
ENGINE OIL, it means that you have no oil life left and
you should change your engine oil right away.
When the oil is changed, you'll need to reset the system.
See ªOil Life Indicator, How to Resetº in the Index.
