2001 CADILLAC ELDORADO Owners Manual

2-76 Fuel Data Display
Everything you need to know about the fuel economy
and how far you can travel with your vehicle's
remaining fuel is displayed. Fuel data can be obtained
by pressing the INFO (SKIP) button. See ªDIC Controls
and Displaysº later in this section.
Driver Information Center (DIC)
This display gives you the status of many of your
vehicle's systems. The DIC is also used to display driver
personalization features and warning/status messages.
DIC Controls and Displays
TRIP RESET (YES): By using this button, you can
tell how far you've gone since you last set the YES
TRIP RESET back to zero. To reset, press and hold t
his button until zeros appear. If your vehicle is domestic,
the trip odometer will return to zero after 999.9 miles
(1 609 km). If your vehicle is Canadian, the
trip odometer will return to zero after
1 999.9 km (1,242 miles).
INFO RESET (NO): Pressing this button will reset the
MPG AVG, GAL FUEL USED, AVG MPH, TIMER,
OIL LIFE LEFT and ENGLISH/METRIC RESET.
Pressing NO INFO RESET when a non
-resettable
display appears will cause a ªrecallº mode to occur.
When this happens, all Driver Information Center (DIC)
warning messages that have been displayed since the
ignition key was turned to RUN will redisplay. If no
messages were displayed, a MONITORED SYSTEMS
OK message will appear.
INFO (SKIP): Pressing this button repeatedly will
display the RANGE, MPG AVG, MPG INST, GAL
FUEL USED, AVG MPH, TIMER, BATTERY VOLTS,
OIL LIFE LEFT and ENGLISH/METRIC RESET.

2-77
FUEL DOOR: Press this button to open the fuel
door. (This feature will work only when the shift lever
is in PARK (P) regardless of whether or not the vehicle
is running.)
TRUNK: Press this button to open the trunk.
(This feature will work only when the shift lever is
in PARK (P) regardless of whether or not the vehicle
is running.)
MPG AVG (Reset): Press the INFO (SKIP) button to
display the MPG AVG (Average Fuel Economy), then
press and hold the NO INFO RESET button until 0.0
MPG AVG is displayed.
GAL FUEL USED (Reset): Press the INFO (SKIP)
button to display the GAL FUEL USED on the Driver
Information Center (DIC), then press and hold the
INFO RESET (NO) button until 0.0 GAL FUEL USED
is displayed.
AVG MPH (Reset): Press the INFO (SKIP) button to
display the AVG MPH (Average Speed), then press and
hold the INFO RESET (NO) button until 0.0 AVG MPH
is displayed.TIMER: This feature is like a stopwatch, in that
you can clock the time it takes to get from one point
to another.
To operate, press the INFO (SKIP) button to display
TIMER. Each of the fields for the hours, minutes and
seconds are two numeric digits.
Once TIMER OFF 00:00:00 is displayed, press the INFO
RESET (NO) button to start the timing feature. Press the
INFO RESET (NO) button again to stop it. If you will be
starting and stopping your vehicle
-- during a trip for
instance
-- the TIMER feature will automatically start
timing where it left off when you last stopped. To reset it,
press and hold the INFO RESET (NO) button until the
display reads TIMER 00:00:00. Press the INFO (SKIP)
button to exit from the TIMER function.
OIL LIFE LEFT (Reset): Press the INFO (SKIP)
button to display the OIL LIFE LEFT, then press and
hold the INFO RESET (NO) button until 100% OIL
LIFE LEFT is displayed. (This only needs to be reset
after you have had the oil changed.)
ENGLISH/METRIC (Reset): Press the INFO
(SKIP) button to display ENGLISH/METRIC RESET,
then press the INFO RESET (NO) button to select.
The display will change from English (miles) to
metric (kilometers).

2-78 DIC Messages
These messages will appear if there is a problem sensed
in one of your vehicle's systems. Vehicles that are first
sold in Canada will have a number after each message.
This number helps to identify the message which is only
displayed in English.
Pressing the INFO or INFO RESET button(s) will
remove most of the following messages from the
DIC display:
APPLY BRAKE TO SHIFT
- 46: This message will
appear if your vehicle is in PARK (P) for about
15 seconds and the brake is not pressed. On the climate
control panel, press the OFF button (next to the MODE
button) and the down arrow on the PASS TEMP button
for about five seconds. Hold the same two buttons to
display the message again.
BATTERY NOT CHARGING
- 7: This message will
appear if the battery is not being charged. Have the
electrical system checked by your dealership at your
earliest convenience.BATTERY VOLTAGE HIGH
- 8: This message
shows that the electrical charging system is
overcharging (more than 16 volts). To avoid being
stranded, have the electrical system checked by your
dealership. You can reduce the charging overload by
using the accessories. Turn on the lamps and radio, set
the climate control on AUTO and the fan speed on HI,
and turn the rear window defogger on. You can monitor
battery voltage on the DIC by pressing the INFO (SKIP)
button. The normal range is 11.5 to 15.5 volts when the
engine is running.
BATTERY VOLTAGE LOW
- 6: This message will
appear when the electrical system is charging less than
10 volts or if the battery has been drained. If this
message appears immediately after starting, it is possible
that the generator can still recharge the battery. The
battery should recharge and may take a few hours to do
so. Consider using an auxiliary charger to boost the
battery after returning home or to a final destination.
(Be sure to follow the manufacturer's instructions when
using a battery charger.)

2-79
If this message appears and stays on while driving or
after starting your vehicle, have it checked immediately
to determine the cause of this problem. To help the
generator recharge the battery quickly, you can reduce
the load on the electrical system by turning off the
accessories. You can monitor battery voltage on the
DIC by pressing the INFO (SKIP) button. The normal
range is 11.5 to 15.5 volts.
CHANGE ENGINE OIL
- 82: This means that the
life of the engine oil has expired and it should be
changed within 200 miles (322 km). See ªEngine Oilº
and ªFilter Recommendationsº in the Maintenance
Schedule booklet. After an oil change, the Oil Life
Indicator must be reset. See ªOil Life Indicator, How to
Resetº in the Index.
CHANGE TRANS FLUID
- 47: This message will
appear when it is time to replace the transaxle fluid. See
the Maintenance Schedule booklet for the proper fluid
and change intervals.
CHECK BRAKE FLUID LEVEL
- 37: This message
will display if the ignition is in RUN to inform the
driver that the brake fluid level is low. Have the brake
system serviced by a technician as soon as possible.
See ªBrake System Warning Lightº in the Index.CHECK COOLANT LEVEL
- 2: This message
will appear when there is a low level of engine coolant.
Have the cooling system serviced by a technician as
soon as possible.
CHECK FUEL GAUGE
- 39: This message will
appear when the fuel supply is less than 3.5 gallons
(13.2 L) remaining. A single chime will also sound
when this message is displayed.
CHECK GAS CAP
- 61: This message will appear if
the gas cap has not been fully tightened. You should
recheck your gas cap to ensure that it's fully tightened.
CHECK OIL LEVEL
- 36: For correct operation of
the low oil sensing system, your vehicle should be on a
level surface. A false CHECK OIL LEVEL message
may appear if the vehicle is parked on grades. The oil
level sensing system does not check for actual oil level
if the engine has been off for a short period of time, and
the oil level is never sensed while the engine is running.
If the CHECK OIL LEVEL message appears and your
vehicle has been parked on level ground with the engine
off for at least 30 minutes, the oil level should be
checked by observing the oil dipstick. Prior to checking
the oil level, be sure the engine has been off for
five minutes and your vehicle is on a level surface. Then
check the dipstick and add oil if necessary. See ªEngine
Oilº in the Index.

2-80
CHECK WASHER FLUID - 25: This message will
appear for several seconds indicating that you need
windshield washer solvent.
CRUISE ENGAGED
- 43: This message will
appear for a few seconds when you select a speed at
which to cruise.
DOOR AJAR
- 141: A door other than the driver's is
open or ajar when this message appears. The vehicle's
engine must be running and the transaxle not in
PARK (P) for this message to display. A chime
will also sound when the vehicle's speed is greater
than 5 mph (8 km/h).
DRIVER DOOR AJAR
- 140: This message will
display when the vehicle is being shifted out of
PARK (P) with the engine running to signal that the
driver's door is open or ajar. A chime will also sound
when the vehicle's speed is greater than 5 mph (8 km/h).
ENGINE COOLANT HOT, IDLE ENGINE
- 44:
This message will appear when the engine coolant
temperature is over 248
F (126
C). To avoid added strain
on a hot engine, turn off the climate control system. Stop
and allow your vehicle to idle until it cools down or the
message is removed. If it does not cool down, turn off the
engine and have it serviced before driving it again. Severe
engine damage can result from an overheated engine.
See ªEngine Overheatingº in the Index.ENGINE HOT
- A/C OFF - 16: This message displays
when the engine coolant becomes hotter than the normal
operating temperature. To avoid added strain on a hot
engine, the air conditioning compressor is automatically
turned off so that air conditioned air is not delivered. If
the coolant temperature returns to normal, you must
select AC to return to a normal A/C compressor
operation. If this message continues to appear, have
the system repaired as soon as possible to avoid
compressor damage.
ENGINE MISFIRE
-- EASE OFF GAS
PEDAL
- 114: An engine misfire has occurred.
You'll need to ease off the gas pedal.
ENGINE OVERHEATED, STOP ENGINE
- 42: This
message will appear when the engine has overheated.
Stop and turn the engine off immediately to avoid severe
engine damage. See ªEngine Overheatingº in the Index.
A multiple chime will also sound when this message
is displayed.
ENGINE POWER REDUCED
- 41: This message
informs you that your vehicle is reducing engine power
because the transaxle is being placed in gear under
conditions that may cause damage to the vehicle
powertrain or vehicle acceleration.

2-81
FUEL LEVEL LOW - 11 : This message serves as a
warning that the fuel level in the tank is critically low.
Stop for fuel soon.
HEADLAMPS SUGGESTED
- 23: If it's dark enough
outside and the Twilight Sentinel control is off, a
HEADLAMPS SUGGESTED message will display on
the DIC. This message informs the driver that turning on
the exterior lamps is recommended even though the
Daytime Running Lamps (DRL) are still illuminated
(it's become dark enough outside to require the
headlamps and/or other exterior lamps).
ICE POSSIBLE
- 13: This message appears when
the outside air temperature is cold enough to create icy
road conditions.
LOW REFRIG A/C OFF
- 12: This message means
that the air conditioning system detects a refrigerant
level that is low enough to cause damage to the air
conditioning compressor. Have the air conditioning
system serviced if this message appears.MONITORED SYSTEMS OK
- 1: This message only
appears in the ªrecallº mode by pressing the INFO
RESET (NO) button. It lets you know that no other
messages are stored or currently active.
OIL PRESSURE LOW STOP ENGINE
- 35: If this
message appears while the engine is running, stop the
engine and do not operate it until the cause of low oil
pressure is corrected. Severe damage to the engine can
result. A multiple chime will also sound when this
message is displayed.
OPTIONS NOT SET
- 99: This message will display if
a fault has occurred in your vehicle's memory. Have
your vehicle serviced by your dealership.
PROGRAM PASS KEY
- 31: This warning message
displays when the PASS
-Key
II pellet information has
not been programmed into your vehicle. See your
dealership for service.

2-82
REMOVE KEY - 70: This message will appear when
the Personalized Automotive Security System
(PASS
-Key
II) is unable to read the pellet on the
ignition key or an improper key pellet has been inserted.
This message usually appears following the display of
STARTING DISABLED REMOVE KEY. The
instrument panel cluster will then run a timer and
change the messages to WAIT 3 MINUTES, WAIT
2 MINUTES, WAIT 1 MINUTE and then START CAR.
When the REMOVE KEY message is displayed, remove
the ignition key. Check the ignition key for damage. If it
is damaged, it may need to be replaced. If you see no
damage, clean the pellet contacts with a soft cloth or
napkin before inserting the key back into the ignition.
Have your vehicle serviced if the message still appears.
SERVICE A/C SYSTEM
- 14: This message appears
when the electronic sensors that control the air
conditioning and heating systems are no longer working.
Have the climate control system serviced if you notice a
drop in heating and air conditioning efficiency.
SERVICE AIR BAG
- 83: There is a problem with
the Supplemental Inflatable Restraint (air bag) system
when this message appears. Let only a qualified
technician work on your vehicle. See your dealership for
service at once. SERVICE BRAKE FLUID SWITCH
- 37: A
problem in the brake fluid detection circuit causes this
message to display if the ignition is in RUN. Have the
brake system serviced by a technician as soon as
possible. If the brake warning light is on, refer to the
directions listed in that part.
SERVICE CHARGING SYSTEM
- 102: This
message will display when a problem with the charging
system has been detected. Have your vehicle serviced at
your dealership.
SERVICE ELECTRIC SYS
- 106: This message will
display if an electrical problem has occurred within the
Powertrain Control Module (PCM). Have your vehicle
serviced by your dealership.
SERVICE FUEL SYSTEM
- 101: The PCM has
detected a problem within the fuel system when this
message appears. See your dealership for service.
SERVICE IDLE CONTROL
- 107: A problem with
the idle control has occurred when this message displays.
Drive your vehicle to the dealership for service.
SERVICE RIDE SYS
- 84: This message is displayed
to indicate that the suspension system is not operating
properly. To correct this problem, have your vehicle
serviced at your dealership.

2-83
SERVICE STEERING SYS - 127: This message is
displayed when a problem has been detected in the
Magnasteer

variable effort steering system. Service is
required. A single chime will also sound when this
message is displayed.
SERVICE TRANSMISSION
- 100: If a problem is
detected with the transaxle, this message will appear.
Have your vehicle checked by your dealership.
SERVICE VEHICLE SOON
- 3: If a problem is
detected with the transaxle, this message will appear.
Have your vehicle checked by your dealership.
SERV STABILITY SYS
- 54: If you ever see the
SERV STABILITY SYS message, it means there may
be a problem with your stability enhancement system. If
you see this message, try to reset the system (stop; turn
off the engine; then start the engine again). If the SERV
STABILITY SYS message still comes on, it means there
is a problem. You should see your dealer for service.
Reduce your speed and drive accordingly. A single
chime will also sound when this message is displayed.STABILITY ENGAGED
- 55: You may see the
STABILITY ENGAGED message on the Driver
Information Center. It means that an advanced,
computer
-controlled system has come on to help your
vehicle continue to go in the direction in which you're
steering. This stability enhancement system activates
when the computer senses that your vehicle is just
starting to spin, as it might if you hit a patch of ice or
other slippery spot on the road. When the system is on,
you may hear a noise or feel a vibration in the brake
pedal. This is normal.
When the STABILITY ENGAGED message is on, you
should continue to steer in the direction you want to go.
The system is designed to help you in bad weather or
other difficult driving situations by making the most of
whatever road conditions will permit. If the STABILITY
ENGAGED message comes on, you'll know that
something has caused your vehicle to start to spin, so
you should consider slowing down.
